Hunter 23902 Installation And Operation Manual
Type 2 models
Hide thumbs
Also See for 23902:
- Parts manual (2 pages) ,
- Installation manual (1 page) ,
- Manual (17 pages)
Table of Contents
Advertisement
Quick Links
For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE 2 Models
42776-01 • 04/29/08
Advertisement
Table of Contents
Related Manuals for Hunter 23902
Summary of Contents for Hunter 23902
- Page 1 Hunter For Your Records and Warranty Assistance Ceiling Fans Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ TYPE 2 Models For reference also attach your receipt or a copy of your receipt to the manual.
-
Page 2: Table Of Contents
Fan .......16 use a solid-state speed control with this fan. Use only Hunter speed 10 • Troubleshooting ....17 controls. © 2008 Hunter Fan Company 42776-01 • 04/29/08 • Hunter Fan Company... - Page 3 Installer’s Choice and Optional Accessories Understanding Mounting and Installer’ s Choice® Support Brace Hunter’s patented 2-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of two ways, depending on ceiling height and your preference: Standard or Angled mounting. The steps in this manual include instructions for Ceiling both Installer’s Choice mounting methods. Standard Outlet Box Mounting Considering Optional Accessories Style Consider using Hunter’s optional accessories, including a wall-mounted or remote speed control. To install and use the accessories, follow the instructions included with each product.
-
Page 4: Getting Ready
To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit • Standard screwdriver (magnetic tip recommended) -
Page 5: Installing The Ceiling Plate
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. For Angled Ceilings: Be sure to orient the ceiling plate so that the arrows printed on the ceiling plate are pointing toward the ceiling peak. 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 6: Assembling And Hanging The Fan
3 • Assembling and Hanging the Fan Note: Your Hunter fan comes with an optional downrod extension Steps 3-2 – 3-3 pipe. If you are hanging the fan on a ceiling higher than 10 feet tall and you would like to use the enclosed optional downrod, follow Downrod steps 3-5 3-9 on the next page. - Page 7 3 • Assembling and Hanging the Fan Steps 3-5 – 3-8 Optional Downrod Instructions: Pipe Ball Screw Your Hunter fan comes with an optional downrod extension pipe. If you would like to use the enclosed optional 6 inch downrod, follow the steps on this page. Ground Wire Note: The Perfect Balance...
-
Page 8: Wiring The Fan
4-6. Turn the splices upward and push them carefully back through the ceiling plate into the outlet box. 4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 9: Installing The Canopy And Canopy
1. Locate the tab indicators, small bumps on top of tabs. 2. Press firmly on opposite sides of the ring toward the canopy. The tabs will flex out releasing the trim ring from the canopy. Step 5-3 Steps 5-4 – 5-5 Canopy Screw 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 10: Assembling The Blades
Blade Assembly 6-4. Slide the blade irons onto the blade iron armature screws and Screw tighten the screws securely. Steps 6-1 – 6-2 Blade Assembly Screw Grommet Blade Blade Iron Armature Screw Shipping Bumper Blade Iron Blade Iron Armature Screw Step 6-3 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 11: Activating Perfect Balance Tm
This is normal, as loose blades are a characteristic of the Perfect Balance system. 7-2. If you are using a downrod longer than 6 inches, leave the retaining screws in their place and continue the installation process. Notch Steps 7-1 – 7-2 Switch Housing Mounting Plate Red Retaining Screws 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 12: Completing Your Installation With Or Without A Bowl Light Fixture
8 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture. The steps below direct you whether or not you are installing a light fixture. - Page 13 Make sure the connectors are properly aligned before connecting them. Incorrect connection could cause improper operation and damage to the product. 8-7. Place the lower switch housing assembly over the upper switch housing. Align the side screw holes in the upper and lower switch Steps 8-6 – 8-7 housings. Attach the lower switch housing to the upper switch Lower Switch Housing housing with three housing assembly screws. Plug Connector Detail Housing Assembly Screw 42776-01 • 04/29/08 • Hunter Fan Company...
- Page 14 (B10 8-14. Place the cover plate up against the Candelabra- glass bowl. Align the holes in the cover Based 60 Watt Maximum) plate and glass bowl. 8-15. Thread the light pull chain through Metal Disc the finial and screw the finial onto the Metal Rod threaded rod end until tight. 8-16. Reattach the fandangle to the extra pull chain. Glass Bowl Cover Plate Breakaway Finial Connector 42776-01 • 04/29/08 • Hunter Fan Company...
- Page 15 (male) through first, and then pull the other plug connector (female) through the hole. 8-21. Install the dummy terminals (included in the sack parts) on the two disconnected wires in the lower switch housing. 8-22. Install the switch housing cap and plug button to the lower switch housing. 8-23. Once you have uninstalled the light fixture, continue with step 8-6. Step 8-19 Male Dummy Terminal Female Dummy Terminal Plug Button Step 8-22 42776-01 • 04/29/08 • Hunter Fan Company...
-
Page 16: Operating And Cleaning Your Ceiling
Clean painted and high-gloss blades in the same manner as the fan air flow pattern finish. To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 42776-01 • 04/29/08 • Hunter Fan Company... -
Page 17: Troubleshooting
2. Tighten all blade iron screws. 3. Turn power off, support fan very carefully, and check that the hanger ball is properly seated. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 42776-01 • 04/29/08 • Hunter Fan Company...
