    Video Cassette Recorder SV-675 SV-670 SV-470 SV-275 SV-270 Instruction Manual www.samsungvcr.com...

  • Page 2: About This Manual

    About this manual Thank you for purchasing a Samsung Video Cassette Recorder (VCR). Your Owner’s Instructions contain much valuable information on setting up and using your VCR. Please take the time to read them as they will help you take full advantage of your VCR’s features.

  • Page 3: Table Of Contents

    Contents Foreword Safety Instructions ..... 4 Playing Back Playing a Cassette ....21 VCR Overviews Adjusting Picture Alignment Automatically Front View of the VCR .

  • Page 4: Safety Instructions

    Safety Instructions The following illustrations represent precautions. The lightning bolt is a warning sign alerting you to dangerous voltage inside the product. DO NOT OPEN THE DVD-VCR. Refer to service personnel. Do NOT expose the DVD-VCR to Do NOT expose the DVD-VCR to Do NOT expose the DVD-VCR to direct sunlight.

  • Page 5: Front View Of The Vcr

    Front View of the VCR (SV-670) (SV-675) STANDBY/ON EJECT PLAY VIDEO CASSETTE STOP BUTTON BUTTON BUTTON BUTTON BUTTON COMPARTMENT STANDBY/ON EJECT STANDBY/ON EJECT PLAY VIDEO L AUDIO R PROG STOP LINE IN 2 LINE IN 2 AUDIO PROGRAMME RECORD PAUSE/STILL LINE IN 2 BUTTON L, R INPUT...

  • Page 6: Rear View Of The Vcr

    Rear View of the VCR (SV-675/SV-670) AUDIO L, R OUTPUT AUDIO L, R INPUT AERIAL IN SOCKETS SOCKETS CONNECTOR LINE LINE IN 1 AUDIO VIDEO VIDEO INPUT VIDEO OUTPUT OUT TO TV CONNECTOR SOCKET SOCKET (SV-470/SV-275/SV-270) AUDIO OUTPUT AUDIO INPUT AERIAL IN SOCKET SOCKET...

  • Page 7: Infrared Remote Control

    Infrared Remote Control (SV-675/SV-670/SV-470/SV-275) VCR STANDBY/ON TV STANDBY/ON VCR STANDBY/ON BUTTON TV STANDBY/ON BUTTON SLOW SLOW BUTTON (SV-675/SV-670/SV-470) SHUTTLE SHUTTLE BUTTON V-LOCK V-LOCK BUTTON CLR/RST F.ADV INDEX INDEX BUTTON CLEAR AND RESET BUTTON -/-- FRAME ADVANCE BUTTON SELECT INPUT TV BUTTON TUNER, LINE IN 1, LINE IN 2 (SV-675/ VCR BUTTON...

  • Page 8: Display Indicator, Accessories, Inserting Batteries In The Remote Control

    4 Timer indicator LINE LINE IN 1 Accessories You have just purchased a SAMSUNG Video Cassette Recorder (VCR). Together with your VCR, you will find the following accessories in the box. REMOTE CONTROL OWNER’S INSTRUCTIONS Plug the coaxial cable supplied into the...

  • Page 9: The Rca Cable, Connecting Other Equipment To Your Vcr

    Connecting Your VCR to the TV Connecting Other Equipment to using the RCA Cable Your VCR You can connect your VCR to the television using the You can connect other audio and/or video equipment RCA cable if the appropriate input is available on the to your VCR in different ways.

  • Page 10: Plug & Auto Set Up, Tuning Your Television For The Vcr

    Plug & Auto Set Up Tuning Your Television for the VCR Your VCR will automatically set itself up when it is You must tune your television for the VCR only if you plugged into the mains for the first time. TV stations are not using a RCA cable will be stored in memory.

  • Page 11: Setting The Date And Time, Displaying/hiding On-screen Information

    Displaying/Hiding On-Screen Setting the Date and Time Information Your VCR contains a 24-hour clock and calendar used to: Your VCR displays most information both on the VCR and the television. Automatically stop programme recording You can choose to display or hide this information on Preset your VCR to record a programme the television screen (except for the Index, automatically...

  • Page 12: Choosing Your Language, Setting The Vcr Output Channel

    Setting the VCR Output Setting the VCR Output Choosing Your Language Channel Channel You can change the language in which information is Your VCR output channel may need to be changed if displayed on the screen. the pictures suffer from interference or if your TV cannot find the pictures.

  • Page 13: Presetting The Stations Automatically

    Presetting the Stations Automatically You do not need to preset the stations if you have already set them automatically (see Plug & Auto INSTALL YOUR DATA WILL BE LOST Set Up on page 10). Your VCR contains a built-in tuner used to receive PRESS TO CONTINUE television broadcasts.

  • Page 14: Presetting The Stations Manually

    Presetting the Stations Manually Your VCR contains a built-in tuner used to receive ❿ Press the button to preset the station. television broadcasts. Result: The MANUAL TUNING menu is displayed. You must preset the stations received through the tuner. ➛ ❿...

  • Page 15: Clearing A Preset Station, Changing The Preset Station Table

    Clearing a Preset Station Changing the Preset Station Table If you have stored a TV station: You can rearrange the Station Table and give different programme numbers to the stations listed according to That you do not require your own preferences. At the wrong programme position you can cancel it.

  • Page 16: Selecting The Cassette Type, Selecting The Recording Speed, Nicam (newzealand Sv-675/sv-670 Only)

    NICAM Selecting the Cassette Type (Newzealand SV-675/SV-670 Only) If you wish to use the tape counter to display the time NICAM programmes are divided into 3 types. NICAM remaining on a cassette, you must indicate the type of Stereo, NICAM Mono and Bilingual (transmission in cassette inserted.

  • Page 17: Recording A Programme With Automatic Stop

    Recording a Programme Recording a Programme Recording a Programme with acxz Immediately Immediately Automatic Stop Before recording a programme, you must have preset This function enables you to record up to nine hours the corresponding station (unless you are recording via of programmes.

  • Page 18

    Using the G-CODE Feature (SV-675/SV-275 Only) Before presetting your VCR: 1/JAN THU 21:28 PROG Switch on both the television and your VCR START STOP TH 1 12:00 12:50SP Check that the date and time are correct ---- --:-- --:---- ---- --:-- --:---- Insert the cassette on which the programme is...

  • Page 19

    Modifying G-CODE Programming (SV-675/SV-275 Only) If you wish to correct the programme displayed or modify certain elements, such as the recording speed, you can do so before you press MENU a second time to confirm. If you wish to... Then... Press the ➛...

  • Page 20: Using The Timer Programming Feature

    Using the Timer Programming Feature The Timer Programming feature allows you to preset Select the required recording end time by pressing the VCR to record a programme up to one month ❷ buttons, following the same procedure before that programme is to be broadcast. Up to six as when selecting the recording start time.

  • Page 21: Checking A Preset Recording, Cancelling A Preset Recording, Playing A Cassette, Adjusting Picture Alignment Manually

    Checking a Preset Recording Playing a Cassette You can check your preset recordings: This function allows you to play back any pre-recorded cassette. When you have finished presetting the VCR If you have forgotten which programmes will be Switch on both the television and your VCR. recorded Insert the video cassette to be played.

  • Page 22: Intelligent Picture Control

    Intelligent Picture Control Intelligent Picture Control (SV-270 Only) The Intelligent Picture Control Feature allows you to The Intelligent Picture Control Feature allows you to adjust the sharpness of the image automatically, adjust the sharpness of the image automatically, according to your own preferences. according to your own preferences.

  • Page 23: Selecting The Colour Mode

    Selecting the Audio Output Mode Selecting the Colour Mode (SV-675/SV-670 Only) Before recording or playing back a cassette, you can When monitoring a TV programme or playing back a Hi- select the required system standard. Fi recorded video tape, press the AUDIO button to select a desired sound output.

  • Page 24: Playing A Sequence Frame By Frame, Picture Search, Fast Forward/rewind

    Playing a Cassette in Slow Motion Picture Search, Fast (SV-675/SV-675/SV-470 Only) Forward/Rewind You can play a cassette in slow motion. Picture Search enables you to Fast Forward or Rewind and look for a particular part of a tape. No sound is heard when playing back a cassette in slow motion.

  • Page 25: Searching For A Specific Sequence, Auto Repeat Play

    Searching for a Specific Sequence Each time you record a cassette on this VCR, an These Index searches can be made forwards: “index” is automatically marked on the tape when (press ❿ ❿) or backwards: (press ➛ ➛). recording starts. The Search function allows you to fast-forward or rewind to a specific index and start playback from that point.

  • Page 26: Interval Repeat Play, Using The Tape Counter

    Interval Repeat Play Using the Tape Counter You can set interval repeat play to repeat the cassette The tape counter: several times for special interval. Indicates the elapsed time in the play and record modes (hours, minutes and seconds) Is reset when a cassette is inserted in the VCR Press MENU on the remote control.

  • Page 27

    Connecting an RCA Audio/Video Input Cable (SV-675/SV-275 Only) You can connect other audio/video equipment to your Connect one end of the RCA audio cable supplied VCR using audio/video cables if the appropriate outputs into the AUDIO INPUT sockets on the front of the are available on the equipment chosen.

  • Page 28: Using The Assemble Edit Function, Recording From Another Vcr Or Camcorder

    Recording from Another VCR or Using the Assemble Edit Function Camcorder This function allows you to start a new recording at a You can copy a cassette to your VCR from another specific position on the cassette while maintaining a video source, such as another VCR or a camcorder.

  • Page 29: Auto Power Off

    The Auto Power Off feature automatically turns off your VCR if no signal is received and you do not press any button for the selected time. Your VCR remote control will work with Samsung televisions and compatible brands. Press MENU on the remote control.

  • Page 30: Technical Specifications

    Technical Specifications Design and specifications are subject to change without notice. MODEL SV-675/SV-670 SV-470/SV-275/SV-270 Format VHS PAL standard VHS PAL standard Heads Video: 4 rotary heads Video: 4 rotary heads (SV-470) Video: 2 rotary heads (SV-275/SV-270) Hi-Fi audio: 2 rotary heads Audio/Control: 1 stationary head Audio/Control: 1 stationary head Erase: 1 full track erase head...

  • Page 31: Problems And Solutions

    Problems and Solutions Before contacting the Samsung after-sales service, perform the following simple checks. Problem Explanation/Solution No power Check that the power plug is connected to a wall outlet. Have you pressed the VCR STANDBY/ON (STANDBY/ON) button? You cannot insert a video cassette A video cassette can only be inserted with the window side up and the safety tab facing you.

  • Page 32: Tv Frequency Table

    TV Frequency Table (Australia Only) DISP CH Band 46.25 57.25 64.25 86.25 95.25 102.25 138.25 175.25 182.25 189.25 196.25 203.25 209.25 216.25 224.25 520.25 527.25 534.25 541.25 548.25 555.25 562.25 569.25 576.25 583.25 590.25 597.25 604.25 611.25 618.25 625.25 632.25 639.25 646.25 653.25...

  • Page 33

    TV Frequency Table (Newzealand Only) 002~012 :CCIR STD VHF 201~241 :CCIR STD CABLE 013~020 :ITALY 244~250 :MOROCCO 021~069 :CCIR STD UHF 251~255 :BELGUIM 071~075 :CCIR CABLE DISP CH Band DISP CH Band DISP CH Band 48.25 CCIR 783.25 CCIR 43.25 Angola 55.25 CCIR...

  • Page 34
