SPLIT-TYPE PACKAGED AIR CONDITIONER
ACONDICIONADOR DE AIRE COMPACTO SISTEMA SPLIT
CONDIZIONATORE D'ARIA COMPATTO AD UNITÀ SEPARATE
AR CONDICIONADO COMPACTO TIPO SPLIT
CLIMATISEUR EMBALLÉ DE TYPE SÉPARÉ
E S I P F DB68-30756B(2)
OWNER'S INSTRUCTIONS
MANUAL DE INSTRUCCIONES
ISTRUZIONI PER L'USO
MANUAL DE INSTRUÇÕES
MANUEL D'UTILISATION
APH240PE / APH240PD
APH-2807ER / DR
PH28ZV
(Refrigeração e Aquecimento)
(Refroidissement et Chauffage)
(Cool and Heat)
(Refrigeración y Calefacción)
(Raffreddamento e Riscaldamento)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APH-2807ERX and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung APH-2807ERX

  • Page 1 OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES ISTRUZIONI PER L’USO MANUAL DE INSTRUÇÕES MANUEL D’UTILISATION APH240PE / APH240PD APH-2807ER / DR PH28ZV SPLIT-TYPE PACKAGED AIR CONDITIONER (Cool and Heat) ACONDICIONADOR DE AIRE COMPACTO SISTEMA SPLIT (Refrigeración y Calefacción) CONDIZIONATORE D’ARIA COMPATTO AD UNITÀ SEPARATE (Raffreddamento e Riscaldamento) AR CONDICIONADO COMPACTO TIPO SPLIT (Refrigeração e Aquecimento)
  • Page 2: Table Of Contents

    Contents REPARING ONDITIONER Getting Started ....................Remote Control - Buttons and Display ............Inserting the Remote Control Batteries ............Keeping the Remote Control ................Indoor Unit ...................... Outdoor Unit ....................Control panel ....................Setting the Time ..................... PERATING ONDITIONER Operating Preparation ..................Using the Control Panel on the Indoor Unit ............
  • Page 3: Getting Started

    Getting Started You have just purchased a packaged air conditioner and it has been installed by your installation specialist. Users of this product are cautioned not to attempt repair of this product at their own discretion. Instead, they are requested to directly contact a designated service center or the outlet at which the product was purchased.
  • Page 4: Remote Control - Buttons And Display

    Remote Control - Buttons and Display Operating mode/Temperature display : Setting display - Mode indicators : AUTO, COOL, DRY, - Indicator : TURBO, MILD, FAN, HEAT Q.TIMER, Transmission Battery discharge. Setting display : - Fan speed - Air flow direction Time/Timer display - Current time - Timer settings...
  • Page 5: Inserting The Remote Control Batteries

    Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two LR03(AAA) 1.5V batteries. Do not use old bat- IMPORTANT teries, or different kinds of batteries together. Batteries may not be usable after 12 months though they have not been used.
  • Page 6: Indoor Unit

    Indoor Unit Air Flow(Direction) adjusting Blade Air Outlet Auto Shutter Each time you can press the ON/OFF( )button, it open or close automatically. Remote Control Case Control Panel Remote Control Sensor Air Inlet Grille To disassemble the air inlet grille. •Hold the upper part of the air inlet grille, and then pull it lightly forward.
  • Page 7: Outdoor Unit

    Outdoor Unit Electric Parts Box Air Outlet Connection Valve Control Panel Open the control panel by pushing a part of it. Temperature adjustment ON/OFF Button Operating Light Temperature display Fan Light Operating Light Turbo setting Mild setting(Automatic stop) Fan Speed adjustment Operating Mode Selection...
  • Page 8: Setting The Time

    Setting the Time Your air conditioner contains a clock used to start or stop the unit automatically at a given time. You must set the time when you: Purchase the air conditioner Replace the batteries Be sure to change the time in an area where summertime NOTE is applied.
  • Page 9: Operating Preparation

    Operating Preparation Look around the indoor and outdoor units. Confirm if any obstacles that may prevent the air flow are present near the air conditioner. Turn the power switch on. Result: The POWER light on the indoor unit switches on. IMPORTANT To operate the unit, the power switch is fitted to the wall must be set to ON...
  • Page 10: Selecting The Auto Operating Mode

    Selecting the Auto Operating Mode You can start the air conditioner in AUTO mode . If necessary, press the ON/OFF( ) button. Result: The OPER. light on indoor unit switches on. The operation mode previously set is displayed. The indoor unit beeps twice. The air conditioner starts up in the current.
  • Page 11: Starting To Heat

    Starting to Heat You must select the HEAT mode if you wish to adjust the: Heating temperature Fan speed when Heating If necessary, press the ON/OFF( ) button. Result: The OPER. light on the indoor unit switches on. The operation mode previously set is displayed. The indoor unit beeps twice.
  • Page 12: Starting To Cool

    Starting to Cool You must select the COOL mode if you wish to adjust the: Cooling temperature Fan speed when cooling If necessary, press the ON/OFF( ) button. Result: The OPER. light on the indoor unit switches on. The operation mode previously set is displayed. The indoor unit beeps twice.
  • Page 13: Selecting The Turbo Operating Mode

    Selecting the Turbo Operating Mode The turbo cooling(heating) operation function provides heavy duty cooling(heating) for 30 minutes regardless of the set temperature. Therefore, you can instantly get cool(warm) in this operation mode when you feel it is very hot(cold) in the room after returning home from outside. After 30 minutes turbo operation, the unit returns automatically to the operation mode previously set.
  • Page 14: Removing Excess Humidity

    Removing Excess Humidity If the atmosphere in your room is very humid or damp, you can remove excess humidity without lowering the room temperature excessively. If necessary, press the ON/OFF( ) button. Result: The OPER. light on the indoor unit switches on. The operation mode previously set is displayed.
  • Page 15: Ventilating Your Room

    Ventilating Your Room If the atmosphere in your room is stale, you can ventilate it using the Fan feature. If necessary, press the ON/OFF( ) button. Result: The OPER. light on the indoor unit switches on. The operation mode previously set is displayed. The indoor unit beeps twice.
  • Page 16: Adjusting The Air Flow Direction Horizontally

    Adjusting the Air Flow Direction Horizontally Depending on the position of the indoor unit, you can adjust the position of the air flow blades on the top of the unit, thus increasing the efficiency of the air conditioner. Press the L/R SWING button on the remote control. Result: The blades are moved between right and left.
  • Page 17: Setting The Timer

    Setting the Timer You can turn the air conditioner on or off automatically. Example: You wish to start cooling your room before you return from work; you decide to: Set the air conditioner going at 5:30 p.m. Switch it off at 11:30 p.m. Check that the current time is correct before setting IMPORTANT the timer;...
  • Page 18: Setting The Quick Timer

    Setting the Quick Timer The quick timer function allows reserved operation using only one button. Therefore, it is very convenient especially for children and elderly people to make reserved operation using this function. When the reserved operation is too complex presenting difficulty in use. You can set reservation in the range of thirty minutes - one hour - two hours - three hours - five hours.
  • Page 19: Cancelling The Timer

    Cancelling the Timer If you no longer wish to use the timer that you have set, you can cancel it at any time. To cancel the start time, press TIMER ON. Result: The ON indicator flash. Press the TIMER-CANCEL. Result: The indoor unit beeps.
  • Page 20: Operating Recommendations

    Operating Recommendations Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Heating The heat pump inside the air conditioner absorbs heat from outside air and brings it indoors. If the temperature performances of the outside air drops, the air conditioner will heat less. If you find that the room is not warm enough, use an additional heating appliance.
  • Page 21: Temperature And Humidity Ranges

    Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges, within which the air conditioner can be used. Mode Outdoor Indoor Indoor Humidity Temperature Temperature Heating 0°C to 24°C approx. 27°C or less Cooling 21°C to 43°C approx. 21°C to 32°C approx.80% or less If the unit is used for long periods at a high humidity level, water may condense...
  • Page 22: Before Calling The After-Sales Service

    Before Calling the After-Sales Service Before calling for service, make a few simple checks as follows. Problem Explanation/Solution The air conditioner Check that the power switch is turned ON. does not operate Check that the OPER. light on the indoor at all unit is on;...
  • Page 23 MEMO...
  • Page 24 THIS AIR CONDITIONER IS MANUFACTURED BY: ESTE ACONDICIONADOR DE AIRE ES FABRICADO POR: QUESTO CONDIZIONATORE D’ARIA E’PRODOTTO DA: ESTE APARELHO DE AR CONDICIONADO É FABRICADO POR: CE CLIMATISEUR EST FABRIQUE PAR: ELECTRONICS Printed in Korea...
