MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS

PAN/TILT
PAN/TILT connector
Connect a pan/tilt head to this connector.
ZOOM/FOCUS
ZOOM/FOCUS connector
This is a standard lens input terminal with a zoom/focus
remote function.
If you are using a Panasonic pan/tilt head (AW-PH300),
connect the remote cable to the LENS I/F connector on
the pan/tilt head, not to the ZOOM/FOCUS connector.
-7-
