Matrix K V M S witc h (K M0216 / K M0432) QUIC K S T A R T G UIDE
© 2004 ALT US E N. All rights res erved. ALT US E N is a trademark of AT E N, Inc. All Other trademarks are the property of their res pective owners . P A P E -1214-701
T hese instr uctions show how to install the K M 0216 /
K M 0432 F or detailed infor mation, r efer to the user
manual included in the kit.
1

Package Contents

T he complete package consists of :
¥ 1 K M0216 / K M0432 Matrix K V M Switch
¥ 1 Power Cord
¥ 1 R ackMounting K it
¥ 1 User Manual
¥ 1 Quick Start Guide
¥ 1 Warranty R egistration Card
2

Hardware Requirements

C onsole
¥ A V GA , SV GA , or Multisync monitor capable of the highest resolution that you will be
using on any computer in the installation.
¥ E ither a PS/2 or a USB keyboard and mouse.
C omputer s
¥ A n HDB -15 video port or, for legacy Sun systems, a Sun 13W3 video port.
¥ E ither a PS/2 style (6 pin mini-DIN) mouse port and PS/2 style keyboard port; or USB
ports (for a USB keyboard and USB mouse); or, for legacy Sun systems, a Sun style key
boardport (8 pin mini-DIN).
3
Hardware Requirements
C ables
F unction
Matrix K V M Switch to Console Module Cat. 5 cable
Matrix K V M Switch to K V M A dapter Cable Cat. 5 cable
K V M A dapter Cable For PS/2 ports : K A 9120
(T o computer or cascaded K V M switch)
For USB ports : K A 9170
For Sun L egacy : K A 9130
For Sun USB : K A 9131
Daisy Chain Cable K C1800
4
The Matrix KVM Switch Unit ( Front View )
1. F ir mwar e Upgr ade R ecover y Switch
2. Por t L E Ds
3. R eset Switch
4. Power L E D
5. Station I D L E D
* T he diagr am shows the K M 0432 model. T he K M 0216 only has one r ow of L E Ds *
5
The Matrix KVM Switch Unit ( Rear View )
1. Power Socket
2. Power Switch
3. C onsole Por t Section
* T he diagr am shows the K M 0432 model. T he K M 0216 only has two console pr ots and
16 C PU por ts *
6
Single Stage Installationtion
C able
1. Connnect the Console to the Console Module
2. Connect the Console Module to the Matrix K V M Switch
NOTE :
T he distance between the Console Module and the Matrix K V M Switch must
not exceed 150m (500').
3. Connect the Matrix K V M Switch to the K V M A dapter Cable
NOTE : T he distance between the Matrix K V M Switch and the K V M A dapter Cable
must not exceed 150m (500').
4. Connect the K V M A dapter Cable to the Computer.
5. R epeat steps 3 and 4 for all the computers you wish to connect.
6. A fter all your computers have been cabled up, plug the female end of the power
cord into the Matrix K V M Switch Power Socket; plug the male end into an A C power
source.
7. For each Console Module, plug its power adapter into an A C source; plug the power
adapter cable into the unit's power jack.
8. T urn on the power to the Matrix K V M Switch.
9. T urn on the power to the computers.
4. F ir mwar e Upgr ade Por t
5. Daisy C hain Por ts
6. C omputer Por t Section
SUN (USB)
PC
KA9120 KA9131
KA9170 KA9130
Mac
SUN
