- The covers for the SIM card and charging socket must be closed in the
Ex-area.
- When replacing the battery cover it must be ensured that the cover locks in
place properly and that the rear is secured using the six screws.
- It must be ensured that the phone is not taken into zone 0 or 20, 2 or 22!
- Only accessories approved by ecom instruments GmbH may be used.
- The mobile phone is not waterproof, therefore keep it dry!
- Observe the corresponding laws that are in force in the respective country
regarding the use of mobile phones while operating a vehicle!
- Use of the mobile phone in an airplane is not permitted!
- Switch off the mobile phone when in close proximity to medical instruments
and if you are requested to do so by corresponding regulations!
- Manufacturers of cardiac pacemakers recommend a minimum distance of
5 cm is maintained between a mobile phone and a pacemaker.
- Do not switch on the mobile phone when the use of such devices is prohibited,
as it may cause interference or result in danger.

5. Ex-Data

EC-Type Examination Certificate No.: ZELM 07 ATEX 0337
Ex-Designation:
Approved for zone , device group II, explosion group IIC (explosive gases,
vapours or mist), temperature class T4.

6. Specifications

Networks:
Data transfer:
Display:
Power supply:
Talk time / standby:
Charging time:
Dimensions:
Weight:
CE-Designation
Ambient temperature Ta:
Storage temperature:
Protection rating:

7. Functional description / Operating instructions

Please read this instruction manual carefully before use so that you are familiar
with, and are able to use, all of the functions of your Ex-Handy 05. For your own
safety and information please read through the instructions on the following
pages.
40
II 2 G Ex ib IIC T4
Triband GSM 900 / 800 / 900 MHz
GPRS class 0 (up to 62.4 kbps)
Passive matrix display with 65,536 colours
(resolution 28 x 28 pixels)
Li-ion rechargeable battery with 850 mAh capacity
max. 4h / max. 350h
approx. 3h
7 x 52 x 24 mm
approx. 50g
0
002
-0°C ... +50°C
0°C ... +40°C
IP54
