Summary of Contents for Ecom Instruments Ex-GSM 01
- Page 1 Safety instructions Ex-GSM 01...
-
Page 2: Table Of Contents
Application Safety instructions Errors and load restrictions Safety regulations Ex-data Accessories Technical Data Operating instructions 8.1 Safety in traffic 8.2 Operating environment 8.3 Electronic equipment 8.3.1 Cardiac pacemaker 8.3.2 Hearing aid 8.3.3 Other medical equipment 8.3.4 Places with appropriate signs 8.4 Transport 8.4.1 Motor vehicles 8.4.2 Aircrafts... -
Page 3: Application
1 Application The Ex-GSM 01 is a portable Non-Incendive cell phone for industrial use in explosion-hazardous areas of Class I, DIV 2, Groups A, B, C and D according to FM standards. -
Page 4: Safety Regulations
- Only the battery module NOKIA BL- 5B may be used. - It must be ensured that the unit is not taken into DIVISION 1. - Only accessories approved by ecom instruments GmbH may be used. - Avoid the use in aggressive acids and alkalis. -
Page 5: Operating Instructions
Before using the equipment for the first time, please read the safety and ope- rating instructions very thoroughly. Remember there is no vibra call in your modified ex-cell phone, please ignore all instructions in the original operating manual which describe the use and function of the vibra call. Further, the inte- grated camera is deactivated due to ex-relevant reasons. -
Page 6: Cardiac Pacemaker
8.3.1 Cardiac pacemaker The following instructions apply to persons fitted with a cardiac pacemaker: • When the mobile phone unit is switched-on, ensure that a minimum distance of 20 cm between the mobile- phone unit and the Pacemaker is maintained. •... -
Page 7: Transport
8.4 Transport 8.4.1 Motor vehicles In certain circumstances, RF signals can interfere with the correct functioning of incorrectly installed or inadequately screened systems in your motor vehi- cle (e.g. electronically controlled fuel injection, electronic ABS - (Antilock Brake Systems), electronic speed controllers or airbag systems). You can obtain information about your vehicle from the manufacturer or his representa- tive. -
Page 8: Certification Information (Sar)
Procedure in the event of an emergency call: 1. Switch the telephone on if it is not already switched on. Check whether the signal strength is adequate. In certain networks it may be necessary to plug a valid SIM card into the telephone. 2. - Page 9 the FCC is 1.6 W/kg*. Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certi- fied power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR of the phone while opera- ting can be well below the maximum value.
-
Page 10: Commissioning
For SAR information in other regions please look under the pro- duct information at www.nokia.com. 10 Commissioning How to connect the Ex-GSM 01 cell phone with the power outlet outside the hazardous areas see following diagram. Control drawing number: 0163EX04A 10.1 Getting started... - Page 11 1 – With the back of the phone facing you, press the indentations on both sides of the lower shell. 2 – Slide the bottom of the shell off to remove it. 3 – Grasp the removal flap, and gently pull it up. 4 –...
-
Page 12: Charging The Battery
The use of any other types may invalidate any approval or warranty, and may be dangerous. The Ex-GSM 01 mobile phone must only be charged outside of the Ex-hazar- dous areas and only with an approved battery charger type. Check the model number of any charger before use with this device. -
Page 13: Keys And Connectors
Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder. To switch the phone on or off, press and hold the power key. If the phone displays Insert SIM card, even though the SIM card is properly inserted or SIM card not supported, contact your service provider. -
Page 14: Changing The Shell And Key Mat
1 – Charger connector 2 – Pop-Port™ connector used, for example, for headsets and the data cable (please refer to the control drawing number: 0163EX04A for allowed con- nections to Ex-GSM 01). 3 – Camera lens (deactivated) 4 – Infrared (IR) port 10.1.5 Changing the shell and key mat... -
Page 15: Attaching The Carrying Strap To The Phone
10.1.6 Attaching the carrying strap to the phone 10.2 Standby mode When the phone is ready for use, and you have not keyed in any characters, the phone is in standby mode. 5 – Slide the upper shell onto the phone. 6 –... -
Page 16: Main Indicators In Standby Mode
1 -Shows the name of the network or the operator logo to indicate the cellu- lar network in which the phone is currently being used. 2 -Shows the signal strength of the cellular network at your current location. The higher the bar, the stronger the signal. 3 -Shows the battery charge level. -
Page 17: Some Useful Shortcuts In Standby Mode
The stopwatch is running. The GPRS connection mode Always online is selected and the (E)GPRS service is available. The indicator for GPRS and EGPRS is the same. An (E)GPRS connection is established. The (E)GPRS connection is suspended (on hold), for example, if there is an active call during an (E)GPRS dial-up connection. -
Page 18: Keypad Lock (Keyguard)
10.3 Telephone functions The Ex-GSM 01 includes functions which are very useful in everyday life, e.g. clock, alarm-clock, countdown timer, games, calculator, calendar and task list. Due to Ex-relevant reasons, the internal vibration motor had to be removed. -
Page 19: Java™-Applications
Enhanced GPRS (EGPRS), uses enhanced data rates for global evolution (EDGE), a radio interface modulation technique, to increase the data rates of GPRS. The functions of your phone that may use (E)GPRS are messaging, browsing pages, e-mail, remote synchronization, application downloading, and the PC dialup (for example, Internet and e-mail). -
Page 20: E-Mails
group of people having compatible devices. When your call is connected, the person or group you are calling does not have to answer the phone. Besides the GPRS counters, the phone registers only one-to-one calls in the recent call list in Call log. The participants should confirm the reception of any communi- cations where appropriate as there is no other confirmation whether the reci- pient(s) have heard the call. -
Page 21: Repairs
11 Repairs Repair work is subject to the nationally valid regulations and directives. We therefore recommend that such work be performed by ecom instruments GmbH, Germany, as all repairs must be examined to ensure functional safety. 12 Care and maintenance Your device is a product of superior design and craftsmanship and should be treated with care. -
Page 22: Warranty And Liability
2 years. 13 Warranty and Liability For this product, ecom Instruments GmbH warrants the function and material for a period of two years beginning on the date of the purchase under normal operating and maintenance conditions. Wearing parts, rechargeable and non- rechargeable batteries are exempt from this. - Page 23 The above-mentioned warranty conditions are the sole and only right of the purchaser to compensation, are exclusively valid and replace all other con- tract or legal warranty obligations. ecom instruments GmbH accepts no res- ponsibility for special, direct, indirect, accompanying or consequential damage...
-
Page 24: Certificate Of Compliance
14 Certificate of Compliance 14.1 For USA... -
Page 26: For Canada
14.2 For Canada... -
Page 28: Control Drawing
15 Control Drawing How to connect the Ex-GSM 01 cell phone with the power outlet outside the hazardous areas see following diagram. Control drawing number: 0163EX04A... - Page 29 GmbH Industriestr.2 97959 Assamstadt Germany Tel.: +49 (0) 62 94 / 42 24-0 Fax: +49 (0) 62 94 / 42 24-90 E-Mail: sales@ecom-ex.com...
