Turn controls
and gas source or tank OFF when not
in use.
CAUTIo.
if ignition does NOT occur in 5 seconds, turn the burner
controls OFF, wait 5 minutes for gas to clear away and
repeat the lighting procedure. If the burner does not ignite
with the valve open, gas will continue to flow out of the
burner and could accidently ignite with risk of injury.
Main Burner Match-Lighting
A Do not lean over grill while lighting.
1. Turn OFF all burner control valves.
2. Open lid during lighting. Turn on gas at LP cylinder.
3. Light match, and place into lighting hole for desired burner to
light. The lighting holes are located at the front of the cooking
grates between the emitter plate mounting brackets.
4. Push in and turn control knob to HI ._
position for desired
burner to light. Be sure burner lights and stays lit.
5. If ignition does NOT occur in 5 seconds, turn the burner
Control knob off, wait 5 minutes for gas to clear away, and
repeat the match lighting procedure.
6. Ignite remaining burners by repeating steps 3 through 5 for
each burner.
Side Burner Ignitor Lighting
Sideburner
Match Lighting
1. Turn OFF all burner control valves.
2. Open the sideburner lid.
Turn on gas at LP cylinder.
3. Place lit match near burner.
4. Turn sideburner knob to HI_
.
Be sure burner lights and stays lit.
WARNING: Sideburner top cover must be open when
sideburner is in operation.
Before Your First Cookout
• Light burners, check to make sure they are lit, close the lid and
warm up grill on HIGH for 15 minutes. This curing of paint and
parts will produce an odor only on first lighting.
Burner Flame Check
• Light burner, rotate knobs from HIGH to LOW. You should see
a smaller flame in LOW position than seen on HIGH. Always
check flame prior to each use. If only low flame is seen refer to
"Sudden drop or low flame" in the Troubleshooting Section.
Hose Check
• Before each use, check to see if hoses are cut, worn or kinked.
Replace damaged hoses before using grill. Use only
valve/hose/regulator specified in the Parts List.
Warning:
Top cover must be open
when side burner(s) is in
operation.
,& Do not lean over grill while lighting.
1. Open lid during lighting.
2. Turn ON gas tank valve.
3. Push and turn sideburner control knob to _1:: HI and
immediately press and hold ELECTRONIC IGNITION button.
4. If ignition does NOT occur in 5 seconds, turn burner control
knob OFF,wait 5 minutes for gas to clear away, and repeat the
lighting procedure.
5. Repeat above steps to light each burner individually.
Normal
Hose
Turning Grill Off
Kinked
Hose
• Turn all knobs to OFF position. Turn LP tank off by turning
OPD hand wheel clockwise to a full stop.
Ignitor Check
• Turn gas off at LP tank. Push and turn burner control to _
.
"Clicking" should be heard and sparking seen each time
between collector box or burner and electrodes. See
"Troubleshooting" if no click or spark occurs.
Valve Check
• Important: Make sure gas is off at LP tank before checking
valves. Knobs lock in OFF position. To check valves, first
push in knobs and release, and knobs should spring back. If
knobs do not spring back, replace valve assembly before using
grill. Turn knobs to LO position then turn back to OFF position.
Valves should turn smoothly.
8. 464261709
