D-Link DCS-3220 - SECURICAM Network Camera Product Manual

2-way audio internet camera with digital zoom
Hide thumbs Also See for DCS-3220 - SECURICAM Network Camera:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
DCS-3220
2-Way Audio Internet Camera
with Digital Zoom
Manual
Version 1.10
Building Networks for People
(10/04/04)

Advertisement

Table of Contents
loading

Related Manuals for D-Link DCS-3220 - SECURICAM Network Camera

Summary of Contents for D-Link DCS-3220 - SECURICAM Network Camera

  • Page 1 DCS-3220 2-Way Audio Internet Camera with Digital Zoom Manual Version 1.10 Building Networks for People (10/04/04)

  • Page 2: Table Of Contents

    Contents Contents of Package ..................3 Introduction ...................... 4 Features and Benefits ..................4 Connections ....................6 Hardware Installation ..................8 Installation Wizard ................... 9 Installation Wizard Screen ................14 Enabling UPnP for Windows XP/Me .............. 17 Installing IP surveillance Software ..............21 Testing the DCS-3220 ...................

  • Page 3: Contents Of Package

    Package Contents D-Link DCS-3220 Internet Camera Power Adapter Installation software and manual on CD Quick Installation Guide Camera Stand Category 5 Ethernet Cable If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage than the one included with the DCS-3220 will cause damage and void the warranty for this product.

  • Page 4: Introduction

    Introduction The D-Link SECURICAM Network DCS-3220 Internet Camera is a full featured surveillance system that connects to an Ethernet, Fast Ethernet or broadband Internet connection to provide remote high-quality video, 2-way audio surveillance, and 4x digital zoom . The DCS-3220 Internet Camera differs from...
  • Page 5 D-Link product provided herein is suitable for the end-user’s intended use under the applicable laws of his or her state. D-Link disclaims any liability whatsoever for any end-user use of the D-Link product, which fails to comply with applicable state, local, or federal laws.

  • Page 6: Connections

    Connections DC Power Connector Audio Out Connector Reset Button Ethernet Cable Connector I/O Connector Ethernet Cable Connector The DCS-3220 back panel features an RJ-45 connector for connections to 10Base-T Ethernet cabling or 100Base-TX Fast Ethernet cabling. This network port supports the NWay protocol, allowing the Internet Camera to automatically detect or negotiate the transmission speed of the network.

  • Page 7: Bottom Panel

    Connections (continued) I/O Connector The DCS-3220 provides a terminal block with two pairs of connectors situated on the back panel. One pair is for input and the other is for output. The I/O connectors provide the physical interface to send and receive digital signals to a variety of external alarm devices.

  • Page 8: Hardware Installation

    Hardware Installation Connect an Ethernet cable Connect an Ethernet cable to the network cable connector located on the DCS-3220’s back panel and attach it to the network. Attach the external power supply Attach the external power supply to the DC power input connector located on the DCS-3220’s back panel labeled 12VDC and connect the other end to your wall outlet.

  • Page 9: Installation Wizard

    Installation Wizard After you have successfully completed the hardware installation of the DCS- 3220 Internet Camera, it is necessary to install software to configure and operate the camera. The first step is to install the Installation Wizard from the CD. Installation Wizard will allow you to configure the Internet Camera to your network After the Installation Wizard software program is completed, you will have an...
  • Page 10 Installation Wizard (continued) Click Installation Wizard. Please wait while the InstallShield Wizard prepares to install. Click Next.
  • Page 11 Installation Wizard (continued) The InstallShield will install in the following folder. To install into a different folder, click Browse and select another folder. Click Next. Select the Program folder that Setup will add program icons to. You may type a new folder name, or select one from the existing folders list.
  • Page 12 Installation Wizard (continued) Installation is now complete. Click Finish. To access the Installation Wizard screen, click on the Installation Wizard Icon on your desktop. The opening Installation Wizard screen will appear and show a MAC address of the DCS-3220 and an IP Address (which may or may not be correct depending on what you have your DCS-3220 connected to).
  • Page 13 Installation Wizard (continued) The Installation Wizard will now show a MAC address for the DCS-3220 and an IP address. This IP address may not be correct at this step in the installation until you see “Yes” under the assigned column. The camera is now automatically configured with an IP address consistent to the device it is connected to.

  • Page 14: Installation Wizard Screen

    Installation Wizard Screen The following options are available on the Installation Wizard screen by clicking on the corresponding tab: Search - Click to search for any available cameras to connect to the network. Add - Click to manually add a camera to the network.
  • Page 15 Installation Wizard Screen (continued) Network Settings - Here users can configure the Network Settings for the camera. Enter the IP address, Subnet mask, Default router IP, Primary DNS, and Secondary DNS. Automatically, the option to reset IP address at boot is selected.
  • Page 16 Installation Wizard Screen (continued) Locate the Firmware to Upgrade - Indicate the location of the firmware to be uploaded to the camera. Selected Package - This displays the file name of the firmware selected for upload. Reset to Default - Click the Reset to Default tab to reset the camera’s settings to factory defaults.

  • Page 17: Enabling Upnp For Windows Xp/Me

    Enabling UPnP for Windows XP/Me UPnP is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. The DCS-3220 is a UPnP enabled Internet camera. If your operating system is UPnP enabled, the device will be easier to configure. If you do not want to use the UPnP functionality, it can be disabled by unchecking the Enabled DDNS check box on the DDNS/UPnP settings page under “Advanced”...
  • Page 18 Enabling UPnP for Windows XP/Me (continued) Click Add/Remove Windows Components The following screen will appear: Select Networking Services (Communications in Windows Click Details Select Universal Plug and Play Click...
  • Page 19 Enabling UPnP for Windows XP/Me (continued) Click Next Please wait while Setup configures the components. Click Finish...
  • Page 20 Enabling UPnP for Windows XP/Me (continued) To view your DCS-3220 Internet Camera in an Internet browser, go to your Desktop and click My Network Places. Click My Network Places Click DCS-3220-100 The last three digits (100), represent the fourth octet of your Internet Camera’s IP address (in this example, 198.168.0.100).

  • Page 21: Installing Ip Surveillance Software

    Installing IP surveillance Software The IP surveillance software on the CD included with the DCS-3220 Internet Camera converts the DCS-3220 into a powerful, yet flexible, surveillance system for home or business, with these features: Real-time Monitoring Video Recording to hard disk High quality video High compression ratio Maximum of 16 cameras with different monitor layouts...
  • Page 22 Installing IP surveillance Software (continued) Click Please read the Software Licensing Agreement and click yes if you wish to accept the agreement. Click “No” to exit the installation. Click Next Enter your name and company information and click “Next.”...
  • Page 23 Installing IP surveillance Software (continued) Select the destination directory. Click Next Select the program folder the software will be installed into. Click Next...
  • Page 24 Installing IP surveillance Software (continued) Click Next Click Finish The installation is complete.

  • Page 25: Testing The Dcs-3220

    Testing the DCS-3220 Internet Camera Open your Internet browser and type in the IP address of the DCS-3220. In this example the address is: http://192.168.0.12 (your DCS-3220 may have a different IP address based on what you used in the Installation Wizard program).

  • Page 26: Security

    Security At this point it is highly recommended that you click on the Configuration button on the Home screen, and then the Tools tab to bring you to the Admin screen. Enter a password for security purposes. To ensure the highest security and prevent unauthorized use of the Internet Camera, the Administrator has the exclusive privilege to access the System Administration settings to allow users entry and authorize privileges for all users.

  • Page 27: Using And Configuring The Dcs-3220 With A Nat Router

    Materials Needed: 1 DCS-3220 Internet Camera 1 Ethernet Cable A Wired or Wireless router such as the D-Link DI-624 Wireless Router Ethernet based PC for system configuration SETTING UP THE DCS-3220 FOR USE BEHIND A ROUTER Installing a DCS-3220 Internet Camera on your network is an easy 4–step...
  • Page 28 Using & Configuring the DCS-3220 with a NAT Router (continued) This is the IP Address assigned to your camera. Write it down for later use. 192.168.0.146 is only an example. You will probably have a different IP Address. Assign a Local IP Address View the Internet Camera using your Internet Explorer Web browser Run your Internet Explorer Web browser.
  • Page 29 The following steps generally apply to any router that you have on your network. The D-Link DI-624 is used as an example to clarify the configuration process. Configure the initial settings of the DI-624 by following the steps outlined in the DI-624 Quick Installation Guide.
  • Page 30 Using & Configuring the DCS-3220 with a NAT Router (continued) Your WAN IP Address will be listed here. Determine Your Router’s IP Address (WAN) Note: Because a dynamic WAN IP can change from time to time depending on your ISP, you may want to obtain a Static IP address from your ISP. A Static IP address is a fixed IP address that will not change over time and will be more convenient for you to use to access your camera from a remote location.
  • Page 31 Using & Configuring the DCS-3220 with a NAT Router (continued) Follow these steps to configure your router’s Virtual Server settings: Click Enabled. Enter a different name for each entry. Enter your camera’s local IP Address (e.g., 192.168.0.146 in the example in step on page 28) in the Private IP field.

  • Page 32: Viewing Your Camera

    Viewing Your Camera After all settings have been entered correctly, a PC user inside or outside your network will have access to the camera through the Internet Explorer Web browser. To access the camera from the Internet, type the IP Address of the router given to you by your ISP, followed by a colon, and the port number that you gave your camera (e.g., http://205.163.122.96:83).

  • Page 33: Using The Dcs-3220 With An Internet Browser

    Using the DCS-3220 with an Internet browser If you are following this manual in the order it is presented, you should now have an operating DCS-3220 Internet Camera configured with the Installer program. You also have installed the IP surveillance software from the CD. This section of the manual will deal with using the Internet Camera in two parts: Using the DCS-3220 with an Internet browser and accessing the screens to control and monitor the camera.

  • Page 34: Home Page Screen

    Using the DCS-3220 with an Internet browser (continued) Home Page Screen The image from the DCS-3220 should be visible from the Home page on your computer monitor. Below the image are controls that allow you to control zoom and two way audio functions. Push/Toggle –...
  • Page 35 Using the DCS-3220 with an Internet browser (continued) Home Page Screen The image from the DCS-3220 should be visible from the Home page on your computer monitor. There are two buttons on the left side of the Home page: Connection Type and Configuration.
  • Page 36 Using the DCS-3220 with an Internet browser (continued) Home > Connections Screen The following options are available from the Connections settings screen: Media Option Disable Audio - Option for users to disable or enable audio when viewing video. Speaker button Operation - If Push is selected, the user must push and hold the speaker button each time to speak.
  • Page 37 Using the DCS-3220 with an Internet browser (continued) Home > Configuration Click on the Configuration button on the Home page: Click Configuration There are 5 tabs across the top of the Configuration screen. From each tab, different elements of the DCS-3220 can be configured. The Advanced tab is the default screen in Configuration and Network is the default screen under Advanced.
  • Page 38 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > Network Reset IP Address at next boot Once the DCS-3220 is configured, this box should be unchecked at all times. If the box has been checked and the connection is lost, run the Installation Wizard to find the camera’s IP address.

  • Page 39: Ftp Settings

    Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced >Network Settings (continued) The user name for the second SMTP server. 2nd SMTP account name - The password used to log into the second e-mail 2nd SMTP password - account.
  • Page 40 Using the DCS-3220 with an Internet browser (continued) Primary FTP Passive If the DCS-3220 is located inside the network Mode- protected by firewall, a data connection for FTP may be prohibited. Passive mode FTP can bypass the rule and succeed to upload snapshots. If the passive mode is selected, the DCS-3220 can automatically attempt for an active mode if the external FTP server does not support passive...
  • Page 41 Using the DCS-3220 with an Internet browser (continued) UDP Video port - Can be set to a port other than the default port 5003. A corresponding port must be opened on your firewall. Click Apply to make changes effective. Configuration > Advanced > DDNS & UPnP Click the DDNS &...
  • Page 42 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > DDNS & UPnP (Continued) Enable DDNS - Click to enable the DDNS function. Provider- Select your Dynamic DNS provider from the pull down menu. Host name- Enter the host name of the DDNS server. Username/E-mail- Enter your username or e-mail used to connect to the DDNS server.
  • Page 43 Using the DCS-3220 with an Internet browser (continued) Invalid settings may cause the DCS-3220 to not respond. Change the configurations only if necessary. Consult with your network administrator or your Internet Service Provider (ISP) if you do not have the necessary information.
  • Page 44 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > Video (Continued) Size - Three options exist for the video display: 176 x 120, 352 x 240, and 704 x 480. In 704x480 mode, the frame rate will be reduced to 10 fps and increased to 30fps automatically when it is switched back to a lower image size.
  • Page 45 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > Video Settings (continued) Click Apply to make changes effective. Recommendations for setting video for the best performance: “Best performance” means the image refresh rate should be the fastest possible and the video quality should be the best possible using the lowest amount of network bandwidth possible.
  • Page 46 Using the DCS-3220 with an Internet browser (continued) Recommendations for setting video for the best performance (continued): Recording settings for clear identification for each image To have the best video quality, you should set Fix quality to detailed or excellent and tune the Maximum frame rate to suit your network bandwidth.
  • Page 47 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > Audio (continued) Transmission Mode - Select the transmission mode that the camera will use to transmit audio. You can select: Talk and Listen Simultaneously; Talk or Listen, not at the same time; Talk Only;...
  • Page 48 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced > Image Setting (continued) Click the image setting button from the configuration screen to access additional settings that affect how the video image appears. From this screen you can fine tune the video image. Image Brightness, Contrast, Saturation, and Hue are all adjusted in the same manner.
  • Page 49 Using the DCS-3220 with an Internet browser (continued) Configuration > Advanced >Motion Detection (continued) Enable motion detection - Check this option to turn on the motion detection. Window Name - The text entered here will show at the top of the motion window.
  • Page 50 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Admin Click on the Tools tab to access 4 utility screens for controlling and administering the DCS-3220. The default screen in Tools is the Admin screen. The DCS-3220 is manufactured without any passwords by default. This allows the ability to access the DCS-3220 (including the Configuration) by anyone as long as the IP address is known.
  • Page 51 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Admin (continued) Guest account: This option allows a user to connect to a camera with view -only privileges. User name is “demo.” No password is required. This is useful for demonstrations and keeps guests separate from users with accounts.
  • Page 52 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > System Keep current date and Click to save the current date and time of time - DCS-3220. An internal real-time clock maintains the date and time even when the power is off. Sync with computer time- Synchronize the date and time of DCS-3220 with the local computer.
  • Page 53 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Applications Click on the Applications button to access the Applications settings from the Tools menu.
  • Page 54 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Applications (Continued) Weekly schedule: Sunday through Saturday - Select the weekdays that should perform the following operations: Set the time to start operations. Setting the begin Snapshots begin at - time the same as the stop time will force the operations to run continuously.
  • Page 55 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Applications (Continued) Trigger action - There are four options for two actions regarding either trigger condition. They can have multiple selections. While choosing the trigger output alarm, the digital output will short both pins to connect the circuit of the attached external device;...
  • Page 56 Using the DCS-3220 with an Internet browser (continued) Configuration > Tools > Default Click Apply to make changes effective. Click on the Default button to access the option to restore to factory default settings. Click Default. Click Apply on this screen to restore factory default settings. This means any changes made will be lost and the system will be reset to the initial status when shipped from the factory.
  • Page 57 Using the DCS-3220 with an Internet browser (continued) Click Device Info. The Device Info screen lists the following important settings that are currently set for the DCS-3220. • Firmware Version number • Mac Address • IP Address • Subnet Mask •...
  • Page 58 Using the DCS-3220 with an Internet browser (continued) Configuration > Help Click on the Help tab to access descriptions of the particular function you need help with. The help screen is organized in the order of the tabs and then each menu item under that tab.

  • Page 59: Record Snapshots To Your Ftp Server With Motion Detection

    Record Snapshots to your FTP server with Motion Detection Administrators can combine options on the application page to perform many useful security applications. There are two trigger sources available: from an external sensor or with built-in motion detection. There are also two kinds of actions that can respond to these events that include uploading snapshots over the internet and driving attached devices.
  • Page 60 Record Snapshots to your FTP server with Motion Detection (continued) Next, click the Network button under the Advanced tab to set the FTP server settings for the DCS-3220. Click Network 123.123.123.1 John Smith Snapshot In this window, enter the settings for the FTP server you wish to record to. Optionally, you can enter settings for a secondary backup FTP server.
  • Page 61 Record Snapshots to your FTP server with Motion Detection (continued) 1st FTP server port- The port of the FTP server. The default is 21 for an external FTP site. 1st FTP user name- Specify the user name to access the external FTP server (e.g.
  • Page 62 Record Snapshots to your FTP server with Motion Detection (continued) Next, click the Applications button under the Tools tab to set the application settings for the DCS-3220. Click Applications Back Door In this window, follow the steps below to set the application settings for snapshots to be recorded to an FTP site: Select the weekdays you would like to record and enter the “Snapshots begin”...

  • Page 63: Using Ip Surveillance Software

    Using IP surveillance Software Installing the IP surveillance Software Hardware System Requirements Before you begin installing this application software, the hardware system requirements must be checked first. The system minimum requirements recommended for this application are as follows: Browser: Internet Explorer 5.x or above CPU: Intel Pentium 4 1.7GHz or above (Pentium 4, 2.8GHz plus processor with 512MB memory and a 32MB video card is required for multiple camera viewing and recording in IP Surveillance)
  • Page 64 Using IP surveillance Software (continued) Installing the IP surveillance software (continued) Click Next The “License Agreement” window below will appear. Please read the following license agreement carefully. Click “Yes” to accept this agreement and proceed with the installation. Click...
  • Page 65 Using IP surveillance Software (continued) Installing the IP surveillance software (continued) Next, the “User information” window below will appear. This window will prompt you to enter the user name and company name. Enter your user name and company name and then click “Next” to continue. Click Next You must setup the administrator’s password in order to proceed.
  • Page 66 Using IP surveillance Software (continued) Installing the IP surveillance software (continued) Select the installation directory for this application software and click “Next”, which is shown in the figure below. You can change the installation directory by clicking “Browse…” Click Next Select a program folder to install the application software and then click “Next”, which is shown in the figure below.
  • Page 67 Using IP surveillance Software (continued) Installing the IP surveillance software (continued) After checking all the setup information in the window shown below, click “Next” to start the installation of the application software. Click Next Click “Finish”, in the window shown below, to finish installation. The program is now installed on your computer.

  • Page 68: Launcher

    Using IP surveillance Software (continued) Launcher Launcher is a controller program that allows users to invoke Monitor or Playback quickly. System Tray Icon The Launcher icon reflects current state of IP surveillance. The icon in the system tray signifies that the IP surveillance Software is currently active on the system.
  • Page 69 Using IP surveillance Software (continued) Launcher (continued) When Launcher is locked, the unlock window will appear, prompting for the user password in order to unlock. The input area of the dialog will be grayed (disabled) for 60 seconds after 3 consecutive failures.
  • Page 70 Using IP surveillance Software (continued) Launcher (continued) Tools Contains many utilities. Currently only change password is implemented. The change password dialog looks like this: Autorun at Startup Users can select whether or not to autorun Launcher when Window boots up. Monitor Starts up the Monitor program.

  • Page 71: Monitor Program

    Using IP surveillance Software (continued) Monitor Program Features of the Monitor Program Traditional Surveillance Features: Real-time monitoring Pan and Tilt control Recording Special Features: The digital surveillance system supports not only the features listed above, but also the following features, which make the system more powerful and convenient.
  • Page 72 Using IP surveillance Software (continued) Monitor Program (continued) Application Layout and Functionalities This section demonstrates a global view of the monitor program, shown below. The components of the monitor tool will be introduced in detail in the following sections. Misc. Functions Video Area Channel Area Layout Area...
  • Page 73 Using IP surveillance Software (continued) Monitor Program (continued) Layout area You can change the monitoring layout in this area. There are six kinds of layouts: 1, 4, 6, 9, 13, or 16 video display windows in the video area. Hard disk status In this area, you can get the status of the hard disk in which the video database resides.
  • Page 74 Using IP surveillance Software (continued) Monitor Program (continued) The Admin Privilege In the monitor program, the admin has the right to access the DCS-3220 Network Camera through this application software and change the local settings as well. But the admin password for the software is not the same as the admin password for the Internet camera.
  • Page 75 Using IP surveillance Software (continued) Monitor Program (continued) The Layout of the Configuration This section discusses the local settings for the connection and the functional configuration of each camera. If you are interested in the remote settings for each camera, you can refer to “Using the DCS-3220 with an Internet Browser,” which starts on page 33.
  • Page 76 Using IP surveillance Software (continued) Monitor Program (continued) Insert – To insert a remote network camera to the camera list. Click the “Insert” button, an “Insert New Channel” dialog will popup, as shown below. Specify the IP address, port, and admin password of the network camera, click the “Ok” button to close the dialog.
  • Page 77 Using IP surveillance Software (continued) Monitor Program (continued) Delete – The deletion of a device is a much easier operation than “insertion”. It removes the selected network camera from the camera list. Highlight the camera that you want to delete from the list and click on the “Delete” button. The selected camera will be deleted.
  • Page 78 Using IP surveillance Software (continued) Monitor Program (continued) Alert Settings: Specific alert actions can be performed by setting the options in this window. Enable motion detect This will trigger an alert sound that has been specified in the section titled “Global Settings \ Alert Sound.” Check this option to enable audio alert for the camera selected.
  • Page 79 Using IP surveillance Software (continued) Monitor Program (continued) Changing the Camera Order in the List You can “drag and drop” in the grid area of the camera list to change the sequence of the connected Network Cameras, which is shown below. This will allow you to rearrange the cameras in an order of your choice.
  • Page 80 Using IP surveillance Software (continued) Monitor Program (continued) Global Settings After completing the connection to each remote Network Camera, we need to configure some global settings for all the cameras. These include the video database directory, the usage of the Hard disk, and options for video display. You can activate the global settings window from “Configuration Menu >...
  • Page 81 Using IP surveillance Software (continued) Monitor Program (continued) Directory Settings: Snapshot directory The directory for storing snapshots in *.bmp format from video channels of the monitor and playback programs, which is shown on page 80. Recording directory The directory for storing the recorded video data from video channels.
  • Page 82 Using IP surveillance Software (continued) Monitor Program (continued) Modulation Mode You must select the input signal format (NTSC or PAL) for displaying the original resolution of video stream from DCS-3220. NOTE: You need to select the input signal format according to the camera type or CCD module type that is connected to the DCS-3220.
  • Page 83 Using IP surveillance Software (continued) Monitor Program (continued) Backup Settings: Using Backup Settings in the global settings window, you can backup recorded data from selected cameras to a specified location. Directory This is the directory where backup data will be saved. You can select the location by clicking on the folder icon.
  • Page 84 Using IP surveillance Software (continued) Monitor Program (continued) Using the Monitor Program This section depicts, in detail, how to manipulate the monitor tool. Connection of the DCS-3220 Channel: Once you have the privilege to connect to the DCS-3220, the cameras will automatically appear in the video area in the order they are connected.
  • Page 85 Using IP surveillance Software (continued) Monitor Program (continued) Not configured channel Selected Channel Recording Connected and monitoring Configured but not connected (no video) Trashcan If you do not want to monitor one video, you can drag and drop the video (in the video area) to the trashcan in the common control area of the monitor program.
  • Page 86 Using IP surveillance Software (continued) Monitor Program (continued) Step 2: Press and hold the left mouse button, and then move the cursor to a display window in the video area, which is shown below. Note that the cursor will change according to the area in order to indicate whether the area is droppable or not.
  • Page 87 Using IP surveillance Software (continued) Monitor Program (continued) Video shown Empty video box Removing video from a display window Step 1: Move the mouse cursor to the display window that contains the video channel you wish to remove. Step 2: Note that the cursor will change to the hand-shape when it has been moved onto the displaying frame.
  • Page 88 Using IP surveillance Software (continued) Monitor Program (continued) Press and hold the left mouse button here. Move the mouse cursor here, and then release the left mouse button. The Layout There are six different layouts available, as shown below, for the display windows in the monitor program.
  • Page 89 Using IP surveillance Software (continued) Monitor Program (continued) Double click on a dis- play window to switch to a single channel layout. When you choose the one-channel layout or four-channel layout, the “Page up” and “Page down” buttons will be shown in the left-bottom corner of the video area.
  • Page 90 Using IP surveillance Software (continued) Monitor Program (continued) To view an individual camera from the multi-camera layout, double-click on the desired display window. You will see that the size of the display window is the same as the one-channel layout. Clicking the “Back” button in the upper-left corner of the video area will switch to the previous selected multi-camera layout.
  • Page 91 Using IP surveillance Software (continued) Monitor Program (continued) IP surveillance includes DI/DO (Digital Input / Digital Output) control and an alert message receiver. These features are described in detail below. DI/DO Control Clicking on the “DI/DO” button shown below, you can switch to the DI/DO controls.
  • Page 92 Using IP surveillance Software (continued) Monitor Program (continued) Alert Message If you have checked the box for “Enable Motion Detect” or “Enable Digital Input” on “Camera Configurations > Alert Settings“ screen, the alert message will show in the window shown above. Once the alert, caused by motion detection or a digital input level changer, is triggered, the alert message will be shown in this window.
  • Page 93 Using IP surveillance Software (continued) Monitor Program (continued) About By choosing “About”, located in the configuration menu shown below, a dialog box will appear and display the information about the installed version of IP surveillance. The information includes the software name, version, user name, and company.
  • Page 94 Using IP surveillance Software (continued) Monitor Program (continued) Full Screen With this function, you can enlarge the selected video channel to a full-screen display. Press the “ESC” key on the keyboard or double-click the mouse on the screen to return to a regular display. Stop Alert Sound If an alert is triggered, the alert sound will start to play.
  • Page 95 Using IP surveillance Software (continued) Monitor Program (continued) Record By clicking on this button, you can manually record video from the selected channel. Stop After video recording has been activated, this button allows you to manually stop recording of the selected video channel. Snapshot This button will take a snapshot of the selected video channel and save the picture as a bitmap file to the hard disk.

  • Page 96: Scheduling

    Using IP surveillance Software (continued) Scheduling The scheduler allows the user to schedule recordings from the selected video channel of the DCS-3220. Through both the graphic user interface and time period selection options, you will be able to easily regulate a schedule for each video channel.
  • Page 97 Using IP surveillance Software (continued) Scheduling (continued) The scheduler will not be accessible until at least one camera has been added to the camera list. Go to the configuration menu and click on “Scheduler” to launch the scheduler. The Layout and Functionalities Introduction The layout of the scheduler and its components, shown below, will be described.
  • Page 98 Using IP surveillance Software (continued) Scheduling (continued) The layout of the scheduler tool is roughly divided into 4 parts. Part 1 The first part of the scheduler is the video channel selection area. It provides the IP addresses and location information of the connected video channels for the user’s reference.
  • Page 99 Using IP surveillance Software (continued) Scheduling (continued) In this area you will select the video channel that you want to set a schedule for. Each video channel will display a name, IP address, and location. Please note that when you switch between video channels in this area, the changes in the schedule of the previous video channel will be saved automatically.
  • Page 100 Using IP surveillance Software (continued) Scheduling (continued) Hour Time-Line In the figure below, the Hour time-line is displayed. Marking/Unmarking the Recording Time on the Hour Time-Line You can apply the one-click function by clicking the left mouse button and dragging to mark the time on this time-line. The operating method for the hour time-line is the same as that of the week time-lines.
  • Page 101 Using IP surveillance Software (continued) Scheduling (continued) Apply and Erase Buttons After you have selected the time period with “Begin time” and “End time” picker, you can apply the period picker, shown in the figure below, to set the periodical types of the time interval set previously.
  • Page 102 Using IP surveillance Software (continued) Scheduling (continued) Digital Input In the figure above, there are four conditions for the digital input. Check the condition that you would like to record while the condition triggers. high Checking this will trigger recording while the digital input is high. The technical name for this event is line trigger.
  • Page 103 Using IP surveillance Software (continued) Scheduling (continued) There are three modes in the secondary schedule: Disable, Event mode, and Continuous mode. You can either disable the secondary schedule or choose the event or continuous mode. These two modes are the same as the primary schedule.

  • Page 104: Playback Program

    Using IP surveillance Software (continued) Playback Program The playback program is a very powerful, convenient, and easy way to browse the recorded video. It has one display mode (normal display mode) and two playback methods (full range and time period). There are several main functions including special features in the Playback program.
  • Page 105 Using IP surveillance Software (continued) Playback Program (continued) Logging In Before you start the playback program, it is necessary for you to log in to the application software. The figure below shows the login dialog. For security concerns, only the admin account can log in to this program. To change the password of the admin account, please refer to the section titled “Logging In.”...
  • Page 106 Using IP surveillance Software (continued) Playback Program (continued) When you successfully log in to the playback system, the main window will be shown on the top of the screen and the display resolution will be changed to 1024x768 automatically (see P. 105). There are four main areas, i.e. display area, histogram area, control area, and status area.
  • Page 107 Using IP surveillance Software (continued) Playback Program (continued) Histogram Area The histogram is an interactive control. Not only can you get the event’s location in time domain and its quantity of the motion percentage, but you can also select a group of events or a period from the event histogram area and show it on the display area.
  • Page 108 Using IP surveillance Software (continued) Playback Program (continued) Pull Bar The pull bar is a fast, flexible control for seeking data in the selected time period. It represents the total length of time in that period. You can pull the indicator on the pull bar to the specific time-point you would like to view.
  • Page 109 Using IP surveillance Software (continued) Playback Program (continued) The items in the settings windows are: Database location The most important item in the settings dialog is the database location setting. You must set it to the directory that contains the surveillance database to make the program to work properly.
  • Page 110 Using IP surveillance Software (continued) Playback Program (continued) Normal (Single Frame) Mode While in the normal (single frame) display mode, you can change the video currently displayed by: (1) Changing the database path for retrieving another one in the settings dialog of “System Control”...
  • Page 111 Using IP surveillance Software (continued) Playback Program (continued) Histogram Area Inverted region Dark Region The histogram area in the normal display (single frame) mode only shows the events’ occurred time and the percentage of motion detection with red bars. If you want to access the histogram area, you must change the area selection indicator to the histogram area.
  • Page 112 Using IP surveillance Software (continued) Playback Program (continued) Location selector Period selector Playback method selector Alert area selector Location Selector The location selector is a control that lets you select the camera you want to see (refer to the figure above). The location name is the same as the camera name (text on video) unless you have specified otherwise.
  • Page 113 Using IP surveillance Software (continued) Playback Program (continued) Playback Method Selector Full Range If you select this method, the database will be displayed from the beginning to the end of this location. Any change in the period selector will have no effect except when you change this selector to “Time Period.”...
  • Page 114 Using IP surveillance Software (continued) Playback Program (continued) Speed Indicator Pause Play Forward Stop Play The supported “Play” button is an intelligent play user-interface. The functionality of this button can vary to fit different circumstances. In the normal display mode, clicking on the “Play” button can restart the displaying video sequence.
  • Page 115 Using IP surveillance Software (continued) Playback Program (continued) Display Adjustment Tool When you move the mouse cursor to the displaying area, the display adjustment toolbox will appear. Using the display adjustment toolbox, you can change the displaying video sequence to the size you want to see in the normal display mode when you move the area selection indicator to the display area.
  • Page 116 Using IP surveillance Software (continued) Playback Program (continued) Full Screen When you click on the “Full Screen” button, the video sequence will be enlarged to the whole screen instantly. You can double click on any place or the “ESC” key to return back to the normal screen. When you switch to the full screen display, you can press the “Alt”...
  • Page 117 Using IP surveillance Software (continued) Playback Program (continued) Zoom Out Each time you click on the “Zoom Out” button in the searching range adjustment toolbox, the displayed time period will be double in the center of the original time period unless the start time or end time exceeds the whole database time- boundary.
  • Page 118 Using IP surveillance Software (continued) Playback Program (continued) Settings The settings dialog will pop up when you click the “Settings” button. For more information about setting this program, please refer to the section titled "Settings.” Minimize Click this button in order to minimize the playback program window. Exit The playback program will be closed immediately when you click on the “Exit”...

  • Page 119: Schedule Video Recording With Motion Detection

    Schedule Video Recording with Motion Detection To schedule video recording with motion detection, you must first enable motion detection on the Internet Camera. Click the Motion Detection button under the Advanced tab from the Configuration screen to access settings that affect how the DCS-3220 Internet Camera can serve as a security device by recording only when motion is detected.
  • Page 120 Schedule Video Recording with Motion Detection (continued) Click Scheduler In the Primary Schedule you can choose either Once (for one time recording) or Every Day (for scheduled recording). For example, if you would like to record events every day during a certain time frame, click on the beginning time and drag your mouse to the ending time.
  • Page 121 Schedule Video Recording with Motion Detection (continued) In this window, follow the steps below to schedule video recording with motion detection in the Primary Schedule: Check if you want the recording schedule to occur Once or Every day. Set the date, time-line, and begin and end times for recording. Check Event Mode.

  • Page 122: Appendix

    Appendix Frequently Asked Questions Internet Camera Features Q: What is an Internet Camera? A: The Internet Camera is a stand-alone system connecting directly to an Ethernet or Fast Ethernet network. It differs from a conventional PC Camera, the Internet Camera is an all-in-one system with built-in CPU and Web-based solutions providing a low cost solution that can transmit high quality video images for monitoring.
  • Page 123 A: No, the Internet Camera is used only on an Ethernet or Fast Ethernet network. The D-Link DSB-C110, DSB-C310, can be used as a PC Camera (Webcam). Q: Can the Internet Camera be connected on the network if it consists of...
  • Page 124 Frequently Asked Questions (continued) Q: I connected the Internet Camera directly to a computer with a cross- over cable Ethernet cable and received the following Windows error upon running the Installation Wizard: A1: This Windows error will occur if the Internet Camera is connected to a computer that is not properly configured with a valid IP address.

  • Page 125: How To Ping Your Ip Address

    Frequently Asked Questions (continued) Q: Noisy images occur. How can I solve the problem? A1: The video images might be noisy if the DCS-3220 is used in a very low light environment. To solve this issue you need more lighting. Q: The images are of poor quality, how can I improve the image quality? A1: Make sure that your computer’s display properties are set to at least 15-bit color.

  • Page 126: Reset And Restore

    Reset and Restore There is a button hidden in the pinhole beside the Ethernet socket. It is used to reset the system or restore the factory default settings. Sometimes resetting the DCS-3220 will return the system back to a normal state. If the system still has problems after reset, restore the factory settings and install again: RESET:...

  • Page 127: I/O Connector

    I/O Connector I/O Connector Definition for the Internet Camera The DCS-3220 provides a general I/O terminal block with one digital input and one relay switch for device control. Pin 1 and pin 2 can be connected to an external sensor and the state of voltage will be monitored from the initial state ‘LOW’.
  • Page 128 I/O Connector (continued) The above diagram shows a typical wiring configuration for a normally closed PIR motion sensor. Please refer to your specific motion sensor for the power supply connection to the device since this will be critical to the success of your installation.
  • Page 129 I/O Connector (continued) Configuring Your Camera for External Trigger Based Recording (continued) Click the Network button under the Advanced tab to set the SMTP or FTP server settings for the DCS-3220. Click Network In this window, enter the settings for the SMTP or FTP server to which recorded snapshots will be sent.
  • Page 130 I/O Connector (continued) Configuring Your Camera for External Trigger Based Recording (continued) Next, click the Applications button under the Tools tab to set the application settings for the DCS-3220. Click Applications In this window, follow the steps below to set the application settings for snapshots to be sent to your email account or FTP server when triggered by a motion sensor or other external device: Select the weekdays you would like to record and enter the...

  • Page 131: Adjusting The Cameras Focus

    Adjusting the Cameras Focus The DCS-3220 Internet Camera features an interchangeable C/CS-type lens that can be used for different applications as necessary. It supports rotational focus control so the lens can be adjusted to focus under normal and stable conditions to maximize the image quality of the Internet Camera. Fixed Lens Assembly Do NOT adjust Camera Lens...

  • Page 132: Replacing The Lens

    Replacing the Lens Since the DCS-3220 is designed with a CS- mount, the lens equipped with the Internet Camera can be replaced with any standard C or CS lens commonly used within the surveillance industry. Follow the instructions below to replace the supplied lens with any C or CS type lens.

  • Page 133: Technical Specifications

    Technical Specifications Remote management Configuration and system log can be accessed via Web browser using Internet Explorer 6.X and above Networking Protocol TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, DDNS, and UPnP Ethernet 10BaseT or 100BaseT Fast Ethernet Video Algorithm supported MPEG4 Simple Profile Audio...
  • Page 134 Technical Specifications (continued) LED indicator Bi-color status indicator Camera specification 1/4 inch color CCD sensor 1.0Lux/F2.0 AGC/AWB Electronic shutter: 1/60 ~ 1/15000 second Standard CS mount type lens, 6mm, F1.8 4x Digital Zoom Power 12VDC 1.2A, external power supply Weight About 240g (8.5oz.) Dimension 159mm(L) x 83mm(W) x 54mm(H) (6.25 in.

  • Page 135: Contacting Technical Support

    Technical Support Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product.

  • Page 136: Time Zone Table

    Time Zone Table GMT stands for Greenwich Mean Time, which is the global time that all time zones are measured from.
  • Page 137 Time Zone Table (continued)

  • Page 138: Warranty

    Warranty Period from the date of original retail purchase. If a material defect is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to repair or replace the defective Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
  • Page 139 RMA number must be prominently marked on the outside of the package. Do not include any manuals or accessories in the shipping package. D-Link will only replace the defective portion of the Product and will not ship back any accessories.
  • Page 140 Warranty (continued) USA only Trademarks: D-Link is a registered trademark of D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective manufacturers or owners. Copyright Statement: No part of this publication or documentation accompanying this Product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States...

  • Page 141: Registration

    Registration Register online your D-Link product at http://support.dlink.com/register/ 10/04/04...

Table of Contents
