Frontload Washers
Metered Commercial
NOTA: El manual en
español aparece después
del manual en inglés.
H264I
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 800536R3
www.comlaundry.com
October 2002

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H2641 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems H2641

Summary of Contents for Alliance Laundry Systems H2641

  • Page 1 Frontload Washers Metered Commercial NOTA: El manual en español aparece después del manual en inglés. H264I Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 800536R3 www.comlaundry.com October 2002...
  • Page 3 Always contact the distributor, service agent, or the manufacturer about any problems or conditions you do not understand. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536 WARNING W030...
  • Page 4 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536...

  • Page 5: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536 Replacement Parts ...
  • Page 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operation Instructions for NetMaster Washers ... 26 Step 1: Load Laundry... 26 Step 2: Close Loading Door... 26 Step 3: Add Laundry Supplies ... 26 Step 4: Set Fabric Selector ... 27 Step 5: Set Wash Temperature...

  • Page 7: Replacement Parts

    Replacement Parts If replacement parts are required, contact the source from which you purchased your washer, or contact: 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A.
  • Page 8 Notes 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 9: Important Safety Instructions

    9. Do not install or store the washer where it will be exposed to water and/or weather. 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT (Save These Instructions) 10. Do not tamper with the controls.
  • Page 10 25. DO NOT operate the washer with missing or broken parts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 26. DO NOT bypass any safety devices. 27. Failure to install, maintain, and/or operate this washer according to the manufacturer’s...

  • Page 11: Dimensions And Specifications

    Installation Dimensions and Specifications 17.5" (44.8 cm) 14.3" (36.3 cm) 28" (71.1 cm) 26.9" (68.3 cm) 2" (5.1 cm) H270I H270I 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 12: Meter Case

    1/4 turn or 5/16 inch (6.4 or 7.9 mm) holes, and install a bicycle lock through these holes. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Before You Start Tools...

  • Page 13: Installing The Washer

    800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: Thread hose couplings onto valve connections finger-tight, then approximately 1/4 turn with pliers. DO NOT cross thread or overtighten couplings.

  • Page 14: Step 3: Connect Drain Hose To Drain Receptacle

    1-3/8 inch (3.5 cm) outside diameter drain hose. Retainer Clamp Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Standpipe Installation Place the drain hose into the standpipe. Remove the beaded tie-down strap from accessories bag and place around standpipe and drain hose and tighten strap to hold hose to standpipe.

  • Page 15: Step 4: Position And Level The Washer

    800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: Use of the dispenser drawer or washer door as a handle in the transportation of the washer may cause damage to the dispenser or door.

  • Page 16: Step 5: Remove The Shock Sleeves And Shipping Brace

    Moving Washer to a New Location for instructions. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 6: Wipe Out Inside of Wash Drum Before using washer for the first time, use an all-...

  • Page 17: Moving Washer To A New Location

    Attach with bolts and lockwashers. Refer to Figure 11. Reinstall front access panel. 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Shock Sleeves Motor Mount Bolts and Lockwashers Hooked End of Shipping Brace...

  • Page 18: Electrical Requirements

    120 Volt, 60 Hertz, AC (alternating current) circuit protected by a 15 ampere fuse, equivalent fusetron or circuit breaker. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT The three-prong grounding plug on the power cord should be plugged directly into a polarized three-slot effectively grounded receptacle rated 110/120 Volts AC (alternating current) 15 Amps.
  • Page 19 120 ± 12 V.A.C. 120 ± 12 V.A.C. STANDARD 120 VOLT, 60 HERTZ, 3-WIRE EFFECTIVELY GROUNDED CIRCUIT Ground Neutral Side Round Grounding Prong Neutral Figure 13 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT V.A.C. D799I Installation...

  • Page 20: Water Supply Requirements

    Owner should turn off water supply whenever there will be an extended period of non-use. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: Longer inlet hoses are available (as optional equipment at extra cost) if the hoses supplied with the washer are not long enough for the installation.

  • Page 21: Risers

    (refer to Figure 15). Risers (Air Cushions) Water Supply Faucets Figure 15 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT W005I W005I Installation...
  • Page 22 Notes 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 23: Operation

    Close the loading door tightly. The washer will not operate with the loading door open. Figure 17 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operation Step 3: Add Laundry Supplies Open dispenser drawer. Measure and add low sudsing detergent (1), bleach (2) and fabric softener (3) to the dispenser drawer (refer to Figure 18).

  • Page 24: Step 4: Set Fabric Selector

    IN USE light comes on (indicating start of cycle), press the PUSH-TO-START button. Figure 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Indicator Lights IN USE This light will remain on while washer is in use.

  • Page 25: Operation Instructions For Mdc Washers

    Figure 22 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 2: Add Laundry Supplies Open dispenser drawer. Measure and add low sudsing detergent (1), bleach (2) and fabric softener (3) to the dispenser drawer (refer to Figure 23).

  • Page 26: Step 3: Load Laundry

    Close loading door tightly. The washer will not operate with the loading door open. H283I Figure 25 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 5: Insert Coin(s) or Card To Insert Money Check pricing as seen on digital display.

  • Page 27: Step 6: Start Washer

    SPIN SPIN is lit for all spin cycles. 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT DOOR LOCKED DOOR LOCKED is lit whenever the door is locked. The door cannot be opened when this light is on.

  • Page 28: Operation Instructions For Netmaster Washers

    H283I Figure 30 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 3: Add Laundry Supplies Open dispenser drawer. Measure and add low sudsing detergent (1), bleach (2) and fabric softener (3) to the dispenser drawer (refer to Figure 31).

  • Page 29: Step 4: Set Fabric Selector

    NOTE: Always follow manufacturer’s care labels. Figure 33 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 6: Insert Coin(s) or Card To Insert Money Check pricing as seen on digital display. H199I...

  • Page 30: Step 7: Start Washer

    SPIN SPIN is lit for all spin cycles. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT DOOR LOCKED DOOR LOCKED is lit whenever the door is locked. The door cannot be opened when this light is on.

  • Page 31: Maintenance

    Some products will cause permanent damage if spilled on the cabinet. 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Maintenance Do not use scouring pads or abrasive cleansers. Do not lay sharp or rough objects on or against the washer.

  • Page 32: Before You Call For Service

    • • • • • • • © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Won’t Won’t Possible Reason – Do This to Correct Spin Drain Be sure power cord is plugged all the way into the electrical outlet.

  • Page 33: If Service Is Required

    Phone: (920) 748-3950 Nameplate Figure 38 800536 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT When calling or writing about your unit, PLEASE GIVE THE MODEL AND SERIAL NUMBERS. The model and serial numbers are located on the nameplate.

  • Page 34: Copyright, Alliance Laundry Systems Llc – Do Not Copy Or Transmit

    Service Agency Address NOTE: Record the above information and keep your sales slip. Model and serial numbers are located on the nameplate. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Serial Number Phone Number Phone Number...
  • Page 35 Lavadoras con carga frontal comerciales con contador de monedas H264I Guarde estas instrucciones para referencia en el futuro. (Si la lavadora cambia de dueño, asegúrese de que este manual vaya con la misma). Pieza No. 800536R3 www.comlaundry.com Octubre 2002...
  • Page 37 Comuníquese siempre con el concesionario, distribuidor, agente de servicios o fabricante cuando tenga problemas o se encuentre en una situación que no comprenda. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536 (SP) ADVERTENCIA...
  • Page 38 Notas © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536 (SP)
  • Page 39 Reservados todos los derechos. Ninguna sección del presente manual puede ser reproducida o transmitida en forma alguna o a través de ningún medio sin el expreso consentimiento por escrito del editor. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 800536 (SP) Piezas de repuesto ...
  • Page 40 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Instrucciones de funcionamiento de las lavadoras NetMaster... 60 Paso 1: Cargue la lavadora... 60 Paso 2: Cierre la puerta de carga... 60 Paso 3: Agregue los suministros para lavar ... 60 Paso 4: Ajuste el selector de tela...

  • Page 41: Piezas De Repuesto

    Si necesita piezas de repuesto, llame al distribuidor donde haya comprado su lavadora o póngase en contacto con: 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A.
  • Page 42 Notas 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 43: Instrucciones De Seguridad Importantes

    800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT (Guarde estas instrucciones) 8. No introduzca la mano en la lavadora si la tina o el agitador está en movimiento.
  • Page 44 (guárdelos preferiblemente en un gabinete con llave). © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 23. Siga siempre las instrucciones para el cuidado de la ropa suministradas por el fabricante de las prendas de vestir.

  • Page 45: Installación

    Installación Dimensiones y especificaciones 44,8 cm (17,5 plg) 36,3 cm (14,3 plg) 71,1 cm (28 plg) 68,3 cm (26,9 plg) 5,1 cm H270I (2 plg) H270I 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 46: Contador De Monedas

    6,4 ó 7,9 mm (1/4 de vuelta ó 5/16 plg) e instale un seguro para bicicleta a través de estos orificios. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Antes de comenzar Herramientas Éstas son las principales herramientas que necesitará...

  • Page 47: Instalación De La Lavadora

    800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTA: Cuando instale la lavadora en un local recién construido o remodelado debe limpiar las tuberías dejando que el agua fluya, ya que pudo...

  • Page 48: Paso 3: Conexión De La Manguera De Desagüe En El Receptáculo De Desagüe

    3,5 cm (1-3/8 plg) como mínimo. Abrazadera de fijación Figura 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Instalación del tubo vertical de desagüe Coloque la manguera de desagüe dentro del tubo vertical de desagüe.

  • Page 49: Paso 4: Coloque La Lavadora En Su Lugar Y Nivélela

    800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTA: NO deslice la lavadora sobre el piso con las patas niveladoras extendidas ya que podrían resultar dañadas.

  • Page 50: Paso 5: Saque Los Manguitos De Amortiguador Y El Tirante Sujetador

    Las instrucciones se encuentran en la sección Desplazamiento de la lavadora a un nuevo sitio. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Paso 6: Limpie el interior del tambor de la lavadora Antes de usar la lavadora por primera vez, limpie el tambor de lavado con un paño húmedo utilizando un...

  • Page 51: Desplazamiento De La Lavadora A Un Nuevo Sitio

    Fije utilizando los pernos y arandelas de seguridad. Consulte la Figura 11. Vuelva a instalar el panel de acceso frontal. 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Manguitos de amortiguador Montaje del motor Pernos y arandelas de seguridad...

  • Page 52: Requisitos Eléctricos

    15 Amperios, un Fusetrón (fusible de acción lenta) o un interruptor de circuito. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT La clavija de conexión a tierra de tres patillas en el cable de corriente debe ser conectada directamente en un tomacorriente con conexión a tierra de tres ranuras...
  • Page 53 CIRCUITO CONECTADO A TIERRA DE 3 CONDUCTORES, ESTÁNDAR, 120 VOLTIOS, 60 HERTZIOS Conexión a tierra Lado neutral Patilla redonda de conexión a tierra Neutral Figura 13 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT V.C.A. D799I Installación...

  • Page 54: Requisitos De Suministro De Agua

    © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTA: Pueden adquirirse mangueras de suministro de agua más largas (como equipo opcional con un costo...

  • Page 55: Tubos Ascendentes

    (consulte la Figura 15). Tubos ascendentes (cojines de aire) Grifos de suministro de agua Figura 15 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT W005I W005I Installación...
  • Page 56 Notas 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 57: Operación

    Cierre firmemente la puerta de carga. La lavadora no funcionará con la puerta de carga abierta. Figura 17 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operación Paso 3: Agregue los suministros para lavar Abra la gaveta del surtidor.

  • Page 58: Paso 4: Ajuste El Selector De Tela

    PUSH-TO-START (oprima para arrancar). Figura 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Luces indicadoras IN USE (EN USO) Permanece encendida mientras se esté usando la lavadora.

  • Page 59: Instrucciones De Funcionamiento De Las Lavadoras Mdc

    NOTA: Pueden hacerse cambios en el selector de tela hasta completarse el primer llenado. Figura 22 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Paso 2: Agregue los suministros para lavar Abra la gaveta del surtidor. Mida y agregue detergente de baja espuma (1) blanqueador (2) y suavizador de tela (3) a la gaveta del surtidor (consulte la Figura 23).

  • Page 60: Paso 3: Cargue La Lavadora

    Cierre bien la puerta de carga. La lavadora no funcionará con la puerta de carga abierta. Figura 25 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Paso 5: Inserte la(s) moneda(s) o la tarjeta Para insertar monedas Compruebe el precio que aparece en la pantalla digital.

  • Page 61: Paso 6: Arranque La Lavadora

    Esta luz se enciende en todos los ciclos de centrifugado (SPIN). 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT DOOR LOCKED (PUERTA CERRADA CON SEGURO) Esta luz se enciende cuando la puerta está cerrada con seguro.

  • Page 62: Instrucciones De Funcionamiento De Las Lavadoras Netmaster

    Cierre bien la puerta de carga. La lavadora no funcionará con la puerta de carga abierta. Figura 30 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Paso 3: Agregue los suministros para lavar Abra la gaveta del surtidor. Mida y agregue detergente de baja espuma (1) blanqueador (2) y suavizador de tela (3) a la gaveta del surtidor (consulte la Figura 31).

  • Page 63: Paso 4: Ajuste El Selector De Tela

    Figura 33 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Paso 6: Inserte la(s) moneda(s) o la tarjeta Para insertar monedas Compruebe el precio que aparece en la pantalla digital.

  • Page 64: Paso 7: Arranque La Lavadora

    Esta luz se enciende cuando la puerta está cerrada con seguro. La puerta no puede abrirse cuando esta luz está encendida. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT INSERT COIN/CARD (INSERTE MONEDAS/TARJETA) Esta luz se enciende para indicar al usuario que debe introducir monedas o la tarjeta para completar el precio de la transacción.

  • Page 65: Mantenimiento

    Algunos productos causan un daño permanente si caen sobre el gabinete de la lavadora. 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Mantenimiento No utilice esponjas para restregar ni limpiadores abrasivos.

  • Page 66: Antes De Llamar Para Solicitar Servicio De Reparación

    • • • • • • • • • • © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT No funciona funciona durante el durante el Siga este procedimiento para solucionar ciclo de ciclo de centrifugado desagüe Asegúrese de que el cable de suministro de...

  • Page 67: Si La Unidad Necesita Servicio

    Placa Figura 38 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Cuando llame o escriba por un asunto relacionado con su unidad, POR FAVOR SUMINSTRE EL MODELO Y EL NÚMERO SE SERIE DE LA UNIDAD. El número de serie y el modelo de su unidad se...

  • Page 68: Información De Referencia

    Dirección de la agencia de servicio Teléfono NOTA: Registre la información anterior y guarde su recibo de compra. Los números de modelo y de serie aparecen en la placa . 800536 (SP) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 70: Installer Checklist

    Fast Track for Installing the Washer (Refer to the manual for more detailed information) Lista de comprobación del instalador Guía rápida para instalar la lavadora (Consulte el manual para una información más detallada) – • Position Washer Near Installation Area. •...
