Cable Connections

System board connectors are color-coded to make it easier to find the proper connection.
System Board Connections
System Board
Connector
PWR (P1)
PWRCMD (P2)
PWRCPU (P3)
CHFAN (P11)
CPUFAN (P8)
SATAPWR0 (P160)
SATAPWR1 (P161)
PB/LED (P5)
FRONT USB (P24)
FRONT USB2 (P25)
FRONT AUD (P23)
SPRK (P6)
COMB (P52)
HLCK (P124)
HSENSE (P125)
MEDIA (P150)
MEDIA2 (P151)
PAR (P126)
Connector Color Description
White Power supply, 6-pin
White Power supply, 6-pin
White Power supply, 4-pin
Brown Rear chassis fan
White Heat sink fan
Black HDD power
Black ODD power
Black Front power button/LED
Yellow Front I/O USB
Green Front I/O USB
Blue Front audio
White Internal speaker
Black Serial port
Black Hood lock solenoid
White Hood sensor
Black Media card reader
Black Media card reader
Black Flying parallel port
Cable Management 47
