3.5.6

Onboard Devices Configuraton

Azalia HD Audio [Enabled]
[Disabled] Disables the controller.
[Enabled] Enables the High Definition Audio Controller.
The following two items appear only when you set the Azalia HD Audio item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high definition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Intel LAN Controller [Enabled]
[Disabled] Disables the controller.
[Enabled] Enables the Intel LAN controller.
Intel LAN PXE OPROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the PXE OptionRom of the Intel LAN controller.
Configuration options: [Enabled] [Disabled]
ROG RAMPAGE IV FORMULA 3-27
