PORTABLE
FORCED AIR HEATERS
"USER'S MANUAL"
LISTED
MODEL : RMC-KFA45T, RMC-KFA65T, RMC-KFA120T
RMC-KFA170T, RMC-KFA210T
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
CFM RMC INTERNATIONAL
3501 W. HOWARD ST.,
SKOKIE, IL 60076
1-800-527-4948
Advertisement
Table of Contents
Related Manuals for Dyna-Glo Dyna-Glo RMC-KFA45T, RMC-KFA65T, RMC-KFA120T, RMC-KFA170T, RMC-KFA210T
Summary of Contents for Dyna-Glo Dyna-Glo RMC-KFA45T, RMC-KFA65T, RMC-KFA120T, RMC-KFA170T, RMC-KFA210T
- Page 1 PORTABLE FORCED AIR HEATERS “USER’S MANUAL” LISTED MODEL : RMC-KFA45T, RMC-KFA65T, RMC-KFA120T RMC-KFA170T, RMC-KFA210T Before the first use of this heater, please read this USER’S MANUAL very carefully. This USER’S MANUAL has been designed to instruct you as to the proper manner in which to assemble, maintain, store, and most importantly, how to operate the heater in a safe and efficient manner.
- Page 2 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER - IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! • Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/hr.
-
Page 3: Table Of Contents
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! ITEM PRECAUTIONS - SAFETY GUIDE 1. INTRODUCTION 2. FEATURES 3. UNPACKING AND ASSEMBLY 4. KEROSENE (1-K OR NO. 1 FUEL OIL) 5. OVERVIEW OF HEATER DESIGN 6. FUELING YOUR HEATER 7. OPERATION 8. LONG TERM STORAGE OF YOUR HEATER 9. - Page 4 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Handle Hot Air Outlet Upper Shell Upper Shell Fan Guard Lower Shell Fuel Gauge Fuel Cap Power Cord Side Cover Lamp Fuel Tank Power/Reset Switch Thermostat Knob Figure 2. RMC-KFA120T / RMC-KFA170T MODELS Handle Hot Air Outlet Upper Shell...
-
Page 5: Unpacking And Assembly
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 3. UNPACKING AND ASSEMBLY 1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5) NOTE: Save the shipping carton and packing materials for future storage. RMC-KFA45T/65T RMC-KFA120T RMC-KFA170T RMC-KFA210T Wheel Support Frame Wheels Handle... - Page 6 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY A. For RMC-KFA45T/RMC-KFA65T Models only (Figure 6) Tools Required • Medium Phillips Screwdriver 1. Align the holes on the upper shell with the 2 mounting holes on the handle as shown in Figure 6. 2.
- Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Hot Air Outlet Fuel Tank Flange Wheel Support Frame Flat Washer Figure 7. Wheel and Handle Assembly, RMC-KFA120T/RMC-KFA170T/RMC-KFA210T MODELS ONLY NOTE: Heater should be inspected before each use, and at least annually by a qualitied service person. 4.
-
Page 8: Overview Of Heater Design
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 5. OVERVIEW OF HEATERS DESIGN Fuel System: This heater is equipped with an electric air pump that forces air through the air line connected to the fuel intake and then through a nozzle in the burner head. When the air passes in front of the fuel intake it causes fuel to rise from the tank and into the burner nozzle. -
Page 9: Fueling Your Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 6. FUELING YOUR HEATER NEVER FILL THE HEATER FUEL TANK IN THE LIVING SPACE: FILL THE TANK OUTDOORS. DO NOT OVERFILL YOUR HEATER AND BE SURE HEATER IS LEVELED. IMPORTANT NOTICE REGARDING FIRST IGNITION OF HEATER: The first time you light the heater, it should be done outdoors. -
Page 10: Long Term Storage Of Your Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! TO STOP HEATER 1. Turn switch to “OFF” and unplug power cord. TO RESTART HEATER 1.Wait 10 seconds after stopping heater. 2. Repeat steps under to start heater. 8. LONG TERM STORAGE OF YOUR HEATER 1. - Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! C.) AIR OUTPUT FILTER, LINT FILTER REPLACE EVERY 500 HOURS OF OPERATION OR ONCE A YEAR. - Remove upper shell and fan guard (See page 9). - Remove end filter cover screws using medium phillips screwdriver.
- Page 12 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (For RMC-KFA 210T Model Only) - Remove upper shell (See page 9). - Remove fan (See page 10). - Remove fuel and air line hoses from adaptor-nozzle. - Remove ignitor wire from spark plug. - Remove photocell from photocell bracket.
- Page 13 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (For RMC-KFA 210T Models Only) - Remove upper shell (See page 9). - Remove fan (See page 10). - Remove ignitor wire from spark plug. - Remove spark plug from bracket-spark using medium phillips screwdriver.
- Page 14 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! .) FUEL FILTER CLEAN OR REPLACE TWICE A HEATING SEASON OR AS NEEDED. (For RMC-KFA 45T/65T/120T/170T Models Only) - Remove side cover screws using medium phillips screwdriver. - Remove side cover. - Pull fuel line off fuel filter neck. - Turn fuel filter 90。...
- Page 15 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! I) FUEL VALVE ( For RMC-KFA210T Model only) - Remove side cover screws using medium phillips screwdriver (See page 13). - Remove upper shell (See page 9). - Remove fan (See page 10). - Pull fuel line (lower and upper) off the fuel valve fittings (See figure 21).
- Page 16 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! .) PUMP PRESSURE ADJUSTMENT - Remove pressure gauge plug from end filter cover. - Install accessory pressure gauge. - Start heater (See Operation, page 8) Allow motor to reach full speed - Adjust pressure (Using a flat blade screwdriver) Turn relief valve to right to increase pressure.
-
Page 17: Trouble Shooting Guide
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . TROUBLE SHOOTING GUIDE TROUBLE Heater ignites but MAIN PCB assembly shuts heater off after a short period of time. (Lamp is flickering) Heater will not ignite but motor runs for a short period of time. -
Page 18: Wiring Diagram
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . WIRING DIAGRAM A) WIRING DIAGRAM (RMC-KFA45T / RMC-KFA65T) B) WIRING DIAGRAM (RMC-KFA120T) - Page 19 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . WIRING DIAGRAM C) WIRING DIAGRAM (RMC-KFA170T) D) WIRING DIAGRAM (RMC-KFA210T)
-
Page 20: Specifications
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . SPECIFICATIONS MODEL BTU/Hr. Fuel Consumption - Gal./Hr. Fuel Tank Capacity - Gal. Pump Pressure PSI Volt/Hz Amps. Phase Size(W×D×H) Weight Lbs. RMC-KFA45T / RMC-KFA65T RMC-KFA120T / RMC-KFA170T / RMC-KFA210T RMC-KFA45T RMC-KFA65T RMC-KFA120T RMC-KFA170T RMC-KFA210T 45,000 65,000 0.35... -
Page 21: Exploded Parts Drawing
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . EXPLODED PARTS DRAWING (RMC-KFA45T/65T/120T/170T Models Only) NOTE: SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. 17-1 17-10 17-2 17-9 17-3 17-4 17-6 Burner Head Assembly 17-7 22-1 17-8 17-5 22-2 22-3 23-1 22-4 22-7... - Page 22 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . EXPLODED PARTS DRAWING (RMC-KFA 210T Model Only) 18-5 18-6 18-4 18-7 18-13 18-8 18-9 18-10 18-12 18-1 18-3 Burner Head Assembly 18-11 18-2 23-1 23-2 23-4 23-3 Fuel Valve Assembly 14-1 14-3 23-5 23-6 23-8...
-
Page 23: Parts List
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST (RMC-KFA 45T/65T/120T/170T Models Only) KEY NO. DESCRIPTION Fuel Tank Assembly Fuel Gauge Fuel Filter Assembly Fuel Cap Power Cord Cord Bushing Power Switch Display P.C.B Assembly Button Support Thermostat Control Knob Lower - Shell Bushing - Grommet Bushing - Cover... - Page 24 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! KEY NO. DESCRIPTION 22-6 Rotor Kit 22-7 Blade 22-8 End Pump Cover 22-9 Nipple 22-10 Flange Bolt 22-11 Filter Kit 22-12 Lint Filter 22-13 OutPut Filter 22-14 End Filter Cover 22-15 Flange Bolt 22-16 Plug / Pump Adj.
- Page 25 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST (RMC-KFA 210T Model Only) KEY No. DESCRIPTION Fuel Tank Assembly Fuel Filter Assembly Display P.C.B Assembly Button Support Thermostat Control Knob Bushing - Grommet Bushing - Cover Fuel Valve Assembly 14-1 Solenoid Valve 14-2...
- Page 26 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! KEY No. DESCRIPTION 23-1 23-2 Motor Supportor 23-3 23-4 23-5 23-6 23-7 23-8 23-9 End Pump Cover 23-10 23-11 23-12 23-13 23-14 23-15 End Filter Cover 23-16 23-17 Plug / Pump Adj. Kit 23-18 23-19 23-20...
- Page 27 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST (WHEELS AND HANDLE) 1) RMC-KFA45T/65T MODELS KEY NO. DESCRIPTION Handle Screw 2) RMC-KFA120T/170T/210T MODEL KEY NO. DESCRIPTION Handle Screw(L) Screw(S) Wheel Support Frame Axle Wheel Flat Washer Split Pin PART NO. RMC-KFA45T 3231-0073-00 4319-0015-00...
- Page 28 4221 - 0059- 00 07/03 Rev. 00 EDITION 2003...
