INDOOR/OUTDOOR PRODUCTS
KEROSENE PORTABLE
FORCED AIR HEATERS
"USER'S MANUAL AND
OPERATING INSTRUCTIONS"
COMPLIES WITH UL733 AND
ANSI A10.10-1990
CAN/CSA/B140.0-03 AND CSA
B140.8-1967
MODEL : RMC-KFA45DGD, RMC-KFA75TDGD, RMC-KFA125TDGD
RMC-KFA170TDGD, RMC-KFA210TDGD, RMC-KFA210TDGD-01
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
CONSUMER : Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. - 4:30 pm CST, Monday - Friday.
or email us at customerservice@ghpgroupinc.com
https://manual-hub.com/
Advertisement
Related Manuals for Dyna-Glo Delux RMC-KFA45DGD
Summary of Contents for Dyna-Glo Delux RMC-KFA45DGD
- Page 1 INDOOR/OUTDOOR PRODUCTS KEROSENE PORTABLE FORCED AIR HEATERS “USER’S MANUAL AND OPERATING INSTRUCTIONS” COMPLIES WITH UL733 AND ANSI A10.10-1990 CAN/CSA/B140.0-03 AND CSA B140.8-1967 MODEL : RMC-KFA45DGD, RMC-KFA75TDGD, RMC-KFA125TDGD RMC-KFA170TDGD, RMC-KFA210TDGD, RMC-KFA210TDGD-01 Before the first use of this heater, please read this USER’S MANUAL very carefully.
- Page 2 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER: IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! • Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/hr.
- Page 3 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! CONTENTS OF USER’S MANUAL ITEM PAGE # PRECAUTIONS - SAFETY GUIDE 1. INTRODUCTION 2. FEATURES 3. UNPACKING AND ASSEMBLY 4. KEROSENE (1-K OR NO. 1 FUEL OIL) 5. OVERVIEW OF HEATER DESIGN 6. FUELING YOUR HEATER 7.
- Page 4 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Upper Shell Hot Air Outlet Shell Lower Fuel Gauge Fan Guard Fuel Cap Side Cover Lamp Thermostot Knob Power Cord Power/Reset Switch Pneumatic Wheel Drain Plug Figure 2. RMC-KFA125TDGD MODEL Front Handle Upper Shell Hot Air Outlet Shell Lower...
- Page 5 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 3. UNPACKING AND ASSEMBLY 1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5) NOTE : Save the shipping carton and packing materials for future storage. RMC-KFA45/75TDGD RMC-KFA125TDGD RMC-KFA170/210TDGD RMC-KFA210TDGD-01 Wheel Support Frame Axle Front Handle...
- Page 6 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY A. For RMC-KFA45DGD/75TDGD Models only Tools Required Handle Screw • Medium Phillips Screwdriver. Frong Guard Assembling Handle Wedged Portion 1. Lift front guard for arrow direction and make sure that guard’s wedged portion fits into the slit Slit Hole hole on the upper housing.
- Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! C. For RMC-KFA170/210TDGD/210TDGD-01 Models only Tools Required • Medium Phillips Screwdriver. • M5 open, or adjustable wrench • Long nose pliers. 1. Slide axle through wheel support frame. Install wheel bushings and wheels on axle. NOTE : When installing wheels, tube valve should face out from support frame (Figure 8).
- Page 8 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! D. For RMC-KFA210DGP-01 Model Only. Knob direction when install valve to End Filter Cover. Assembling BTU Control Valve 1. Align slit hole on body of Valve with Tab on the End Filter Cover as shown in Figure 9. correct 2.
- Page 9 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 5. OVERVIEW OF HEATERS DESIGN Fuel System : This heater is equipped with an electric air pump that forces air through the air line connected to the fuel intake and then through a nozzle in the burner head. When the air passes in front of the fuel intake it causes fuel to rise from the tank and into the burner nozzle.
- Page 10 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 6. FUELING YOUR HEATER NEVER FILL THE HEATER FUEL TANK IN THE LIVING SPACE : FILL THE TANK OUTDOORS. DO NOT OVERFILL YOUR HEATER AND BE SURE HEATER IS LEVELED. IMPORTANT NOTICE REGARDING FIRST IGNITION OF HEATER : The first time you light the heater, it should be done outdoors.
- Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! NOTICE : The major electrical components of this heater are protected by a safety fuse mounted to the PCB board. If your heater fails to start, check this fuse first and replace as necessary. You should also check your power source to insure that proper voltage and frequency are being supplied to the heater.
- Page 12 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 9. MAINTENANCE WARNING!! : NEVER SERVICE HEATER WHILE IT IS PLUGGED IN OR WHILE HOT! USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party or other alternate components will void warranty and may cause unsafe operating conditions. A.) FUEL TANK Screw FLUSH EVERY 200 HOURS OF OPERATION OR AS...
- Page 13 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! E.) NOZZLE REMOVE DIRT IN NOZZLE AS NEEDED (SEE PAGE 16). Combustion Chamber (For RMC-KFA45DGD/75/125/170TDGD Models Only) Screw - Remove upper shell (See page 10). Ignitor Wire - Remove fan blade (See page 10). - Remove fuel and air line hoses from burner head.
- Page 14 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Spark Plug F.) SPARK PLUG CLEAN AND REGAP EVERY 600 HOURS OPERATION OR REPLACE AS NEEDED. (For RMC-KFA45DGD/75/125/170TDGD Models Only) - Remove upper shell (See page 10). - Remove fan (See page 10). Ignitor wire - Remove ignitor wire from spark plug.
- Page 15 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! H.) FUEL FILTER Fuel Filter CLEAN OR REPLACE TWICE A HEATING Fuel line SEASON OR AS NEED. - Remove side cover screws using medium phillips Switch Wires screwdriver. - Disconnect switch wires from power switch and remove side cover.
- Page 16 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 10. REPLACING FUSE NOTICE : This heater is fuse protected. If your heater fails to ignite, DO NOT RETURN YOUR HEATER TO THE STORE. Please follow the simple instruction below to inspect and change the fuse. PROCEDURE FOR REPLACING FUSE WARNING : SHOCK HAZARD To prevent personal injury, unplug the power cord before replacing fuse.
- Page 17 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION Heater ignites but MAIN PCB 1. Wrong pump pressure 1. See Pump Pressure Adjustment, assembly shuts heater off after Page 14. a short period of time. 2.
- Page 18 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 12. WIRING DIAGRAM A) WIRING DIAGRAM (RMC-KFA45DGD Model) B) WIRING DIAGRAM (RMC-KFA75TDGD Model) 1/G WIRE MODEL CAPACITOR COLOR BLACK 75TDGD 12uF/230VAC BLACK 125TDGD 30uF/250VAC WHITE BLACK 170TDGD 30uF/250VAC BLUE BLACK 210TDGD 30uF/250VAC BLACK BLACK 210TDGD-1 30uF/250VAC...
- Page 19 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 13. SPECIFICATIONS RMC-KFA45DGD/75TDGD Models 125TDGD 170/210TDGD 43.5"(1105 ) 36.0"(914 ) 19.0"(483 ) 23.9"(607 ) 26.6"(675 ) 23.0"(584 ) RMC-KFA125/170/210TDGD/210TDGD-01 Models MODEL RMC-KFA45DGD RMC-KFA75TDGD RMC-KFA125TDGD RMC-KFA170TDGD RMC-KFA210TDGD RMC-KFA210TDGD-01 BTU/Hr HIGH 45,000 75,000 125,000 170,000 210,000 210,000 170,000...
- Page 20 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (RMC-KFA45DGD/75/125/170TDGD Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. https://manual-hub.com/...
- Page 21 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (RMC-KFA 210TDGD/210TDGD-01 Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. https://manual-hub.com/...
- Page 22 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA45DGD/75/125/170TDGD Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA45DGD RMC-KFA75TDGDRMC-KFA125TDGD Fuel Tank Assmebly 2151-0005-00 2151-0007-00 2151-0008-00 2151-0009-00 Drain-Plug 3331-0051-00 3331-0051-00 Fuel Gauge 2156-0005-00 2156-0005-00 2156-0001-00 2156-0001-00 Fuel Filter Assmbly 2155-0005-00 2155-0005-00 2155-0001-00...
- Page 23 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA45DGD/75/125/170TDGD Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA45DGD RMC-KFA75TDGDRMC-KFA125TDGD 27-5 Holder Capacitor 3231-0152-00 3231-0152-00 27-6 Pump Body 3541-0022-00 3541-0022-00 3541-0022-00 3541-0022-00 27-7 Bolt-BH Special 4321-0198-00 4321-0198-00 4321-0198-00 4321-0198-00 27-8 Rotor *SP-KFA1000...
- Page 24 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA210TDGD/210TDGD-01 Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA210TDGD RMC-KFA210TDGD-01 Fuel Tank Assmebly 2151-0009-00 2151-0009-00 Drain-Plug 3331-0051-00 3331-0051-00 Fuel Gauge 2156-0001-00 2156-0001-00 Fuel Filter Assmbly 2155-0001-00 2155-0001-00 Fuel Cap 2151-0003-00 2151-0003-00 Cord Bushing...
- Page 25 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA210TDGD/210TDGD-01 Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA210TDGD RMC-KFA210TDGD-01 25-5 Holder Capacitor 3231-0152-00 3231-0152-00 25-6 Pump Body 3541-0050-00 3541-0050-00 25-7 Bolt-BH Special 4321-0198-00 4321-0198-00 25-8 Rotor *SP-KFA1022 *SP-KFA1022 25-9 Blade See SP-KFA1022...
- Page 26 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (WHEELS AND HANDLE) 1) RMC-KFA45DGD/75TDGD MODELS PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA45DGD/75TDGD Handle 3231-0073-00 Hardware Kit HW-KFA1000 2) RMC-KFA125TDGD MODEL PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA125TDGD Front Handle 3551-0023-00 Wheel Support Frame 3551-0014-00...
- Page 27 4221 - 0059- 00 EDITION 2009 04/09 Rev. 00 https://manual-hub.com/...
