EDITION 2004
"USER'S MANUAL"
MODEL : RMC-KFA65TDLX, RMC-KFA120TDLX
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
4 2 21- 0 0 5 9- 0 0
06/04 Rev. 00
PORTABLE
FORCED AIR HEATERS
RMC-KFA170TDLX
CFM HOME PRODUCTS
2695 MEADOWVALE BOULEVARD
MISSISSAUGA, ONTARIO L5N 8A3
1-800-668-5323
LISTED
Advertisement
Table of Contents
Related Manuals for Dyna-Glo RMC-KFA120TDLX, RMC-KFA170TDLX
Summary of Contents for Dyna-Glo RMC-KFA120TDLX, RMC-KFA170TDLX
- Page 1 EDITION 2004 FORCED AIR HEATERS “USER’S MANUAL” MODEL : RMC-KFA65TDLX, RMC-KFA120TDLX RMC-KFA170TDLX Before the first use of this heater, please read this USER’S MANUAL very carefully. This USER’S MANUAL has been designed to instruct you as to the proper manner in which to assemble, maintain, store, and most importantly, how to operate the heater in a safe and efficient manner.
-
Page 2: Table Of Contents
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER - IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WA R N I N G S : 1. RISK OF INDOOR AIR POLLUTION! •... -
Page 3: Unpacking And Assembly
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Figure 2. RMC-KFA120TDLX Figure 3. RMC-KFA170TDLX NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 3. UNPACKING AND ASSEMBLY 1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. NOTE : Save the shipping carton and packing materials for future storage. RMC-KFA/65TDLX RMC-KFA120TDLX Wheel... -
Page 4: Kerosene (1-K Or No. 1 Fuel Oil)
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY A. For RMC-KFA65TDLX Model only (See Figure 6,7) Tools Required • Medium Phillips Screwdriver 1. Assembling Handle. 1) Align boss on bottom of handle with the 2 holes on the shell cover as shown in Figure 6 NOTE : Be sure to match the tab in the bottom of the handle with the slot in housing cover. -
Page 5: Overview Of Heater Design
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 5. OVERVIEW OF HEATERS DESIGN Fuel System : This heater is equipped with an electric air pump that forces air through the air line connected to the fuel intake and then through a nozzle in the burner head. When the air passes in front of the fuel intake it causes fuel to rise from the tank and into the burner nozzle. -
Page 6: Long Term Storage Of Your Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 8. LONG TERM STORAGE OF YOUR HEATER FUEL TANK DRAIN 1. Remove Fuel Cap and Cap Fuel Filter(See Figure 10). 2. Drain Fuel Tank through Fuel Cap Opening and wash Fuel Cap Filter with clean fuel. 3.Using a small amount of kerosene,swirl and rinse the inside of the tank. - Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! D.) FAN BLADES CLEAN EVERY SEASON OR AS NEEDED. -Remove upper shell(See 10 page.) -Use 1/8" allen wrench to loosen set screw which holds Fan Blade to motor shaft. - Slip Fan Blade off motor shaft. -Clean Fan Blade using a soft colth moistened with kerosene or solvent.
-
Page 8: Trouble Shooting Guide
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! H.) FUEL FILTER CLEAN OR REPLACE TWICE A HEATING SEASON OR AS NEED. -Remove upper shell(See 10 page). -Remove Fan Blade(See 11 Page). -Pull Fuel Line off from Fuel Filter Neck. -Remove Fuel Filter. -Wash Fuel Filter with clean kerosene and replace in tank. -
Page 9: Wiring Diagram
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. WIRING DIAGRAM A) WIRING DIAGRAM(RMC-KFA65TDLX) B) WIRING DIAGRAM(RMC-KFA120TDLX/RMC-KFA170TDLX) NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 12. SPECIFICATIONS RMC-KFA65TDLX RMC-KFA120TDLX / RMC-KFA170TDLX M O D E L R M C - K FA 6 5 T D L X R M C - K FA 1 2 0 T D L X B T U / H r. - Page 10 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 13. EXPLODED PARTS DRAWING NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. PARTS LIST(RMC-KFA65TDLX Model Only) KEY NO. D E S C R I P T I O N P A R TN O . KEY NO.
- Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. EXPLODED PARTS DRAWING(RMC-KFA120T/170TDLX Models Only) NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 16. PARTS LIST(RMC-KFA120T/170TDLX Models Only) KEY NO. DESCRIPTION RMC-KFA120TDLX Fuel Tank Assembly 2151-0012-00 Fuel Gauge 2156-0022-00 Fuel Gauge Cap 3231-0123-00 Fuel Cap Filter 3221-0063-00 Fuel Cap...
-
Page 12: Parts List(Wheels And Handle)
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! KEY NO. DESCRIPTION RMC-KFA120TDLX 23-8 Rotor Kit SP-KFA1000 See SP-KFA1000 23-9 Blade 3531-0008-00 23-10 End Pump Cover Nipple(Air) 3541-0020-00 23-11 Flange Bolt 4329-0014-00 23-12 Lint Filter See SP-KFA1005 23-13 Output Filter See SP-KFA1005 23-14 23-15 Filter Kit...
