Dyna-Glo Thermoheat RMC-LPC25DGD User's Installation, Operation And Maintenance Manual
Propane construction heater
Hide thumbs
Also See for Thermoheat RMC-LPC25DGD:
Advertisement
Quick Links
Propane Construction Heater
RMC-LPC25DG/DGD/DGP/DGP-01 & LPC25
RMC-LPC80DG/DGD/DGP/DGP-01
RMC-LPC80C/L/L-01
RMC-LPC200L/DG/DGP/DGP-01
ANS Z83.7-2011 CSA 2.14-2011
Adequate ventilation must be provided.
This product and the fuels used to operate this product (liquid propane), and the products of combustion
of such fuels, can expose you to chemicals including benzene, which is known to the State of California to
cause cancer and reproductive harm.
For more information go to www.p65Warnings.ca.gov
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768
C
US
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
WARNING
8:30 a.m. –
or email us at customerservice@ghpgroupinc.com
www.ghpgroupinc.com
www.ghpgroupinc.com.
(PROPANE, 25,000 BTU/hr)
(PROPANE, 80,000 BTU/hr)
(PROPANE, 80,000 BTU/hr)
(PROPANE, 200,000 BTU/hr)
4:30
pm CST, Monday – Friday
IMLPCDG - KCA
Advertisement
Related Manuals for Dyna-Glo Thermoheat RMC-LPC25DGD
Summary of Contents for Dyna-Glo Thermoheat RMC-LPC25DGD
- Page 1 Propane Construction Heater RMC-LPC25DG/DGD/DGP/DGP-01 & LPC25 (PROPANE, 25,000 BTU/hr) RMC-LPC80DG/DGD/DGP/DGP-01 (PROPANE, 80,000 BTU/hr) RMC-LPC80C/L/L-01 (PROPANE, 80,000 BTU/hr) RMC-LPC200L/DG/DGP/DGP-01 (PROPANE, 200,000 BTU/hr) ANS Z83.7-2011 CSA 2.14-2011 Adequate ventilation must be provided. GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 WARNING This product and the fuels used to operate this product (liquid propane), and the products of combustion of such fuels, can expose you to chemicals including benzene, which is known to the State of California to...
- Page 3 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! RMC-LPC25Series / RMC-LPC80 Series........RMC-LPC200 Series....Illustration RMC-LPC25 Series..............Illustration RMC-LPC80 Series..............Illustration RMC-LPC200 Series..............WARNING : Using this heater in a residential garage requires that the heater is positioned so that it is protected against any possible damage by a moving vehicle, etc.
-
Page 4: Clearance To Combustibles
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (lb/h) Minimum Maximum Maximum Minimum 1.16 .196 11.7 x 12.87 LPC25 Series (0.53 kg/h) (4.98 mm) (0.32 kg/h) (29.69 x 32.79 cm) 3.71 .196 2.32 15.9 x 18.3 LPC80 Series (1.68 kg/h) (4.98 mm) (1.05 kg/h) (40.41 x 46.99 cm) 9.28... - Page 5 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (100 lb.) 60 °F (15.56 °C) 40 °F (4.44 °C) 32 °F (0 °C) 20 °F (-6.67 °C) 10 °F (-12.22 °C) 0 °F (-17.78 °C) WARNING: Provide at least a 2½ square feet (.23 square meters) opening of fresh, outside air while running heater.
- Page 6 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Assembly Time: 10 minutes Contents All Models: Unit, Manual, Hose and Regulator Assembly LPC80 and 200 Series Include: Upper Shell, Lower Shell and Hardware Kit With Screws (8) Tools Required for Assembly All Models: Adjustable Wrench LPC80 and LPC200 Series: Phillips head screwdriver Slide upper shell assembly up and off lower shell.
- Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. Check all connections for leaks. Apply mixture of liqud soap and water to gas joints. Bubbles forming show a leak that must be corrected before using the heater. Turn propane supply valve on by turning tank valve counterclockwise If flame burner goes out, wait 5 minutes then repeat steps 4 and 5.
- Page 8 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Fully open the valve on the propane cylinder counter clockwise and wait 15 seconds before proceeding to step 2. RMC-LPC25/80/200 Propane Convection Heater gap is .196” (4.98 mm). Check wire lead for damage. For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.com...
- Page 9 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Store propane tank(s) in safe manner. Refer to Chapter 5 of Standard for Storage and handling of Liquefied Petroleum Gases, ANSI/NFPA 58, and the Natural Gas and Propane Installation Code CSA B149.1. Follow all local codes.
- Page 10 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC25 Series GS22-LPC25 Regulator & Hose Assy 10’ (3.05 m) KR10601-10-31 Regulator & Hose Assy 15’ (4.57 m) KR10601-15-31 For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.com...
- Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC80 Series GS22-LPC80 Regulator & Hose Assy 10’ (3.05 m) GR109-10-31 Regulator & Hose Assy 15’ (4.57 m) GR109-15-31 For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.com...
- Page 12 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC200 Series GQ01 GS16 Regulator & Hose Assy 10’ (3.05 m) GR108-10-25 Regulator & Hose Assy 15’ (4.57 m) GR108-15-25 For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.com...
- Page 13 Warranty LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only).
-
Page 14: Warranty Registration
WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
