3Com 3CRWE554G72T - OfficeConnect Wireless 11g Cable/DSL Router User Manual page 35

3 Enter your PPP over Ethernet service name in the PPPoE Service Name text
box.
Do not enter anything in this box if your ISP does not require a service
name.
4 Enter the MTU value supplied by your ISP in the MTU text box. If your ISP
has not supplied an MTU value, leave this at the default value. The
default is 1454.
5 Select an idle time from the Maximum Idle Time drop down list. This is
the amount of time without Internet activity that you want to allow
before the Router ends the PPPoE session.
6 Check all of your settings, and then click Next. Refer to
on page 40 for more information.
Dynamic IP Address Mode
To setup the Router for use with a dynamic IP address connection:
1 Select the ISP provides configuration dynamically (via DHCP) and then
click Next. See Figure
Figure 18 Hostname Screen
2 Some ISPs require a host name. If your ISP has this requirement, enter the
host name in the Host Name text box
Clone MAC Address screen displays.
16.
(Figure
Accessing the Wizard
"LAN Settings"
18) and click Next. The
35
