  • Page 1 Drying Tumblers 110 Pound Capacity Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. D0582 September 2007...
  • Page 3 Addendum A Information in this manual is applicable to these models: HD110 D0582...
  • Page 4: Important Notices

    IMPORTANT NOTES - PLEASE READ For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this manual in a file or binder and keep for future reference. WARNING: Purchaser must post the following notice in a prominent location: WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or death.
  • Page 5 IMPORTANT NOTES - PLEASE READ WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials. Do not put into this dryer flammable items such as baby bed mattresses, throw rugs, undergarments (brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing excessive heat and possible fire.
  • Page 6: Que Faire Si Vous Sentez Une Odeur De Gaz

    IMPORTANT NOTES - PLEASE READ ATTENTION: L’ACHETEUR DOIT PLACER L’AVERTISSEMENT SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE: AVERTISSEMENT. Assurez-vous de bien suivre les instructions donnees dans cette notice pour reduire au minimum le risque d’incendie ou d’explosion ou pour eviter tuot dommage materiel, toute blessure ou la mort.
  • Page 7: Table Of Contents

    Exhaust Installation - Separate Exhaust ... 25 Dryer Air Flow Installation ... 26 (C) Copyright Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 8: Customer Service

    CUSTOMER SERVICE If literature or replacement parts are required, contact the source from which the machine was purchased or contact Alliance Laundry Systems at (920) 748- 3950 for the name and address of the nearest authorized parts distributor. For technical assistance, call (920) 748-3121.
  • Page 9: Warnings, Symbols

    The following symbols are used in this manual and/or on the machine. Symbol NOTE! Hot! Do Not Touch Heiß! Nicht Beruhren Haute temperature! Ne pas toucher Caliente! no tocar dangerous voltage tension dangereuse Gefährliche elektrische Spannung tension peligrosa marche conectado arrêt desconectado start...
  • Page 10 SYMBOLS Description Symbol rotation in two directions rotation dans les deux sens Drehbewigung in zwei Richtungen movimiento rotativo en los dos sentidos direction of rotation sens de mouvement continu de rotation Drehbewegung in Pfeilrichtung movimiento giratorio o rotatorio en el sentido de la flecha End of Cycle caution attention...
  • Page 11: Unpacking/General Installation

    UNPACKING/GENERAL INSTALLATION (ALL DRYERS) UNPACKING GENERAL INSTALLATION (ALL DRYERS) This dryer is packed in a large wooden crate. Upon arrival of the equipment, any damage in shipment should be reported to the carrier immediately. Upon locating permanent location of a unit, care should be taken in movement and placement of equipment.
  • Page 12: General Dimensions

    GENERAL DIMENSIONS - GAS DRYERS ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 9...
  • Page 13 DRYER DIMENSIONS - STEAM MODEL ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 10...
  • Page 14 DRYER DIMENSIONS - ELECTRIC MODEL ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 11...
  • Page 15: Dryer Specifications

    GENERAL SPECIFICATIONS FOR 110 lb. DRYERS SPECIFICATIONS Floor Space Gas ...67” Deep x 47” W x 89-1/8” H Steam ...67” Deep x 47” W x 93-3/4” H Door Opening ...31-1/4” diameter (794 mm) Basket Size ...44” diameter x 42” Deep Basket Load Capacity ...110 lbs.
  • Page 16: Specifications

    STEAM HEATED DRYERS ONLY ELECTRIC LAUNDRY DRYER (see Electric Bonnet Sheet) SPECIFICATIONS Operating Steam Pressure ... 100 PSIG (6.9 bar) Max. Boiler HP (w/normal ld.) (14FPI) ...10.4 (7.76 kW) (4-Coil) ... 7.87 (5.88 kW) (6-Coil) ... 9.5 (5.88 kW) Steam Coils ...(2) 40-1/2”L x 15-3/4”H x 6”W Traps for Steam Heating Coils ...
  • Page 17: Electrical Connections

    ELECTRICAL CONNECTIONS (WITH GROUNDING INSTRUCTIONS ELECTRICAL CONNECTIONS FOR ALL DRYERS Dryers must be electrically grounded by a separate #14 or larger green wire from the grounding terminal within the service connection box, to a cold water pipe. In all cases, the grounding method must comply with local electrical code requirements;...
  • Page 18: Gas Service Installation Information

    GAS SERVICE INSTALLATION INFORMATION GAS PIPING The size of the gas service pipe is dependant upon many variables, such as tees, lengths, etc. Specific pipe size should be obtained from the gas supplier. Refer to the Gas Pipe Size Chart in this manual for general gas pipe size information.
  • Page 19 GAS PIPING Page 16...
  • Page 20: Gas Pipe Size Chart

    TOTAL BTU/HR (for LP Gas correct TOTAL total BTU/HR below by KCAL multiplying by .6) HOUR 60,000 15000 20000 80,000 25200 100,000 30200 120,000 35200 140,000 40300 160,000 45300 180,000 50400 200,000 300,000 75600 100800 400,000 126000 500,000 151200 600,000 176400 700,000 202000...
  • Page 21: Gas Piping Installation

    GAS PIPING INSTALLATION GAS PIPING INSTALLATION 1. The installation must conform to local codes or in absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 or the CAN/CGA-B149, Installation Codes. 2. Check with utilities for proper gas pressure and gas supply line.
  • Page 22: Installation Instructions

    STEAM PIPING INSTALLATION INSTALLATION INSTRUCTIONS PIPING R E C O M M E N D A T I O N S 1. Set and anchor dryer in position. Machine should be level to assure proper steam circulation. 2. To prevent condensate draining from headers to dryer, piping should have a minimum 12”...
  • Page 23 STEAM PIPING INSTALLATION (ILLUSTRATION) Page 20...
  • Page 24: Exhaust Installation - Multiple Exhaust

    EXHAUST INSTALLATION—MULTIPLE EXHAUST For Exhaust Duct less than 14 feet and 2 elbows equivalent and less than 0.6 inches static pressure. Area of section "A-A" must be equal to the sum of dryer exhaust pipes entering muliple exhaust pipe. (See chart below.) MODELS: HD110 No.
  • Page 25 DRYER INSTALLATION WITH MULTIPLE EXHAUST (ILLUSTRATION) Page 22...
  • Page 26: Dryer Installation With Multiple Exhaust

    DRYER INSTALLATION WITH MULTIPLE EXHAUST EXHAUST INSTALLATION— MULTIPLE MANIFOLD DUCT For Exhaust Duct more than 14 feet (5 m) and 2 elbows equivalent and more than 0.3 inches (8 mm) static pressure. 1. Make-up air from outside building may enter enclosure from top or side walls.
  • Page 27: Dryer Make-Up Air Requirements

    RECOMENDED MINIMUM DRYER MAKE-UP AIR REQUIREMENTS Dryer Dryer Pocket Maximum Air Flow Duct Size For Model Capacity Rate per Pocket HD110 HD110 E/S Service Connection m3/h inch 2200 3740 1445 Page 24 Required Make-up Air Area per Pocket sq. inch cm2 2723 1052...
  • Page 28: Dryer Installation With Separate Exhaust (Preferred)

    DRYER INSTALLATION WITH SEPARATE EXHAUST (PREFERRED) DRYER INSTALLATION WITH SEPARATE EXHAUST (PREFERRED) DRYER INSTALLATION WITH SEPARATE EXHAUST (PREFERRED) For Exhaust Duct less than 14 feet (5 m) and 2 elbows equivalent and less than 0.3 (8 mm) inches static pressure. NEVER exhaust the dryer into a chimney.
  • Page 29: Dryer Air Flow Installation

    DRYER AIR FLOW INSTALLATION DRYER AIR FLOW INSTALLATION EXHAUST DUCT MAKE-UP AIR OTHER RECOMMENDATIONS TROUBLESHOOTING Nothing is more important than air flow for the proper operation of a clothes dryer. A dryer is a pump which draws make-up air from the out-of-doors, through the heater, through the clothes and then forces the air through the exhaust duct back to the out-of-doors.
