XDMP680 OPERATION
Control Locations
1 2
22 21 20
1
2
3
4
5
6
7
8
9
10
11
The XDMP680 allows playback of your favorite MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while
maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic
Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track
search - even while a song is currently playing!
4
3
19 18 17
Release
Power
Volume
Band/Play/Pause
Mode/Search
Auto Store/Preset Scan/Enter
Tune/Track Down
Eject
Tune/Track Up
Display/0
EQ/9
4
16 15 14
Tuner Scan/8
12
Local/Distance/Return/7
13
14 Preset 6/Folder Up
15 Preset 5/Folder Down
16 Preset 4/Menu
17
Preset 3/Intro
18
Preset 2/Random
19
Preset 1/Repeat
20
Audio
21
Loudness
22
Record
5 6 7 8
13 12 11
9 10
