AUTOCAD 2010 PREVIEW GUIDE
You can use the Plotter Configuration Editor to view and modify the PDF settings for plotted output. Select the
DWG to PDF.pc3 plotter in the Plot dialog box and then choose Properties. The new Merge Control option is
displayed under the Graphics node and the other options are accessible when you select Custom Properties.
Figure 54. DWG to PDF Plotter Configuration Properties
You can control many of the PDF output settings separately for exported, published, or plotted PDF files. A new
Export to DWF/PDF panel on the Output ribbon tab provides access to the Export to DWF/PDF Options dialog
box where you can specify a single- or multi-sheet PDF file, include layer information, and apply merge control.
After applying the appropriate options, you can select PDF from the flyout tools.
Figure 55. Export to DWF/PDF
In addition to the Plot and Export functionality, PDF support has been integrated into Sheet Sets and Publish.
You can specify PDF output, including single- or multi-sheet, layer information, and merge control, in the Sheet
Set Publish Options and the Publish Options dialog boxes.
