AUTOCAD 2010 PREVIEW GUIDE
You can use the Volume tool to specify boundary points with visual feedback similar to the Area option, and
then specify a height to determine the volume. Additionally, you can display the volume of selected solids or
regions.
Figure 38. Volume highlighting

Reverse Tools

The new REVERSE command enables you to reverse the direction of lines, polylines, splines, and helixes.
Simply select the object(s) to reverse. The ability to change the direction of these objects provides you with
more control, such as the display of special linetypes.
Figure 39. Reverse results
In addition to the new REVERSE command, the PEDIT command has been updated to include a new Reverse
option. Simply select the polyline you want to edit and choose the Reverse option. The results are the same as
using the REVERSE command.
