CDA RV 1001 Installation And Use Manual

Twin cavity dual fuel cookers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RV 901 .. - RV 1001 ..
Twin Cavity Dual Fuel Cookers
Manual for Installation, Use and Maintenance
GB
Customer Care Department • The
Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RV 1001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CDA RV 1001

Summary of Contents for CDA RV 1001

  • Page 1 Twin Cavity Dual Fuel Cookers Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...

  • Page 2: Appliance Information

    The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.

  • Page 3: Features And Technical Data

    Features and Technical Data - Gas Burners 1. Auxiliary burner (A) 1.00 kW 2. Semi-Rapid burner (SR) 1.75 kW 3. Semi-Rapid burner (SR) 1.75 kW 4. Rapid burner (R) 3.00 kW 5. Triple Ring burner (TR) 3.50 kW Note: The electric ignition is incorporated in the knobs. The appliance has a safety valve system fitted, the flow of gas will be stopped if and when the flame should accidentally go out.
  • Page 4 The electric ignition is incorporated in the knobs. The appliance has a safety valve system fitted, the flow of gas will be stopped if and when the flame should accidentally go out. Fig. 1b mod. RV 1001 .. 1.00 kW 1.75 kW 3.00 kW 3.50 kW...

  • Page 5: Control Panel

    The cooling fan may also operate when the oven is switched off. This fan is to reduce the external temperature of the appliance and cool the internal components. Fig. 2a Fig. 2b mod. RV 901 .. mod. RV 1001 ..

  • Page 6: Clock And Timer With "Touch-Control" Keys

    Clock and Timer with “Touch-Control” Keys (Multifunction Main Oven only) Keys: – Touched simultaneously (for more than 2 seconds): • setting the clock; • s etting the timer volume (by touching once, along with the “MODE” key); • to cancel automatic cooking at any time. MODE Function selection (touched for more than 2 seconds): • s etting the clock (only after first connection or after a power failure);...

  • Page 7: Setting The Clock

    “Touch-Control” Keys The “touch-control” keys shall be operated by the fingers (just by touching the key). When using touch controls it is best to use the ball of your finger rather than the tip. The keys are automatically deactivated: - 8 seconds after the last selection; the deactivation is indicated by an acoustic signal (“beep”). To reactivate just touch the “MODE”...

  • Page 8: Automatic Cooking

    Automatic Cooking Use automatic cooking to automatically turn the oven on, cook, and then turn the oven off. 1. Check the clock shows the correct time. 2. Select the function and temperature (function and temperature knobs). The oven will come on. 3.

  • Page 9: Lighting Of The Hob Burners

    How to Use the Hob Burners Hob Burners Each hob burner is controlled by a separate gas valve operated by a control knob (fig. 4) which has 3 positions marked on the control panel, these are: – Symbol : Tap closed (burner off) –...

  • Page 10: Table Of Contents

    Rapid (RV 1001 .. model) Triple Ring AIR FLOW (cooling fan) Fig. 6 Minimum Pan Diameter (cm) AIR FLOW (cooling fan) CORRECT USE OF RAPID BURNER (mod. RV 1001 .. only) Fig. 5 Maximum Pan Diameter (cm) AIR FLOW (cooling fan)
  • Page 11 Correct Use of Triple-Ring Burner The flat-bottomed pans are to be placed directly onto the pan-support. To use the WOK you need to place the proper stand in order to avoid any faulty operation of the triple- ring burner (Figs. 7 - 8). Important: The wok pan stand (fig.

  • Page 12: General Features

    How to Use the Multifunction Main Oven General Features As its name indicates, this is an oven that presents particular features from an operational point of view. In fact, it is possible to insert 7 different programmes to satisfy every cooking need.

  • Page 13: Oven Light

    Thermostat Knob (fig. 9) This only sets the cooking temperature and does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 to 250°C). The light between the thermostat and the function selector will illuminate when the oven is switched on and turns off when the oven reaches the correct temperature.

  • Page 14: Defrosting Frozen Foods

    Grilling The infrared grill element comes on. The heat is dispersed by radiation. Use with the oven door closed and the thermostat knob to position 225°C for max 15 minutes, then to position 175°C. For cooking hints, see the chapter “USE OF THE GRILL”. Recommended for: Intense grilling, browning, cooking au gratin and toasting etc.
  • Page 15 Ventilated Grill Cooking The infrared grill element and the fan come on. The heat is dispersed mainly by radiation and the fan then distributes it all over the oven. Use with the door closed. The temperature can be regulated via the thermostat knob to between 50° and 175°...

  • Page 16: Cooking Advice

    Cooking Advice Sterilization Sterilization of foods to be conserved, in full and hermetically sealed jars, is done in the following way: a. Set the switch to position b. Set the thermostat knob to position 185 °C and preheat the oven. c.

  • Page 17: Use Of The Grill

    Roasting To obtain classical roasting, it is necessary to remember: – that it is advisable to maintain a temperature between 180° and 200 °C. – that the cooking time depends on the quantity and the type of foods. Use of the Grill –...

  • Page 18: How To Use The Conventional Oven

    How to Use the Conventional Oven General Features As its name indicates, this is an oven that presents particular features from an operational point of view. The conventional oven is provided with 3 heating elements which are: – Bottom element 800 W –...

  • Page 19: Traditional Grilling

    Function Selector Knob (fig. 11) Rotate the knob clockwise to set the oven for one of the following functions. Oven Light By setting the knob to this position, only the oven light comes on. It remains on in all the cooking modes. Traditional Convection Cooking The upper and lower heating elements come on.
  • Page 20 Use of the Grill Switch the grill on, setting the two knobs: – Function selector to – Thermostat selector to position 225°C for 15 minutes then to 175°C. Leave to warm up for approximately 5 minutes with the door closed. Place the food inside positioning the rack as near as possible to the grill.
  • Page 21 Use of Special Dish Rack This special shelf can be used as dish rack or turning over, as normal shelf for oven cooking. It must be inserted between the guides of the lateral racks. Using the Special Shelf as a Dish Rack Slide in the shelf on the guides, on the lower level of the lateral racks.

  • Page 22: Do's And Do Not's

    – Do not attempt to repair the internal workings of your cooker. – Do remove the protective film before the first use. – Fire risk! Do not store flammable material in the ovens and in the storage compartment (RV 901 .. model) or bottom drawer (RV 1001 .. model).

  • Page 23: Important Notes

    For Your Safety – The product should only be used for its intended purpose which is for the cooking of domestic foodstuffs. – Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified personnel. –...

  • Page 24: Care And Maintenance

    Care and Maintenance Important: As a safety measure, before you start cleaning the cooker be sure to disconnect it from the mains supply. Do not use cleaning products with a chlorine or acidic base. Do not use a steam cleaner because the moisture can get into the appliance thus make it unsafe.
  • Page 25 Stainless Steel, Aluminium, Painted Parts and Silk-Screen Printed Surfaces Clean using an appropriate product. Always dry thoroughly. Stainless steel surfaces: can be cleaned with an appropriate stainless steel cleaner. IMPORTANT: these parts must be cleaned very carefully to avoid scratching and abrasion. You are advised to use a soft cloth and neutral soap.
  • Page 26 Burners and Grids – These parts can be removed and cleaned with appropriate products. – After cleaning, the burners and their flame spreaders must be well dried and correctly replaced. – It is very important to check that the burner flame spreader and the cap have been correctly positioned. Failure to do so can cause serious problems.
  • Page 27 Correct Position of Triple Ring Burner The triple ring burner must be correctly positioned (see fig. 18); the burner ribs must be fitted in their housing as shown by the arrow. The burner correctly positioned must not rotate (fig. 19). Then position the cap “A“...
  • Page 28 Attention: Do not store flammable material in the oven, or the storage compartment. Fig. 21 Drawer (Model RV 1001 ..) The drawer (fig. 22) comes out like a normal drawer. Attention: Do not store flammable material in the ovens, or the drawer.
  • Page 29 Inside of Oven The oven should always be cleaned after use when it has cooled down. The cavity should be cleaned using a mild detergent solution and warm water. Suitable proprietary chemical cleaners may be used after first consulting with the manufacturers recommendations and testing a small sample of the oven cavity.
  • Page 30 Replacing the Halogen Oven Lights WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. – Let the oven cavity and the heating elements to cool down; – Switch off the electrical supply; –...

  • Page 31: Removing The Oven Doors

    Oven Doors Removing the Oven Doors Please operate as follows: – Open the door completely. – The swivel retainers of the rh and lh hinges (fig. 26a) are hooked onto the metal bar above them (fig. 26b). – Lift the oven door slightly. The noch on the bottom of the hinge will disengage (fig.
  • Page 32 Over Doors - Cleaning The Panes Of Glass The oven doors have two panes. To clean these, you need to remove the inner pane. Removing the Inner Pane – Open the door to the full extent (fig. 26a). – Attach the swivel retainers of the rh and lh hinges onto the metal bar above them (fig.

  • Page 33: For The Installer

    FOR THE INSTALLER Location This cooker has class “2/1” overheating protection so that it can be installed next to a cabinet. The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but not in a room or space containing a bath or a shower.
  • Page 34 The cooker must be installed by a qualified technician and in compliance with local safety standards. If the cooker is located on a pedestal it is necessary to provide safety measures to prevent falling out. mod. RV 901 .. Fig. 28a mod. RV 1001 .. Fig. 28b...

  • Page 35: Assembling The Backguard

    Assembling the Backguard – Remove the two spacers “A” and the screw “B” from the rear of the cooktop. – Assemble the backguard as shown in figure 29 and fix it by screwing the central screw “B” and the spacers “A”. Fig.
  • Page 36 Fitting the Adjustable Feet and Levelling the Cooker mod. RV 901 .. – The adjustable feet must be fitted to the base of the cooker before use. – Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet.

  • Page 37: Levelling The Cooker

    Levelling the cooker mod. RV 1001 .. The cooker is equipped with 4 levelling feet and may be levelled by screwing or unscrewing the feet with a spanner (fig. 33). It is important to observe the prescriptions of figures 33a - 33b.
  • Page 38 Moving the Cookers Warning When raising cooker to upright position always ensure two people carry out this manoeuvre to prevent damage to the adjustable feet (figs. 34a - 34b). Fig. 34a Fig. 34b Warning Be carefull: do not lift the cooker by the door handle when raising to the upright position (figs. 35a - 35b). Fig.

  • Page 39: Stability Bracket

    Stability Bracket mod. RV 901 .. We recommend a stability bracket is fitted to the cooker. The type shown in fig. 38 can be purchased from most plumbers merchants and do it yourself (D.I.Y.) shops. mod. RV 901 .. Fig. 37 Fig.
  • Page 40 Stability Bracket mod. RV 1001 .. We recommend a stability bracket is fitted to the cooker. The type shown in fig. 40 can be purchased from most plumbers merchants and do it yourself (D.I.Y.) shops. mod. RV 1001 .. Fig. 39 Fig.

  • Page 41: Provision For Ventilation

    Provision for Ventilation – The appliance should be installed into a room or space with an air supply in accordance with BS 5440-2: 2000. – For rooms with a volume of less than 5m – For rooms with a volume of between 5m required unless the room has a door which opens directly to the outside air in which case no permanent ventilation is required.

  • Page 42: Gas Installation

    Gas Installation Important Note This appliance is supplied for use on NATURAL GAS or LPG (check the gas regulation label attached on the appliance). – Appliances supplied for use on NATURAL GAS: they are adjusted for this gas only and cannot be used on any other gas (LPG) without modification.

  • Page 43: Gas Connection

    Gas Connection The installation of the gas appliance to Natural Gas or LP Gas must be carried out by a suitably qualified and registered installer. Installers shall take due account of the provisions of the relevant British Standards Code of Practice, the Gas Safety Regulations and the Building Standards (Scotland) (Consolidation) Regulations issued by the Scottish Development Department.
  • Page 44 Left gas inlet pipe 1/2” BSP (male) mod. RV 901 .. Left gas inlet pipe 1/2” BSP (male) mod. RV 1001 .. Fig. 41 Right gas inlet pipe Plug Fig. 42a Right gas inlet pipe Plug Fig. 42b...
  • Page 45 Important Prescriptions for Gas Connection mod. RV 901 .. Rear wall Suggested area for gas mains connection Fig. 43a mod. RV 1001 .. Rear wall Suggested area for gas mains connection Fig. 43b...

  • Page 46: Conversion To Natural Gas Or To Lpg

    Conversion to Natural Gas or to LPG Injectors Replacement of Top Burners Every cooker is provided with a set of injectors for the various types of gas. Injectors not supplied can be obtained from the After-Sales Service. Select the injectors to be replaced according to the table at page 47. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector.

  • Page 47: Lubrication Of The Gas Taps

    Table for the Choice of the Injectors Burners Nominal Power Auxiliary (A) 1,00 Semi-Rapid (SR) 1,75 Rapid (R) 3,00 Triple Ring (TR) 3,50 Increase of Air Necessary for Gas Combustion (2 m Burners Auxiliary (A) Semi-Rapid (SR) Rapid (R) Triple Ring (TR) Lubrication of the Gas Taps The operations must be executed by a qualified technician.

  • Page 48: Electrical Installation

    Electrical Installation WARNING! Electricity can be extremely dangerous. This appliance must be earthed. The appliance must be connected to the electrical network verifying above all that the voltage corresponds to the value indicated on the specifications plate and that the cables section of the electrical plant can bear the load which is also indicated on the plate.
  • Page 49 Connection to Fixed Wiring A double pole switch must be provided no further than 2 metres from the appliance to the electrical supply. The appliance should be connected to a DOUBLE POLE SWITCHED FUSED SPUR OUTLET, similar to that shown in Fig. 49. We recommend that the appliance is connected by a suitably qualified person who will comply with the IEE and local DOUBLE POLE SWITCHED...

  • Page 50: Appliance Servicing

    Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1.
  • Page 51 After the first year and within five years, the parts will be supplied free of charge provided that the repair is carried out by an agent authorised by CDA and the labour will be charged at the commercial rate applicable at the time of repair.
  • Page 52 Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
