Use and Controls

FWC150 control panel
1 5 6
2 4
FWC300/FWC600 control panel
1
For the FWC600 dual zone wine cooler the left control panel is for the upper zone, and the right control panel is for the
lower zone.
The appliance switches on automatically when plugged in to the mains power supply. The preset temperature is 13ºC.
To change the temperature
• Press the set button.
• Press the up and down buttonS until the required temperature is shown on the display.
• Press the set button to confirm the selection.
In the event of a power cut, the appliance will automatically revert to the selected temperature settings. To ensure the
smallest change in temperature during a power cut, do not open the door any more than is necessary.
Optimal temperature selection
Whilst wine is best stored at temperatures between 13 and 15 ºC, your wine cooler can also be stored at drinking
temperature. For red wine this is between 15 and 17 ºC, and for white wine between 12 and 13 ºC.
To use the internal light
• Press the light button to switch the light on.
• Press the light button again to switch the light off.
The internal light switches off automatically five minutes after being switched on.
Compressor Indicator
This indicator illuminates to show when the compressor is running, and "run" will also show in the display. When the
compressor is not running, "stop" will show in the display.
Alarm indicator
This indicator illuminates to show there is an error with the appliance. There will be an audible alarm, and the display will
show an error code. For information on error codes, see the troubleshooting section.
Key:
3
1 – Light button
2 – Set button
3 – Up/Down button
4 – Compressor indicator
5 – Alarm indicator
6 – Temperature display
2 5 4 6 3
