Revert to a Previous App Firewall Configuration

The vShield Manager saves a snapshot of App Firewall settings each time you commit a new rule. Clicking
Commit causes the vShield Manager to save the previous configuration with a timestamp before adding the
new rule. These snapshots are available from the Revert to Snapshot drop-down list.
To revert to a previous App Firewall configuration
1 In the vSphere Client, go to Inventory > Hosts and Clusters.
2 Select a datacenter or cluster resource from the inventory panel.
3 Click the vShield App tab.
4 Click App Firewall.
5 From the Revert to Snapshot drop-down list, select a snapshot.
Snapshots are presented in the order of timestamps, with the most recent snapshot listed at the top.
6 View snapshot configuration details.
7 Do one of the following:

To return to the current configuration, select the - option from the Revert to Snapshot drop-down list.

Click Commit to overwrite the current configuration with the snapshot configuration.

Delete an App Firewall Rule

You can delete any App Firewall rule you have created. You cannot delete the any rules in the Default Rules
section of the table.
To delete an App Firewall rule
1 Click an existing row in the App Firewall table.
2 Click Delete.
3 Click Commit.

Using SpoofGuard

After synchronizing with the vCenter Server, the vShield Manager collects the IP addresses of all vCenter
guest virtual machines from VMware Tools on each virtual machine. Up to vShield 4.1, vShield trusted the IP
address provided by VMware Tools on a virtual machine. However, if a virtual machine has been
compromised, the IP address can be spoofed and malicious transmissions can bypass firewall policies.
SpoofGuard allows you to authorize the IP addresses reported by VMware Tools, and alter them if necessary
to prevent spoofing. SpoofGuard inherently trusts the MAC addresses of virtual machines collected from the
VMX files and vSphere SDK. Operating separately from the App Firewall rules, you can use SpoofGuard to
block traffic determined to be spoofed.
When enabled, you can use SpoofGuard to monitor and manage the IP addresses reported by your virtual
machines in one of the following modes.

Automatically Trust IP Assignments On Their First Use: This mode allows all traffic from your virtual
machines to pass while building a table of MAC-to-IP address assignments. You can review this table at
your convenience and make IP address changes.

Manually Inspect and Approve All IP Assignments Before Use: This mode blocks all traffic until you
approve each MAC-to-IP address assignment.
N SpoofGuard inherently allows DHCP requests regardless of enabled mode. However, if in manual
OTE
inspection mode, traffic does not pass until the DHCP-assigned IP address has been approved.
