vShield Administration Guide
vShield Edge
N
You must obtain an evaluation or full license to use vShield Edge.
OTE
vShield Edge provides network edge security and gateway services to isolate the virtual machines in a port
group, vDS port group, or Cisco
(uplink) networks by providing common gateway services such as DHCP, VPN, NAT, and Load Balancing.
Common deployments of vShield Edge include in the DMZ, VPN Extranets, and multi-tenant Cloud
environments where the vShield Edge provides perimeter security for Virtual Datacenters (VDCs).
Standard vShield Edge Services (Including Cloud Director)
Firewall: Supported rules include IP 5-tuple configuration with IP and port ranges for stateful inspection
for TCP, UDP, and ICMP.
Network Address Translation: Separate controls for Source and Destination IP addresses, as well as TCP
and UDP port translation.
Dynamic Host Configuration Protocol (DHCP): Configuration of IP pools, gateways, DNS servers, and
search domains.
Advanced vShield Edge Services
Site-to-Site Virtual Private Network (VPN): Uses standardized IPsec protocol settings to interoperate with
all major firewall vendors.
Load Balancing: Simple and dynamically configurable virtual IP addresses and server groups.
vShield Edge supports syslog export for all services to remote servers.
vShield App
N
You must obtain an evaluation or full license to use vShield App.
OTE
vShield App is an interior, vNIC-level firewall that allows you to create access control policies regardless of
network topology. A vShield App monitors all traffic in and out of an ESX host, including between virtual
machines in the same port group. vShield App includes traffic analysis and container-based policy creation.
vShield App installs as a hypervisor module and firewall service virtual appliance. vShield App integrates
with ESX hosts through VMsafe APIs and works with VMware vSphere platform features such as DRS,
vMotion, DPM, and maintenance mode.
vShield App provides firewalling between virtual machines by placing a firewall filter on every virtual
network adapter. The firewall filter operates transparently and does not require network changes or
modification of IP addresses to create security zones. You can write access rules by using vCenter containers,
like datacenters, cluster, resource pools and vApps, or network objects, like Port Groups and VLANs, to
reduce the number of firewall rules and make the rules easier to track.
You should install vShield App instances on all ESX hosts within a cluster so that VMware vMotion™
operations work and virtual machines remain protected as they migrate between ESX hosts. By default, a
vShield App virtual appliance cannot be moved by using vMotion.
The Flow Monitoring feature displays allowed and blocked network flows at the application protocol level.
You can use this information to audit network traffic and troubleshoot operational.
12
®
Nexus 1000V. The vShield Edge connects isolated, stub networks to shared
VMware, Inc.
