MINOURA TWIN - SCHEMATICS Manual

TWIN Schematics
TM-1
UF-1
GM-7
GM-9
GM-10
GM-11
GM-12
GM-13
GM-14
UF-1 : Main Frame
UF-2 : U-Leg (Chrome Plated)
UF-3 : Alloy Leg Guide
UF-4 : Height Adjuster Cap
UF-5 : Height Adjuster Knob
UF-6 : Right Side Coupling & Clamp Lever (Red)
UF-7 : Clamp Lever Guide
UF-8 : Left Side Coupling
UF-9 : Coupling Lock Ring (Red)
UF-10 : U-Leg Bushing
UF-11 : U-Leg Pivot Sleeve
UF-12 : Alloy Leg Support Bracket Cover
UF-13 : Ruber Cap
UF-14 : Pivot Bolt Set (Long)
UF-15 : Pivot Bolt Set (Short)
UF-9
UF-10
UF-13
TM-2
TM-3
GM-15
UF-8
UF-11
UF-10
UF-12
UF-5
UF-15
TM-5
TM-4
! CAUTION
Do NOT touch TM-6 "Alloy Rotor"
during and 15 minutes after workout.
It's VERY HOT and may burn you.
GM-1 :
GM-7 :
GM-8 :
GM-9 :
GM-10 :
GM-11 :
GM-12 :
GM-13 :
GM-14 :
GM-15 :
TM-1 :
TM-2 :
TM-3 :
TM-4 :
TM-5 :
TM-6 :
UF-6
UF-4
UF-3
TM-6
GM-1
V270 / TWIN Flywheel
Drive Roller Holder
Flywheel Nut Cap
Axle End Cap
Mag Unit Fitting Bracket
Rubber Shim
Mount Base
Rubber Washer Set
Foot Pedal
Foot Pedal Adjust Knob Set
TWIN Remote Shifter
TWIN Drive Roller
TWIN Housing Cover
TWIN Main Housing
TWIN Alloy Sleeve
TWIN Alloy Rotor
UF-7
UF-14
UF-2
GM-8
