Dometic CONCERTO 3210 Installation And Operation Instructions Manual

All-china gravity discharge toilet for recreation vehicles
Hide thumbs Also See for CONCERTO 3210:
Table of Contents

Advertisement

Quick Links

CONCERTO
TM
ALL-CHINA GRAVITY DISCHARGE TOILET

INSTALLATION AND OPERATION

INSTRUCTIONS
Model 3210 Toilet
for Recreation Vehicles
WARNING
!
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can
result in property damage.
Dometic Corporation
13128 State Rt. 226, P.O. Box 38
Big Prairie, OH 44611-0038 USA
330-496-3211
1-800-321-9886 • Fax: 330-496-3097
® Registered; ™ Trademark of Dometic Corporation
© Dometic Corporation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONCERTO 3210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic CONCERTO 3210

Summary of Contents for Dometic CONCERTO 3210

  • Page 1: Installation And Operation

    Modification of this product can result in property damage. Dometic Corporation 13128 State Rt. 226, P.O. Box 38 Big Prairie, OH 44611-0038 USA 330-496-3211 1-800-321-9886 • Fax: 330-496-3097 ® Registered; ™ Trademark of Dometic Corporation © Dometic Corporation...

  • Page 2: Table Of Contents

    The model identification label is located on the inside wall of the toilet under the access cover. It will show the model number and serial number. Concerto is a trademark, and SeaLand is a registered trademark of Dometic Corporation. Flush Mechanism Components ... 9 Troubleshooting ... 10 Parts List ...

  • Page 3: Toilet Dimensions

    CONCERTO TOILET DIMENSIONS MODEL 3210 INSTALLATION INSTRUCTIONS System Requirements: • 2 GPM (10.6 lpm) or larger water pump. • 1/2-inch (12.7 mm) water line terminating in 1/2-inch MPT fitting (to connect to toilet water supply hose). • 4-bolt floor (closet) flange. SeaLand flanges available include 3-inch spigot, socket, MPT, or 45-degree swivel socket.
  • Page 4 STEP 5a: For through-the-floor water line and electrical wires, mark another centerline 6 inches (152 mm) from the back wall (fig. 4). Fig. 4 STEP 5b: For through-the-wall water line and electrical wires, mark a centerline 8 inches (203 mm) up from the floor centerline (fig.
  • Page 5 STEP 9: WITH THE ELECTRICAL POWER OFF, route #14 gauge stranded copper wire from 12 VDC ground and positive 12 VDC from the fuse panel through a 2-amp fuse or circuit breaker. Leave at least 12 inches (305 mm) of wire for connecting to toilet (fig.

  • Page 6: Toilet Operation

    STEP 17: Connect the positive (+) 12 VDC lead to the red wire and the negative (-) lead to the black wire (fig. 18). Fig. 18 STEP 18: REMOVE RED CAP FROM MIDDLE OF FLANGE ADAPTER BEFORE FINAL TOILET INSTALLATION. IMPORTANT –...

  • Page 7: Proper Cleaning And Maintenance

    PROPER CLEANING AND MAINTENANCE The Concerto toilet should be cleaned regularly for maximum sanitation and operational efficiency. You can clean it just as you would a household toilet. Do not use caustic chemicals, such as drain-opening types, as they will damage the seals.

  • Page 8: Deodorants And Special Tissue

    Formaldehyde versus Non-Formaldehyde: Dometic manufactures both types of deodorants. Generally speaking, formaldehyde formulas control odor very effectively at all temperatures and with all degrees of water hardness. SeaLand Environment-Friendly brand, which is formaldehyde free, is similarly effective.

  • Page 9: Flush Mechanism Components

    FLUSH MECHANISM COMPONENTS 1. To access base assembly components, remove decorative screw caps and unscrew two bolts that hold china toilet to floor. 2. Remove access cover from top of china and set it aside. Water Valve Switch Flush Handle Bracket and Pulley Flush Handle...

  • Page 10: Troubleshooting

    TROUBLESHOOTING Important: Always turn off electrical power and water to the toilet for disassembly. Problem 1. Toilet emits odor (flush ball open). 2. Water will not stay in bowl. 3. Water will not enter bowl. 4. Water will not shut off and overflows bowl.

  • Page 11: Parts List

    PARTS LIST WIRING DIAGRAM Item Part No. Access Cover, White 385311001 Access Cover, Bone 385311002 385311003 Flush Switch Assembly 385311004 Flush Handle Shaft Kit 385311005 Seat and Lid, White Seat and Lid, Bone 385311006 385311007 China Bowl, White (incl. item 1 and locking material) 385311008 China Bowl, Bone (incl.

  • Page 12: Ordering Parts

    (10) years if used for personal, family or household-like purposes, and is regularly cleaned as described in the product’s owner’s manual. If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
