VACUFLUSH
®
SANITATION SYSTEM
OWNER'S MANUAL
500 Plus Series, 1000 Series, Model 706 Toilets
WARNING
!
This manual must be read and understood
before adjustment, maintenance, or service
is performed. Modification of this product
can result in property damage.
Dometic Corporation • Sanitation Systems
13128 State Rt. 226, P.O. Box 38
Big Prairie, OH 44611-0038 USA
SeaLand Product Hotline 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Dometic 1000 Series
Summary of Contents for Dometic 1000 Series
- Page 1 VACUFLUSH ® SANITATION SYSTEM OWNER’S MANUAL 500 Plus Series, 1000 Series, Model 706 Toilets WARNING This manual must be read and understood before adjustment, maintenance, or service is performed. Modification of this product can result in property damage. Dometic Corporation • Sanitation Systems 13128 State Rt.
-
Page 2: Table Of Contents
Toilet Model Identification ....7 WARNING – HIGH VOLTAGE SYSTEM. Turn off electrical power before servicing. PRODUCT FEATURES Dometic brings the technology, comfort and efficiency of VacuFlush Sanitation Systems in an easy-to- use and easy-to-maintain package. • Freshwater Flush •... -
Page 3: Marine Sanitation Regulations
MARINE SANITATION REGULATIONS All boats with fixed toilets in U.S. waters and in the waters of some other countries are required to be equipped with an operable marine sanitation device (MSD). The VacuFlush system is a holding tank or Type III system as defined by the U.S. -
Page 4: Key System Components
Holding Tanks: Holding tanks from Dometic are made of super-strong, 3/8" (9.5mm) thick polyethylene — 50% thicker than most other holding tanks. Each unit has a solid, one-piece construction with no seams for unmatched durability. -
Page 5: System Start Up
SYSTEM START UP 1. Turn on inlet water supply. 2. Turn on electrical power to system. 3. Flush water into system by depressing flush lever until water starts flowing to the vacuum pump, approxi- mately 15 seconds. The vacuum pump will run for approximately 60 to 90 seconds until system reaches operating vacuum level and then will shut off. -
Page 6: Maintenance
MAINTENANCE Maintenance intervals and normal parts replacement vary widely depending on numerous factors such as: type of vessel, frequency of system use, quality of flushing water, etc. The chart below is intended strictly as a general guideline. Owner discretion and consideration of actual usage must be the first basis for determining proper maintenance levels. -
Page 7: Vacuflush Maintenance Kit
ORDERING PARTS Dometic is ready to assist you in the event service is required. Before calling, please have the following informa- tion available. Your cooperation in having this information ready is appreciated and allows us to better meet your needs. -
Page 8: Deodorants And Special Tissue
Environmental Hazards: If you would like further information on the impact of holding tank deodorants, call or write Dometic at the number and address listed on the back page of this manual. Request a copy of Clean Water Notebook, Volume 5, which provides complete information in this regard. -
Page 9: Accessories
Order part number 310289 (12 VDC) or 310290 (24 VDC). VACUUM TESTER Dometic has developed a simple tool to assist in identifying the location of vacuum leaks. The vacuum tester consists of a vacuum gauge and a cone-shaped plug. -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE BASE ASSEMBLY REAR VIEW, VACUUM TOILET Problem 1. Water will not stay in bowl. a. Loose clamp ring. b. Improper seal around flush ball due c. Worn or damaged seal. d. Worn or damaged flush ball. 2. Plastic flush ball will not a. - Page 11 TROUBLESHOOTING GUIDE Problem a. Too much clearance between the 6. Lifting foot pedal does not add water to the bowl. a. Water valve body cracked due to 7. Water leaking from water valve. b. Water line connection is loose or not c.
-
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem 13.Vacuum pump is running too slow, overheating, blowing fuses or circuit breaker. 14.Toilet will not flush. (No vacuum.) See problems 3 and 15 if necessary. 15.Blockage between toilet and vacuum generator. 16.Pump emits odor. Possible Cause a. Gear motor is worn or defective. b. -
Page 13: Parts Lists
PARTS LIST MODEL 706 MODEL 1147 & 1148 Item Part No. 385344436 Seat Assembly, White 385344437 Seat Assembly, Bone 385310676 China Bowl, White 385310736 China Bowl, Bone 385310048 Ring and Half Clamp Kit 385316140 Teflon and Rubber Seal Kit ® 385310132 Base Kit, White 385310133... -
Page 14: Parts List
PARTS LIST MODEL 506+ MODEL 508+ MODEL 547+ MODEL 548+... - Page 15 PARTS LIST Item 506+ 508+ 385343830 385343830 385343832 385343832 385343898 385343898 385343902 385343902 385343900 385343900 385310739 385310739 385310740 385310740 385310741 385310741 385310742 385310742 385310743 385310743 385310048 385310048 385316140 385316140 385310064 385316323 385310108 385310111 385310109 385310112 385310113 385310110 385310600 385310173 385310603 385310203 600341549 385318864...
- Page 16 PARTS LIST MODEL 1006 MODEL 1008 MODEL 1047 MODEL 1048...
- Page 17 PARTS LIST Item 1006 1008 385344436 385344436 385344437 385344437 385344438 385344438 385310615 385310615 385310616 385310616 385310585 385310585 385310048 385310048 385316140 385316140 385310132 385310126 385310133 385310127 385310607 385310171 385310064 385316323 385310108 385310111 385310109 385310112 385310600 385310173 385318864 385318741 385310117 385310114 385310118 385310115 385310593 385310175...
- Page 18 PARTS LIST VACUUM GENERATOR Item Part No. Description Pan Phillips Head Screw, #4 x 3/8", SS 600340237 600343027 Flat Washer, .312" OD x .030 Thick, SS Motor/Switch Cover 600342804 Pump Top Closure 600341506 600344087 Flat Washer, #10 x 5/8" OD, SS Hex Washer Head Screw, #10-32 x ½", SS 600342332 Hex Washer Head Screw, #10-12 x 7/8", SS...
- Page 19 PARTS LIST LOW-PROFILE VACUUM GENERATOR Item Part No. Description Pan Phillips Head Screw, #4 x 3/8", SS 600340237 Pump Cover 385640239 600341506 Top Closure 600341503 Hex Washer Head Screw, #10-12 x 7/8", SS Hex Washer Head Screw, #10-32 x ½", SS 600342332 O-Ring Replacement Kit 385310151...
-
Page 20: Parts Lists
PARTS LIST VACUUM PUMP, S-SERIES NOTE: S-Series pump valve adapter and nipple (items 9 and 11) have right-hand threads (clockwise to tighten, counterclockwise to loosen). VACUUM TANK SMALL IN-LINE CHECK VALVE LARGE IN-LINE CHECK VALVE Item Part No. Description 600340237 Cover Screw, #4 x 3/8"... -
Page 21: Dimensional Specifications
DIMENSIONAL SPECIFICATIONS * Width measurement includes flush pedal. Toilet dimensions may vary ± 3/8-inch (10mm). -
Page 22: Wiring Diagrams
WIRING DIAGRAMS VACUUM GENERATOR VACUUM PUMP... -
Page 23: Parts Distributors
There is a strong, worldwide network to assist in servicing and maintaining your sanitation system. For the Authorized Service Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) Monday through Friday. You may also write us at Dometic Corp., P.O. Box 38, Big Prairie Ohio 44611. Telephone: 1 800-321-9886 U.S.A. -
Page 24: Manufacturer's One-Year Limited Warranty
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
