3000, 3100, 3300, 3400 Series VacuFlush
3000 Series
IMPORTANT NOTICE
VacuFlush sanitation systems must be installed according to Dometic's recommended
procedures. Do not attempt installation without first contacting a VacuFlush Certified
Dealer, your nearest VacuFlush Parts Distributor, or Dometic.
WARNING
!
WARNING
This manual must be read and understood
before adjustment, maintenance, or service
is performed. Modification of this product
can result in property damage.
VACUFLUSH
ALL-CHINA VACUUM TOILET
OWNER'S MANUAL
3100 Series
3300 Series
Dometic Corporation • Sanitation Systems
SeaLand Product Customer Service: 1-800-321-9886
1
Toilets
®
3400 Series
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
(8:00 a.m. - 5:00 p.m. ET)
®
Advertisement
Table of Contents
Related Manuals for Dometic 3000
Summary of Contents for Dometic 3000
- Page 1 3000, 3100, 3300, 3400 Series VacuFlush 3000 Series IMPORTANT NOTICE VacuFlush sanitation systems must be installed according to Dometic’s recommended procedures. Do not attempt installation without first contacting a VacuFlush Certified Dealer, your nearest VacuFlush Parts Distributor, or Dometic. WARNING...
-
Page 2: Table Of Contents
flow into bowl for two seconds, then flush ball will open. Toilet will not flush again until “OK to Flush” light is on. DOMETIC CORPORATION P.O. BOX 38, 13128 STATE RT 226 (800) 321-9886 BIG PRAIRIE, OH 44611 USA MODEL NO. -
Page 3: Operating Instructions
OPERATING INSTRUCTIONS 1. Adding More Water To Toilet Bowl Raise flush handle or press “Add Water” switch until desired water level is attained. To prevent toilet overflow, the control module limits the amount of water that can be added. 2. Flushing The Toilet When the vacuum status panel’s green “OK to Flush”... -
Page 4: Flush Operation Timing Chart
FLUSH OPERATION TIMING CHART Water Valve Low Refill Normal Refill High Refill Flush Valve Begin Opening for 0.1 sec. Wait for 0.1 sec. Continue Opening Held Open Closing Time Additional “Add Water” Time Allowance Water Valve Low Position Normal Position High Position Service Position PROPER CLEANING –... -
Page 5: Clearing Discharge Lines
(2 ea. per kit) ORDERING PARTS Dometic is ready to assist you in the event service is required. Before calling, please have the following information available. Your cooperation in having this information ready is appreciated and allows us to better meet your needs. -
Page 6: Sanitation System Components
SANITATION SYSTEM COMPONENTS Vacuum Toilet: VacuFlush all-ceramic vacuum toilets with technology operate differently compared Flush and Forget ® to other toilets. The vacuum system uses a small amount of water (a little more than a pint or .5 liter) per flush in addition to a simple vacuum. - Page 7 SANITATION SYSTEM COMPONENTS (cont’d) TankWatch Level Indicator (marine option only): ® The TankWatch unit utilizes micro-float switches which activate an indicator panel. The micro-float switches are installed in the top of the holding tank. The adjustable probe assemblies are flexible polybutylene tubing and are designed to flex when tank contents move.
-
Page 8: Deodorants And Special Tissue
Sewage from any source should not be discharged directly into our waters. If you are interested in learning more about this issue, please contact Dometic at the phone number or address listed on the back page of this manual. Environment Friendly... -
Page 9: Flush Mechanism Components
floor. REMOTE FLUSH SWITCHES (3100, 3400 toilets) Vimar switch - marine Gewiss switch - marine FLUSH HANDLE (3000, 3300 toilets) (under Access Cover) Flush Flush Handle Switch BASE ASSEMBLY COMPONENTS (under china toilet) Flush Ball... -
Page 10: Manual Flush Operations
MANUAL FLUSH OPERATION In the event of an electrical failure, the flush ball can be manually operated to clear the bowl. We recommend using a long-neck screwdriver or 7/16-in. socket for the operation shown below. NEVER PRY OPEN THE FLUSH BALL FROM INSIDE THE TOILET BOWL. -
Page 11: Troubleshooting
TROUBLESHOOTING A volt/ohmmeter (VOM) and the appropriate Toilet Wiring Diagram may be required for this section. Caution: Portions of this section will require that power be applied to the toilet. Keep hands away from the flush ball, motor drive arm and rotor shaft to prevent personal injury during testing and troubleshooting. The control module uses a microprocessor to provide all the automatic and timing functions. -
Page 12: Toilet Operation
TROUBLESHOOTING (cont’d) ERROR CODE CORRECTIVE PROCEDURES Condition Mode Switch in SERVICE position. Valve Open Limit Switch problem. Valve Closed Limit Switch problem. Insufficient vacuum in system. Flush valve motor relay failure. TOILET OPERATION SYMPTOM 1. Toilet will not flush and water will not enter toilet bowl. Condition +5V status light is off (on far right of control module):... - Page 13 TROUBLESHOOTING (cont’d) SYMPTOM 3. Flush valve will not close. Condition/Procedure Mode Switch is in SERVICE position: Foreign object prevents the flush valve from closing and the safety circuit locked flush valve in open position: Check for error code at “DO NOT FLUSH”...
- Page 14 TROUBLESHOOTING (cont’d) SYMPTOM 8. Water will not stay in bowl and system loses vacuum. Condition/Procedure Put Mode Switch in “Service” position: Worn or damaged flush valve ball and seal: SYMPTOM 9. Water will not shut off and overflows the toilet. Procedure Check the “WATER VALVE”...
-
Page 15: Rv Wiring Diagrams
RV WIRING DIAGRAMS RV VACUFLUSH TOILET – FLUSH HANDLE (3000, 3300 SERIES) RV VACUFLUSH TOILET – REMOTE FLUSH SWITCH (3100, 3400 SERIES) REMOTE FLUSH SWITCH (3100, 3400 series RV toilets) - Page 16 RV WIRING DIAGRAMS (cont’d) RV VACUSTAT PANEL OPTION RV VACUFLUSH STATUS PANEL OPTION...
-
Page 17: Marine Wiring Diagrams
MARINE WIRING DIAGRAMS MARINE VACUFLUSH TOILET – FLUSH HANDLE (3000, 3300 SERIES) MARINE VACUFLUSH TOILET – GEWISS FLUSH SWITCH (3100, 3400 SERIES) GEWISS FLUSH SWITCH OPTION (3100, 3400 series marine toilets) - Page 18 MARINE WIRING DIAGRAMS (cont’d) VIMAR FLUSH SWITCH OPTION VIMAR FLUSH SWITCH OPTION (3100, 3400 marine toilets) MARINE VACUSTAT PANEL OPTION...
- Page 19 MARINE WIRING DIAGRAMS (cont’d) MARINE VACUFLUSH STATUS PANEL / TANKWATCH OPTION VACUFLUSH STATUS PANEL OPTION IMPORTANT: ORANGE WIRE ON PIN 15 OF CONTROL MODULE MUST BE CONNECTED TO THE “A” TERMINAL OF THE VACUUM SWITCH REGARDLESS OF WHICH VACUUM SOURCE IS USED.
- Page 20 MARINE WIRING DIAGRAMS (cont’d) VACUUM GENERATOR/VACUUM TANK AND PUMP OPTION M-SERIES VACUUM PUMP AC CIRCUIT OPTION...
-
Page 21: Dimensions
MARINE WIRING DIAGRAMS (cont’d) M-SERIES VACUUM PUMP DC CIRCUIT OPTION DIMENSIONS Models 3006, 3106* Models 3309, 3348, 3409*, 3448* 3100 and 3400 series toilets operate with wall-mounted flush switch, and do not include flush handle on toilet. Models 3009, 3048, 3109*, 3148* China toilet dimensions may vary ±3/8-inch (10mm). -
Page 22: Customer Service
There is a strong, worldwide network to assist in servicing and maintaining your sanitation system. For the Authorized Service Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) Monday through Friday. You may also write us at Dometic Corp., P.O. Box 38, Big Prairie Ohio 44611. Telephone: 1 800-321-9886 U.S.A. -
Page 23: Other Rights
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase. - Page 24 If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
