CARAVAN SANITATION SYSTEM
OWNER'S MANUAL
VacuFlush
1600 Series Toilets and
®
Holding Tank Systems for European Caravans (HTS-EC)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VacuFlush 1600 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dometic VacuFlush 1600 Series

  • Page 1 CARAVAN SANITATION SYSTEM OWNER’S MANUAL VacuFlush 1600 Series Toilets and ® Holding Tank Systems for European Caravans (HTS-EC)
  • Page 2: Table Of Contents

    Dometic reserves the right to change specifications without notice. FEATURES Dometic Caravan Sanitation Systems are the newest standard in mobile sanitation. Each system is comprised of a VacuFlush 1600 series toilet and a vacuum holding tank system – a fully integrated vacuum generator/holding tank module designed specifically for European caravans.
  • Page 3: Model Numbers And Dimensions

    MODEL NUMBERS AND DIMENSIONS 1600 SERIES TOILETS Size Model Description Weight Length x Width x Height 10 Kg 495 mm x 438 mm x 356 mm 1606 Low-profile vacuum toilet. Below-floor discharge. 19 1/2" x 17 1/4" x 14" 22 Lbs. 495 mm x 378 mm x 457 mm 10.4 Kg 1609...
  • Page 4: Key System Components

    KEY SYSTEM COMPONENTS Vacuum Toilet: The VacuFlush toilet operates differently as compared to other toilets. VacuFlush systems use a small amount of water (from as little as 400 ml) per flush in addition to a powerful vacuum. The toilet is connected to a pressurized fresh- Vacuum water system.
  • Page 5: Important Information Before Operation

    2. Make sure all guests understand the operation of the VacuFlush system and the instruction label is in plain sight and easy for guests to read. If this label is not included in this manual, please contact Dometic’s Customer Service Department immediately.
  • Page 6: Vacuum Toilet Operation

    VACUUM TOILET OPERATION 1. To add water to the toilet before 2. To flush toilet, press flush lever 3. Do not dispose of sanitary napkins using, raise flush lever until desired sharply down to the floor until contents or other non-dissolving items in toilet, water level is reached.
  • Page 7: Proper Toilet Cleaning And Maintenance

    5. After cleaning, turn on water and electrical power to toilet system. WINTERIZING – TOILET At the end of each season, the Dometic toilet should be winterized for storage by either draining or using potable water-safe antifreeze in the system.
  • Page 8: Maintenance Schedule

    ORDERING PARTS Dometic is ready to assist you in the event that service is required. Before calling your local dealer or parts distributor, please have the following information available. Your cooperation in having this information ready is appreciated.
  • Page 9: Toilet Model Identification

    SPECIAL TOILET TISSUE AND CLEANER Why Not Use Household Toilet Paper in Your Dometic Toilet. Household tissues often contain adhesives which bond together the paper fibers from which the tissue is made. The adhesives prevent the tissue from breaking apart, and their use in “ultra-low flow”...
  • Page 10: Troubleshooting Guide

    TROUBLESHOOTING GUIDE ADJUSTING NUT BALL SEAL MODELS 1609, 1648 FLUSH BALL BASE ASSEMBLY CLAMP RING FLUSH PEDAL WATER VALVE ASSEMBLY TOP VALVE CAP FILTER SCREEN SHAFT SPRING CARTRIDGE VALVE BODY PEDAL WATER COVER VALVE SCREWS BALL SEAL MODEL 1606 BASE ASSEMBLY ADJUSTING NUT CAM STRAP WATER VALVE ASSEMBLY...
  • Page 11 TROUBLESHOOTING GUIDE Problem Possible Cause Service Instructions 2. Flush ball will not close a. Clamp ring is overtightened, a. Loosen clamp ring. causing too much tension on completely. seal and flush ball. b. Weak or defective flush lever b. Check spring tension by letting return spring.
  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Problem Possible Cause Service Instructions 9. Vacuum pump will not run. a. No electrical power. a. Check input power, circuit breaker. b. “Tank full” float switch is stuck b. Remove switch and clean or replace. c. Loose or broken electrical wiring. c.
  • Page 13: Parts Lists

    PARTS LIST MODEL 1606 Description Item Part No. Seat Assembly, White 385344088 China Bowl Kit, White 385310790 Ring & Half Clamp Kit, White 385310048 385316140 Teflon & Rubber Seal Kit ® 385310064 Floor Bolt Mounting Kit 385310108 Pedestal Cover Kit, White Floor Flange Seal 600341549 Funnel Kit (includes item 7)
  • Page 14: Parts List

    PARTS LIST MODEL 1648 Description Item Part No. 385344088 Seat Assembly, White China Bowl Kit, White 385310790 385310025 Ring & Half Clamp Kit, White 385316140 Teflon & Rubber Seal Kit ® 385310941 Base Kit, White (includes items 3-11) 385310954 Ball, Shaft & Cartridge Kit 385318741 Funnel Kit 385310682...
  • Page 15 PARTS LIST – 35 HTS-EC Item Part No. Description 385310930 Discharge Pump, 38 mm Adapter, Deutsch Connectors, 12 VDC 600346604 Nut, 1/4-20, SS 600346795 Washer, .625" x .281" x .05", SS 385310931 Quick-Connect 38 mm MPT Elbow 600342781 Slip Nut Seal 385310937 Diptube Kit 600343023...
  • Page 16 PARTS LIST – 60 HTS-EC Item Part No. Description Discharge Pump, 38 mm Adapter, Deutsch Connectors, 12 VDC 385310945 600346604 Nut, 1/4-20, SS 600346795 Washer, .625" x .281" x .05", SS Quick-Connect 38 mm MPT Elbow 385310931 600342781 Slip Nut Seal 385310946 Diptube Kit 600343023...
  • Page 17 PARTS LIST – 90 HTS-EC Item Part No. Description 385310945 Discharge Pump, 38 mm Adapter, Deutsch Connectors, 12 VDC 600346604 Nut, 1/4-20, SS 600346795 Washer, .625" x .281" x .05", SS 385310931 Quick-Connect 38 mm MPT Elbow 600342781 Slip Nut Seal 385310950 Diptube Kit 600343023...
  • Page 18 PARTS LIST – VACUUM GENERATOR Item Part No. Description Item Part No. Description Pan Phillips Head Screw, #4 x 3/8", SS O-Ring, 2" ID x 2-1/4" OD 600340237 600342778 600343027 Flat Washer, .312" OD x .030 Thick, SS 600342782 2 ½" Diameter Worm Gear Clamp Motor/Switch Cover Mounting Spindle 600342804...
  • Page 19: Parts Lists

    PARTS LIST – DISCHARGE PUMP Item Part No. Description Item Part No. Description #4 x 3/8" Pan Head Screw Set Screw, ¼-28 x 5/16" 600340237 600347788 Pump Cover Kit Eccentric 385640239 600344470 Pump Top Closure ¼-28 x ½" Phillips Head Screw 600341502 600340017 600342332...
  • Page 20: Wiring

    WIRING HOLDING TANK SYSTEM DISCHARGE PUMP ON/OFF SWITCH * Indicates electrical components supplied by vehicle manufacturer.
  • Page 21: Parts Distributors

    Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) parts needs. They carry a complete inventory for the Dometic Monday through Friday. You may also write us at Dometic Corp., toilet product line. P.O. Box 38, Big Prairie Ohio 44611.
  • Page 22: Sales Offices

    DOMETIC CORPORATION AND SALES OFFICES Dometic is the leading worldwide provider of product systems business. Dometic has production facilities in 10 countries, its for increased convenience away from home. Dometic provides own sales and marketing operations in 35 countries plus ap- RV and Pleasure Boat Systems, Silent Refrigeration Systems proximately 65 distributors globally.
  • Page 24 (1) year from the date of purchase. If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
