Intel Desktop Board D865PERL Product Guide

Installing and Removing Memory

CAUTION
To be fully compliant with all applicable Intel SDRAM memory specifications, the boards require
DIMMs that support the Serial Presence Detect (SPD) data structure. You can access the PC
Serial Presence Detect Specification at:
http://www.intel.com/technology/memory/pcsdram/spec/
Desktop Board D865PERL has four 184-pin DIMM sockets arranged as DIMM 0 and DIMM 1 in
both Channel A and Channel B, as shown in Figure 9 (color was added to DIMM sockets to show
how to place DIMMs for dual configuration).
Dual Channel Configuration
Before installing DIMMs, read and follow these guidelines for dual channel configuration.
Install a matched pair of DIMMs equal in speed, size, and technology (see Figure 7) in
DIMM 0 in both channels A and B.
If additional memory is to be used, install another matched pair of DIMMs in DIMM 1 in
both channels A and B (see Figure 8).
34
Channel A
1 GB, 512 Mb, DDR400
Channel B
1 GB, 512 Mb, DDR400
Figure 7. Dual Configuration Example 1
Channel A
256 MB, 256 Mb, DDR400
512 MB, 256 Mb, DDR400
Channel B
256 MB, 256 Mb, DDR400
512 MB, 256 Mb, DDR400
Figure 8. Dual Configuration Example 2
DIMM 0
DIMM 1
DIMM 0
DIMM 1
DIMM 0
DIMM 1
DIMM 0
DIMM 1
