1 Desktop Board Features

This chapter briefly describes the main features of Intel
NOTE
The board for Desktop Board D865PERL may be either green or black depending on the options
that are included on the board.
Table 1 summarizes the major features of the desktop board.
Table 1.

Feature Summary

Processor
Main Memory
Chipset
Audio
Expansion
Capabilities
Support for:
• Intel
® ®
Pentium 4 processor in the mPGA478 package
• Intel
® ®
Celeron processor the mPGA478 package
• Four 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets
• 400/333/266 MHz single or dual channel DDR SDRAM interface
• Designed to support up to 4 GB of system memory
System resources (such as PCI and AGP) require physical memory address
NOTE:
locations that reduce available memory addresses above 3 GB. This may result in
less than 4 GB of memory being available to the operating system and applications.
For the latest list of tested memory, refer to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
• Intel
®
865PE chipset consisting of:
• Intel
®
82865PE Memory Controller Hub (MCH) with Accelerated Hub Architecture
(AHA) bus
• Intel
®
82801ER I/O Controller Hub (ICH5R) supporting Intel
®
Intel 82801EB I/O Controller Hub (ICH5)
• Firmware Hub (FWH)
• Intel 865PE chipset (AC '97)
• Analog Devices Inc. codec
• Up to five PCI bus add-in card connectors (SMBus routed to PCI bus 2)
• One AGP 8x, 4x, 1x connector
®
Desktop Board D865PERL.
®
RAID Technology or
continued
