Table 23. SATA and PATA Submenus (continued)
Feature Options
• Auto (default)
DMA Mode
• SWDMA 0
• SWDMA 1
• SWDMA 2
• MWDMA 0
• MWDMA 1
• MWDMA 2
• UDMA 0
• UDMA 1
• UDMA 2
• UDMA 3
• UDMA 4
• UDMA 5
• Auto (default)
S.M.A.R.T.
• Disable
• Enable
None
Cable Detected
(Note)
Note: These configuration options appear only if an IDE device is installed.
Description
Specifies the Ultra DMA mode for the drive.
Self-monitoring analysis and reporting technology.
Displays the type of cable connected to the IDE interface:
40-conductor or 80-conductor (for ATA-66/100 devices) or
Serial ATA.
