Intel
D845GEBV2/D845GERG2

Technical Product Specification

®
The Intel
Desktop Board D845GEBV2/D845GERG2 may contain design defects or errors known as errata that may cause the product to deviate from published specifications.
Current characterized errata are documented in the Intel Desktop Board D845GEBV2/D845GERG2 Specification Update.
®
Desktop Board
October 2002
Order Number: C14584-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D845GEBV2 - OCTOBRE 2002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel D845GEBV2 - OCTOBRE 2002

Summary of Contents for Intel D845GEBV2 - OCTOBRE 2002

  • Page 1: Technical Product Specification

    Order Number: C14584-001 ® The Intel Desktop Board D845GEBV2/D845GERG2 may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current characterized errata are documented in the Intel Desktop Board D845GEBV2/D845GERG2 Specification Update.
