EPSON ActionPC 8000, ActionTower 8000
Controllers
PCI chipset
Provides PCI caching, memory, and
control for the PCI bus and the two-
channel PCI IDE interface (described
under 'Hard disk and other IDE devices"
below); integrated PCI bridge translates
CPU bus cycles to PCI bus cycles and
CPU-to-PCI memory write cycles to PCI
burst cycles
Video
S3™ Trio64™ PCI VGA controller with
integrated 24-bit RAMDAC, 64-bit DRAM
interface; includes power-saving and
multimedia features; supports resolutions
up to 1280 x 1024 in 16 colors with 1MB of
video RAM, increasing to 256 colors with
2MB
of video RAM; True Color support in
the 640 x 480 resolution with 2MB of video
Controller on main system board supports
D i s k e t t e
up to two diskette drives, or one
diskette/combo diskette and one tape
drive
Hard disk and
Two PCI, ATA-2 compatible, IDE
IDE
other
interfaces on main system board support
devices
up to four IDE devices (two on each
interface); IDE CD-ROM drives cannot be
connected to the primary IDE interface or
to the same interface as IDE hard disk
drives; BIOS provides hard disk
auto-sensing and enhanced IDE functions
Interfaces
Monitor
Energy Star compliant video interface for
fixed or multi-frequency monitor built into
system board; 15-pin, D-shell connector
Parallel
One standard, multimode parallel
interface built into main system board;
supports 8-bit unidirectional, 16-bit
bidirectional, and ECP (Extended
Capability Port) modes; 25-pin, D-shell
connector; operation controllable by
SETUP program and jumpers
Serial
Two high-speed RS-232C, programmable,
asynchronous interfaces built into main
system board; 16C550 compatible; 9-pin,
D-shell connectors; operation controllable
through SETUP
Keyboard
PS/2™ compatible keyboard interface built
into main system board; 6-pin, mini DIN
connector
Mouse
PS/2 compatible mouse interface built
into main system board; 6-pin mini DIN
connector
2 - ActionPC 8000, ActionTower 8000
Option slots
Connector card with five I/O expansion
slots; three ISA compatible (8.33 MHz bus
speed) and two PCI compatible (33 MHz
bus speed); PCI slots support up to two
PCI bus masters
Speaker
Internal
Mass Storage
Slimline computer
Internal bays:
One 3.5-inch
Externally accessible bays:
One 3.5-inch
and two 5.25-inch wide, half-height drives
Tower computer
Front internal bay:
One 3.5-inch
Rear internal bracket:
Two
or one 35-inch wide, full-height drive
Externally accessible bays:
Two 3.5-inch wide, one-inch high
and two 5.25-inch wide, half-height drives
3.5-inch
Diskette drive
storage capacity; 5.25-inch diskette drive,
types
360KB or 1.2MB storage capacity; or a
combination 3.5-inch/5.25-inch diskette
drive
Hard disk drive
5.25-inch or 3.5-inch form factor hard disk
drive(s), up to half-height size; maximum
types
of four drives
Other devices
Half-height tape drives, CD-ROM drives,
optical drives, PCMCIA card readers, or
other devices; 5.25-inch, or 3.5-inch with
mounting frames
Keyboard
Detachable, two-position height; 101, 102,
or 104 sculpted keys; country-dependent
main typewriter keyboard; numeric/
cursor control keypad; four-key cursor
control keypad; 12 function keys
Mouse
Detachable, two-button, PS/2 compatible
SETUP
Stored in ROM accessible by pressing Del
duringboot
Program
System security
User and Supervisor level passwords
available for system boot or diskette access
Virus protection
Write protection feature for the hard disk
drive boot sector
9/95
wide, one-inch high drive
wide, one-inch high drive
wide, half-height drive
3.5-inch wide, one-inch high drives
diskette drive, 720KB or 1.44MB
drives
