Summary of Contents for Dodge 2008 Ram 3500

  • Page 1: Introduction

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 3: Table Of Contents

    CONTENTS Introduction ......4 A Message From DaimlerChrysler Corporation – Diesel Engines Only ..... . 4 How To Use This Manual .
  • Page 4: Introduction

    A MESSAGE FROM DAIMLERCHRYSLER CORPORATION – DIESEL ENGINES ONLY DaimlerChrysler Corporation and Cummins welcome you as a new Dodge Ram Cummins Turbo Diesel- powered truck owner. Almost 100% of the heavy duty trucks in the United States and Canada are diesel powered because of the fuel economy, rugged durability, and high torque which per- mits pulling heavy loads.
  • Page 5: How To Use This Manual

    Thank you for choosing the Dodge Ram truck with Cummins Turbo Diesel power. HOW TO USE THIS MANUAL Consult the table of contents to determine which section contains the information you desire.
  • Page 6 6 INTRODUCTION...
  • Page 7: Warnings And Cautions

    For information on the Body Builders Guide go to: www.dodgebodybuilder.com. This website contains di- mensional and technical specifications for Dodge trucks. It is intended for Second Stage Manufacturer’s technical support. For service issues, contact your Dodge dealer. INTRODUCTION 7...
  • Page 8: Vehicle Identification Number

    8 INTRODUCTION VEHICLE IDENTIFICATION NUMBER The vehicle identification number (VIN) is found on the left front corner of the instrument panel, visible through the windshield. This number also appears on the Auto- mobile Information Disclosure Label affixed to a window on your vehicle, the vehicle registration and title.
  • Page 9 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Locking Doors With The Key .
  • Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Keyless Entry — If Equipped ..21 To Unlock The Doors ....21 To Lock The Doors .
  • Page 11 Driver And Right Front Passenger Supplemental Restraint System (SRS)—Airbag ... .47 Event Data Recorder (EDR) ....57 Child Restraint .
  • Page 12: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer. Ask your dealer for these numbers and keep them in a safe place.
  • Page 13 NOTE: If you try to remove the key before you place the lever in PARK, the key may become trapped temporarily in the ignition cylinder. If this occurs, rotate the key to the right slightly, then remove the key as described. If a malfunction occurs, the system will trap the key in the ignition cylinder to warn you that this safety feature is inoperable.
  • Page 14: Locking Doors With The Key

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked car is an invitation to thieves. Always remove key from the ignition and lock all doors when leaving the vehicle unattended. Manual Transmission — If Equipped When the steering wheel is in the LOCK position, the steering and ignition systems are locked to provide antitheft protection for your vehicle.
  • Page 15: Sentry Key

    SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked. The system uses ignition keys, which have an embedded electronic chip (transponder), to prevent unauthorized vehicle operation.
  • Page 16: Replacement Keys

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Exxon/Mobil Speed Pass,™ additional Sentry Keys, or any other transponder-equipped components on the same key chain will not cause a key-related (transpon- der) fault unless the additional part is physically held against the ignition key being used when starting the vehicle.
  • Page 17: Customer Key Programming

    Customer Key Programming If you have two valid sentry keys, you can program new sentry keys to the system by performing the following procedure: 1. Cut the additional Sentry Key Transponder blank(s) to match the ignition switch lock cylinder key code. 2.
  • Page 18: General Information

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information The Sentry Key system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
  • Page 19: Automatic Transmission Ignition Interlock System

    Automatic Transmission Ignition Interlock System This system prevents the key from being removed unless the shift lever is in PARK. It also prevents shifting out of PARK unless the key is in the ON positions, and the brake pedal is depressed. SECURITY ALARM SYSTEM —...
  • Page 20: To Disarm The System

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the SECURITY light stays on continuously during vehicle operation, have the system checked by your dealer. To Disarm the System: Use the Keyless Entry transmitter to unlock the door. If something has triggered the system in your absence, the horn will sound three times when you unlock the doors and the security lamp will flash for 30 seconds.
  • Page 21: Things To Know Before Starting Your Vehicle 21

    REMOTE KEYLESS ENTRY — IF EQUIPPED Three Button Transmitter This system allows you to lock or unlock the doors from distances up to about 23 feet (7 meters) using a hand held radio transmitter. The transmitter need not be pointed at the vehicle to activate the system.
  • Page 22: To Lock The Doors

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Perform this operation while standing outside the vehicle. 2. Press and hold the LOCK button on your key. 3. Continue to hold the LOCK button at least 4 seconds, but no longer than 10 seconds, then press and hold the UNLOCK button while still holding the LOCK button.
  • Page 23 3. Continue to hold the LOCK button, wait at least 4 seconds, but no longer than 10 seconds, then press and hold the PANIC button. Release both buttons at the same time. 4. To reactivate this feature, repeat the above steps. Vehicles will be shipped from the assembly plants with the park lamp flash feature activated.
  • Page 24: Using The Panic Alarm

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the Panic Alarm To activate the Panic mode while the ignition is OFF press and release the PANIC button on the transmitter once. When the Panic mode is activated, the interior lights will illuminate, the headlamps and parking lights will flash, and the horn will sound.
  • Page 25: Transmitter Battery Service

    Transmitter Battery Service Transmitter Battery Replacement NOTE: Perchlorate Material – special handling may apply, see www.dtsc.ca.gov/hazardouswaste/perchlorate. The recommended replacement battery is CR2032 bat- tery. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: Do not touch the battery terminals that are on the back housing or the printed circuit board.
  • Page 26: Remote Starting System - If Equipped

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED Your vehicle may be equipped with a remote starting system, which will allow the vehicle to be started from distances up to approximately 300 feet away from the vehicle using the remote keyless entry key fob which is part of your ignition key.
  • Page 27: Door Locks

    To enter the vehicle while the engine is running during a remote start, you must first unlock the vehicle using the UNLOCK button on the key fob. After the vehicle is unlocked, you have 15 minutes to enter the vehicle, insert the key in the Ignition and move it to the RUN position, otherwise the engine will cancel remote start and auto- matically turn off.
  • Page 28: Power Door Locks - If Equipped

    28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors when you drive as well as when you park and leave the vehicle. • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
  • Page 29 Automatic Door Locks – If Equipped If this feature is enabled, your door locks will lock automatically when the vehicle’s speed exceeds 15 mph. Automatic Door Lock Programming This feature is enabled when your vehicle is shipped from the assembly plant and can be disabled by using the following procedure: •...
  • Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Unlock On Exit — If Equipped This feature unlocks all of the doors of the vehicle when any door is opened. This will occur only after the vehicle has been shifted into the Park position after the vehicle has been driven (shifted out of Park and all doors closed).
  • Page 31: Child Protection Door Lock

    Child Protection Door Lock To provide a safer environment for children riding in the rear seat, the rear doors of your vehicle have the child- protection door lock system. Child Protection Door Lock Location THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 To use the system, open each rear door, slide the lever UP to engage the locks and DOWN to disengage the child- protection locks.
  • Page 32: Windows

    32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: After setting the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
  • Page 33 and on the rear doors of Quad Cab and Mega Cab models. The windows will operate only when the igni- tion switch is turned to the ON or ACC (Accessory) position. WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
  • Page 34: Power Sliding Rear Window - If Equipped

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Sliding Rear Window – If Equipped Power Sliding Rear Window Switch The power sliding rear window switch is located on the instrument panel below the climate controls. Press the right side of the switch to open the glass and the left side of the switch to close the glass.
  • Page 35: Occupant Restraints

    OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, front airbags for both the driver and front passenger. If you will be carrying children too small for adult-size belts, your seat belts also can be used to hold infant and child restraint systems.
  • Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE normal conditions. But in a collision, the belt will lock and reduce the risk of your striking the inside of the vehicle or being thrown out. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle.
  • Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt.
  • Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! • A belt buckled into the wrong buckle will not protect you properly.
  • Page 39 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
  • Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
  • Page 41 Detaching Buckle with Key 2. To reattach the seat belt to the front center seat, pull the black buckle latch plate forward from the cab back panel and insert it into the black keyed buckle until there is an audible click. Refer to the previous section for the proper seat belt usage.
  • Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Inserting Latch Plate In Use Position WARNING! If the black latch and buckle are not connected when the seat belt is used by an occupant, the seat belt will not restrain you properly.
  • Page 43: Adjustable Upper Shoulder Belt Anchorage

    Adjustable Upper Shoulder Belt Anchorage In the front row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck. Press the button located on the upper belt guide, and then move it up or down to the position that serves you best.
  • Page 44: Center Lap Belts

    44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use The Automatic Locking Mode 1. Buckle the combination lap/shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
  • Page 45: Seat Belt Pretensioners

    Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove slack from the seat belt system in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
  • Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Enhanced Warning System (BeltAlert) can be en- abled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position.
  • Page 47: Seat Belts And Pregnant Women

    Seat Belts and Pregnant Women We recommend that pregnant women use seat belts throughout their pregnancies. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug against the hips as possible. Keep the belt low so that it does not come across the abdomen.
  • Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE These airbags are certified to the new Federal regulations that allow less forceful deployments. This vehicle may also be equipped without a passenger side airbag. In this case the passenger side airbag will be replaced with a storage bin.
  • Page 49 Airbags inflate in moderate to high speed impacts. Along with the seatbelts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger. The seat belts are designed to protect you in many types of collisions.
  • Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The driver and front passenger seats should be moved back as far as practical to allow the airbag room to inflate. WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision.
  • Page 51 How The Airbag System Works • The airbag control module determines if a frontal collision is severe enough to require the airbags to inflate. • The airbag control module will not detect roll over, or rear collisions. • The airbag control module also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or RUN positions.
  • Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When the airbag control module detects a collision requiring the airbags, it signals the inflator units. A large quantity of nontoxic gas is generated to inflate the airbags. The airbag covers separate and fold out of the way as the airbags inflate to their full size.
  • Page 53 because the infant has a medical condition which makes it necessary for the driver to be able to see the infant, • is a child, age 1 to 12 who must ride in the front seat because there is no rear seat, because there is no rear seat position available, or because the child has a medical condition which makes it necessary for the driver to be able to see the child,...
  • Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Turn On the Passenger Airbag (Standard Cab Ve- hicles Only) (If Equipped) Place the ignition key in the Passenger Airbag On/Off Switch (If Equipped), push the key in and turn counter- clockwise, and remove the key from the switch.
  • Page 55 irritation, move to fresh air. If the irritation continues, see your doctor. If these particles settle on your clothing, follow the garment manufacturer’s instruc- tions for cleaning. • It is not advisable to drive your vehicle after the airbags have deployed. If you are involved in another collision, the airbags will not be in place to protect you.
  • Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag Systems WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you.
  • Page 57: Event Data Recorder (Edr)

    NOTE: If the speedometer, tachometer or any engine related gauges are not working, the airbag control mod- ule may also be disabled. The airbags may not be ready to inflate for your protection. Promptly check fuse block for blown fuses. Refer to the label located on the inside of the fuse block cover for the proper airbag fuses.
  • Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In the event that an investigation is undertaken by DaimlerChrysler Corporation (regardless of initiative), the company or its designated representative will first obtain permission of the appropriate custodial entity for the vehicle (usually the vehicle owner or lessee) before accessing the electronic data stored, unless ordered to download data by a court with legal jurisdiction (i.e., pursuant to a warrant).
  • Page 59: Child Restraint

    • Airbag deployment level (if applicable) • Impact acceleration and angle • Seatbelt status • Brake status (service and parking brakes) • Accelerator status (including vehicle speed) • Engine control status (including engine speed) • Transmission gear selection • Cruise control status •...
  • Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are.
  • Page 61 • Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
  • Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
  • Page 63 around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. • Buckle the child into the seat according to the child restraint manufacturer’s directions. • When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle.
  • Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For children riding in the front seat of a Stan- dard Cab model refer to the “Passenger Airbag On/Off Switch” (If Equipped) located in this section. Standard Cab Passenger Seat Quad Cab Rear Outboard Seats...
  • Page 65 Child restraint systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the seatback tether anchorage have been available for some time. In fact, many child restraint manufacturers will provide add-on tether strap kits for some of their older products.
  • Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing the Child Restraint System WARNING! Do not install child restraint systems equipped with LATCH attachments in the center position of a Quad Cab model rear seat. The LATCH anchorages in this seat are designed for the two outboard seating posi- tions only.
  • Page 67 Child Restraint Tether Anchor Child restraints having tether straps and hooks for con- nection to tether anchors have been available for some time. In fact, many child restraint manufacturers will provide add-on tether strap kits for their older products. Regular Cab models of Ram Pickups have two tether anchorages, one each behind the front center and right seats.
  • Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Install the child restraint and remove the slack in the tether strap according to the manufacturer’s instructions. Regular Cab Tether Strap Mounting Multiple Child Restraint Installation Sequence - (Quad Cab Rear Seats) 1.
  • Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Multiple Child Restraint Quad Cab...
  • Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tether Anchorage Points at All Three Seating Positions (Mega Cab) 1. Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.
  • Page 71: New Engine Break-In

    Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seat back should use the lap/shoulder belt in a rear seat. •...
  • Page 72: 6.7L Diesel Engine

    72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NON-DETERGENT OR STRAIGHT MINERAL OILS MUST NEVER BE USED. A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and is not an indication of difficulty. CAUTION! •...
  • Page 73: Safety Tips

    • Check the coolant and oil levels frequently. • Vary throttle position at highway speeds when carry- ing or towing significant weight. Because of the construction of the Cummins Diesel engine, engine run-in is enhanced by loaded operating conditions which allow the engine parts to achieve final finish and fit during the first 6,000 miles (10 000 km).
  • Page 74: Lock Your Vehicle

    74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lock Your Vehicle Always remove the keys from the ignition and lock all doors when leaving the vehicle unattended, even in your own driveway or garage. Try to park your vehicle in a well-lighted area and never invite theft by leaving ar- ticles of value exposed.
  • Page 75: Safety Checks You Should Make Inside The Vehicle

    Safety Checks You Should Make Inside The Vehicle Heater Defroster Ducts Inspect the heater defroster ducts for proper operation. Check for proper air flow through all defroster ducts. If there are any question regarding the operation of your heater defroster ducts, have the system checked by an authorized dealer Seat Belts Inspect the belt system periodically, checking for cuts,...
  • Page 76 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lights Check the operation of all exterior lights. Check turn signal and high beam indicator lights on the instrument panel. Door Latches Check for positive closing, latching and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, water, oil, or other fluid leaks.
  • Page 77: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......81 Inside Mirror ......81 Automatic Dimming Mirror –...
  • Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats ....... . 114 40-20-40 Front Seat .
  • Page 79 To Deactivate ......133 To Resume Speed ..... 133 To Vary The Speed Setting .
  • Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cupholders ......154 Front Instrument Panel Cupholders (40–20–40 Seats) —...
  • Page 81: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 MIRRORS Inside Mirror The mirror should be adjusted to center on the view through the rear window. Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).
  • Page 82: Understanding The Features Of Your Vehicle

    82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror – If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light in the button will indicate when the dimming feature is activated.
  • Page 83: Exterior Mirrors Folding Feature

    WARNING! Vehicles and other objects seen in a right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side convex mirror could cause you to collide with an- other vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the right side convex mirror.
  • Page 84: Electronic Power Mirrors - If Equipped

    84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electronic Power Mirrors – If Equipped Power Mirror Movement The controls for the power mirrors are located on the driver’s door trim panel. Power Mirror Switches Set the top switch to the left or right for the left or right mirror, and set it to the center off position to prevent accidentally moving a mirror when you are finished adjusting the mirror.
  • Page 85: Electric Rear Window Defroster And Heated

    Electric Rear Window Defroster and Heated Sideview Mirrors – If Equipped The Electric Rear Window Defroster and Heated side view mirrors are activated by pressing the heated grid button, located on the Climate Control panel, with the ignition On. Turning Off the rear window defroster or the ignition will deactivate the Electric Rear Window Defroster and Heated side view mirrors feature.
  • Page 86 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Fold the 7 x 10 inch trailer towing mirrors rearward prior to entering an automated car wash. Trailer Towing Position Blindspot Mirror...
  • Page 87: Hands-Free Communication (Uconnect™) - If Equipped

    HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED NOTE: The sales code RER radio contains an inte- grated Hands-Free Communication (UConnect™) sys- tem. Refer to your “Navigation User’s Manual” for UConnect™ system operating instructions for this ra- dio. UConnect™ is a voice-activated, hands-free, in- vehicle communications system.
  • Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE your phone is turned on and has been paired to the vehicle’s UConnect™ system. The UConnect™ system allows up to seven cellular phones to be linked to system. Only one linked (or paired) cellular phone can be used with the system at a time.
  • Page 89: Operations

    Headset Profile), you may not be able to use any UCon- nect™ features. Refer to your cellular service provider or the phone manufacturer for details. The UConnect™ system is fully integrated with the vehicle’s audio system. The volume of the UConnect™ system can be adjusted either from the radio volume control knob, or from the steering wheel radio control (right switch), if so equipped.
  • Page 90 To complete the pairing process, you will need to refer- ence your cellular phone owner’s manual. One of the following vehicle specific websites may also provide detailed instructions for pairing with the brand of phone that you have: NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect...
  • Page 91 The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing and follow the audible prompts. • When prompted, after the voice on beep, say Pair a Phone and follow the audible prompts.
  • Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call/Dial by Saying a Number • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Dial. • System will prompt you to say the number you want call.
  • Page 93 Add Names to Your UConnect™ Phonebook NOTE: Adding names to phonebook is recommended when vehicle is not in motion. • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Phonebook New Entry. • When prompted, say the name of the new entry. Use of long names helps the voice recognition and is recom- mended.
  • Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You will then be asked for the name of the phonebook entry that you wish to edit. • Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. •...
  • Page 95 • After you enter the name, the UConnect™ system will ask you which designation you wish to delete, home, work, mobile, or pager. Say the designation you wish to delete. • Note that only the phonebook entry in the current language is deleted.
  • Page 96: Phone Call Features

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features The following features can be accessed through the UConnect™ system if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the UConnect™...
  • Page 97 Making a Second Call while Current Call in Progress To make a second call while you are currently in a call, press the ’Voice Recognition’ button and say Dial or Call followed by the phone number or phonebook entry you wish to call. The first call will be on hold while the second call is in progress.
  • Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Termination To end a call in progress, momentarily press the Phone’ button. Only the active call(s) will be terminated and if there is a call on hold, it will become the new active call. If the active call is terminated by the far end, a call on hold may not become active automatically.
  • Page 99: Uconnect™ System Features

    UConnect™ System Features Language Selection To change the language that the UConnect™ system is using, • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say the name of the language you wish to switch to (English, Espanol, or Francais, if so equipped).
  • Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The emergency number dialed is based on the Country where the vehicle is purchased (911 for USA and Canada and 060 for Mexico). The number dialed may not be applicable with the available cellular service and area. The UConnect™...
  • Page 101 Working with Automated Systems This method is designed to be used in instances where one generally has to press numbers on the cellular phone keypad while navigating through an automated tele- phone system. You can use your UConnect™ system to access a voice- mail system or an automated service, such as, paging service or automated customer service.
  • Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts On/Off Turning confirmation prompts off will stop the system from confirming your choices (e.g., the UConnect™ system will not repeat a phone number before you dial it). • Press the ’Phone’ button to begin. •...
  • Page 103: Advanced Phone Connectivity

    Mute/Un-mute (Mute off) When you mute the UConnect™ system, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the UConnect™ system: •...
  • Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Connect or Disconnect Link Between the UConnect™ System and Cellular Phone Your cellular phone can be paired with many different electronic devices, but can only be actively connected with one electronic device at a time. If you would like to connect or disconnect the Blue- tooth™...
  • Page 105 Select another Cellular Phone This feature allows you to select and start using another phone with the UConnect™ system. The phone must have been previously paired to the UConnect™ system that you want to use it with. • Press the ’Phone’ button to begin. •...
  • Page 106: Things You Should Know About Your Uconnect™ System

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your UConnect™ System Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. To enter this training mode, follow one of the two procedures: From outside the UConnect mode (e.g.
  • Page 107 • low road noise, • smooth road surface, • fully closed windows, • dry weather condition. • In a convertible vehicle, the system performance may be compromised with roof top down. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some.
  • Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Far End Audio Performance • Audio quality is maximized under: • low-to-medium blower setting, • low-to-medium vehicle speed, • low road noise, • smooth road surface, • fully closed windows, and • dry weather condition. •...
  • Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
  • Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111...
  • Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE North American English Primary Alternate(s) Zero Three Four Five Seven Eight Nine Star (*) Plus (+) Pound (#) Add Location Call Cancel Confirmation Prompts Continue Delete Dial Edit Emergency English Erase All Espanol Francais Help Home...
  • Page 113: General Information

    Mobile Mute Mute off New entry Pager Pair a phone Phone pairing Pairing Phonebook Phone book Previous Record again Redial Return to main menu Return. Main menu Select phone Select Send Set up Phone settings / Phone set up UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Towing assistance Transfer call Try again...
  • Page 114: Seats

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS The seating options available in this truck are the result of extensive customer research and evaluations. Seats are also a primary part of the Occupant Restraint (protection) System of the vehicle. They need to be used properly for safe operation of the vehicle.
  • Page 115: Reclining Seats

    Each outboard seat is independently adjustable forward or rearward and is equipped with a back recliner. The manual forward or rearward seat adjustment handle is found at the front edge of each seat cushion. Pull up on the handle and slide the seat to get the most comfortable position.
  • Page 116: Adjustable Head Restraints

    116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! You can be seriously, even fatally, injured riding in a seat with the seatback reclined. Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. If you ride in this position, the shoulder harness will no longer be restraining you.
  • Page 117: Manual Rotary Lumbar Support Adjustment - If Equipped

    Manual Rotary Lumbar Support Adjustment — If Equipped Rotating the lumbar control knob on the left side of the driver’s seatback and on the right side of the passenger’s seatback increases or decreases the lumbar (lower back) support. Manual Lumbar Adjustment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Power Seats —...
  • Page 118 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Up, Down, Forward, and Rearward The power seat controls are on the outboard side of the front seat cushions. Three switches control the seat move- ment. The four-way switch in the center can be moved forward or backwards to get the most comfortable posi- tion.
  • Page 119: Heated Seats - If Equipped

    Heated Seats — If Equipped The heated seat switches are located in the instrument panel under the climate controls. Heated Seat Switches UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Each heated seat switch has two settings (HI and LOW). Press the switch once to obtain High heat level, then press the switch again to obtain Low heat level.
  • Page 120: To Open And Close The Hood

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater.
  • Page 121 To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the front center of the hood to ensure that both latches engage. Secondary Latch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision.
  • Page 122: Lights

    122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlight Switch Location Interior Lights Dimmer Control Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the right side of the switch) is rotated to the upward detent position, or if equipped, when the UN- LOCK button is pressed on the key fob.
  • Page 123: Battery Saver

    open and the interior lights are on, rotating the dimmer control all the way down to the OFF detent will cause all the interior lights to go out. This is also known as the Party mode because it allows the doors to stay open for extended periods of time without discharging the vehi- cle’s battery.
  • Page 124: Headlamp Delay

    124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlamp Delay To aid in your exit, your vehicle is equipped with a headlamp delay that will leave the headlamps on for 90 seconds. This delay is initiated when the ignition is turned OFF while the headlamp switch is on, and then the headlamp switch is cycled off.
  • Page 125: Daytime Running Lights (Canada Only And Fleet Vehicles)

    Your vehicle is equipped with plastic headlight lenses that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed. To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth.
  • Page 126: Multifunction Control Lever

    126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE beam. An indicator light located in the instrument cluster will illuminate when the fog lights are on. The fog lights will turn off when the switch is pushed a second time, when the headlight switch is rotated to the OFF position, or the high beam is selected.
  • Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Passing Light You can signal another vehicle with your headlights by partially pulling the multifunction lever toward the steer- ing wheel. This will cause the high beam headlights to turn on until the lever is released. High Beam / Low Beam Select Switch Pull the multifunction control lever fully toward the steering wheel to switch the headlights from HIGH or...
  • Page 128: Windshield Wipers And Washers

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wipers Windshield Wiper / Washer Switch The wipers and washers are operated by a switch in the multifunction control lever. Turn the end of the handle to select the desired wiper speed. Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle,...
  • Page 129: Windshield Washers

    WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
  • Page 130: Tilt Steering Column

    130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN To tilt the column, pull rearward on the lever below the turn signal control and move the wheel up or down, as desired. Push the lever forward to lock the column firmly in place.
  • Page 131: Driver Adjustable Pedals - If Equipped

    DRIVER ADJUSTABLE PEDALS — IF EQUIPPED Adjustable Pedals Switch The power adjustable accelerator and brake pedals allow the driver to establish a comfortable position relative to the steering wheel and pedals. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Adjustment 1. Position the driver seat so that you are at least 10 inches (254 mm) away from the airbag located in the center of the steering wheel.
  • Page 132: Electronic Speed Control - If Equipped

    132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become lim- ited if movement is stopped by an obstruction in the adjustable pedal’s path.
  • Page 133: To Activate

    To Activate Push the ON/OFF button to the ON position. An indi- cator light in the instrument cluster illuminates when the system is on. To Set At A Desired Speed When the vehicle has reached the desired speed, press and release the SET button. Release the accelerator and the vehicle will operate at the selected speed.
  • Page 134: To Accelerate For Passing

    134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tapping the ACCEL button once will result in a 2 mph (3km/h) speed increase. Each time the button is tapped, speed increases so that tapping the button three times will increase speed by 6 mph (10 km/h), etc. Tapping the DECEL button once will result in a 1 mph (2 km/h) speed decrease.
  • Page 135: Overhead Console With Compass/Temperature Mini-Trip Computer - If Equipped

    OVERHEAD CONSOLE WITH COMPASS/TEMPERATURE MINI-TRIP COMPUTER — IF EQUIPPED This optional overhead console consists of the following: • Courtesy Lights • Compass/Temperature Mini-Trip Computer (CMTC) UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 This overhead console allows you to choose between a compass/temperature display and one of four trip con- ditions being monitored.
  • Page 136: Reset Button

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE RESET Button Use this button to reset the following displays: Average Fuel Economy (AVG ECO) Trip Odometer (ODO) Elapsed time (ET) Global Reset If the RESET button is pressed twice within 2 seconds while in any of the 3 resettable displays (AVG ECO, ODO, ET), the Global Reset will reset all 3 displays.
  • Page 137: Average Fuel Economy (Avg Eco)

    Average Fuel Economy (AVG ECO) Shows the average fuel economy since the last reset. Average fuel economy is a running average of the amount of fuel used and the distance the vehicle has traveled. When the fuel economy is reset, the display will momen- tarily blank.
  • Page 138: Trip Odometer (Odo)

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: It is possible for DTE to display “LO FUEL” before the low fuel warning light turns on in the instru- ment cluster. This could occur because low fuel warning is set to a specified fuel tank volume and DTE is an estimated distance calculation based on fuel economy and remaining fuel tank volume.
  • Page 139: C/T Button

    C/T Button Use this button to select a readout of the outside tem- perature and one of eight compass headings that indicate the direction in which the vehicle is facing. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! Even if the display still reads a few degrees above 32°F ( 0°C), the road surface may be icy, particularly in woods or on bridges.
  • Page 140: Manual Compass Calibration

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Compass Calibration NOTE: To ensure proper compass calibration, make sure the compass variance is properly set before manu- ally calibrating the compass. If the compass appears erratic and the CAL symbol does not appear, you must manually put the compass into the “Calibration”...
  • Page 141: Outside Temperature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 NOTE: The default for the compass variance is zone 8. To set the variance: Turn the ignition ON and set the display to “Compass/Temperature.” Press and hold the RESET button approximately five seconds. The last vari- ance zone number will be displayed.
  • Page 142: Overhead Console With Electronic Vehicle Information Center (Evic) - Diesel Only

    142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE WITH ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — DIESEL ONLY The overhead console contains dome/reading lights, and an Electronic Vehicle Information Center (EVIC). Dome/Reading Lights Located in the overhead console are two dome/reading lights.
  • Page 143: Electronic Vehicle Information Center (Evic) - If Equipped

    Electronic Vehicle Information Center (EVIC) — If Equipped Overhead Console with EVIC Pressing the menu button will change the display to one of the following features: UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Trip Functions Pressing the STEP button allows you to scroll through one of the following Trip Function features: •...
  • Page 144 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the reset. (Example: If your Electronic Vehicle Informa- tion Center (EVIC) displays 18 AVG. MPG and the RESET button is pressed, the previous averaging his- tory will be erased and the display will return to the 18 AVG.
  • Page 145 • DOOR(S) AJAR (with a single chime if vehicle is in motion) • LOW WASHER FLUID (with a single chime) • OIL CHANGE REQUIRED (with a single chime) • CATALYST FULL SEE OWNER MANUAL • CATALYST STAT lllllll 90% • CATALYST FULL SERVICE REQUIRED •...
  • Page 146 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure. Personal Settings (Customer Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK.
  • Page 147 remote keyless entry unlock button twice to unlock the passenger’s doors. To make your selection, press and release the RESET button until “DRV DR 1st ” appears. • “RKE UNLOCK ALL DR 1ST” – When All ALL DR 1ST is selected, all of the doors will unlock on the first press of the remote keyless entry unlock button.
  • Page 148: Compass/Temperature Button

    148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “ILLUMINATED APRCH > OFF” – When this feature is selected, the headlights will activate and remain on for up to 90 seconds when the doors are unlocked with the remote keyless entry transmitter. To make your selection, press and release the RESET button until “OFF,”...
  • Page 149 Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic and the EVIC will display “CAL” until the compass is calibrated. You may also calibrate the compass by completing one or more 360°...
  • Page 150 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Compass Variance Compass Variance is the difference between magnetic North and Geographic North. In some areas of the country, the difference between magnetic and geographic North is great enough to cause the compass to give false readings.
  • Page 151: Electrical Power Outlets

    1. Turn the ignition switch to the ON/RUN position. 2. Press the menu button until Personal Settings is displayed. 3. Press the STEP button until “Compass Variance” is displayed. 4. Press and release RESET button until the proper variance zone is selected according to the map. 5.
  • Page 152: Cigar Lighter And Ash Receiver

    152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Electrical Outlet Use With Engine Off • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
  • Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Ash Tray Automatic Transmission Ash Tray Manual Transmission...
  • Page 154: Cupholders

    154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Instrument Panel Cupholders (40–20–40 Seats) — Automatic Transmission Your new Ram truck is equipped with two adjustable cupholders. The cupholder is opened by pulling on the cup holder door handle, on the front surface. Each opening in the cupholder is adjustable and will hold cups and mugs of various sizes.
  • Page 155: Front Instrument Panel Cupholders

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Front Instrument Panel Cupholders (Bucket Seats) — Automatic Transmission If your new Ram truck is equipped with bucket seats there are three cup holders located on the front of the center console. Cup Holders Automatic Transmission Cup Holders Bucket Seat...
  • Page 156: Front Instrument Panel Cupholders - Manual

    156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Instrument Panel Cupholders — Manual Transmission Cup Holders Manual Transmission Rear Cupholder (Quad Cab) — If Equipped Quad Cab vehicles may be equipped with a rear cup- holder that consists of two cupwells for rear passenger convenience.
  • Page 157: Storage

    STORAGE Center Storage Compartment (40–20–40 Seat) — If Equipped The center portion of the seat folds down to provide an armrest with unique storage compartments under the lid. Push the button on the front of the armrest to raise the cover.
  • Page 158: Center Storage Compartment (Bucket Seats) - If Equipped

    158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
  • Page 159 storage area into separate compartments. Lift the lower handle on the front of the armrest, and raise the armrest for access to the lower storage bin. On Quad Cab models the rear of the floor console offers a power outlet, and a tip out bin.
  • Page 160: Storage And Seats (Quad Cab Models)

    160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Storage and Seats (Quad Cab Models) Located in the center of the front 40/20/40 seat cushion there is a storage compartment. Standard cab models also have storage behind the seat. The Quad Cab models provide additional storage under the rear seat.
  • Page 161: Plastic Grocery Bag Retainers

    Plastic Grocery Bag Retainers Retainer hooks which will hold plastic grocery bag handles are built into the back panel of the cab, behind the rear seat. Grocery Bag Hooks UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 REAR WINDOW FEATURES Electric Rear Window Defroster and Heated Side view Mirrors —...
  • Page 162: Power Sliding Rear Window - If Equipped

    162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sliding Rear Window — If Equipped Power Sliding Rear Window Switch The power sliding rear window switch is located on the instrument panel below the climate controls. Press the right side of the switch to open the glass and the left side of the switch to close the glass.
  • Page 163: Fold Flat Load Floor - If Equipped

    FOLD FLAT LOAD FLOOR — IF EQUIPPED Quad Cab models with a 60/40 rear seat, may be equipped with a folding load floor. Quad Cab Rear 60/40 Seat UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 WARNING! Do not operate the vehicle with loose items stored on the load floor.
  • Page 164 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Unfolding the Load Floor 1. Lift the 60/40 seat cushion(s) to the upward position. Unfolding The Load Floor 2. Grasp the knob on the load floor and lift the knob until the load floor unfolds into position. Load Floor In Open Position 3.
  • Page 165 Positioning the Load Floor for Storage Access Under the Seat 1. Lift the 60/40 seat cushion(s) to the upward position. 2. Unsnap the securing snap located at either side of the load floor. 3. Lift the load floor up to access storage under the load floor.
  • Page 167 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instruments And Controls ....171 Instrument Clusters ..... 172 5.7L Gas Engines .
  • Page 168: Understanding Your Instrument Panel

    168 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Hands Free Phone — If Equipped ......193 Operating Instructions - Satellite Radio —...
  • Page 169 Noise Reduction ..... . 214 Operation Instructions - (CD Mode For CD Audio Play) ......214 Load/Eject Button (CD Mode For CD Audio Play) .
  • Page 170 170 UNDERSTANDING YOUR INSTRUMENT PANEL PTY Button Seek ..... 229 Satellite Antenna ..... . 229 Reception Quality .
  • Page 171: Instruments And Controls

    UNDERSTANDING YOUR INSTRUMENT PANEL 171 INSTRUMENTS AND CONTROLS...
  • Page 172: Instrument Clusters

    172 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTERS 5.7L Gas Engines...
  • Page 173: 6.7L Cummins Diesel Engines

    UNDERSTANDING YOUR INSTRUMENT PANEL 173 6.7L Cummins Diesel Engines...
  • Page 174: Instrument Cluster Description

    174 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTION 1. Check Gages This light illuminates when the Voltmeter, Engine Oil Pressure or Engine Coolant Temperature gages indicate a reading either too high or too low. Examine the gages carefully, and follow the instructions contained below for each indicated problem.
  • Page 175 3. Turn Signal Indicators Lights in instrument cluster flash when outside turn signals are operating. 4. Tachometer The tachometer indicates engine speed in revolutions per minute. CAUTION! Do not operate the engine with the tachometer pointer at high rpm for extended periods. Engine damage may occur.
  • Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL 9. Oil Pressure Gauge The pointer should always indicate some oil pres- sure when the engine is running. A continuous high or low reading, under normal driving conditions, may indicate a lubrication system malfunction. Immedi- ate service should be obtained.(See page 406 for more information.) NOTE: If the gauge pointer moves to either extreme of...
  • Page 177 CAUTION! Do not leave your vehicle unattended with the en- gine running as you would not be able to react to the temperature indicator if the engine overheats. NOTE: Engine idle speed will automatically increase to 1000 rpm at elevated coolant temperatures to improve engine cooling.
  • Page 178 178 UNDERSTANDING YOUR INSTRUMENT PANEL The two trip odometers show individual trip mileage. To switch from odometer to trip odometers, press and release the Trip Odometer button. To reset a trip odometer, display the desired trip odom- eter to be reset then push and hold the button until the display resets (approximately 2 seconds).
  • Page 179 seconds after a single chime has sounded to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position.
  • Page 180 180 UNDERSTANDING YOUR INSTRUMENT PANEL If this light comes on and remains on while driving, it suggests a potential engine control problem and the need for system service. Although your vehicle will usually be drivable and not need towing, see your dealer for service as soon as possible.
  • Page 181 Acceleration which causes the rear wheels to slip for a period of time may result in the red brake light illumi- nating and a brake switch code being set on ABS equipped vehicles. Depressing the brake pedal should extinguish the red brake light. 20.
  • Page 182 182 UNDERSTANDING YOUR INSTRUMENT PANEL the electric shift 4WD system. If the SERV 4WD light stays on or comes on during driving, it means that the 4WD system is not functioning properly and that service is required. 23. Water In Fuel Indicator — Diesel Only Indicates there is water detected in the fuel filter.
  • Page 183: Electronic Digital Clock

    27. Fuel Gauge Shows level of fuel in tank when ignition switch is in the ON position. 28. Low Fuel Warning Light Glows when the pointer is between “E” and 1/8 indication mark (approximately 15% of tank vol- ume) on the fuel gauge. When the fuel gauge pointer is on “E”...
  • Page 184: Clock Setting Procedure

    184 UNDERSTANDING YOUR INSTRUMENT PANEL On the RAQ radio the time button alternates the location of the time and frequency on the display. On the REF only one of the two, time or frequency is displayed at a time. Clock Setting Procedure 1.
  • Page 185: Electrical Disturbances

    Electrical Disturbances Radio waves may pick up electrical disturbances during transmission. They mainly affect the wave amplitude, and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal. AM Reception AM sound is based on wave amplitude, so AM reception can be disrupted by such things as lightning, power lines and neon signs.
  • Page 186: Sales Code Ref - Am/Fm/Cd (Single Disc) Radio With Optional Satellite Radio And Hands Free Phone Capability

    186 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE REF — AM/FM/CD (SINGLE DISC) RADIO WITH OPTIONAL SATELLITE RADIO AND HANDS FREE PHONE CAPABILITY NOTE: The radio sales code is located on the lower right side of your radio faceplate. REF Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
  • Page 187 Mode Button (Radio Mode) Press the mode button repeatedly to select between the CD player and Satellite Radio (if equipped). SEEK Button (Radio Mode) Press and release the SEEK button to search for the next listenable station in either AM/FM or Satellite (if equipped) mode.
  • Page 188 188 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune/ Audio control. 3. After the hours are adjusted, press the right side Tune/Audio control to set the minutes.
  • Page 189 Press the rotary TUNE control a fourth time and BAL will display. Turn the TUNE control to the right or left to adjust the sound level from the right or left side speakers. Press the rotary TUNE control a fifth time and FADE will display.
  • Page 190: Operation Instructions - Cd Mode

    190 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - CD Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Inserting The Compact Disc (Single CD Player) Gently insert one CD into the CD player with the CD label facing up.
  • Page 191 SCAN Button (CD Mode) Press this button to play the first 10 seconds of each track. To stop the scan function, press the button a second time. EJECT Button (CD Mode) Press this button and the disc will unload and move to the entrance for easy removal.
  • Page 192: Operation Instructions - Auxiliary Mode

    192 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3 player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
  • Page 193: Operating Instructions - Hands Free Phone - If Equipped

    TIME Button (Auxiliary Mode) Press this button to change the display from elapsed playing time to time of day. The time of day will display for 5 seconds. RW/FF (Auxiliary Mode) No function. RND/SET Button (Auxiliary Mode) No function. Mode Button (Auxiliary Mode) Press the mode button repeatedly to select between the CD player and Satellite Radio (if equipped).
  • Page 194: Sales Code Raq - Am/Fm/Cd (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, And Vehicle Entertainment Systems (Ves) Capabilities

    194 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAQ – AM/FM/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, AND VEHICLE ENTERTAINMENT SYSTEMS (VES) CAPABILITIES NOTE: The radio sales code is located on the lower right side of your radio faceplate. RAQ Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
  • Page 195 Mode Button (Radio Mode) Press the mode button repeatedly to select between the CD player, Satellite Radio, or Vehicle Entertainment System (VES) (if equipped). SEEK Button (Radio Mode) Press and release the SEEK button to search for the next listenable station in either AM/FM or Satellite (if equipped) mode.
  • Page 196 196 UNDERSTANDING YOUR INSTRUMENT PANEL Time Button Press the time button and the time of day will be displayed for 5 seconds. Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune / Audio control.
  • Page 197 Press the rotary TUNE control a third time and TREBLE will display. Turn the TUNE control to the right or left to increase or decrease the Treble tones. Press the rotary TUNE control a fourth time and BAL- ANCE will display. Turn the TUNE control to the right or left to adjust the sound level from the right or left side speakers.
  • Page 198 198 UNDERSTANDING YOUR INSTRUMENT PANEL Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Top 40 Weather By pressing the SEEK button when the PTY icon is Jazz displayed, the radio will be tuned to the next frequency News...
  • Page 199: Operation Instructions

    You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET/DIR button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
  • Page 200 200 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! This CD player will accept 4 3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. You may eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc.
  • Page 201: Load/Eject Button (Cd Mode For Cd Audio Play)

    LOAD/EJECT Button (CD Mode for CD Audio Play) LOAD/ EJECT - Load Press the LOAD/ EJECT button and the push- button with the corresponding number where the CD is being loaded. The radio will display PLEASE WAIT and prompt when to INSERT DISC.
  • Page 202 202 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (CD MODE for CD Audio Play) Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF (CD MODE for CD Audio Play) Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed.
  • Page 203: Notes On Playing Mp3 Files

    Notes On Playing MP3 Files The radio can play MP3 files, however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CD-ROM, CD-R and CD-RW.
  • Page 204 204 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.mp3 exten- sion as MP3 files. Non-MP3 files named with the *.mp3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
  • Page 205: Operation Instructions - (Cd Mode For Mp3 Audio Play)

    Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: •...
  • Page 206 206 UNDERSTANDING YOUR INSTRUMENT PANEL LOAD / EJECT - Eject Press the LOAD/ EJECT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
  • Page 207 AM/FM Button (CD Mode for MP3 Play) Switches back to Radio mode. RND/ PTY Button (CD Mode for MP3 Play) Pressing this button plays files randomly. SET/DIR Button (CD Mode for MP3 Play) Press the SET/DIR Button to display folders, when playing an MP3 discs that have a file/folder structure.
  • Page 208: Sales Code Rak - Am/Fm/Cassette/Cd (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, Video, Mp3, And Wma Capabilities

    208 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAK – AM/FM/CASSETTE/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, VIDEO, MP3, and WMA CAPABILITIES NOTE: The radio sales code is located on the lower right side of your radio faceplate. RAK Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
  • Page 209 SEEK Button (Radio Mode) Press and release the SEEK button to search for the next station in either AM/FM or Satellite (if equipped) mode. Press the right side of the button to seek up and the left side to seek down. The radio will remained tuned to the new station until you make another selection.
  • Page 210 210 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF (Radio Mode) Pressing the rewind/fast forward button causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM, FM or Satel- lite (if equipped) frequencies. TUNE Control (Radio Mode) Turn the right side rotary control to increase or decrease the frequency.
  • Page 211 Turn the tune knob to select the following format types: 16 Digit-Character Dis- Program Type No program type or un- defined News Information Sports Talk Rock Classic Rock Adult Hits Soft Rock Top 40 Country Oldies Soft UNDERSTANDING YOUR INSTRUMENT PANEL 211 Nostalgia play Classical...
  • Page 212: Operating Instructions - Tape Player

    212 UNDERSTANDING YOUR INSTRUMENT PANEL If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station. NOTE: If you have selected a PTY with the tune knob, simply pressing the tune button in will go directly to a “PTY seek”.
  • Page 213: Fast Forward (Ff)

    Fast Forward (FF) Press the FF button up momentarily to advance the tape in the direction that it is playing. The tape will advance until the button is pressed again or the end of the tape is reached. At the end of the tape, the tape will play in the opposite direction.
  • Page 214: Noise Reduction

    214 UNDERSTANDING YOUR INSTRUMENT PANEL Noise Reduction The Dolby Noise Reduction System* is on whenever the tape player is on, but may be switched off. To turn off the Dolby Noise reduction System: Press Preset 1 after you insert the tape. The NR light in the display will go off when the Dolby System is off.
  • Page 215: Load/Eject Button (Cd Mode For Cd Audio Play)

    SEEK Button (CD MODE for CD Audio Play) Press the right side of the SEEK button for the next selection on the CD. Press the left side of the button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first 5 seconds of the current selection.
  • Page 216 216 UNDERSTANDING YOUR INSTRUMENT PANEL radio, the radio will remain in CD mode and display INSERT DISC” for 2 minutes. After 2 minutes, the radio will go to the previous tuner mode. The disc can be ejected with the radio and ignition OFF. TIME Button (CD MODE for CD Audio Play) Press this button to change the display from a large CD playing time display to a small CD playing time display.
  • Page 217: Notes On Playing Mp3 Files

    Buttons 1 - 6 (CD MODE for CD Audio Play) Selects disc positions 1 - 6 for Play/Load/Eject. Notes On Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions.
  • Page 218 218 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.mp3 exten- sion as MP3 files. Non-MP3 files named with the *.mp3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
  • Page 219: Operation Instructions - (Cd Mode For Mp3 And Wma Audio Play)

    Playback of MP3 and WMA Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 and WMA files may be affected by the following: •...
  • Page 220 220 UNDERSTANDING YOUR INSTRUMENT PANEL LOAD/EJT - Eject Press the LOAD/EJT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
  • Page 221 AM/FM Button (CD Mode for MP3 Play) Switches back to Radio mode. RND/PTY Button (CD Mode for MP3 Play) Pressing this button plays files randomly. SET/DIR Button (CD Mode for MP3 Play) Press the SET/DIR Button to display folders, when playing an MP3 discs that have a file/folder structure.
  • Page 222: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System

    222 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE REC — AM/FM/CD (6–DISC) RADIO WITH NAVIGATION SYSTEM REC Radio Satellite Navigation Radio with CD Player with MP3 Capability (REC) - combines a Global-Positioning System-based navigation system with an integrated color screen to provide maps, turn identification, selection menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD changer with MP3 capability.
  • Page 223 the worldwide standard for time. This makes the sys- tem’s clock very accurate once the appropriate time zone and daylight savings information is set. 1. At the Main Menu screen, highlight “Clock Setup” and press ENTER OR press and hold for 3 seconds the TIME button on the unit’s faceplate.
  • Page 224 224 UNDERSTANDING YOUR INSTRUMENT PANEL 1. At the Clock Setup screen highlight “Displayed Clock: User Defined Clock”. 2. To increase the clock by hours, make sure “HR +” is highlighted and press ENTER. Press ENTER again to increase the clock by another hour. You will see on the “User Defined Time”...
  • Page 225: Audio Clock Display

    Audio Clock Display Select this option to change the size of the clock on the audio screens. 1. When you are at an audio screen, quickly press the TIME button on the navigation faceplate. 2. In this example the large clock appears on the screen. UNDERSTANDING YOUR INSTRUMENT PANEL 225 3.
  • Page 226: Video Entertainment System (Sales Code Xrv) - If Equipped

    226 UNDERSTANDING YOUR INSTRUMENT PANEL VIDEO ENTERTAINMENT SYSTEM (SALES CODE XRV) — IF EQUIPPED The optional VES™ (Video Entertainment System) con- sists of a DVD player and LCD (liquid crystal display) screen, a battery-powered remote control, and two head- sets. The system is located in the headliner behind the front row seat.
  • Page 227: Electronic Serial Number/Sirius Identification Number (Esn/Sid)

    Electronic Serial Number/Sirius Identification Number (ESN/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access with REF Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and Time buttons simultaneously for 3 seconds.
  • Page 228: Selecting Satellite Mode In Ref, Raq, And Rak Radios

    228 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting Satellite Mode in REF, RAQ, and RAK Radios Selecting Satellite Mode — REF Radio Press the MODE button repeatedly until the word SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode.
  • Page 229: Storing And Selecting Pre-Set Channels

    Storing and Selecting Pre-Set Channels In addition to the 12 AM and 12 FM pre-set stations, you may also commit 12 satellite stations to push button memory. These satellite channel pre-set stations will not erase any AM or FM pre-set memory stations. Follow the memory pre-set procedures that apply to your radio.
  • Page 230: Reception Quality

    230 UNDERSTANDING YOUR INSTRUMENT PANEL Reception Quality Satellite reception may be interrupted due to one of the following reasons. • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception. •...
  • Page 231: Radio Operation

    The left hand control is a rocker type switch with a push button in the center. The function of the left hand control is different depending on which mode you are in. The following describes the left hand control operation in each mode.
  • Page 232: Cassette Tape And Player Maintenance

    232 UNDERSTANDING YOUR INSTRUMENT PANEL CASSETTE TAPE AND PLAYER MAINTENANCE To keep the cassette tapes and player in good condition, take the following precautions: 1. Do not use cassette tapes longer than C-90; otherwise, sound quality and tape durability will be greatly dimin- ished.
  • Page 233: Compact Disc Maintenance

    COMPACT DISC MAINTENANCE To keep the compact discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge. 3.
  • Page 234: Climate Controls

    234 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS Heater Only — If Equipped The controls for the heating and ventilation system in this vehicle consist of a series of rotary knobs. These comfort controls can be set to obtain desired interior conditions. Manual Heating Controls Climate Control Location...
  • Page 235 The mode control (at the right of the control panel) can be set in any of the following positions: NOTE: To improve your selection choices, the system allows you to operate at intermediate positions between the major modes. These intermediate positions are iden- tified by the small dots.
  • Page 236 236 UNDERSTANDING YOUR INSTRUMENT PANEL Defrost Outside air is primarily directed to the windshield through the defroster outlets located at the base of the windshield, and the demister outlets located at the edge of each side of the instrument panel. Blower Control The rotary knob on the left of the control panel is the blower control.
  • Page 237: Air Conditioning And Heating

    Air Conditioning and Heating — If Equipped Air Conditioning And Heating UNDERSTANDING YOUR INSTRUMENT PANEL 237 Air Conditioning Operation To turn on the Air Conditioning, set the fan control at any speed and press the snowflake button located at the right of the control panel. Conditioned air will be directed through the outlets selected by the mode control.
  • Page 238 238 UNDERSTANDING YOUR INSTRUMENT PANEL The mode control (at the right of the control panel) can be set in any of the following positions: NOTE: To improve your selection choices, the system allows you to operate at intermediate positions between the major modes.
  • Page 239 Defrost Outside air is primarily directed to the windshield through the defroster outlets located at the base of the windshield, and the demister outlets located at the edge of each side of the instrument panel, and the air conditioning may be on. Blower Control The rotary knob on the left of the control panel is the blower control.
  • Page 240: Air Conditioning With Dual Zone Temperature Control - If Equipped

    240 UNDERSTANDING YOUR INSTRUMENT PANEL edges of the instrument panel. The demisters also pro- vide extra air ducts for circulation. They are in operation whenever the Floor, Mix or Defrost modes are in use. To remove frost from the side windows, it is best to use the full defrost mode.
  • Page 241 Air Conditioning and Heating Operation To turn on the Air Conditioning, set the fan control at any speed and press the snowflake button located on the control panel. Conditioned air will be directed through the outlets selected by the mode control. A light in the snowflake button shows that the air conditioning is on.
  • Page 242 242 UNDERSTANDING YOUR INSTRUMENT PANEL the major modes. These intermediate positions are iden- tified by the small dots and give an even blend of both modes. Panel Outside air flows through the outlets located in the instrument panel. These outlets can be adjusted to direct the airflow.
  • Page 243 Dual Zone Temperature Control Dual Zone Temperature Control Use this control to regulate the temperature of the air inside the passenger compartment. This is accomplished by having separate temperature control slides for both the driver and front passenger. The blue area of the scale indicates cooler temperatures while the red area indicates warmer temperatures.
  • Page 244: Operating Tips

    244 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Fast Cooldown For a fast cooldown, turn the blower fan rotary knob to the extreme right position, turn the mode control to the panel fresh position, press the snowflake button to turn on the air conditioning, and drive with the windows open for the first few minutes.
  • Page 245 Summer Operation Air conditioned vehicles must be protected with a high quality antifreeze coolant during summer to provide proper corrosion protection and to raise the boiling point of the coolant for protection against overheating. A 50 % concentration is recommended. Refer to Recommended Fluids and Genuine Parts for the proper coolant type.
  • Page 246: Operating Tips Chart

    246 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Chart...
  • Page 247 STARTING AND OPERATING CONTENTS Starting Procedures – Gas Engines ... 252 Manual Transmission – If Equipped ..252 Automatic Transmission – If Equipped ..252 Normal Starting .
  • Page 248: Starting And Operating

    248 STARTING AND OPERATING Operating Precautions ....268 Cooling System Tips — Automatic Transmission ......268 Engine Block Heater (Gas Engines)—...
  • Page 249 Stationary Mode ..... . 302 Mobile Mode ......303 Power Take Off –...
  • Page 250 250 STARTING AND OPERATING Alignment And Balance ....332 Supplemental Tire Pressure Information — If Equipped ......333 Tire Chains .
  • Page 251 Before Plowing ..... . . 366 Snowplow Prep Package Model Availability . . 366 Over The Road Operation With Snowplow Attached .
  • Page 252: Starting Procedures - Gas Engines

    252 STARTING AND OPERATING STARTING PROCEDURES – GAS ENGINES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. The starter should not be operated for more than 15- second intervals. Waiting a few seconds between such intervals will protect the starter from overheating.
  • Page 253: Normal Starting

    Normal Starting Normal starting of either a warm or cold engine is obtained without pumping or depressing the accelerator pedal. Turn the key to the START position and release when the engine starts. If the engine fails to start within 10 seconds, turn the key to the OFF position, wait 5 seconds, then repeat the starting procedure.
  • Page 254 254 STARTING AND OPERATING CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. WARNING! Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle.
  • Page 255: After Starting

    If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released. If this occurs, continue cranking with the accel- erator pedal pushed all the way to the floor. Release the accelerator pedal and the key once the engine is running smoothly.
  • Page 256: Manual Transmission - If Equipped

    256 STARTING AND OPERATING WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat build up may cause serious injury or death. Manual Transmission – If Equipped Apply the parking brake, place the gearshift control lever in NEUTRAL and depress the clutch pedal to the floor before starting the vehicle.
  • Page 257: Normal Starting Procedure - Engine Manifold Air Temperature Above 66°F (19°C)

    Normal Starting Procedure — Engine Manifold Air Temperature Above 66°F (19°C) Observe the Instrument Panel Cluster lights when start- ing the engine. 1. Always apply the parking brake. 2. Shift into PARK for an automatic transmission. Fully depress and hold the clutch and shift into NEUTRAL for a manual transmission.
  • Page 258: Starting Procedure - Engine Manifold Air Temperature Below 66°F (19°C)

    258 STARTING AND OPERATING 5. When the engine starts, release the key. 6. Check to see that there is oil pressure. 7. Release the parking brake. Starting Procedure — Engine Manifold Air Temperature Below 66°F (19°C) NOTE: The temperature displayed on the overhead console (if equipped) does not necessarily reflect the engine manifold air temperature.
  • Page 259 • Allow the engine to idle about three minutes until the manifold heaters have completed the post-heat cycle. • Release the parking brake and drive. NOTE: Engine idle speed will automatically increase to 1000 rpm at low coolant temperatures to improve engine warm-up.
  • Page 260 260 STARTING AND OPERATING NOTE: Excessive white smoke and poor engine perfor- mance will result if manifold heaters are not recycled. • Heat generated by the manifold heaters dissipates rapidly in a cold engine. If more than two minutes pass between the time the WAIT TO START light goes OFF and the engine is started, recycle the manifold heaters by turning the ignition OFF for at least 5 seconds and then back ON.
  • Page 261: Starting Fluids

    4. Repeat the procedure if the engine does not start. WARNING! Do not open the high pressure fuel system when cranking the engine or with the engine running. Engine operation causes high fuel pressure. High pressure fuel spray can cause serious injury or death. NOTE: The engine may run rough until the air is forced from all the fuel lines.
  • Page 262: Normal Operation - Diesel Engine

    262 STARTING AND OPERATING WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat build up may cause serious injury or death. NORMAL OPERATION – DIESEL ENGINE Observe the following when the engine is operating. •...
  • Page 263: Cold Weather Precautions

    Cold Weather Precautions Operation in ambient temperature below 32°F (0°C) may require special considerations. The following charts sug- gest these options: Fuel Operating Range NOTE: Use “Ultra Low Sulfur Diesel Fuels” ONLY. *No. 1 Ultra Low Sulfur diesel fuel should only be used where extended arctic conditions (-10°F/-23°C) exist.
  • Page 264 264 STARTING AND OPERATING Engine Block Heater The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the heater cord to a ground–fault interrupter protected 110–115 volt AC electrical outlet with a grounded, three-wire exten- sion cord.
  • Page 265 Winter Front Usage If a winter front or cold weather cover is to be used, a percentage of the total grille opening area must be left uncovered to provide sufficient air flow to the charge air cooler and automatic transmission oil cooler. The per- centage of opening must be increased with the increasing ambient air temperature and/or engine load.
  • Page 266: Engine Idling - In Cold Weather

    266 STARTING AND OPERATING If temperatures are below 32°F (0°C), operate the engine at moderate speeds for 5 minutes before full loads are applied. Engine Idling — In Cold Weather Avoid prolonged idling in ambient temperatures below 0°F. Long periods of idling may be harmful to your engine because combustion chamber temperatures can drop so low that the fuel may not burn completely.
  • Page 267: Stopping The Engine

    Stopping The Engine Idle the engine a few minutes before routine shutdown. After full load operation, idle the engine 3 to 5 minutes before shutting it down. This idle period will allow the lubricating oil and coolant to carry excess heat away from the combustion chamber, bearings, internal components, and turbocharger.
  • Page 268: Engine Speed Control

    268 STARTING AND OPERATING Engine Speed Control CAUTION! Prevent overspeeding the engine going down hill. When descending steep grades, use a combination of gears and service brakes to control vehicle/engine speed. Overspeed can cause severe engine damage. Operating Precautions Avoid Overheating The Engine The temperature of the coolant (a mixture of 50% ethylene-glycol and 50% water) must not exceed the normal range of the temperature gauge (240°F/116°C)
  • Page 269 • Up Steep Hills — select a lower transmission gear, but try and keep the torque converter clutch engaged. • Air Conditioning — turn it off temporarily. Do Not Operate The Engine With Low Oil Pressure When the engine is at normal operating temperature, the minimum oil pressures required are: Idle 700 to 800 RPM .
  • Page 270: Engine Block Heater (Gas Engines)- If Equipped

    270 STARTING AND OPERATING ENGINE BLOCK HEATER (GAS ENGINES)— IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 volt AC electrical outlet with a grounded, three-wire extension cord. The engine block heater cord, on gas engines, is routed under the hood on the driver side of the vehicle.
  • Page 271 STARTING AND OPERATING 271 WARNING! Do not use the Exhaust Brake feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control, which may cause an accident possi- bly resulting in personal injury or death.
  • Page 272 272 STARTING AND OPERATING NOTE: For optimum braking power it is recommended to use the Exhaust Brake while in Tow/Haul Mode. The purpose of the exhaust brake (engine braking) fea- ture is to supply negative (braking) torque to the engine. Typically, the engine braking is used for, but not limited to, vehicle towing applications where vehicle braking can be achieved by the internal engine power, thereby spar-...
  • Page 273: Automatic Transmission

    AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
  • Page 274 274 STARTING AND OPERATING lever out of park (P) position (Brake Interlock System). To drive, move the selector lever from Park or Neutral to the desired drive position. Pull the selector lever toward you when shifting into Reverse, Second, First or Park, or when shifting out of Park.
  • Page 275 WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.
  • Page 276 276 STARTING AND OPERATING “1” First Use this position for driving up very steep hills and for engine braking at low speeds 20 mph (32 km/h) or less when going downhill. To prevent excessive engine speed, do not exceed 25 mph (40 km/h) in this range. NOTE: Use caution when operating a heavily loaded vehicle in “2”...
  • Page 277 If the transmission temperature gets extremely hot, the transmission will automatically select the most desirable gear for operation at this temperature. If the transmission temperature becomes hot enough the TRANS TEMP light may illuminate and the transmission may downshift out of Overdrive until the transmission cools down.
  • Page 278 278 STARTING AND OPERATING reduce the potential for transmission overheating or failure due to excessive shifting. When operating in “TOW HAUL” mode, 5th gear is disabled and 2-3 and 3-4 shift patterns are modified. Shifts into Overdrive (4th gear) are allowed during steady cruise (for improved fuel economy) and automatic closed-throttle downshifts to 3rd gear (for improved braking) will occur during steady braking.
  • Page 279: Automatic Transmission (6 Speed As68Rc) - If Equipped

    NOTE: The torque converter clutch will not engage until the transmission fluid and engine coolant are warm [usually after 1-3 miles (1.6 - 4.8 km) of driving]. Because the engine speed is higher when the torque converter clutch is not engaged, it may seem as if the transmission is not shifting into Overdrive when cold.
  • Page 280 280 STARTING AND OPERATING “P” Park This gear position supplements the parking brake by locking the transmission. The engine can be started in this range. Never use Park while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
  • Page 281 WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.
  • Page 282 282 STARTING AND OPERATING “2” Second Use this position for driving on more severe conditions and lower speeds than “3” third. To prevent excessive engine speed do not exceed 25 mph (40 km/h) in this range. “1” First Use this position for driving up very steep hills and for engine braking at low speeds 12 mph (19 km/h) or less when going downhill.
  • Page 283 a suitable level. During this condition, the ability of the vehicle to accelerate under heavily loaded conditions may be reduced. Refer also to the Note under torque converter clutch, later in this section. If the transmission temperature gets extremely hot, the transmission will automatically select the most desirable gear for operation at this temperature.
  • Page 284 284 STARTING AND OPERATING reduce the potential for transmission overheating or failure due to excessive shifting. When operating in “TOW HAUL” mode, 6th gear (if equipped) is disabled and 2-3 and 3-4 and 4–5 shift patterns are modified. Shifts into Overdrive (5th gear) are allowed during steady cruise (for improved fuel economy).
  • Page 285: Manual Transmission

    Torque Converter Clutch A feature, designed to improve fuel economy, has been included in the automatic transmission on your vehicle. A clutch within the torque converter engages automati- cally at calibrated speeds. This may result in a slightly different feeling or response during normal operation in high gear.
  • Page 286: Manual Transmission - 6 Speed (G56)

    286 STARTING AND OPERATING Truck models with manual transmission are equipped with a clutch interlocking ignition system. The clutch pedal must be fully depressed to start the vehicle. Fully depress the clutch pedal before shifting gears. As you release the clutch pedal, lightly depress the accelera- tor pedal.
  • Page 287: Recommended Vehicle Shift Speeds

    To shift into Reverse, come to a complete stop. Depress the clutch and pause briefly to allow the gear train to stop. Reverse has a “crash-through” lockout feature. Move the shift lever from the Neutral position straight across, in one swift motion, and down into Reverse. Recommended Vehicle Shift Speeds To utilize your manual transmission efficiently for both fuel economy and performance, it should be upshifted as...
  • Page 288: Downshifting - Gas Engine

    288 STARTING AND OPERATING Downshifting – Gas Engine Moving from a high gear down to a lower gear is recommended to preserve brakes when driving down steep hills. In addition, downshifting at the right time provides better acceleration when you desire to resume speed.
  • Page 289: Four-Wheel-Drive Operation - If Equipped

    FOUR-WHEEL-DRIVE OPERATION — IF EQUIPPED Four-Wheel-Drive Dodge Ram Trucks are equipped with either a Manually Shifted transfer case or an Electroni- cally Shifted transfer case. See the operating instructions for your transfer case, located within this section. Manually Shifted Transfer Case Operating...
  • Page 290 290 STARTING AND OPERATING This transfer case is intended to be driven in the 2-wheel- drive position (2H) for normal street and highway con- ditions such as dry hard surfaced roads. When additional traction is required the transfer case 4H and 4L positions can be used to lock the front and rear driveshafts together and force the front and rear wheels to rotate at the same speed.
  • Page 291 NOTE: Delayed shifts out of four-wheel drive may be experienced due to uneven tire wear, low or uneven tire pressures, excessive vehicle loading, or cold tempera- tures. WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake.
  • Page 292: Shifting Procedure - Manually Shifted Transfer Case

    292 STARTING AND OPERATING 4-Wheel-Drive Low Range - Low speed 4-wheel-drive. Locks the front and rear driveshafts together. Forces the front and rear wheels to rotate at the same speed. Additional traction and maximum pulling power for loose, slippery road surfaces only. Do not exceed 25 mph (40 km/h).
  • Page 293: Transfer Case Reminder Light

    vehicle in motion, the transfer case will engage / disen- gage faster if you momentarily release the accelerator pedal after completing the shift. Apply a constant force when shifting the transfer case lever. 2H or 4H ⇔ 4L With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission to N (Neutral) or depress the clutch on a manual transmission.
  • Page 294: Electronically Shifted Transfer Case Operating Information/Precautions (4 Position Switch) - If Equipped

    294 STARTING AND OPERATING Electronically Shifted Transfer Case Operating Information/Precautions (4 Position Switch) — If Equipped Transfer Case Switch This is an electric shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel. This Electronically Shifted transfer case provides 4 mode positions: 2 (rear) wheel drive high range, 4 wheel drive lock range, 4 wheel drive low range, and neutral.
  • Page 295 NOTE: The transfer case Neutral (N) position is selected by depressing the recessed button located on the lower left hand corner of the 4WD Control Switch. The transfer case Neutral (N) position is to be used for recreational towing only. See the Recreational Towing section for specific procedures on shifting into and out of Neutral (N).
  • Page 296 296 STARTING AND OPERATING If One or More Shift Conditions are not Met 1. The indicator light for the current position will remain 2. The newly selected position indicator light will con- tinue to flash. 3. The transfer case will not shift. NOTE: Before retrying a selection, make certain that all the necessary requirements for selecting a new transfer case position have been met.
  • Page 297 When operating your vehicle in 4WD LOW, the engine speed is approximately three times that of the 2WD or 4WD LOCK positions at a given road speed. Take care not to overspeed the engine and do not exceed 25 mph (40 km/h).
  • Page 298: Shifting Procedure - Electronically Shifted Transfer Case

    298 STARTING AND OPERATING 4WD LOCK 4 Wheel Drive Lock Range - Locks the front and rear driveshafts together. Forces the front and rear wheels to rotate at the same speed. Additional traction for loose, slippery road surfaces only. 4WD LOW 4 Wheel Drive Low Range - Low speed 4 wheel drive.
  • Page 299 light will continue to flash until all the requirements for the selected position have been met. To retry a shift: return the control knob back to the original position, make certain all shift requirements have been met, wait five (5) seconds and try the shift again. NOTE: If all the requirements to select a new transfer case position have been met, the current position indica- tor light will turn OFF, the selected position indicator...
  • Page 300 300 STARTING AND OPERATING Preferred Procedure 1. With engine RUNNING, slow vehicle to 2 to 3 mph (3 to 5 km/h). 2. Shift the transmission into NEUTRAL (depress clutch on manual transmissions). 3. While still rolling, rotate the transfer case control switch to the desired position.
  • Page 301: Limited-Slip Differential - If Equipped

    LIMITED-SLIP DIFFERENTIAL — IF EQUIPPED The limited-slip differential provides additional traction on snow, ice, mud, sand and gravel, particularly when there is a difference between the traction characteristics of the surface under the right and left rear wheels. During normal driving and cornering, the limited-slip unit per- forms similarly to a conventional differential.
  • Page 302: Power Take Off Operation - If Equipped

    302 STARTING AND OPERATING POWER TAKE OFF OPERATION – IF EQUIPPED The Dodge Chassis Cab vehicle, when equipped with either the automatic 6 speed or manual G-56 6 speed transmissions, will allow for an aftermarket upfit with a transmission driven PTO (power take off). The customer will have the ability to operate the PTO in either a “stationary”...
  • Page 303: Mobile Mode

    operation and return to “standard vehicle operation” simply turn the up fitter provided on/off switch to the off position or press the “cancel” cruise switch. To operate the PTO via a remote switch the customer must make sure the above conditions are met. It is vital for proper operation that the PTO and remote have been installed correctly paying special attention to ensure the vehicle provided wiring has been connected properly.
  • Page 304: Power Take Off - Aftermarket Installation

    PTO and pump requirements and additional vehicle information (wiring schematics, preset idle values, en- gine speed limits, and vehicle hardware and software requirements) please refer to the Dodge Body Builders Guide by accessing “www.dodge.com/bodybuilder” and choosing the appropriate links.
  • Page 305: Driving Through Water

    6. Do not use trailer tow mode on vehicle’s with the AISIN 6 speed automatic transmission (6.7L Diesel En- gine only). DRIVING THROUGH WATER Driving through water more than a few inches deep will require extra caution to ensure safety and prevent dam- age to your vehicle.
  • Page 306 306 STARTING AND OPERATING CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle. • Determine the condition of the road or the path that is under water and if there are any obstacles in the way before driving through the standing water.
  • Page 307: Driving Off-Road

    DRIVING OFF-ROAD Care should be taken when attempting to climb steep hills or driving diagonally across a hill or slope. If natural obstacles force you to travel diagonally up or down a hill, choose a mild angle and keep as little side tilt as possible. Keep the vehicle moving and make turns slowly and cautiously.
  • Page 308: Parking Brake

    308 STARTING AND OPERATING PARKING BRAKE The foot operated parking brake is positioned below the lower left corner of the instrument panel. To release the parking brake, pull the parking brake release handle. NOTE: The instrument cluster red brake warning light will come on and flash to indicate that the parking brake is applied.
  • Page 309: Brake System

    WARNING! • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also be certain to leave an automatic transmission in Park, a manual transmission in Reverse or First gear. Failure to do so may allow the vehicle to roll and cause damage or injury.
  • Page 310: Brake Noise

    310 STARTING AND OPERATING Brake Noise During normal operation of the brake system certain noises may be present from time to time. Occasional groan or squeal noises may occur during normal operation of the brake system which may not be indica- tive of a problem.
  • Page 311 WARNING! • Anti-lock system (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. •...
  • Page 312: Power Steering

    312 STARTING AND OPERATING ABS Warning Light The Anti-lock Brake System includes an amber warning light, located in the instrument cluster. When the light is illuminated, the Anti-lock Brake System is not function- ing. The system reverts to standard non-anti-lock brakes. WARNING! Pumping of the anti-lock brakes will diminish their effectiveness and may lead to an accident.
  • Page 313: Tire Safety Information

    WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and should be avoided when pos- sible.
  • Page 314 314 STARTING AND OPERATING NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards.
  • Page 315 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm) 65 = Aspect Ratio in Percent (%)
  • Page 316 316 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions.
  • Page 317: Tire Identification Number (Tin)

    Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
  • Page 318: Tire Loading And Tire Pressure

    318 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
  • Page 319 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
  • Page 320 320 STARTING AND OPERATING 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
  • Page 321 STARTING AND OPERATING 321...
  • Page 322: Tires - General Information

    322 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
  • Page 323: Tire Inflation Pressures

    2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
  • Page 324 324 STARTING AND OPERATING The pressure should be checked and adjusted as well as inspecting for signs of tire wear or visible damage at least once a month. Use a good quality pocket-type gauge to check tire pressure. Do not make a visual judgement when determining proper inflation.
  • Page 325 Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. Tire Inflation Pressure — 4500/5500 with Steel Carcass Ply Tires This type of tire utilizes steel cords in the sidewall.
  • Page 326 326 STARTING AND OPERATING 4500/5500 Tire Inflation...
  • Page 327 When adjusting inflation pressure to a tire and wheel assembly mounted on a vehicle, use Remote Mount Automatic Inflation Kit (similar to model number 27- cc1021234, available from TEAM PSE – PENTASTAR Service Equipment Phone Number 1-800-734-4334. NOTE: Never attempt to re-inflate a tire and wheel assembly which has been run flat or extremely under inflated without first removing the tire from the wheel assembly for inspection.
  • Page 328: Radial-Ply Tires

    328 STARTING AND OPERATING WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Don’t drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
  • Page 329: Limited Use Spare - If Equipped

    Limited Use Spare — If Equipped The limited use spare tire is for temporary emergency use on your vehicle. This tire is identified by a limited use spare tire warning label located on the limited use spare tire and wheel assembly. This tire may look like the original equipped tire on the front or rear axle of your vehicle, but it is not.
  • Page 330: Tread Wear Indicators

    330 STARTING AND OPERATING Refer to “Freeing A Stuck Vehicle” in Section 6 of this manual for additional information. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one.
  • Page 331: Life Of Tire

    Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure.
  • Page 332: Alignment And Balance

    332 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
  • Page 333: Supplemental Tire Pressure Information - If

    Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SUPPLEMENTAL TIRE PRESSURE INFORMATION — IF EQUIPPED A light load vehicle condition is defined as two passen- gers {150 lbs (68 kg) each} plus 200 lbs (91kg) of cargo.
  • Page 334: Snow Tires

    334 STARTING AND OPERATING These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires of Ram 4X2 trucks. NOTE: The use of class “U” chains is permitted on the front and rear of 4X4, Ram Trucks with Dual Rear Wheels and LT235/80R17E tires.
  • Page 335: Tire Rotation Recommendations

    poorer than that of non-studded tires. Some states pro- hibit studded tires; therefore, local laws should be checked before using these tire types. TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions.
  • Page 336: Dual Rear Wheels

    336 STARTING AND OPERATING Dual Rear Wheels The tires used on dual wheel assemblies should be matched for wear to prevent overloading one tire in a set. To check if tires are even, lay a straight edge across all four tires. The straight edge should touch all the tires. CAUTION! 3500/4500/5500 Dual Rear Tires have only one ap- proved direction of rotation.
  • Page 337: Engine Runaway

    ENGINE RUNAWAY WARNING! In case of engine runaway due to flammable fumes from gasoline spills or turbocharger oil leaks being sucked into the engine do the following to help avoid personal injury and/or vehicle damage: 1. Shut off engine ignition switch. 2.
  • Page 338 338 STARTING AND OPERATING Poor quality gasoline can cause problems such as hard starting, stalling and hesitations. If you experience these symptoms, try another brand of “regular” gasoline be- fore considering service for the vehicle. Over 40 auto manufacturers world-wide have issued and endorsed consistent gasoline specifications (the World- wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, performance...
  • Page 339 Problems that result from using methanol/gasoline or E85 Ethanol blends are not the responsibility of the manufacturer. While MTBE is an oxygenate made from Methanol, it does not have the negative effects of Metha- nol. MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane.
  • Page 340 340 STARTING AND OPERATING • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance, damage the emission control system. • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat.
  • Page 341: Fuel Requirements (6.7L Diesel Engines)

    engine running for an extended period. If the vehicle is stopped in an open area with the engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle. • Guard against carbon monoxide with proper mainte- nance.
  • Page 342 342 STARTING AND OPERATING Diesel fuel is seldom completely free of water. To prevent fuel system trouble, drain the accumulated water from the fuel/water separator using the fuel/water separator drain provided. If you buy good quality fuel and follow the cold weather advice above, fuel conditioners should not be required in your vehicle.
  • Page 343: Adding Fuel

    ADDING FUEL Adding Fuel (Gas Engines) CAUTION! Damage to the fuel system or emission control sys- tem could result from using an improper fuel tank filler tube cap (gas cap). A poorly fitting cap could let impurities into the fuel system. Also a poorly fitted after-market cap can cause the MIL (Malfunction Indicator Light) to illuminate, due to fuel vapors escaping from the system.
  • Page 344 344 STARTING AND OPERATING NOTE: Tighten the gas cap 1/4 turn until you hear one click. This is an indication that the cap is properly tightened. If the gas cap is not tightened properly, the Malfunction Indicator Light will come on, Be sure the gas cap is tightened every time the vehicle is refueled.
  • Page 345: Adding Fuel (Diesel Engines)

    Adding Fuel (Diesel Engines) CAUTION! To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling. NOTE: • When the fuel nozzle “clicks” or shuts off, the fuel tank is full. • Tighten the gas cap until you hear a “clicking” sound. This is an indication that the gas cap is properly tightened.
  • Page 346 You may try priming as described below. However, if the engine will not start, refer to the fuel priming procedure in the Service Manual or have the vehicle towed to an authorized Dodge dealer.
  • Page 347: Vehicle Loading

    WARNING! Do not open the high pressure fuel system with the engine running. Engine operation causes high fuel pressure. High pressure fuel spray can cause serious injury or death. Priming if the engine has run out of fuel 1. Add a substantial quantity of fuel to the tank 5 to 10 gallons (19 to 38L).
  • Page 348 348 STARTING AND OPERATING Rating (GAWR) front and rear, and Vehicle Identification Number (VIN). A Month-Day-Hour (MDH) number is included on this label and indicates the Month, Day and Hour of manufacture. The bar code that appears on the bottom of the label is your Vehicle Identification Number (VIN).
  • Page 349 Inflation Pressure This is the cold tire inflation pressure for your vehicle for all loading conditions up to full GAWR. Curb Weight The curb weight of a vehicle is defined as the total weight of the vehicle with all fluids, including vehicle fuel, at full capacity conditions, and with no occupants or cargo loaded into the vehicle.
  • Page 350 350 STARTING AND OPERATING CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles. This could cause you to lose control.
  • Page 351: Trailer Towing

    TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
  • Page 352 352 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
  • Page 353 Weight-Distributing Hitch A weight-distributing system works by applying lever- age through spring (load) bars. They are typically used for heavier loads, to distribute trailer tongue weight to the tow vehicle’s front axle and the trailer axle(s). When used in accordance with the manufacturers’ directions, it provides for a more level ride, offering more consistent steering and brake control thereby enhancing towing safety.
  • Page 354 354 STARTING AND OPERATING Weight Distributing Hitch System Improper Adjustment of Weight Distributing System...
  • Page 355: Trailer Hitch Classification

    Fifth-Wheel Hitch A special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. Connects a vehicle and fifth-wheel trailer with a coupling king pin. Gooseneck Hitch The gooseneck hitch employs a pivoted coupling arm which attaches to a ball mounted in the bed of a pickup truck.
  • Page 356: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    • http:// www.dodge.com/towing. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
  • Page 357: Towing Requirements

    • The weight of any other type of cargo or equipment put in or on your vehicle. • The weight of the driver and all passengers. NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle.
  • Page 358 358 STARTING AND OPERATING WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
  • Page 359 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements — Tires −...
  • Page 360 360 STARTING AND OPERATING − An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. −...
  • Page 361 Two of the twelve circuits are additional trailer circuits. For addi- tional information about trailer tow circuits or other exterior lighting capabilities of your Dodge Truck, please refer to the Body Builder’s Guide by accessing “www.dodge.com/bodybuilder” and choosing the ap- propriate links.
  • Page 362: Towing Tips

    362 STARTING AND OPERATING Trailer Tow Additional Lamp Loads Output Maximum Functions Current Stop/Turn Left Stop/Turn Right Trailer Park Lamps Towing Tips Before setting out on a trip, practice turning, stopping Additional Bulbs and backing the trailer in an area away from heavy Allowed Example traffic.
  • Page 363 The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. See Maintenance Schedule in section 8 of this manual for transmission fluid change intervals. NOTE: Check the automatic transmission fluid level before towing.
  • Page 364: Trailer Towing Mirrors - If Equipped

    364 STARTING AND OPERATING − Air Conditioning Turn off temporarily. − refer to Cooling System Operating information in the Maintenance section of this manual for more informa- tion. Trailer Towing Mirrors — If Equipped These mirrors are designed with an adjustable mirror head to provide a greater vision range when towing extra-wide loads.
  • Page 365: Snowplow

    / installer obtain and STARTING AND OPERATING 365 follow the recommendations contained within the cur- rent Dodge Body Builders Guide. See your dealer, in- staller or snowplow manufacture for this information. There are unique electrical systems that must be con- nected to properly assure operator safety and prevent overloading vehicle systems.
  • Page 366: Before Plowing

    • Check that snowplow lighting is connected and func- tioning properly. Snowplow Prep Package Model Availability For Information about snowplow applications visit www.dodge.com or refer to the current Dodge Body Builders Guide. 1. The maximum number of occupants in the truck should not exceed two.
  • Page 367: Over The Road Operation With Snowplow Attached

    Vehicle front end wheel alignment was set to specifica- tions at the factory without consideration for the weight of the plow. Front end tow-in should be checked and reset if necessary at the beginning and end of the snowplow season. This will help prevent uneven tire wear.
  • Page 368: Operating Tips

    368 STARTING AND OPERATING Operating Tips Under ideal snow plowing conditions, 20 mph (32 km/h) should be maximum operating speed. The operator should be familiar with the area and surface to be cleaned. Reduce speed and use extreme caution when plowing unfamiliar areas or under poor visibility.
  • Page 369: Recreational Towing

    • Do not shift the transmission unless the engine has returned to idle and wheels have stopped. Make a practice of stepping on the brake pedal before shifting the transmission. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Recreational Towing – 2 Wheel Drive Models Recreational towing of 2 Wheel Drive models is not allowed.
  • Page 370 370 STARTING AND OPERATING Recreational Towing Procedure — Manual Shift Transfer Case — If Equipped Use the following procedure to prepare your vehicle for recreational towing: CAUTION! It is necessary to follow these steps to be certain that the transfer case is fully in N (NEUTRAL) before recreational towing to prevent damage to internal parts.
  • Page 371 CAUTION! Damage to the automatic transmission may occur if the transmission is shifted into P (PARK) with the transfer case in N (NEUTRAL) and the engine RUN- NING. With the transfer case in N (NEUTRAL) ensure that the engine is OFF prior to shifting the transmission into P (PARK) Returning to Normal Operation —...
  • Page 372 372 STARTING AND OPERATING CAUTION! • Do not use a bumper mounted clamp-on tow bar on your vehicle. The bumper face bar will be damaged. • Do not disconnect the rear driveshaft because fluid will leak from the transfer case and damage the internal parts.
  • Page 373 6. Using the point of a ballpoint pen or similar object, depress the recessed transfer case Neutral (N) button for 4 seconds. 7. After shift is completed and the Neutral (N) light comes on release Neutral (N) button. 8. Start engine. 9.
  • Page 374 374 STARTING AND OPERATING NOTE: The ignition key must be ON for a shift to take place and for the position indicator lights to be operable. If the key in not ON, the shift will not take place and no position indicator lights will be on or flashing.
  • Page 375 8. After the Neutral (N) button has been released the transfer case will shift to the position identified by the selector switch. 9. Shift automatic transmission into P (Park). NOTE: The transfer case can not be shifted into Neutral (N) from the 4Auto (if equipped) position. NOTE: Items 1 through 5 are requirements that must be met prior to depressing the Neutral (N) selection button, and must continue to be met until 1 second elapses and...
  • Page 376 376 STARTING AND OPERATING WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake. The transfer case Neutral (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move despite the transmission position.
  • Page 377: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....378 Jacking And Tire Changing ....379 3500 Models –...
  • Page 378: Hazard Warning Flasher

    378 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning switch is mounted on the top of the steering column as shown in the illustration. Hazard Light Warning Switch To engage the Hazard Warning lights, depress the button on the top of the steering column.
  • Page 379: Jacking And Tire Changing

    JACKING AND TIRE CHANGING WARNING! • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. Never start or run the engine while the vehicle is on a jack.
  • Page 380: Jacking Instructions

    380 WHAT TO DO IN EMERGENCIES WARNING! After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience, abrupt stopping, rapid accelera- tion, or sharp turns. A loose jack, tools, bracket or other objects in the vehicle may move around with force, resulting in serious injury.
  • Page 381 NOTE: Jacking and tire changing on 4500/5500 models should be performed by an authorized dealer, or knowl- edgeable service personnel with the appropriate heavy duty equipment like a tire service company. Preparations Park the vehicle on a firm level surface, avoiding ice or slippery areas.
  • Page 382 382 WHAT TO DO IN EMERGENCIES Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
  • Page 383 When changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Securely place the jack under the sway bar bracket (unless both tire’s are flat on one side, then place jack under shock bracket) facing forward in vehicle.
  • Page 384 384 WHAT TO DO IN EMERGENCIES 4. By rotating the wheel wrench clockwise, raise the vehicle until the wheel just clears the surface. WARNING! Raising the vehicle higher than necessary can make the vehicle unstable and cause an accident. It could slip off the jack and hurt someone near it.
  • Page 385 8. Lower the jack to its fully closed position. If the jack will not lower by turning the dial (thumb wheel) by hand, it may be necessary to use the jack drive tube in order to lower the jack. Stow the replaced tire, jack, and tools as previously described.
  • Page 386 386 WHAT TO DO IN EMERGENCIES CAUTION! The rear hub caps on the dual rear wheel has two pry off notches. Make sure that the hook of the jack handle driver is located squarely in the cap notch before attempting to pull off. You must use the flat end of the lug wrench to pry off the wheel skins.
  • Page 387 WHAT TO DO IN EMERGENCIES 387 Slots in the wheels will assist in properly orienting the These dual rear wheels should be tightened as follows: inner and outer wheels. Align these slots when assem- bling the wheels for best access to the tire valve on the inner wheel.
  • Page 388 388 WHAT TO DO IN EMERGENCIES 1. Tighten the wheel nuts in the numbered sequence to a snug fit. 2. Retighten the wheel nuts in the same sequence to the torques listed in the table. Go through the sequence a second time to verify that specific torque has been achieved.
  • Page 389: Hoisting

    Disc Type Nut Stud Size Torque Wheels Ft. Lbs. Cone 9/16-18 120-150 Flanged 9/16-18 130-160 To Stow The Flat Or Spare (If Equipped) Refer to Upfitters Body Builders Guide for information on stowing your spare tire (If Equipped). HOISTING Torque A conventional floor jack may be used at the jacking Newton locations, refer to the graphics that show jacking loca-...
  • Page 390: Jump-Starting

    390 WHAT TO DO IN EMERGENCIES JUMP-STARTING WARNING! To prevent personal injury or damage to clothing, do not allow battery fluid to contact eyes, skin or fabrics. Do not lean over a battery when connecting jumper cables or allow cable clamps to touch each other. Keep open flames or sparks away from battery vent holes.
  • Page 391 CAUTION! Use the Jump Start Procedure only when the charge indicator (if equipped) in both batteries is dark in the center. Do not attempt jump starting when either battery charge indicator (if equipped) is bright or yellow. If charge indicator (if equipped) has a green dot in the center, failure to start is not due to a discharged battery and cranking system should be checked.
  • Page 392 392 WHAT TO DO IN EMERGENCIES 2. Connect one end of the other jumper cable to negative (-) post of booster battery. Connect the other end of the jumper cable to a good ground on the engine block of the vehicle with the discharged battery.
  • Page 393: With Portable Starting Unit

    WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle. With Portable Starting Unit There are many types of these units available.
  • Page 394: Emergency Tow Hooks - If Equipped

    394 WHAT TO DO IN EMERGENCIES In general, the least amount of accelerator pedal pressure to maintain the rocking motion without spinning the wheels or racing the engine is most effective. Racing the engine or spinning the wheels, due to the frustration of not freeing the vehicle, may lead to transmission over- heating and failure.
  • Page 395: Towing A Disabled Vehicle

    WARNING! Stand clear of vehicles when pulling with tow hooks. Tow straps and chains may break, causing serious injury. CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow truck hookup or highway towing.
  • Page 396: 4-Wheel- Drive Vehicles

    396 WHAT TO DO IN EMERGENCIES 4-Wheel- Drive Vehicles CAUTION! To avoid damage to the transfer case while towing, always use one of the following methods. NOTE: The Transfer Case must be in the neutral posi- tion, and the transmission must be in Park (Automatic Transmission), or in gear (Manual Transmission) to tow a 4WD vehicle with one end of the vehicle raised.
  • Page 397: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 6.7L Diesel Engine ..400 Engine Compartment— 5.7L Gas Engine ..401 Onboard Diagnostic System (OBD II) ..402 Loose Fuel Filler Cap Message .
  • Page 398 398 MAINTAINING YOUR VEHICLE Catalytic Converter (Gas Engines) ..420 Intervention Regeneration Strategy – EVIC Message Process Flow (Catalyst Full Message) (Diesel Engines Only) ....422 Emission-Related Components (Gas Engines) .
  • Page 399 Rear Axle And 4X4 Front Driving Axle Fluid Level ......443 Transfer Case — If Equipped ... . . 445 Manual Transmission —...
  • Page 400: Maintaining Your Vehicle

    400 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 6.7L DIESEL ENGINE...
  • Page 401: Engine Compartment- 5.7L Gas Engine

    MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT— 5.7L GAS ENGINE...
  • Page 402: Onboard Diagnostic System (Obd Ii)

    402 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM (OBD II) Vehicles equipped with California emissions controls have a sophisticated onboard diagnostic system called OBDII. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.
  • Page 403: Replacement Parts

    tightened. Press the odometer reset button to turn the message off. If the problem persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the Malfunction Indicator Light (MIL).
  • Page 404: Service Information

    404 MAINTAINING YOUR VEHICLE WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
  • Page 405 • If you have your vehicle undercoated, make sure no undercoating material is sprayed on the exhaust sys- tem or components of the seat belt system. NOTE: It is not possible for the manufacturer and Cummins, Inc. to anticipate every possible circumstance that can involve a potential hazard.
  • Page 406: Maintenance Procedures

    • Important: All maintenance other than that listed in this manual, as well as some procedures listed here, MUST be performed by your local Dodge Truck Dealer. Your authorized Dodge Dealer has been trained and has the necessary parts to maintain your engine.
  • Page 407 engine, first ensure the engine is at full operating tem- perature, then wait for 30 minutes (6.7L Diesel Engine), and 15 minutes (5.7L Gas Engine) after engine shutdown to check the oil. Checking the oil while the vehicle is on level ground will improve the accuracy of the oil level readings.
  • Page 408 408 MAINTAINING YOUR VEHICLE Engine Oil Selection (Gas Engines) For best performance and maximum protection under all types of operating conditions, the manufacture only recommends engine oils that are API certified and meet the requirements of DaimlerChrysler Material Standard MS-6395. Use Mopar or an equivalent oil meeting the specification MS-6395.
  • Page 409 Change Engine Oil (Diesel Engines) Follow the Diesel Maintenance Schedule for recom- mended engine oil change intervals. Engine Oil Selection (Diesel Engines) For best performance and maximum protection under all types of operating conditions, the manufacture only recommends engine oils that are API CJ-4 certified and meet the requirements of DaimlerChrysler.
  • Page 410 410 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) 15W-40 Engine DaimlerChrysler Materials Standard MS-10902 and the API CJ-4 engine oil category. Engine oil not designated by the DaimlerChrysler or Cummins Material Standards and API CJ-4 should not be used, engine and exhaust system durability may be compromised.
  • Page 411 Use a container that can hold at least 12 quarts (11.3 Liters) to hold the used oil. Always check the condition of the used oil. This can give you an indication of some engine problems that might exist. • Thin, black oil indicates fuel dilution. •...
  • Page 412 412 MAINTAINING YOUR VEHICLE CAUTION! Overtightening may distort the threads or damage the filter element seal. Install the filter as specified by the filter manufacturer. Turn the filter 3/4 to one full turn after making contact with the gasket. Check the condition of the threads and sealing surface on the oil pan and drain plug.
  • Page 413: Drive Belts (Gas Engines)

    Drive Belts (Gas Engines) Belt tension is controlled by means of an automatic tensioner. No belt tension adjustments are required. However, belt and belt tensioner condition should be inspected at the specified intervals and replaced if re- quired. See your authorized dealer for service. At the mileage indicated in the maintenance schedule, all belts and tensioner should be checked for condition.
  • Page 414: Engine Air Cleaner Filter (Diesel Engines)

    414 MAINTAINING YOUR VEHICLE WARNING! The air induction system (air cleaner, hoses, etc) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc) unless such removal is necessary for repair or maintenance.
  • Page 415 to this sensor could result in major engine and/or exhaust aftertreatment damage. This includes the use of non-approved air filters. Use only MOPAR approved air filters or equivalent. The clear plastic housing on the Filter Minder™ allows you to view the amount of air pressure drop across the filter element.
  • Page 416 416 MAINTAINING YOUR VEHICLE • If the filter is not damaged, remove all snow/ice, reinstall filter and reset the Filter Minder™. A visual inspection of the air cleaner filter element is never recommended under normal circumstances. A badly restricted element may appear clean while a soiled element may be quite effective in filtering particles without restricting air flow.
  • Page 417: Draining Fuel/Water Separator Filter (Diesel Engines)

    Draining Fuel/Water Separator Filter (Diesel Engines) CAUTION! Do not drain the fuel/water separator filter when the engine is running. MAINTAINING YOUR VEHICLE CAUTION! Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action.
  • Page 418 418 MAINTAINING YOUR VEHICLE agency for advice on recycling programs and for where used fluids and filters can be properly disposed of in your area. Drain a small amount from the fuel/water separator filter monthly or when the WATER IN FUEL indicator lamp is on.
  • Page 419 4. Repeat the procedure if the engine does not start. CAUTION! Do not engage the starter motor for more than 15 seconds at a time. Allow two minutes between the cranking intervals. NOTE: The engine may run rough until the air is forced from all the fuel lines.
  • Page 420: Engine Fuel Filter (Gas Engines)

    420 MAINTAINING YOUR VEHICLE mixture in excess of 5% can negatively impact the on- engine fuel filter’s ability to separate water from the fuel, resulting in high pressure fuel system corrosion or dam- age. NOTE: As sufficient testing has not been completed, ethanol blends are not recommended or approved for use with your Cummins Diesel equipped vehicle.
  • Page 421 CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and the...
  • Page 422: Intervention Regeneration Strategy - Evic

    422 MAINTAINING YOUR VEHICLE To minimize the possibility of catalyst damage: • Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion. • Do not try to start engine by pushing or towing the vehicle.
  • Page 423 Service CCV Filter will be displayed on the overhead console of your Dodge truck if the CCV filter is due for required maintenance. This filter is located on the top of the engine valve cover. For addi- tional information, see your Dodge truck dealer.
  • Page 424 424 MAINTAINING YOUR VEHICLE trapped in the particulate filter. This message indicates the percentage of the particulate filter capacity that has been used. By simply driving your vehicle at highway speeds for as little as 45 minutes you can remedy the condition in the particulate filter system and allow your Cummins engine and exhaust Aftertreatment system to remove the trapped PM and restore the system to normal operating...
  • Page 425: Emission-Related Components (Gas Engines)

    Emission-Related Components (Gas Engines) Positive Crankcase (PCV) Valve Proper operation of the crankcase ventilation system requires that the PCV valve be free of sticking or plug- ging from deposits. Deposits can accumulate in the PCV valve and passages with increasing mileage. Have the PCV valve, hoses, and passages checked for proper operation at the intervals specified.
  • Page 426: Maintenance Free Batteries (Diesel Engines)

    426 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked (+) positive and negative (-) and identified on the battery case.
  • Page 427: Air Conditioner Maintenance

    CAUTION! It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked (+) positive and negative (-) and identified on the battery case. Also, if a “fast charger”...
  • Page 428: Power Steering - Fluid Check

    428 MAINTAINING YOUR VEHICLE WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information book for further warranty information.
  • Page 429: Front Suspension Ball Joints

    WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to insure accurate fluid level reading. Do not overfill. Use only manufacturers recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
  • Page 430: Front Axle Universal Drive Joints And Ball Joints

    430 MAINTAINING YOUR VEHICLE Front Prop Shaft Lubrication Lubricate the front driveshaft grease fitting at each oil change listed in the appropriate Maintenance Schedule for your vehicle. Use Mopar based grease), or equivalent. Front Driveshaft Grease Fitting Front Axle Universal Drive Joints And Ball Joints The front axle universal joint and ball joints are perma- nently lubricated and do not require servicing.
  • Page 431: Windshield Wiper Blades

    amount of a high quality lubricant such as Mopar Lock Cylinder Lubricant directly into the lock cylinder. Windshield Wiper Blades The rubber edges of the wiper blades and the windshield should be cleaned periodically with a sponge or soft cloth and a mild nonabrasive cleaner.
  • Page 432: Exhaust System

    432 MAINTAINING YOUR VEHICLE WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. After the engine has warmed, operate the defroster for a few minutes to reduce the possibility of smearing or freezing the fluid on the cold windshield.
  • Page 433: Cooling System

    WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, fol- low the preceding safety tips. Exhaust System Rubber Isolator and Loop-Type Hanger —...
  • Page 434 434 MAINTAINING YOUR VEHICLE accumulation of bugs, leaves, etc. If dirty, clean by gently spraying water from a garden hose vertically down the face of the condenser. Check the coolant recovery bottle tubing for brittle rub- ber, cracking, tears, cuts and tightness of the connection at the bottle and radiator.
  • Page 435 Cooling System — Drain, Flush and Refill At the intervals shown on the Maintenance Schedules, the system should be drained, flushed and refilled. If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner.
  • Page 436 436 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to 5 Years or 100,000 miles before replacement. To prevent reducing this extended mainte- nance period, it is important that you use the same coolant throughout the life of your vehicle.
  • Page 437 WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
  • Page 438 438 MAINTAINING YOUR VEHICLE When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill. Points To Remember NOTE: When the vehicle is stopped after a few miles (a few kilometers) of operation, you may observe vapor coming from the front of the engine compartment.
  • Page 439: Fan

    Make sure it is securely mounted. NOTE: This service procedure must be performed by a trained service technician. Make arrangements with your authorized Dodge Truck Dealer for this inspection. MAINTAINING YOUR VEHICLE Charge Air Cooler — Inter-Cooler (Diesel Engines) The charge air cooler is positioned between the radiator and the air conditioner condenser.
  • Page 440: Hoses And Vacuum/Vapor Harnesses

    440 MAINTAINING YOUR VEHICLE Hoses And Vacuum/Vapor Harnesses Inspect surfaces of hoses and nylon tubing for evidence of heat and mechanical damage. Hard or soft spots, brittle rubber, cracking, tears, cuts, abrasions, and exces- sive swelling indicate deterioration of the rubber. Pay particular attention to those hoses nearest to high heat sources such as the exhaust manifold.
  • Page 441 heat and mechanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasion, and excessive swelling indicate deterioration of the rubber. Particular attention should be made to examining those hose surfaces nearest to high heat sources, such as the exhaust manifold. Insure nylon tubing in these areas has not melted or collapsed.
  • Page 442 442 MAINTAINING YOUR VEHICLE Brake Master Cylinder – Brake Fluid Level Check The fluid level of the master cylinder should be checked when performing under the hood service, or immedi- ately if the brake system warning lamp indicates system failure. The brake master cylinder has a translucent plastic reservoir.
  • Page 443: Clutch Hydraulic System

    CAUTION! Do not allow a petroleum-base fluid to contaminate the brake fluid. Seal damage and loss of brake performance may result. Clutch Hydraulic System The clutch hydraulic system is a sealed maintenance-free system. In the event of leakage or other malfunction, the system must be replaced.
  • Page 444 444 MAINTAINING YOUR VEHICLE Drain And Refill On 3500 vehicles the differential cover must be removed to drain the axle fluid. On 4500/5500 vehicles remove the lower bolt to drain the axle fluid. 1 — 4500/5500 Rear Axle Fluid Fill Plug 2 —...
  • Page 445: Transfer Case - If Equipped

    Transfer Case — If Equipped Drain And Refill Follow the appropriate Maintenance Schedule for recom- mended transfer case fluid change intervals. Lubricant Selection Refer to Fluids, Lubricants and Genuine Parts for the correct lubricant type. Fluid Level Check This fluid level can be checked by removing the filler plug.
  • Page 446: Automatic Transmission (Gas Engine Only)

    446 MAINTAINING YOUR VEHICLE Automatic Transmission (Gas Engine Only) Selection Of Lubricant Refer to Fluids, Lubricants and Genuine Parts for the correct lubricant type. It is important that the transmis- sion fluid be maintained at the prescribed level using the recommended fluid.
  • Page 447 5. Remove the dipstick, wipe it clean and reinsert it until seated. 6. Remove the dipstick again and note the fluid level on both sides. The fluid level should be between the HOT (upper) reference holes on the dipstick at normal operat- ing temperature.
  • Page 448: Automatic Transmission (Diesel Engine Only)

    448 MAINTAINING YOUR VEHICLE Automatic Transmission Fluid and Filter Change Follow the Maintenance Schedule for recommended transmission fluid and filter change intervals. If the transmission is disassembled for any NOTE: reason, the fluid and filter should be changed. Special Additives The manufacturer recommends against the addition of any additives to the transmission.
  • Page 449 Procedure For Checking Fluid Level To properly check the automatic transmission fluid level, the following procedure must be used: 1. The vehicle must be on level ground. 2. Operate the engine at idle speed for a minimum of 60 seconds and normal operating temperature. 3.
  • Page 450 Authorized Dodge Dealer or Service Center. It is important that the transmission fluid is maintained at the correct level, and that it be drained and refilled as specified.
  • Page 451: Front And Rear Wheel Bearings

    Front and Rear Wheel Bearings Front Wheel Bearings Front wheel bearings for all Dodge Ram Trucks are sealed-for-life. They do not require greasing or seal replacement. In some instances, these bearings will MAINTAINING YOUR VEHICLE “purge”...
  • Page 452 452 MAINTAINING YOUR VEHICLE All vehicles built over 10,000 lbs. (4 535 kg) Gross Vehicle Weight Rating and manufactured for sale and use in the United States are required to comply with the Federal Government’s Exterior Noise Regulations. These vehicles can be identified by the Noise Emission Control Label located in the operator’s compartment.
  • Page 453 Air Cleaner Assembly Inspect air cleaner housing for proper assembly and fit. Make certain that the air cleaner is properly positioned and that the cover is tight. Check all hoses leading to the air cleaner for tightness. The air filter element must also be clean and serviced according to the instructions out- lined in the Maintenance Schedule Section of this manual.
  • Page 454 454 MAINTAINING YOUR VEHICLE Noise Emission Warranty The manufacturer warrants that this vehicle as manufac- tured by the manufacturer, was designed, built and equipped to conform at the time it left the manufacturer’s control with all applicable U.S. EPA Noise Control Regu- lations.
  • Page 455 Noise Systems Maintenance Chart and Service Log Maintenance Log and Service Chart (Gas Engines) Insert Month, Day, Year under column mileage closest to the mileage at which service was performed. MILES KILOMETERS Exhaust system-inspect Air cleaner assembly-inspect ODOMETER READING PERFORMED BY PERFORMED AT MILES KILOMETERS...
  • Page 456: Miles Kilometers

    456 MAINTAINING YOUR VEHICLE Maintenance Log and Service Chart (Diesel Engines) Noise Systems Maintenance Chart and Service Log — Insert Month, Day, Year under column mileage closest to the mileage at which service was performed. MILES KILOMETERS Exhaust system-inspect Air cleaner assembly-inspect ODOMETER READING PERFORMED BY PERFORMED AT...
  • Page 457: Appearance Care And Protection From Corrosion

    Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and those that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
  • Page 458 458 MAINTAINING YOUR VEHICLE • Use Mopar Cleaner Wax to remove road film, stains and to protect your paint finish. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
  • Page 459 • Use Mopar touch up paint on scratches as soon as possible. Your dealer has touch up paint to match the color of your vehicle. Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
  • Page 460 460 MAINTAINING YOUR VEHICLE Interior Care Use Mopar Total Clean to clean fabric upholstery and carpeting. Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recommended for leather upholstery. Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth.
  • Page 461 Glass Surfaces All glass surfaces should be cleaned on a regular basis with Mopar Glass Cleaner or any commercial household-type glass cleaner. Never use an abrasive type cleaner. Use caution when cleaning the inside rear win- dow equipped with electric defrosters or the right rear quarter window equipped with the radio antenna.
  • Page 462: Fuses (Integrated Power Module)

    462 MAINTAINING YOUR VEHICLE FUSES (INTEGRATED POWER MODULE) An integrated Power Module is located in the engine compartment near the battery. This center contains car- tridge fuses and mini fuses. A description of each fuse and component may be stamped on the inside cover otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
  • Page 463 Cavity Cartridge Mini Fuse Fuse 20 Amp Power Outlet Console Yellow 20 Amp Cabin Compartment Yellow Node (CCN) Door Locks — — 15 Amp Aisin Transmission Blue Controls (Diesel Only) 20 Amp Power Sunroof Yellow 10 Amp Vistronic Fan/ Wastegate Solenoid —...
  • Page 464 464 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 30 Amp Pink 25 Amp Natural 15 Amp Blue 20 Amp Yellow 15 Amp Blue — 40 Amp Green 30 Amp Pink Description Cavity Cartridge Electric Brake Power-Battery RWAL/ABS Module Feed Park Lamps Left Trailer Park Lamps Park Lamps Right...
  • Page 465 Cavity Cartridge Mini Fuse Fuse 40 Amp Power Seats Green 10 Amp Power Run/Start- PCM/Steering Angle Sensor 10 Amp 4X4 Switch/Pass Dr Switch/EC Mirror 15 Amp Power Run/Start- Blue ABS/RWAL/Smart Bar/YAW Sensor/ Universal Exhaust Gas Oxygen (Uego) Sensor Controller 10 Amp PCM (Gas)/TCM (Diesel 58RFE) Description...
  • Page 466 466 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 10 Amp 20 Amp Yellow — 30 Amp Pink Description • When installing the Integrated Power Module Seatbelt Tension Reducer/Power IGN cover, it is important to ensure the cover is prop- Run/Acc erly positioned and fully latched.
  • Page 467: Vehicle Storage

    VEHICLE STORAGE If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: • Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse located in the Integrated Power Module, located in the engine compartment.
  • Page 468: Replacement Light Bulbs

    468 MAINTAINING YOUR VEHICLE REPLACEMENT LIGHT BULBS LIGHT BULBS — Inside Overhead Console Lights ....TS 212-2 Dome Light......7679 NOTE: For lighted switches, see your dealer for replace- ment instructions.
  • Page 469 2. Remove the two (2) bolts from the front of the head- light housing. Front Headlight Housing Bolts MAINTAINING YOUR VEHICLE 3. Remove the plug from the inner fender well and remove the nut through the access hole. Inner Fender Plug...
  • Page 470 470 MAINTAINING YOUR VEHICLE 4. Pull the housing out from the fender to allow room to disconnect the electrical connectors. NOTE: For easier removal, pull the headlight assembly straight forward, applying the greatest amount of force to the outer edge of the headlight assembly. Rear Headlight Housing Nut Access Headlight Removal...
  • Page 471 MAINTAINING YOUR VEHICLE 5. Unlock and pull connector straight from the base of the headlight halogen bulb. 6. Twist connector on the side marker/turn signal/park light bulb ⁄ turn and remove connector and bulb from housing. 7. Remove housing from vehicle with headlight halogen bulb in housing.
  • Page 472: Fog Lights

    472 MAINTAINING YOUR VEHICLE Fog Lights 1. Reach under the vehicle, unlock and twist connector counterclockwise ⁄ turn and remove connector and bulb from housing. 2. Pull bulb straight from the connector. 3. Reverse procedure for installation of bulbs and hous- ing.
  • Page 473: Cab Top Clearance Lights - If Equipped

    Cab Top Clearance Lights — If Equipped 1. Remove the two screws from the top of the light. MAINTAINING YOUR VEHICLE 2. Rotate the socket ⁄ turn and pull it from the light assembly.
  • Page 474: Fluid And Capacities

    474 MAINTAINING YOUR VEHICLE 3. Pull the bulb straight from it’s socket and replace. FLUID AND CAPACITIES U.S. Fuel (Appoximate) 6.7L HO Turbo Diesel Engine Standard Rear Tank 52 gal. Optional Midship Tank 22 gal. Fuel (Appoximate) 5.7L Gas Engine Standard Rear Tank 52 gal.
  • Page 475 U.S. Engine Oil (with filter) 6.7L HO Turbo Diesel 12 qts. Engine (SAE 15W-40, API CJ-4 Certified, that meets CES 20081 Standards.) 5.7L Gas Engine V-8 (SAE 7.0 qts. 5W-30, API Certified). For trucks operating un- der a gross combined weight rating greater than 14,000 lbs.
  • Page 476: Fluids, Lubricants And Genuine Parts

    476 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant 6.7L HO Turbo Diesel Engine Oil 5.7L Gas Engine Oil (For trucks operating under a gross combined weight rating less than 14,000 lbs.) 5.7L Gas Engine Oil (For trucks operating under a gross combined weight rating greater than 14,000 lbs.) Engine Oil Filter ( 5.7L Gas Engine )
  • Page 477 Component Crankcase Ventilation Filter ( 6.7L Diesel Engine ) Fuel Selection ( 5.7L Gas Engine ) Fuel Selection ( 6.7L Diesel Engine ) Spark Plugs (5.7L Engine) Fluids, Lubricants and Genuine Parts Mopar CCV Filter, P/N 68001433AA or equivalent. 89 Octane, (R+M)/2 Method, Mid-Grade Preferred (87 Octane acceptable). Use good quality diesel fuel from a reputable supplier in your vehicle.
  • Page 478: Chassis

    478 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission (5 Speed 545RFE) Automatic Transmission (6 Speed AS68RC) Transfer Case Manual Transmission Fluid G-56 Clutch Linkage Front and Rear Axle Fluid (3500) Front and Rear Axle Fluid (4500/5500) Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts.
  • Page 479: Maintenance Schedules

    MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..480 Maintenance Schedules — 6.7L Turbo Diesel ..480 Oil Change Indicator System ... . . 482 Maintenance Schedule .
  • Page 480: Emission Control System Maintenance

    480 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type in this section (Section 8) must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
  • Page 481 • Check the windshield washer solvent and add if required. When refilling the washer fluid reservoir, take some washer fluid and apply it to a cloth or towel and wipe clean the wiper blades, this will help blade performance. Once a Month •...
  • Page 482: Oil Change Indicator System

    482 MAINTENANCE SCHEDULES Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts. Oil Change Indicator System Your vehicle is equipped with an engine oil change indicator system. This system will alert you when it is time to change your engine oil by displaying the words “Oil Change Required”...
  • Page 483: Maintenance Schedule

    Maintenance Schedule Miles (Kilometers) [Months] Change engine oil and engine oil filter. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and correct stowage. Lubricate outer tie rod ends. Check transfer case fluid level (4X4). Change front axle fluid (3500/4500/5500 4X4) (Die- sel Engine only).
  • Page 484 484 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Inspect brake linings. Inspect and adjust parking brake if necessary. Inspect fan hub. Inspect damper. Inspect front wheel bearings. Inspect drive belt, replace as necessary. 7,500 15,000 22,500 (12 000) (24 000) (36 000) [12] [18] 30,000...
  • Page 485 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and correct stowage. Lubricate outer tie rod ends. Drain and refill transfer case fluid (4X4). Change front axle fluid (3500/4500/5500 4X4) (Die- sel Engine only).
  • Page 486 486 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Flush and replace engine coolant at 60 months, if not replaced at 100,000 miles (160 000 km). Inspect drive belt, replace as necessary. Replace fuel filter element. Inspect brake linings. Inspect and adjust parking brake if necessary. Inspect fan hub.
  • Page 487 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and correct stowage. Lubricate outer tie rod ends. Flush and replace engine coolant, if not replaced at 60 mos.
  • Page 488 488 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Inspect fan hub. Inspect damper. Replace fuel filter element. Inspect front wheel bearings. Inspect brake linings. Inspect and adjust parking brake if necessary. 82,500 90,000 97,500 (133 000) (145 000) (157 000) [66] [72] [78] 100,000 105,000...
  • Page 489 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Lubricate outer tie rod ends. Flush and replace engine coolant at 120 months, if not replaced at 100,000 miles (161 000 km).
  • Page 490 490 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Change rear axle fluid (3500 4X4 and 4X2) (Diesel Engine only). Change rear axle fluid (4500/5500 4X4 and 4X2). Change automatic transmission fluid. Change manual transmission fluid. Inspect fan hub. Inspect damper. Replace fuel filter element. Inspect front wheel bearings.
  • Page 491: Maintenance Schedule - 5.7L Gas Engine

    Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts. *This maintenance is not required if belt was previously replaced. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
  • Page 492 492 MAINTENANCE SCHEDULES • Change your engine oil more often if you drive your vehicle off-road for an extended period of time. • Under no circumstances should oil change intervals exceed 6,000 miles (10,000 km) or 6 months, whichever comes first. Your dealer will reset the oil change indicator message after completing the scheduled oil change.
  • Page 493 At Each Oil Change • Change the engine oil filter. • Inspect the brake hoses and lines. • Check the Manual Transmission fluid level. MAINTENANCE SCHEDULES 493 CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
  • Page 494: Required Maintenance Intervals

    494 MAINTENANCE SCHEDULES Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate Tires. Lubricate outer tie rod ends. Lube Front Drive Shaft Fitting (4x4 only). If using your vehicle for any of the following: Dusty or off-road conditions.
  • Page 495 Maintenance Items Inspect Exhaust System. Perform the first inspection at 12,000 miles (20 000 km) or 12 months. Inspect the front suspension, tie rod ends and boot seals, replace if necessary. Replace the engine air cleaner filter. Inspect the transfer case fluid. Replace the spark plugs on 5.7L engines.
  • Page 496 496 MAINTENANCE SCHEDULES Maintenance Items Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow- plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more then 50% of your driving is at sustained high speeds during hot weather, above 90F°...
  • Page 497 WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
  • Page 499: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......500 Prepare For The Appointment .
  • Page 500: Suggestions For Obtaining Service For Your Vehicle

    We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
  • Page 501 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
  • Page 502 502 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
  • Page 503: Warranty Information (U.s. Vehicles Only)

    WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 504: In Canada

    504 IF YOU NEED CONSUMER ASSISTANCE To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 400 Seventh Street, SW., Wash- ington, DC 20590. You can also obtain other information about motor vehicle...
  • Page 505 • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features. They show exactly how to find and correct problems the first time, using step-by-step troubleshooting and driveability procedures, proven diagnostic tests and a complete list of all tools and equipment.
  • Page 506: Department Of Transportation Uniform Tire Quality Grades

    506 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
  • Page 507: Temperature Grades

    Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
  • Page 509 INDEX...
  • Page 510 510 INDEX Adding Fuel ......343,345 Adjustable Pedals ..... . . 131 Air Cleaner, Engine (Engine Air Cleaner Filter) .
  • Page 511 Automatic Transmission (Gas Engine Only) ..448 Axle Fluid ......444,478 Axle Lubrication (Axle Fluid) .
  • Page 512 512 INDEX Cassette Tape and Player Maintenance ..232 Catalyst Full Message ..... 422 Catalytic Converter .
  • Page 513 Radiator Cap ......436 Selection of Coolant (Antifreeze) ..435,476 Temperature Gauge .
  • Page 514 514 INDEX Electronic Vehicle Information Center (EVIC) ..143 Electronically Shifted Transfer Case ... 294 Emergency Brake ......308 Emergency, In Case of Freeing Vehicle When Stuck .
  • Page 515 Fabric Care ......459 Fan ........439 Filters Air Cleaner .
  • Page 516 516 INDEX Gas Cap (Fuel Filler Cap) ....344,402 Gasoline (Fuel) ......337 Gasoline, Reformulated .
  • Page 517 Hitches Trailer Towing ......355 Hoisting ......389 Hood Release .
  • Page 518 518 INDEX Lane Change and Turn Signals ....126 Lap Belts ......44 Lap/Shoulder Belts .
  • Page 519 Tires ....... 318 Locks ....... . . 27 Child Protection .
  • Page 520 520 INDEX Tampering Prohibited ....453 Noise Emission Warranty ....451,454 Occupant Restraints .
  • Page 521 Phone, Cellular ......87 Phone, Hands-Free (UConnect™) ... . . 87 Placard, Tire and Loading Information .
  • Page 522 522 INDEX Shifting out of Transfer Case Neutral (N) . . . 371,374 Reformulated Gasoline ....338 Refrigerant ......428 Reminder, Seat Belt .
  • Page 523 Folding Floor ......163 Heated ......119 Lumbar Support .
  • Page 524 524 INDEX Automatic Transmission ....252,256 Engine Block Heater ....256,264 Engine Fails to Start .
  • Page 525 Changing ......380 Dual ......336,386 General Information .
  • Page 526 526 INDEX Trailer Weight ......356 Transaxle Automatic ......12 Manual .
  • Page 527 Washers, Windshield ....129,431 Washing Vehicle ......457 Water Driving Through .
  • Page 528 INTRODUCTION INTRODUCTION A MESSAGE FROM DAIMLERCHRYSLER CORPORATION - DIESEL ENGINES ONLY HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VAN CONVERSIONS/CAMPERS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS/ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Ignition Key RemovalLocking Doors With The KeySENTRY KEY Replacement KeysCustomer Key ProgrammingGeneral InformationSTEERING WHEEL LOCK - IF EQUIPPED If You Wish To Manually Lock The Steering WheelTo Release The Steering Wheel LockAutomatic Transmission Ignition Interlock SystemSECURITY ALARM SYSTEM - IF EQUIPPED Rearming of the SystemTo Set the AlarmTo Disarm the SystemILLUMINATED ENTRY SYSTEM - IF EQUIPPED REMOTE KEYLESS ENTRY - IF EQUIPPED To unlock the doorsTo lock the doorsUsing the Panic AlarmGeneral InformationTransmitter Battery Service REMOTE STARTING SYSTEM - IF EQUIPPED DOOR LOCKS Manual Door Locks - If EquippedPower Door Locks - If EquippedChild Protection Door LockWINDOWS Power Windows - If Equipped Power Sliding Rear Window - If Equipped Sliding Rear Window - If EquippedWind BuffetingOCCUPANT RESTRAINTS Lap/Shoulder Belts...

Table of Contents

Save PDF
