Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5 INTRODUCTION 5...
Page 6: Vehicle Identification Number
The vehicle identification number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN LOCATION Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.
Page 7: Vehicle Modifications / Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . .12 FOB With Integrated Key .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlatch The Trunk ....24 Using The Panic Alarm ....24 Programming Additional Transmitters .
Page 11 Driver And Front Passenger Supplemental Restraint System (SRS) - Airbag ... .50 Event Data Recorder (EDR) ....63 Child Restraint .
Page 12: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Fob with Integrated Key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided integrated key into the igni- tion switch with either side up.
Page 13: Fob With Integrated Key
Fob with Integrated Key The Fob with Integrated Key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a valet key, which stores in the rear of the Fob. The valet key allows for entry into the vehicle should the battery in the vehicle or the Fob go dead.
Page 14: Tip Start Feature
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tip Start Feature Do not press the accelerator. Use the Fob with Integrated Key to briefly turn the ignition switch to the START position and release it as soon as the starter engages. The starter motor will continue to run, and it will disengage automatically when the engine is running.
Page 15: Key-In-Ignition Reminder
CAUTION! An unlocked car is an invitation to thieves. Always remove key from the ignition and lock all doors when leaving the vehicle unattended. Key-In-Ignition Reminder If you open the driver’s door and the key is in the ignition, a chime will sound to remind you to remove the key.
Page 16: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE flash after the bulb check, it indicates that someone used an invalid Fob to start the engine. Either of these condi- tions will result in the engine being shut off after two (2) seconds.
Page 17: Customer Key (Fob) Programming
location. This number is required for dealer replacement of Fobs. Duplication of Fobs may be performed at an authorized dealer or by using the Customer Key Pro- gramming procedure. This procedure consists of pro- gramming a blank Fob to the vehicle electronics. A blank Fob is one, which has never been programmed.
Page 18: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If a programmed key is lost, see your dealer to have all remaining keys erased from the systems memory. This will prevent the lost key from starting your vehicle. The remaining keys must then be repro- grammed.
Page 19: To Arm The System
To Arm the System: Remove the key from the ignition switch and either press a power door lock switch while the driver or passenger door is open or press the LOCK button on the Remote Keyless Entry (RKE) transmitter. After the last door is closed, or if all doors are closed, the system will arm itself in about 16 seconds.
Page 20: Illuminated Entry System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the alarm system is armed and the battery becomes disconnected the system will remain armed when the battery is reconnected. The exterior lights will flash, the horn will sound, and the ignition will not start the vehicle.
Page 21: To Unlock The Doors
Keyless Entry Transmitter To unlock the doors: Press and release the UNLOCK button on the transmitter once to unlock the driver’s door, or twice within 5 seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.
Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Release both buttons at the same time. 3. Test the feature while outside of the vehicle, by pressing the LOCK/UNLOCK buttons on the transmitter with the ignition switch in the LOCK position, and the key removed.
Page 23: To Lock The Doors
4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the LOCK button on the transmitter while you are in the vehicle will activate the Security Alarm. Opening a door with the Security Alarm activated will cause the alarm to sound.
Page 24: To Unlatch The Trunk
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Press the LOCK button on a programmed transmitter for at least 4 seconds, but no longer than 10 seconds. Then, press the PANIC button while still holding the LOCK button. 2. Release both buttons at the same time. 3.
Page 25: Programming Additional Transmitters
• You may need to be less than 35 feet (11 meters) from the vehicle when using the transmitter to turn off the panic alarm due to the radio frequency noises emitted by the system. Programming Additional Transmitters Refer to SENTRY KEY “Customer Key (Fob) Program- ming.”...
Page 26: General Information
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Reposition the access door panel over the battery opening and snap into place. General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: •...
Page 27 • Hood closed. • Trunk closed. • Hazard switch off. • Brake switch inactive (brake pedal not pressed). • Ignition key removed from ignition switch. • Battery at an acceptable charge level. • RKE Panic button not pressed. To Enter Remote Start Mode Press and release the Remote Start button on the RKE transmitter twice within 5 seconds.
Page 28: Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Exit Remote Start Mode & Drive the Vehicle Before the end of the 15-minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped).
Page 29: Power Door Locks
If the door lock plunger is down when you shut the door, the door will lock. Therefore, make sure the key is not inside the vehicle before closing the door. WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle.
Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate. This prevents you from acciden- tally locking the key in the vehicle.
Page 31 2. Cycle the ignition switch between LOCK and ON and then back to LOCK 4 times ending up in the LOCK position. 3. Depress the power door lock switch to lock the doors. 4. A single chime will indicate the completion of the programming.
Page 32: Child Protection Door Lock
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, performing the following procedure: 1. Close all doors and place the key in the ignition. 2. Cycle the ignition switch between LOCK and ON and then back to LOCK 4 times ending up in the LOCK position.
Page 33 Child Lock Control 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: When the child lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 34: Windows
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the tip of the valet key or alike into the child lock control and pull it downward. Child Lock Control 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: After disengaging the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
Page 35 There are single window controls on each passenger door trim panel, which operate the passenger door windows. The window controls will operate only when the ignition switch is in the ON or ACC position. WARNING! Never leave children in a vehicle, with the keys in the ignition switch.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE programmable. For details, refer to “Delay Power Off to Accessories Until Exit,” under “Personal Settings (Cus- tomer Programmable Features),” under “Electronic Ve- hicle Information Center (EVIC)” in Section 4 of this manual. Auto Up Feature with Anti–Pinch Protection —...
Page 37 • Any impact due to rough road conditions may trigger the auto reverse function unexpectedly during auto- closure. If this happens, pull the switch lightly to the first detent and hold to close window manually. WARNING! There is no anti-pinch protection when the window is almost closed.
Page 38: Wind Buffeting
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Pull the window switch up to close window com- pletely and continue to hold the switch up for an additional two seconds after the window is closed. 2. Push the window switch down firmly to the second detent to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open.
Page 39: Trunk Safety Warning
The trunk lid can be released from outside the vehicle by pressing the trunk button on the Remote Keyless Entry (RKE) transmitter twice within 5 seconds. With the ignition switch in the ON position, the trunk open symbol will display in the instrument cluster indi- cating that the trunk is open.
Page 40: Trunk Emergency Release
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Trunk Emergency Release Emergency Release The trunk of your vehicle is equipped with an emergency release handle. It is located on the inside of the trunk lid, near the latch, and is coated so that it glows in a darkened trunk.
Page 41: Lap/Shoulder Belts
WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Pulling Out Lap/Shoulder Belt Connecting Latch Plate To Buckle...
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. •...
Page 45 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as pos- sible and keep it snug.
Page 46: Lap/Shoulder Belt Untwisting Procedure
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the driver and front passenger seats, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Push and fully depress the button above the webbing to release the anchorage, and then move it up or down to the position that serves you best.
Page 47: Seat Belt Pretensioners
3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate. 4. Continue to slide the latch plate up until it clears the folded webbing. Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove any slack from the seat belts in the event of a...
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE be reactivated if the driver’s seat belt is unbuckled for more than 10 seconds and the vehicle speed is greater than 5 mph (8 km/h). BeltAlert Programming The Enhanced Warning System (BeltAlert ) can be en- abled or disabled by your authorized dealer or by performing the following steps: NOTE: DaimlerChrysler does not recommend deacti-...
Page 49: Automatic Locking Mode - If Equipped
Automatic Locking Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. However, the belt will still retract to remove slack in the shoulder belt. Use The Automatic Locking Mode any time a child safety seat is installed in a seating position that has a seat belt with this feature.
Page 50: Seat Belt Extender
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Extender If a seat belt is too short, even when fully extended, and when the adjustable upper shoulder belt anchorage (if so equipped) is in its lowest position, your dealer can provide you with a seat belt extender.
Page 51 NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 WARNING! •...
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This vehicle may also be equipped with supplemental side curtain airbags to protect the driver and passengers sitting next to a window and/or supplemental front-seat- mounted side airbags. If the vehicle is equipped with supplemental side curtain airbags, they are located above the side windows.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 WARNING! • If your vehicle is equipped with supplemental front-seat- mounted side airbags, do not use accessory seat covers or place objects between you and the seat airbags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Do not use a clothing bar mounted to the coat hooks in this vehicle. A clothing bar will impede the proper performance of the curtain airbags. Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger.
Page 55 5. If a child from 1 to 12 years old must ride in the front passenger seat because the vehicle is crowded, move the seat as far back as possible, and use the proper child restraint (refer to information on Child Restraint in this section). 6.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag System Components The airbag system consists of the following: • Occupant Restraint Controller (ORC) • Side Remote Acceleration Sensors (if equipped) • Airbag Warning Light • Driver Airbag • Front Passenger Airbag •...
Page 57 • The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON positions. These include all of the items listed above except the knee bolster, the instru- ment panel, and the steering wheel and column. If the key is in the LOCK position, in the ACC position, or not in the ignition, the airbags are not on and they will not inflate.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE separate and fold out of the way, as the bags inflate to their full size. The bags fully inflate in about 50 - 70 milliseconds. This is about half of the time that it takes to blink your eyes.
Page 59 seam in the seat’s trim cover and opens into the space between the occupant and the door. The airbag inflates at a very high speed and with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area where the front-seat- mounted side airbag inflates.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If A Deployment Occurs The airbag system is designed to deploy when the ORC detects a moderate-to-severe collision, to help restrain the driver and front passenger, and then to immediately deflate. NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system.
Page 61 WARNING! Deployed airbags can’t protect you in another colli- sion. Have the airbags replaced by an authorized dealer as soon as possible. Enhanced Accident Response System In the event of an impact that causes airbag deployment, with the vehicle stopped, and the vehicle communication network intact, and the power intact, the Enhanced Accident Response System performs the following func- tions:...
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you.
Page 63: Event Data Recorder (Edr)
Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to 5 seconds of specific vehicle data parameters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near deployment, and up to a quarter second of high-speed deceleration data during and/or after airbag deployment.
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states. Data of a potentially sensitive nature, such as would identify a particular driver, ve- hicle, or crash, will be treated confidentially.
Page 65: Child Restraint
• Traction/stability control status • Tire pressure monitoring system status (if equipped) Child Restraint Everyone in your vehicle needs to be buckled up all the time — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants and Child Restraints • Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and “convertible”...
Page 67 The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seat back, they should use a belt-positioning booster seat.
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint.
Page 69 without using the vehicle’s seat belts, instead securing the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle structure. LATCH-compatible child restraint systems are now avail- able. However, because the lower anchorages are to be introduced over a period of years, child restraint systems having attachments for those anchorages will continue to have features for installation using the vehicle’s seat...
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.
Page 71 most direct path between the anchor and the child restraint. Finally, tighten all three straps as you push the child restraint rearward and downward into the seat, removing slack in the straps according to the child restraint manufacturer’s instructions. NOTE: •...
Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using the Vehicle Seat belt The passenger seat belts are equipped with either cinch- ing latch plates or automatic locking retractors, which are designed to keep the lap portion tight around the child restraint so that it is not necessary to use a locking clip.
Page 73 To attach a child restraint tether strap: 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint. Tether Strap Mounting 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 3.
Page 74: Engine Break-In Recommendations
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 75: Safety Tips
SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 76 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken, damaged, deteriorated, or mispositioned parts.
Page 77: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 78: Periodic Safety Checks You Should Make Outside The Vehicle
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside The Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......83 Inside Day/Night Mirror ....83 Automatic Dimming Inside Mirror —...
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your UConnect™ System ....105 General Information ....114 Seats .
Page 81 Mist Feature ......131 Windshield Washers ....131 Headlights On With Wipers (Available With Auto Headlights Only) .
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sunroof — If Equipped ... . . 146 Opening Sunroof - Express ....147 Closing Sunroof - Express .
Page 83: Mirrors
MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).
Page 84: Automatic Dimming Inside Mirror
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Inside Mirror — If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light, next to the button, will illuminate to indicate when the dimming feature is activated.
Page 85: Exterior Mirrors Folding Feature - If Equipped
WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger side convex mirror.
Page 86: Power Remote-Control Mirrors
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Remote-Control Mirrors The power mirror switch is located on the driver’s door trim panel next to the power door lock switch. A rotary knob selects the left mirror, right mirror, or off position. After selecting a mirror, move the knob in the same direction you want the mirror to move.
Page 87: Illuminated Vanity Mirrors - If Equipped
Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on the sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward. The light turns on automatically. Closing the mirror cover turns off the lights. Illuminated Vanity Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 HANDS–FREE COMMUNICATION (UConnect™) —...
Page 88 NOTE: For UConnect™ customer support, visit the following web sites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 UConnect™ allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle, and enables you to mute the system’s micro-...
Page 89: Operation
radio or the mirror has the two control buttons (Phone Button and Voice Recognition Button) that will enable you to access the system. Voice Recognition Button Actual button location may vary with radio. The individual buttons are described in the “Operation”...
Page 90 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing. • For each feature explanation in this section, only the combined form of the voice command is given.
Page 91 To complete the pairing process, you will need to refer- ence your cellular phone owner’s manual. The UCon- nect™ website may also provide detailed instructions for pairing. The following are general phone to UConnect™ System pairing instructions: • Press the “Phone” button to begin. •...
Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dial by Saying a Number • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Dial. • System will prompt you to say the number you want call.
Page 93 Add Names to Your UConnect™ Phonebook NOTE: Adding names to phone book is recommended when vehicle is not in motion. • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Phonebook New Entry. •...
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Exchange Profile (OBEX). Please see your phone owners’ manual for specific instructions on how to send these entries from your phone. NOTE: • Phone handset must support Bluetooth OBEX trans- fers of phonebook entries to use this feature. •...
Page 95 Phonebook Edit can be used to add another phone number to a name entry that already exists in the phonebook. For example, the entry John Doe may have a mobile and a home number, but you can add John Doe’s work number later using the Phonebook Edit feature.
Page 96: Phone Call Features
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After confirmation, the phone book entries will be deleted. • Note that only the phone book in the current language is deleted. List All Names in the UConnect™ Phonebook • Press the “Phone” button to begin. •...
Page 97 call, press and hold the ’Phone’ button until you hear a single beep indicating that the incoming call was rejected. Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cell phone.
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conference Call When two calls are in progress (one active and one on hold), press and hold the “Phone” button until you hear a double beep indicating that the two calls have been joined into one conference call.
Page 99: Uconnect™ System Features
Call Continuation Call continuation is progression of a phone call on UConnect™ system after the vehicle ignition key has been switched to off. Call continuation functionality available on the vehicle can be any one of three types: • After ignition key is switched off, a call can continue on the UConnect™...
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Assistance If you are in an emergency and the mobile phone is reachable: • Pick up the phone and manually dial the emergency number for your area. If the phone is not reachable and the UConnect™ system is operational, you may reach the emergency number as follows: •...
Page 101 Please refer to the 24-Hour “Towing Assistance” cover- age details in the Warranty information booklet and on the 24–Hour Towing Assistance Card. Paging To learn how to page refer to Working with Automated Systems. Paging works properly except for pagers of certain companies which time-out a little too soon to work properly with the UConnect™...
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE entries. To use this feature, dial the number you wish to call and then press the “Voice Recognition” button and say “Send.” The system will prompt you to enter the name or number, say the name of the phonebook entry you wish to send.
Page 103 notification to inform you of your phone and network status when you are attempting to make a phone call using UConnect™. The status is given for roaming, network signal strength, phone battery strength, etc. Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™...
Page 104: Advanced Phone Connectivity
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect™ system allows on going calls to be transferred from your cellular phone to the UConnect™ system without terminating the call. To transfer an ongo- ing call from your UConnect™...
Page 105: Understanding The Features Of Your Vehicle 105
• Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts. • You can also press the “Voice Recognition” button anytime while the list is being played, and then choose the phone that you wish to select.
Page 106 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE From outside the UConnect™ mode (e.g. from radio mode) • Press and hold the “Voice Recognition” button for 5 seconds until the session begins, or, • Press the “Voice Recognition” button and say Setup, Voice Training command.
Page 107 • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. • When navigating through an automated system, such as voice mail, or when sending a page, at the end of speaking the digit string, make sure to say Send.
Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • dry weather condition. • operation from driver seat. • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect™ system. •...
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111...
Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts. continue delete dial download edit emergency English erase all Espanol...
Page 113 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 114: General Information
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 115: Power Seats - If Equipped
WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked. •...
Page 116: Power Reclining Seats - If Equipped
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
Page 117: Lumbar Support - If Equipped
WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 118: Head Restraints
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjust the restraint so that the upper edge is as high as practical. To raise it, pull upward on the head restraint.
Page 119 The controls for each heater are located near the bottom center of the instrument panel. After turning on the ignition, you can choose from High, Off, or Low heat settings. Amber LEDs in the top portion of each switch indicate the level of heat in use. Two LEDs will illuminate for high, one for low, and none for off.
Page 120: Folding Rear Seat
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical condition must exercise care when using the seat heater.
Page 121: To Open And Close The Hood
When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. WARNING! • Be certain that the seatback is securely locked into position. If the seatback in not securely locked into position the seat will not provide the proper stability for child seats and/or passengers.
Page 122 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Next, move to the outside of the vehicle and push the safety catch to the left. The safety catch is located under the center front edge of the hood. Hood Safety Catch Use the hood prop rod (if equipped) to secure the hood in the open position.
Page 123: Lights
LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instru- ment panel lights, instrument panel light dimming, inte- rior lights, and fog lights. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Headlight Switch Rotate the headlight switch clockwise to the first detent...
Page 124: Automatic Headlights - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped This system automatically turns the headlights ON or OFF according to ambient light levels. To turn the system ON, rotate the headlight switch counter-clockwise to the AUTO (A) position. When the system is ON, the Head- light Time Delay feature is also ON.
Page 125: Headlights On With Wipers (Available With Auto Headlights Only)
Headlights On with Wipers (Available with Auto Headlights Only) When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned on if the headlight switch is placed in the AUTO position. In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature.
Page 126: Daytime Running Lights - If Equipped
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights — If Equipped The high beam headlights will come on as Daytime Running Lights, whenever the ignition switch is on, the headlights are off, and the parking brake is off. The headlight switch must be used for normal nighttime driving.
Page 127 Multi-Function Lever Turn Signals Move the Multi-Function Lever up or down and the corresponding turn signal indicator in the instrument cluster flashes to show proper operation of the front and rear turn signal lights. You can also signal a lane change UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 by moving the lever partially up or down without moving beyond the detent.
Page 128: Overhead Console Map/Reading Lights
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash to Pass You can signal another vehicle with your headlights by lightly pulling the Multi-Function Lever toward you. This will cause the headlights to turn on at high beam and remain on until the lever is released. Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console.
Page 129 because a door is open. This includes the glove box light, but not the trunk light. To restore interior light operation, either turn the ignition switch ON or cycle the light switch. Dimmer Control The dimmer control is part of the headlight switch, and is located on the left side of the instrument panel.
Page 130: Windshield Wipers And Washers
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The multi-function lever operates the windshield wipers and washer when the ignition switch is in the ON position. The lever is located on the left side of the steering column. Windshield Wiper/Washer Control Rotate the end of the multi-function lever to the first detent past the intermittent settings for Low-speed wiper...
Page 131: Mist Feature
the wipe interval from a minimum of one cycle every second to a maximum of approximately 30 seconds between cycles. WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 132: Adding Washer Fluid
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Headlights On with Wipers feature can be turned on or off through the Electronic Vehicle Information Center (EVIC) — if equipped. For details, refer to ”Headlights On with Wipers,” under “Personal Settings (Customer Programmable Features),”...
Page 133: Tilt/Telescoping Steering Column
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column.
Page 134: Adjustable Pedals - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not adjust the steering wheel while driving. The telescoping adjustment must be locked while driv- ing. Adjusting the steering wheel while driving or driving without the telescoping adjustment locked could cause the driver to lose control of the vehicle. ADJUSTABLE PEDALS —...
Page 135: Electronic Speed Control
• The pedals can be adjusted while driving. • The pedals cannot be adjusted when the vehicle is in R (Reverse) or when the Speed Control is ON. CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls.
Page 136: To Activate
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate: Push and release the (“ON/OFF”) button lo- cated on the end of the speed control lever. The indicator light in the instrument cluster will illuminate to show that the speed control sys- tem is ON.
Page 137: To Resume Speed
• Pull the speed control lever toward you (“CANCEL”). Pushing and releasing the (“ON/OFF”) button or turning off the ignition erases the set speed from memory. To Resume Speed: If you deactivated the speed control without erasing the set speed from memory and your vehicle speed is above 20 mph (32 km/h) you can resume the previous set speed.
Page 138: Overhead Console
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using Speed Control On Hills NOTE: The speed control system maintains speed up and down hills. A slight speed change on moderate hills is normal. The automatic transmission will downshift while climb- ing uphill or descending downhill. This downshift is necessary to maintain vehicle set speed.
Page 139: Courtesy/Reading Lights
Courtesy/Reading Lights At the forward end of the console are two courtesy/ reading lights. Press the lens to turn on the light. Press it a second time to turn off the light. These lights also turn on when a door is opened, or when the unlock button on the remote keyless entry transmitter is pressed, or when the dimmer control is turned fully upward, past the second detent.
Page 140: Programming Homelink
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 141 It is recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for more efficient training and accurate transmission of the radio-frequency signal. Your vehicle should be parked outside of the garage while training.
Page 142 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: After training a HomeLink garage door does not operate with HomeLink and the garage door opener was manufactured after 1995, the garage door opener may have rolling code. If so, proceed to the heading “Programming A Rolling Code System.” 5.
Page 143: Gate Operator/Canadian Programming
7. Return to the vehicle and press the programmed HomeLink button twice (holding the button for 2 sec- onds each time). If the device is plugged in and activates, programming is complete. If the device does not activate, press the button a third time (for 2 seconds) to complete the training.
Page 144: Using Homelink
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Then proceed with Step 4 under “Programming HomeLink.” earlier in this section. Using HomeLink To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device (i.e. garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.
Page 145: Troubleshooting Tips
Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the Learn Button on the Garage Door Opener to complete the training for Rolling Code. •...
Page 146: Power Sunroof - If Equipped
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED The power sunroof switch is located between the sun visors on the overhead console. Power Sunroof Controls WARNING! • Never leave children in a vehicle, with the keys in the ignition switch.
Page 147: Opening Sunroof - Express
Opening Sunroof - Express Press the switch rearward and release, and the sunroof will open automatically from any position. The sunroof will open fully and then stop automatically. This is called Express Open. During Express Open operation, any movement of the sunroof switch will stop the sunroof. Closing Sunroof - Express Press the switch forward and release, and the sunroof will close automatically from any position.
Page 148: Sunshade Operation
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunshade Operation The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens. NOTE: The sunshade cannot be closed if the sunroof is open. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears.
Page 149: Sunroof Fully Closed
Sunroof Fully Closed Press the switch forward and release to ensure that the sunroof is fully closed. ELECTRICAL POWER OUTLETS There are two 12-volt electrical outlets on this vehicle. Both of the outlets are protected by a fuse. The 12-volt power outlet next to the ash receiver tray (if equipped with an optional Smoker’s Package) has power available only when the ignition is on.
Page 150: Electrical Outlet Use With Engine Off
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console outlet is powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent engine starting. Center Console Power Outlet Electrical Outlet Use With Engine Off CAUTION! •...
Page 151: Cup Holders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 CUP HOLDERS Front Seat Cup Holders The cup holders are located in the forward edge of the center console. Front Seat Cup Holders...
Page 152: Rear Seat Cup Holders
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seat Cup Holders The rear seat cup holders are located in the center armrest between the rear seats. The cup holders are positioned forward in the armrest and side-by-side to provide convenient access to beverage cans or bottles while maintaining a resting place for the rear occupants’...
Page 153: Storage
STORAGE Console Features The center console contains two shift bezel cubby bins with rubber mats for holding small items. For vehicles not equipped with navigation radio, the console also contains an extra storage bin located below the climate control, which holds up to four CD jewel cases. Without Vehicle Entertainment System (VES) Two separate storage compartments are also located underneath the armrest.
Page 154: Cargo Area
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The top compartment holds small items, such as a pen and note pad, while the larger bottom compartment will hold CDs and alike. The bottom compartment also con- tains a 12-volt power outlet and a molded-in coin holder (designed to hold various size coins).
Page 155 WARNING! • Be certain that the seatback is securely locked into position. If the seatback in not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious in- jury.
Page 156: Load Leveling System - If Equipped
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LOAD LEVELING SYSTEM — IF EQUIPPED The automatic load leveling system will provide a level- riding vehicle under most passenger and cargo loading conditions. A hydraulic pump contained within the shock absorbers raises the rear of the vehicle to the correct height. It takes approximately 1 mile (1.6 km) of driving for the leveling to complete depending on road surface conditions.
Page 157: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Controls ... . . 161 Base Instrument Cluster ....162 Premium Instrument Cluster —...
Page 158 158 UNDERSTANDING YOUR INSTRUMENT PANEL AM Reception ..... . . 190 FM Reception ......190 Sales Code REN —...
Page 159 Operation Instructions - CD Mode For CD And MP3 Audio Play ....219 Notes On Playing MP3 Files ... . . 222 List Button (CD Mode For MP3 Play) .
Page 160 160 UNDERSTANDING YOUR INSTRUMENT PANEL Climate Controls ..... . . 239 Manual Air Conditioning And Heating System ......239 Automatic Temperature Control —...
Page 161: Instrument Panel And Controls
INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — Hazard Switch 4 — Electronic Stability Program Off Button* / Traction Control System Off Button* 5 — Glove Box UNDERSTANDING YOUR INSTRUMENT PANEL 161 6 — Radio 7 —...
Page 162: Base Instrument Cluster
162 UNDERSTANDING YOUR INSTRUMENT PANEL BASE INSTRUMENT CLUSTER...
Page 163: Premium Instrument Cluster - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 163 PREMIUM INSTRUMENT CLUSTER — IF EQUIPPED...
Page 164: Instrument Cluster Descriptions
164 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Base Cluster The word TRIP will appear when this button is pressed. Push in and hold the button for two seconds when the trip odometer displays to reset it to 0 miles (kilometers).
Page 165 6. Charging System Light This light shows the status of the electrical charg- ing system. The light should turn on when the ignition switch is first turned ON and remain on briefly as a bulb check. If the light stays on or turns on while driving, turn off some of the vehicle’s non-essential electrical devices (i.e.
Page 166 166 UNDERSTANDING YOUR INSTRUMENT PANEL The gauge pointer will likely indicate a higher tempera- ture when driving in hot weather, up mountain grades, or when towing a trailer. It should not be allowed to exceed the upper limits of the normal operating range. CAUTION! Driving with a hot engine cooling system could damage your vehicle.
Page 167 NOTE: Check for a defective outside light bulb if either indicator flashes at a rapid rate. (See page 127 for more information.) 10. Airbag Warning Light This light will turn on for 6 to 8 seconds as a bulb check when the ignition switch is first turned ON.
Page 168 168 UNDERSTANDING YOUR INSTRUMENT PANEL 14. Oil Pressure Warning Light This light shows low engine oil pressure. The light should turn on momentarily when the engine is started. If the light turns on while driving, stop the vehicle, and shut off the engine as soon as possible. A single chime will sound when this light turns on.
Page 169 19. Odometer/Trip Odometer The odometer shows the total distance the vehicle has been driven. The trip odometer shows individual trip mileage. Refer to “Trip Odometer Button” for additional information. NOTE: U.S. federal regulations require upon transfer of vehicle ownership, the seller certify the mileage the vehicle has been driven.
Page 170 170 UNDERSTANDING YOUR INSTRUMENT PANEL next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the “ON”...
Page 171 NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. Immediate repair is necessary if brake failure is indicated. WARNING! Driving a vehicle with the brake light on is danger- ous.
Page 172 172 UNDERSTANDING YOUR INSTRUMENT PANEL 21. Vehicle Security Alarm (VSA) Indicator Light — If Equipped The VSA indicator Light flashes rapidly when the VSA is arming, and slowly when the VSA is armed. (See page 18 for more information.) 22. Tire Pressure Monitoring Telltale Light — If Equipped Each tire, including the spare (if provided), should be checked monthly when cold and...
Page 173 system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated. This sequence will continue upon subse- quent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the sys- tem may not be able to detect or signal low tire pressure as intended.
Page 174 174 UNDERSTANDING YOUR INSTRUMENT PANEL If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required. However, the con- ventional brake system will continue to operate normally if the BRAKE warning light is not on.
Page 175: Electronic Vehicle Information Center (Evic) - If Equipped
ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) – IF EQUIPPED Electronic Vehicle Information Center The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display. It is located in the instrument cluster below the speedometer. Vehicles UNDERSTANDING YOUR INSTRUMENT PANEL 175 equipped with steering wheel mounted buttons (de- scribed in this section) are also equipped with the EVIC.
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by pressing the following buttons mounted on the steering wheel: Press and release the MENU button and the mode displayed will change between Trip Functions, Navigation (if equipped), System Status, Personal Settings, and Telephone (if MENU equipped).
Page 177: Electronic Vehicle Information Center (Evic)
Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the Electronic Vehicle Information Center (EVIC) displays the following messages: • Turn Signal On (with a continuous warning chime if the vehicle is driven more than 1 mile [1.6 km] with either turn signal on) •...
Page 178: Oil Change Required
178 UNDERSTANDING YOUR INSTRUMENT PANEL • Check Gascap (refer to “Adding Fuel” in Section 5 of this manual for more details) • Oil Change Required (with a single chime) Oil Change Required Your vehicle is equipped with an engine oil change indicator system.
Page 179 • Elapsed Time • Display Units of Measure in Press the SCROLL button to cycle through all the Trip Computer functions. The Trip Functions mode displays the following: • Average Fuel Economy / Fuel Saver Mode Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET”...
Page 180 180 UNDERSTANDING YOUR INSTRUMENT PANEL This feature allows you to monitor when the MDS switches off the fuel on four of the eight cylinders and it can be used to modify driving habits in order to increase the time in which the fuel saver mode is active. 8 Cylinder Operation - MDS Off •...
Page 181: Compass Display
• Trip A Shows the total distance traveled for trip A since the last reset. • Trip B Shows the total distance traveled for trip B since the last reset. • Elapsed Time Shows the total elapsed time of travel since the last reset when the ignition switch is in the ACC position.
Page 182 182 UNDERSTANDING YOUR INSTRUMENT PANEL 360° turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in the EVIC turns off. The compass will now function normally. Manual Compass Calibration If the compass appears erratic and the “CAL” message does not appear in the EVIC display, you must put the compass into the Calibration Mode manually as follows: 1.
Page 183: Telephone - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 183 1. Turn the ignition switch ON. 2. Press and hold the compass button for approximately 2 seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4.
Page 184 184 UNDERSTANDING YOUR INSTRUMENT PANEL • Phone status: idle, voice mail, roaming, battery strength, and signal strength in increments of 20 percent. • Call status: Incoming call, connecting, connected, air time in minutes and seconds, call ended, call failed, roaming, and no phone connection. •...
Page 185: Navigation - If Equipped
The EVIC displays this symbol to indicate that you have voice mail. Voice Mail The EVIC displays this symbol to indicate a text message. Text Message The EVIC displays this symbol to indicate the battery strength of the UConnect™ phone. Battery Strength UNDERSTANDING YOUR INSTRUMENT PANEL 185...
Page 186: Personal Settings
186 UNDERSTANDING YOUR INSTRUMENT PANEL display is active, the SCROLL button can be used to scroll through the list, the FUNCTION SELECT button can be used to select an item, and the AUDIO MODE button can be used to return to the previous menu. When the Map display is active, pressing the FUNCTION SELECT but- ton will change the Navigation Unit Display to the Menu.
Page 187 NOTE: The EVIC will not change the UConnect™ language selection. Please refer to “Language Selection” in the HANDS–FREE COMMUNICATION (UConnect™) section of this manual for details. “Lock Doors Automatically at 15 mph (24 Km/h)” When ON is selected, all doors will lock automatically when the vehicle reaches a speed of 15 mph (24 km/h).
Page 188 188 UNDERSTANDING YOUR INSTRUMENT PANEL “Flash Lights with Remote Key Lock” When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the remote keyless entry transmitter. This feature may be selected with or without the sound horn on lock feature selected.
Page 189 “Delay Power Off to Accessories Until Exit” When this feature is selected, the power window switches, radio, hands–free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned off.
Page 190: Radio General Information
190 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO GENERAL INFORMATION Radio Broadcast Signals Your new radio will provide excellent reception under most operating conditions. Like any system, however, car radios have performance limitations, due to mobile op- eration and natural phenomena, which might lead you to believe your sound system is malfunctioning.
Page 191: Sales Code Ren - Multimedia System - If Equipped
changer (if equipped) will remain active for 10 minutes after the ignition switch is turned off. Opening either front door will cancel this feature. NOTE: For vehicles equipped with the Electronic Ve- hicle Information Center (EVIC), the radio, steering wheel radio controls (if equipped), and 6 disc CD/DVD changer (if equipped) will remain active for up to 60 minutes after the ignition switch is turned off.
Page 192: Operating Instructions - Satellite Radio (If Equipped)
192 UNDERSTANDING YOUR INSTRUMENT PANEL to the car speakers while different audio tracks play through the system’s wireless headphones. This means rear seat passengers can watch a DVD on the optional rear-seat entertainment system while the driver and front seat passenger listen to the radio. Other special features include direct tune, music type selections, easy store presets, backup camera display for vehicles equipped with a backup camera, and on some...
Page 193 4. To move the minute forward, touch the screen where the word “Min” with the arrow pointing upward is displayed. To move the minute backward, touch the screen where the word “Min” with the arrow pointing downward is displayed. 5. To save the new time setting, touch the screen where the word “Save”...
Page 194: Sales Code Req - Am/Fm Stereo Radio And
194 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone 1. Turn on the system. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed.
Page 195: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping.
Page 196 196 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button (UConnect™ Hands Free Phone) — If Equipped Press this button to operate the Hand Free Phone (UCon- nect™) feature (if equipped). Refer to “Hands-Free Com- munication (UConnect™)” in Section 3 for more informa- tion.
Page 197 RW/FF (Radio Mode) Pressing the rewind or fast forward button causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM, FM or Satellite (if equipped) frequencies. TUNE Control (Radio Mode) Turn the right side rotary control clockwise to increase or counter-clockwise to decrease the frequency.
Page 198 198 UNDERSTANDING YOUR INSTRUMENT PANEL program format type to be selected. Many radio stations do not currently broadcast Music Type information. Toggle the Music Type button to select the following format types: Program Type No program type or un- defined Adult Hits Classical Classic Rock...
Page 199 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 200 200 UNDERSTANDING YOUR INSTRUMENT PANEL • Angle – Repeatedly Pressing SELECT will change the viewing angle if supported by the DVD disc (If Equipped). NOTE: The available selections for each of the above entries varies depending upon the disc. NOTE: These selections can only be made while playing a DVD.
Page 201 Audio Language — If Equipped Selecting this item will allow the user to choose a default audio language (effective only if language supported by disc). If customer wishes to select a language not listed, then scroll down and select other. Enter the country code using the TUNE control knob to scroll up and down to select the # and then push to select.
Page 202 202 UNDERSTANDING YOUR INSTRUMENT PANEL a disc is loaded, changes will not be effective. Also, the defaults are effective only if the disc supports the customer-preferred settings. AM and FM Buttons (Radio Mode) Press the buttons to select AM or FM Modes. SET Button (Radio Mode) —...
Page 203: Operation Instructions
Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
Page 204 204 UNDERSTANDING YOUR INSTRUMENT PANEL Eject Button — Ejecting Compact Disc(s) Press the eject button and the push-button with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 205: Notes On Playing Mp3/Wma Files
Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
Page 206 206 UNDERSTANDING YOUR INSTRUMENT PANEL If a disc contains multi formats, such as CD audio and mp3/wma tracks, the radio will only play the mp3/wma tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files.
Page 207: Play)
Playlist files are not supported. MP3 Pro files are not supported. Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files.
Page 208 208 UNDERSTANDING YOUR INSTRUMENT PANEL Press the INFO button once more to return to elapsed time priority mode. Press and hold the INFO button for 3 seconds or more and radio will display song titles for each file. Press and hold the INFO button again for 3 seconds to return to elapsed time display.
Page 209: Sales Code Rer - Multimedia System - If Equipped
SET Button (Auxiliary Mode) No function. Operating Instructions - Hands Free Phone (UConnect™) (If Equipped) Refer to “Hands-Free Communication (UConnect™)” in Section 3 of this manual. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to “Satellite Radio” in this section. Operating Instructions - Video Entertainment System (VES ) (If Equipped) Refer to separate “Video Entertainment System (VES )
Page 210 210 UNDERSTANDING YOUR INSTRUMENT PANEL player, USB port, 20 gigabyte Hard Drive (HDD), and the UConnect hands-free Bluetooth cellular system. NOTE: If your vehicle is not equipped with UConnect , the unit will respond with a “Feature Not Available” message when selecting controls related to this feature. A 6.5-inch touch screen allows easy menu selection, while the Advanced Voice Dialog System recognizes more than 1,000 words for audio, navigation, entertainment, and...
Page 211: Operating Instructions - Satellite Radio
camera, and on some models a dual display screen operation. Refer to your “Navigation User’s Manual” for detailed operating instructions. Operating Instructions — Satellite Radio Refer to your “Navigation User’s Manual” for detailed operating instructions. Operating Instructions — Hands-Free Communication (UConnect™) (If Equipped) Refer to your “Navigation User’s Manual”...
Page 212 212 UNDERSTANDING YOUR INSTRUMENT PANEL Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time. Proceed as follows to change the current setting: 1. Turn on the system. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen.
Page 213: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
6. To save the new time setting, touch the screen where the word “Save” is displayed. Show Time if Radio is Off When selected, this feature will display the time of day on the touch screen when the system is turned off. Proceed as follows to change the current setting: 1.
Page 214: Operating Instructions - Radio Mode
214 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
Page 215 If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UCon- nect” message will display on the radio screen. Phone Button (UConnect™ Hands Free Phone) — If Equipped Press this button to operate the Hand Free Phone (UCon- nect™) feature (if equipped).
Page 216 216 UNDERSTANDING YOUR INSTRUMENT PANEL Step 2. For vehicles not equipped with satellite radio, press the SETUP button and then follow the above procedure, starting at Step 2. INFO Button Press the INFO button for an RDS station (one with call letters displayed).
Page 217 Press the rotary TUNE control knob a fifth time and FADE will display. Turn the TUNE control knob to the left or right to adjust the sound level between the front and rear speakers. Press the rotary TUNE control knob again to exit setting tone, balance, and fade.
Page 218 218 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon 16 Digit-Character is displayed, the radio will be tuned to the next frequency Display station with the same selected Music Type name.
Page 219: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
AM and FM Buttons Press the buttons to select AM or FM Modes. SET Button — To Set the Push-Button Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button. The symbol SET 1 will now show in the display window. Select the button (1-6) you wish to lock onto this station and press and release that button.
Page 220 220 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: This Radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable com- pact discs (CD-RW) compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 221 If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF. NOTE: Ejecting with ignition OFF is not allowed on convertible or soft-top models (if equipped).
Page 222: Notes On Playing Mp3 Files
222 UNDERSTANDING YOUR INSTRUMENT PANEL Press the right SEEK button to move to the next ran- domly selected track. Press the RND button a second time to stop Random Play. Notes On Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited.
Page 223 • Level 2: 31 (including a separator 3-character extension) Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs.
Page 224: List Button (Cd Mode For Mp3 Play)
224 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 225 Press and hold the INFO button again for 3 seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 226: Satellite Radio (Rsc) - If Equipped (Req And Res Radios Only)
226 UNDERSTANDING YOUR INSTRUMENT PANEL SATELLITE RADIO (RSC) — IF EQUIPPED (REQ AND RES RADIOS ONLY) Satellite radio uses direct satellite to receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius™ Satel- lite Radio.
Page 227: Selecting Satellite Mode
selected. Press the TUNE control knob and the Sirius ID number will display. The Sirius ID number display will time out in 2 minutes. Press any button on the radio to exit this screen. Selecting Satellite Mode Press the SAT button until SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode.
Page 228 228 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new channel until you make another selection.
Page 229 By pressing the SEEK button when the Music Type function is active, the radio will be tuned to the next channel with the same selected Music Type name. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset channel.
Page 230: Operating Instructions - Hands Free Phone (If Equipped)
230 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Hands Free Phone (If Equipped) Refer to “Hands-Free Communication (UConnect™)” in Section 3 of this manual. Operating Instructions - Video Entertainment System (VES ) (If Equipped) Refer to separate “Video Entertainment System (VES ) Guide.”...
Page 231 VES™ Video Screen NOTE: Close the armrest after the LCD screen has been raised to its viewing position. • The touch screen radio and DVD player controls allow front seat operation for easy setup in the case of younger rear seat passengers. UNDERSTANDING YOUR INSTRUMENT PANEL 231 •...
Page 232: Universal Consumer Interface (Uci) - If Equipped
232 UNDERSTANDING YOUR INSTRUMENT PANEL • Two wireless infrared headsets allow rear seat passen- gers to listen to the same or individual audio sources. Audio/Video RCA Jacks (AUX Jacks) on the rear of the center console enable the monitor to display video directly from a video camera, connect video games for display on the screen, or play music directly from an MP3...
Page 233: Connecting The Ipod
• the iPod battery charges when plugged into the UCI connector. Connecting the iPod Use the optional connection cable to connect an iPod to the vehicle’s UCI connector (which is located in the glove box on some vehicles. This location may vary with vehicle).
Page 234 234 UNDERSTANDING YOUR INSTRUMENT PANEL RW (Rewind) Button Press and hold the “RW” button to move backward in the current track. Holding the “RW” button long enough will take you back to the beginning of the current track. Pressing and releasing the “RW” button will go back 5 seconds of the current track.
Page 235: List Or Browse Mode
SCAN Button Pressing the “SCAN” button will play the first 5 seconds of each track in the current list and then forward to the next song. To stop the SCAN mode and start playing the desired track, press the “SCAN” button again. During the SCAN mode, you can also press the SEEK button to the left or right to go to the previous or next tracks.
Page 236 236 UNDERSTANDING YOUR INSTRUMENT PANEL During all List modes, the iPod will display all lists in “wrap-around” mode. So if the track you wish to select is at the bottom of the list, you just turn the “TUNE/ SCROLL” knob backwards (counter-clockwise) to get to the track faster.
Page 237: Remote Sound System Controls
REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the surface of the steering wheel at the 3 and 9 o’clock positions. Electronic Vehicle Information Center UNDERSTANDING YOUR INSTRUMENT PANEL 237 Vehicles equipped with steering wheel mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC).
Page 238: Cd/Dvd Disc Maintenance
238 UNDERSTANDING YOUR INSTRUMENT PANEL If the Compass/Temp/Audio screen is already displayed when the AUDIO MODE button is pressed, then the mode will change (i.e. from AM to FM, to Media mode, etc., depending on which radio is in the vehicle). When the EVIC is in the Compass/Temp/ Audio screen, press the FUNCTION SELECT button to operate various radio, media, and...
Page 239: Radio Operation And Cellular Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 239 RADIO OPERATION AND CELLULAR PHONES Manual Air Conditioning and Heating System Under certain conditions, the cellular phone being On in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna.
Page 240 240 UNDERSTANDING YOUR INSTRUMENT PANEL Blower Control The rotary knob on the left controls the blower. The control has an OFF posi- tion and four speed settings. The blower will remain on until the con- trol is turned to the OFF position or the ignition is turned OFF.
Page 241 is also directed to the front door windows through the side window demister grilles. • Floor Air flows through the floor outlets located under the instrument panel and into the rear seating area through vents under the front seats. • Bi-Level Air flows through the outlets located in the instrument panel and through the outlets located on the floor.
Page 242 242 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control — If Equipped Automatic Temperature Controls Automatic Operation The Infrared Dual-Zone Climate Control System auto- matically maintains the climate in the cabin of the vehicle at the comfort levels desired by the driver and passenger. To accomplish this, the system gathers information from the controls on the climate control, from a dual sun- sensor located in the top of the instrument panel, from an...
Page 243 or HI AUTO. The LO AUTO position should be used for front seat occupants only. The HI AUTO position should be used when more airflow is desired, or when rear seat occupants are present. Then, dial in the temperature you would like the system to maintain by rotating the driver or passenger Temperature Control knob.
Page 244 244 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • The surface of the climate control panel and the top center of the instrument panel should be kept free of debris due to the location of the climate control sensors. Mud on the windshield may also cause poor operation of this system.
Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 245...
Page 246 246 UNDERSTANDING YOUR INSTRUMENT PANEL The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Defrost Air is directed to the windshield through the outlets at the base of the windshield.
Page 247 turn off the air conditioning. An LED in the button illuminates when manual compressor operation is selected. NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. • Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
Page 248 248 UNDERSTANDING YOUR INSTRUMENT PANEL Winter Operation Use of the air Recirculation mode during winter months is not recommended because it may cause window fogging. Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e. vacation) for two weeks or more, run the air condi- tioning system at idle for about five minutes in the fresh air and high blower setting.
Page 249 UNDERSTANDING YOUR INSTRUMENT PANEL 249 Control Setting Suggestions for Various Weather Conditions...
Page 250 250 UNDERSTANDING YOUR INSTRUMENT PANEL REAR WINDOW FEATURES Electric Rear Window Defroster The electric Rear Window Defroster Control is located on the climate control. Press this button to turn on the rear window defroster and the heated side mirrors (if equipped). An LED in the button will illumi- nate when the rear window defroster is ON.
Page 251: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 255 Automatic Transmission ....256 Normal Starting (Tip Start) .
Page 252 252 STARTING AND OPERATING Driving On Slippery Surfaces ....275 Acceleration ......275 Traction .
Page 253 Compact Spare Tire — If Equipped ..302 Limited Use Spare — If Equipped ..302 Tire Spinning ......303 Tread Wear Indicators .
Page 254 254 STARTING AND OPERATING Fuel Filler Cap (Gas Cap) ....323 Loose Fuel Filler Cap Message ... . 325 Vehicle Loading .
Page 255: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. STARTING AND OPERATING 255 WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 256: Automatic Transmission
256 STARTING AND OPERATING Automatic Transmission The gear selector must be in the “N” (Neutral) or “P” (Park) position before you can start the engine. Apply the brakes before shifting into any driving gear. CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: •...
Page 257: If Engine Fails To Start
If Engine Fails To Start WARNING! • Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. • Do not attempt to push or tow your vehicle to get it started.
Page 258: After Starting
258 STARTING AND OPERATING After Starting The idle speed is controlled automatically and it will decrease as the engine warms up. ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 volt AC electrical outlet with a grounded, three-wire extension cord.
Page 259: Automatic Transmission - General Information
WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.
Page 260 260 STARTING AND OPERATING • The electronically controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new vehicle may be somewhat abrupt or soft until after the break-in period. This is a normal condition, and pre- cision shifts will develop within a few shift cycles.
Page 261: Brake/Transmission Shift Interlock System
change the way it shifts to help control the condition. This may result in a slightly different feeling or response during normal operation in “D” (Drive) position. After the transmission cools down, it will return to normal operation. Brake/Transmission Shift Interlock System This vehicle is equipped with a brake transmission shift interlock system (BTSI) that holds the selector lever in the “P”...
Page 262: Speed Automatic Transmission
262 STARTING AND OPERATING tab, which can be accessed through a hole inside the bin. While the override is pressed, the shifter can be moved out of the “P” (Park) position without pressing the brake. After operation, return the rubber storage tray to its original position.
Page 263 Never use “P” (Park) while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. When parking on a flat surface, place the gear selector in the “P” (Park) position first, and then apply the parking brake.
Page 264 264 STARTING AND OPERATING CAUTION! Damage to the shifter could result if the selector lever is moved out of “P” (Park) before the ignition is turned from the LOCK to ON position. “R” (Reverse) For moving the vehicle rearward. Always stop before moving the lever to “R”...
Page 265 NOTE: • If the vehicle is started in cold temperatures, shifts into Overdrive may be delayed. Normal Overdrive and shifting operation will resume when the temperature of the transmission reaches the appropriate tempera- ture. Refer to the “Note” under “Torque Converter Clutch”...
Page 266 266 STARTING AND OPERATING Torque Converter Clutch A feature designed to improve fuel economy has been added to the automatic transmission of this vehicle. A clutch within the torque converter engages automatically at calibrated speeds. This may result in a slightly differ- ent feeling or response during normal operation in high gear.
Page 267: Speed Automatic Transmission
If the problem has been momentary, the transmission can be reset to regain all forward gears. • Stop the vehicle and shift into “P” (Park). • Turn the key to LOCK then start the engine. • Shift into “D” (Drive) and resume driving. NOTE: Even if the transmission can be reset, we recom- mend that you visit a dealer at your earliest possible convenience.
Page 268 268 STARTING AND OPERATING Gear Ranges “P” (Park) “P” (Park) supplements the parking brake by locking the transmission. The engine can be started in this range. Never use “P” (Park) while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
Page 269 CAUTION! Damage to the shifter could result if the selector lever is moved out of “P” (Park) before the ignition is turned from the LOCK to ON position. “R” (Reverse) Shift into “R” (Reverse) gear only when the vehicle is completely stopped.
Page 270 270 STARTING AND OPERATING “D” (Drive) This range should be used for most city and highway driving. It provides the smoothest upshifts and down- shifts and the best fuel economy. The transmission automatically upshifts through fifth gear. The “D” (Drive) position provides optimum driving characteristics under all normal operating conditions.
Page 271 WARNING! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehicle control. Your vehi- cle’s ABS will not prevent this type of loss of control. You could lose control of your vehicle and have an accident.
Page 272: Autostick - If Equipped
272 STARTING AND OPERATING 5. Restart the engine. 6. Move the selector lever to the desired range. If the problem is no longer detected, the transmission will return to normal operation. NOTE: Even if the transmission can be reset, we recom- mend that you visit a dealer at your earliest possible convenience.
Page 273: Autostick - 5.7L Engine
selector lever to the Left (-) triggers a downshift and to the Right (+) an upshift. The gear position will display in the instrument cluster on the transmission range indica- tor. You can shift in or out of the Autostick mode at any time without taking your foot off the accelerator pedal.
Page 274: All Wheel Drive - If Equipped
274 STARTING AND OPERATING to the right for at least one second. The transmission will now operate automatically, shifting between the five available gears. • You can start out in first or second gear. The system will ignore attempts to upshift at too low of a vehicle speed.
Page 275: Driving On Slippery Surfaces
DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the rear wheels to pull errati- cally to the right or left. This phenomenon occurs when there is a difference in the surface traction under the rear (driving) wheels.
Page 276: Driving Through Water
276 STARTING AND OPERATING DRIVING THROUGH WATER Driving through water more than a few inches deep will require extra caution to ensure safety and prevent dam- age to your vehicle. Flowing/Rising Water WARNING! Do not drive on or cross a road or a path where water is flowing and/or rising (as in storm run-off).
Page 277 CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle. • Determine the condition of the road or the path that is under water and if there are any obstacles in the way before driving through the standing water.
Page 278: Parking Brake
278 STARTING AND OPERATING PARKING BRAKE The parking brake should always be applied when the driver is not in the vehicle. WARNING! Never use “P” (Park) position on an automatic trans- mission as a substitute for the parking brake. Always apply parking brake fully when parked to guard against vehicle movement and possible injury or damage.
Page 279 Parking Brake The brake light in the instrument cluster will turn on when the parking brake is applied and the ignition switch is on. STARTING AND OPERATING 279 NOTE: This light only shows that the parking brake is applied. It does not show the degree of brake application. WARNING! •...
Page 280: Brake System
280 STARTING AND OPERATING BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic systems loses normal capability, the remaining system will still function. There will be some loss of overall braking effectiveness. This may be evident by increased pedal travel during application, greater pedal force required to slow or stop, and potential activation of the Brake Warning Light.
Page 281 ABS is activated during braking under certain road or stopping conditions. ABS-inducing conditions can in- clude ice, snow, gravel, bumps, railroad tracks, loose debris, or panic stops. You also may experience the following when the brake system goes into Anti-lock: •...
Page 282: Power Steering
282 STARTING AND OPERATING All vehicle wheels and tires must be the same size and type and tires must be properly inflated to produce accurate signals for the computer. Anti-Lock Brake Light The ABS light monitors the Anti-Lock Brake Sys- tem.
Page 283: Multi Displacement System (Mds) - 5.7L Engine
Upon initial start-up in cold weather, the power steering pump may make noise for a short amount of time. This is due to the cold, thick fluid in the steering system. This noise should be considered normal, and it does not in any way damage the steering system.
Page 284: Traction Control System (Tcs) - If Equipped
284 STARTING AND OPERATING TRACTION CONTROL SYSTEM (TCS) — IF EQUIPPED WARNING! The Traction Control System (TCS) cannot prevent the natural laws of physics from acting on the ve- hicle, nor can it increase the traction afforded. The TCS cannot prevent accidents, including those result- ing from excessive speed in turns, or hydroplaning.
Page 285: Brake Assist System (Bas) - If Equipped
allow more engine torque to be applied to the wheel that is not spinning. This wheel slip control is active up to 50 mph (80 km/h). CAUTION! When the ESP/TCS indicator light is illuminated continuously, the ESP is switched off. Avoid spin- ning one drive wheel.
Page 286: Electronic Stability Program (Esp) - If Equipped
286 STARTING AND OPERATING The Brake Assist System (BAS) is standard on vehicles equipped with Electronic Stability Program (ESP). The BAS is designed to optimize the vehicle’s braking capa- bility during emergency braking maneuvers. The system applies optimum pressure to the brakes in emergency braking conditions that might otherwise be afforded solely by the driver’s braking style.
Page 287 This system enhances directional control and stability of the vehicle under various driving conditions. The ESP corrects for oversteering and understeering the vehicle by applying the brake of the appropriate wheel. Engine power may also be reduced to assist in counteracting the condition of oversteer or understeer and help the vehicle maintain the desired path.
Page 288 288 STARTING AND OPERATING The ESP OFF button is located in the center of the instrument panel. To turn OFF the ESP, momentarily press the ESP OFF button and the ESP/TCS Indicator Light will illuminate. To turn the system ON again, momentarily press the ESP OFF button and the indicator light will turn OFF.
Page 289: Synchronizing Esp
Synchronizing ESP The malfunction indicator light for the ESP is combined with BAS indicator. If the power supply is interrupted (battery disconnected or discharged), the ESP/BAS malfunction indica- tor light may illuminate with the engine running. If this should occur, turn the steering wheel completely to the left and then to the right.
Page 290: Tire Safety Information
290 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards.
Page 291 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm) 65 = Aspect Ratio in Percent (%)
Page 292 292 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions.
Page 293: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 294: Tire Loading And Tire Pressure
294 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
Page 295 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
Page 296 296 STARTING AND OPERATING 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 297 STARTING AND OPERATING 297...
Page 298: Tires - General Information
298 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 299: Tire Inflation Pressures
2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
Page 300 300 STARTING AND OPERATING The pressure should be checked and adjusted as well as inspecting for signs of tire wear or visible damage at least once a month. Use a good quality pocket-type gauge to check tire pressure. Do not make a visual judgement when determining proper inflation.
Page 301: Radial-Ply Tires
Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 302: Compact Spare Tire - If Equipped
302 STARTING AND OPERATING Compact Spare Tire — If Equipped The compact spare is for temporary emergency use with radial tires. It is engineered to be used on your style vehicle only. Since this tire has limited tread life, the original tire should be repaired (or replaced) and rein- stalled at the first opportunity.
Page 303: Tire Spinning
original equipped tire on the front or rear axle of your vehicle, but it is not. Installation of this limited use spare tire affects vehicle handling. Since it is not the same tire, replace (or repair) the original tire and reinstall on the vehicle at the first opportunity.
Page 304: Tread Wear Indicators
304 STARTING AND OPERATING Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 inch (2 mm).
Page 305: Replacement Tires
WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death. Keep dismounted tires in a cool, dry place with as little exposure to light as possible.
Page 306: Alignment And Balance
306 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, result- ing in changes to steering, handling, and braking of your vehicle.
Page 307: Self-Sealing Tires - If Equipped
Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SELF-SEALING TIRES — IF EQUIPPED A non-hardening viscous sealant applied to the inner liner of each tire fills punctures up to 0.19 in.
Page 308: Snow Tires
308 STARTING AND OPERATING NOTE: In order to avoid damage to tires, chains, and your vehicle do not drive for a prolonged period of time on dry pavement. Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage.
Page 309: Tire Pressure Monitor System (Tpms) - If Equipped
Remember, more frequent rotation is permissible if de- sired. Also, correct for anything causing rapid or unusual wear prior to performing the tire rotation. The suggested rotation method is the “forward-cross” shown in the following diagram. STARTING AND OPERATING 309 TIRE PRESSURE MONITOR SYSTEM (TPMS) —...
Page 310 310 STARTING AND OPERATING pressure will also increase as the vehicle is driven - this is normal and there should be no adjustment for this increased pressure. • The TPM System will warn the driver of a low tire pressure if the tire pressure falls below the low- pressure warning limit for any reason, including low temperature effects and natural pressure loss through the tire.
Page 311 CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.
Page 312: Base System - If Equipped
312 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System — If Equipped The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels.
Page 313 vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning If a system fault is detected, the Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 314: Premium System - If Equipped
314 STARTING AND OPERATING NOTE: Vehicles with Compact Spare 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, a chime will sound and the TPM Telltale Light will turn ON.
Page 315 • 3 Trigger Modules (mounted in three of the four wheel-wells) • Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) • Tire Pressure Monitoring Telltale Light The matching full size spare wheel and tire assembly (if equipped) has a tire pressure monitoring sensor.
Page 316 316 STARTING AND OPERATING Should this occur, you should stop as soon as possible, and inflate the tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the Tire Pressure Monitoring Telltale Light will...
Page 317 1. Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. 2. Installing aftermarket window tinting that contains materials, which may block radio wave signals. 3. Accumulation of snow or ice around the wheels or wheel housings.
Page 318: General Information
318 STARTING AND OPERATING Light will remain ON and a chime will sound. In addition, the graphic in the EVIC will still display a flashing pressure value. 3. After driving the vehicle for up to 10 minutes above 15 mph (25 km/h), the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 319: Fuel Requirements
The tire pressure sensors are covered under one of the following licenses: United States ..... KR5S120123 Canada ......2671-S120123 FUEL REQUIREMENTS 2.7L Engine The 2.7L engine is designed to meet all...
Page 320: Reformulated Gasoline
320 STARTING AND OPERATING Over 40 auto manufacturers worldwide have issued and endorsed consistent gasoline specifications (the World- wide Fuel Charter, WWFC) which define fuel properties necessary to deliver enhanced emissions, performance, and durability for your vehicle. The manufacturer recom- mends the use of gasoline that meets the WWFC speci- fications if they are available.
Page 321: Mmt In Gasoline
Problems that result from using methanol/gasoline or E85 Ethanol blends are not the responsibility of the manufacturer. While MTBE is an oxygenate made from Methanol, it does not have the negative effects of Metha- nol. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase octane.
Page 322: Carbon Monoxide Warnings
322 STARTING AND OPERATING • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance, and damage the emission control system. • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat.
Page 323: Adding Fuel
• Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the trunk closed when driving your vehicle to prevent carbon monoxide and other poisonous ex- haust gases from entering the vehicle.
Page 324 324 STARTING AND OPERATING NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler cap door reinforcement. Gas Cap Tether Hook CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel tank filler tube cap (gas cap).
Page 325: Loose Fuel Filler Cap Message
WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
Page 326: Vehicle Loading
326 STARTING AND OPERATING VEHICLE LOADING The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information should be used for passenger and luggage loading as indicated. If the seatbacks are folded for carrying cargo, do not exceed the specified GVWR and GAWR.
Page 327: Overloading
WARNING! Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory...
Page 328 328 STARTING AND OPERATING A loaded vehicle is shown in the illustration. Note that neither the GVWR nor the GAWR capacities have been exceeded. EXAMPLE ONLY Empty Weight Load (Including driver, pas- sengers, and cargo) Total GAWR NOTE: Refer to the “Vehicle Certification Label” at- tached to the rear of the driver’s door for your vehicle’s GVWR and GAWRs.
Page 329: Trailer Towing
TRAILER TOWING In this section, you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
Page 330 330 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
Page 331 Weight-Distributing Hitch A weight-distributing system works by applying lever- age through spring (load) bars. They are typically used for heavier loads, to distribute trailer tongue weight to the tow vehicle’s front axle and the trailer axle(s). When used in accordance with the manufacturers’ directions, it provides for a more level ride, offering more consistent steering and brake control thereby enhancing towing safety.
Page 332 332 STARTING AND OPERATING Weight Distributing Hitch System Improper Adjustment of Weight Distributing System...
Page 333: Trailer Hitch Classification
Trailer Hitch Classification Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your authorized dealer for package content. The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition.
Page 334 334 STARTING AND OPERATING Engine/Transmission 2.7L & 3.5L Rear Wheel Drive (RWD) Automatic 3.5L All Wheel Drive (AWD) & 5.7L Automatic Refer to local laws for maximum trailer towing speeds. Frontal Area (Gross Trailer Wt.) 22 SQ. FT. (2.04 square Up to 2 persons &...
Page 335: Trailer And Tongue Weight
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and it should never exceed the weight referenced on the “Tire and Loading Information” placard. Refer to “Tire–Safety Information” in this section. Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 336: Towing Requirements
336 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the “Tire and Loading Information” placard for the maximum combined weight of occupants and cargo for your vehicle.
Page 337 • When hauling cargo, or towing a trailer, do not overload your vehicle or trailer. Overloading can cause a loss of control, poor performance, or damage to brakes, axle, engine, transmission, steering, suspen- sion, chassis structure, or tires. • Safety chains must always be used between your vehicle and trailer.
Page 338 338 STARTING AND OPERATING − Also, check the trailer tires for proper tire inflation pressures before trailer usage. − Check for signs of tire wear or visible tire damage before towing a trailer. Refer to “Tires–General Infor- mation” in this section for information on tread wear indicators and for the proper inspection procedure.
Page 339 WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 340 340 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 7 - Pin Connector 4 - Pin Connector...
Page 341: Towing Tips
Towing Tips Before setting out on a trip, practice turning, stopping, and backing the trailer in an area located away from heavy traffic. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the “3” range should be selected.
Page 342: Recreational Towing (Behind Motorhome, Etc.)
342 STARTING AND OPERATING − Extended driving at high RPM should be avoided to prevent excess heat generation. A reduction in vehicle speed may be required to avoid extended driving at high RPM. Return to a higher gear range or vehicle speed when road conditions and RPM level allows.
Page 343: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....344 If Your Engine Overheats ....345 Jacking And Tire Changing .
Page 344: Hazard Warning Flasher
344 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The hazard flasher switch is located in the center of the instrument panel below the center air outlets. Hazard Flasher Switch To engage the Hazard Warning Flashers, depress the switch on the instrument panel. When the Hazard Warn- ing Switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emer- gency.
Page 345: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, put transmission in “N”...
Page 346: Jacking And Tire Changing
346 WHAT TO DO IN EMERGENCIES WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, see Section 7, Maintenance, of this manual.
Page 347: Preparations For Jacking
Preparations For Jacking 1. Park the vehicle on a firm level surface as far from the edge of the roadway as possible. Avoid icy or slippery areas. 2. Set the parking brake and place the gear selector in PARK. 3. Turn OFF the ignition. 4.
Page 348: Jack Location/Spare Tire Stowage
348 WHAT TO DO IN EMERGENCIES Jack Location/Spare Tire Stowage The jack and spare tire are both stowed under an access cover in the trunk. Follow these steps to access the jack and spare tire. NOTE: The spare tire must be removed in order to access the jack.
Page 349 WHAT TO DO IN EMERGENCIES 349 3. Remove the fastener securing the spare tire. 4. Remove the spare tire. 5. Remove the fastener securing the jack. Spare Tire Fastener Jack Fastener...
Page 350: Jacking And Changing A Tire
350 WHAT TO DO IN EMERGENCIES WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle. Always stow the jack parts and the spare tire in the places provided. Jacking and Changing a Tire 1.
Page 351 WARNING! To avoid possible personal injury, handle the wheel covers with care to avoid contact with the metal edges and retention teeth. 4. Before raising the vehicle, use the lug wrench to loosen, but not remove, the lug nuts on the wheel with the flat tire.
Page 352 352 WHAT TO DO IN EMERGENCIES Jack Engagement Locations...
Page 353 6. Raise the vehicle just enough to remove the flat tire and install the spare tire. WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire.
Page 354: Compact Spare Tire
354 WHAT TO DO IN EMERGENCIES WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle. Always stow the jack parts and the spare tire in the places provided. Compact Spare Tire The compact spare tire is for temporary emergency use with radial tires.
Page 355 1. Mount the road tire on the axle. For vehicles equipped with wheel covers, perform Steps 2 and 3. For vehicles equipped with center caps, proceed to Step 4. 2. Install two lug nuts on the mounting studs, which are on each side of the stud that is in alignment with the valve stem.
Page 356: Jump-Starting Procedures
356 WHAT TO DO IN EMERGENCIES correct tightness of each lug nut is 100 ft/lb. (135 N. m). If in doubt about the correct tightness, have them checked with a torque wrench by your dealer or at a service station. 7.
Page 357 NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump-starting. 1. Wear eye protection and remove any metal jewelry such as watchbands or bracelets that might make an inadvertent electrical contact.
Page 358 358 WHAT TO DO IN EMERGENCIES 6. Connect the other cable, first to the negative terminal of the booster battery and then to the engine ground (-) of the vehicle with the discharged battery. Make sure you have a good contact on the engine ground. Refer to the following illustration for jump-starting connections.
Page 359: Freeing A Stuck Vehicle
NOTE: For vehicles equipped with ESP, refer to Syn- chronizing ESP under Electronic Stability Program in Section 5 of this manual if the ESP/BAS light (in the instrument cluster) remains on continuously after start- ing the engine of the vehicle with the discharged battery. 8.
Page 360: Towing A Disabled Vehicle
360 WHAT TO DO IN EMERGENCIES CAUTION! • When “rocking” a stuck vehicle by moving be- tween “First” and R (Reverse), do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Racing the engine or spinning the wheels too fast may lead to transmission overheating and failure.
Page 361: Towing This Vehicle Behind Another Vehicle
TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground) Flat towing of vehicles equipped with an automatic transmission, is only permitted within the following limitations: With The Ignition Key Your vehicle may be towed under the following condi- tions: The gear selector must be in “N”...
Page 362: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
362 WHAT TO DO IN EMERGENCIES If you must use the accessories (wipers, defrosters, etc.) while being towed, the key must be in the ON position, not the ACC position. Make certain the transmission remains in “N” (Neutral). TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE WITH A TOW DOLLY The manufacture does not recommend that you tow this vehicle on a tow dolly.
Page 363: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 2.7L Engine Compartment ....366 3.5L Engine Compartment ....367 5.7L Engine Compartment —...
Page 364 364 MAINTAINING YOUR VEHICLE Maintenance-Free Battery ....381 Air Conditioner Maintenance ... . . 383 A/C Air Filter —...
Page 365 Low Beam Headlight, High Beam Headlight, Park/Turn Light, And Front Side Marker Light ......413 Backup Light, Side Marker Light, Tail/Turn Light, And Tail/Stop Light .
Page 366: 2.7L Engine Compartment
366 MAINTAINING YOUR VEHICLE 2.7L ENGINE COMPARTMENT 1 — Fuses (Front Power Distribution Center) 2 — Engine Oil Dipstick 3 — Brake Fluid Reservoir Access Cover 4 — Coolant Bottle 5 — Power Steering Fluid 6 — Air Cleaner Filter 7 —...
Page 367: L Engine Compartment
3.5L ENGINE COMPARTMENT 1 — Fuses (Front Power Distribution Center) 2 — Air Cleaner Filter 3 — Brake Fluid Reservoir Access Cover 4 — Coolant Pressure Cap 5 — Power Steering Fluid MAINTAINING YOUR VEHICLE 367 6 — Coolant Bottle 7 —...
Page 368: 5.7L Engine Compartment - Except Daytona & R/T
368 MAINTAINING YOUR VEHICLE 5.7L ENGINE COMPARTMENT — EXCEPT DAYTONA & R/T 1 — Fuses (Front Power Distribution Center) 2 — Coolant Pressure Cap 3 — Brake Fluid Reservoir Access Cover 4 — Coolant Bottle 5 — Power Steering Fluid 6 —...
Page 369: 5.7L Engine Compartment - Daytona & R/T
5.7L ENGINE COMPARTMENT — DAYTONA & R/T 1 — Fuses (Front Power Distribution Center) 2 — Coolant Pressure Cap 3 — Brake Fluid Reservoir Access Cover 4 — Coolant Bottle 5 — Power Steering Fluid MAINTAINING YOUR VEHICLE 369 6 — Air Cleaner Filter 7 —...
Page 370: Onboard Diagnostic System - Obd Ii
370 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 371: Emissions Inspection And Maintenance
odometer reset button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...
Page 372: Replacement Parts
372 MAINTAINING YOUR VEHICLE 5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is not ready and you should not proceed to the I/M station.
Page 373: Dealer Service
DEALER SERVICE Your dealer has the qualified service personnel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 374: Engine Oil
374 MAINTAINING YOUR VEHICLE Engine Oil Checking Oil Level — 2.7L, 3.5L Engines To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about 5 minutes after a fully warmed engine is shut off.
Page 375 Checking Oil Level — 5.7L Engine To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about 5 minutes after a fully warmed engine is shut off.
Page 376 376 MAINTAINING YOUR VEHICLE Change Engine Oil The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Refer to “Maintenance Schedule” in Section 8 of this manual for information on this system. NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or 6 months,...
Page 377 The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to the “Engine Com- partment” illustration in this section. NOTE: Vehicles equipped with a 5.7L engine must use SAE 5W-20 oil.
Page 378: Engine Oil Filter
378 MAINTAINING YOUR VEHICLE Disposing of Used Engine Oil And Oil Filters Care should be taken in disposing of used engine oil and oil filters from your vehicle. Used oil and oil filters, indiscriminately discarded, can present a problem to the environment.
Page 379: Spark Plugs
Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emission control. New plugs should be in- stalled at the specified mileage. The entire set should be replaced if there is any malfunction due to a faulty spark plug.
Page 380: Catalytic Converter
380 MAINTAINING YOUR VEHICLE Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic converter will not require maintenance. However, it is important to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 381: Maintenance-Free Battery
To minimize the possibility of catalyst damage: • Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion. • Do not try to start engine by pushing or towing the vehicle.
Page 382 382 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 383: Air Conditioner Maintenance
Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an Authorized Dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time.
Page 384: A/C Air Filter - If Equipped
384 MAINTAINING YOUR VEHICLE Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocar- bon (HFC) that is endorsed by the Environmental Pro- tection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by dealers or other service facilities using recovery and recycling equipment.
Page 385: Front & Rear Suspension Ball Joints
WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to insure accurate fluid level reading. Do not overfill. Use only manufacturer’s recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 386: Windshield Wiper Blades
386 MAINTAINING YOUR VEHICLE The external lock cylinders should be lubricated twice a year, preferably in the fall and spring. Apply a small amount of a high quality lubricant such as Mopar Lock Cylinder Lubricant or equivalent directly into the lock cylinder.
Page 387: Exhaust System
The fluid reservoir will hold nearly 1 gallon (4 liters) of washer fluid when the message “Low Washer Fluid” appears in the Electronic Vehicle Information Center (EVIC) — if equipped. WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.
Page 388: Cooling System
388 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the OFF position. The fan is temperature controlled and can start at any time the ignition switch is in the ON position.
Page 389 drain from the coolant recovery bottle. DO NOT RE- MOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown in the “Maintenance Schedule” in Sec- tion 8 of this manual.
Page 390 390 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to 5 Years or 100,000 miles (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
Page 391 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated.
Page 392 392 MAINTAINING YOUR VEHICLE service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill.
Page 393: Hoses And Vacuum/Vapor Harnesses
• Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean, also. • Do not change the thermostat for summer or winter operation. If replacement is ever necessary, install ONLY the correct type thermostat.
Page 394: Brake System
394 MAINTAINING YOUR VEHICLE Care should be taken in installing quick connect fittings to insure they are properly installed and fully connected. See your authorized dealer for service. Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Suggested service intervals can be found in the “Mainte- nance Schedule”...
Page 395 necessarily an indication of leakage. Actual dripping of hot fluid when systems are under pressure (during vehicle operation), should be noted before a hose is replaced based on leakage. • Inspect the brake hoses whenever the brake system is serviced and at every engine oil change. Inspect hy- draulic brake hoses for surface cracking, scuffing, or worn spots.
Page 396: Automatic Transmission
396 MAINTAINING YOUR VEHICLE Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. WARNING! • Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire.
Page 397 CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than that recommended by the manufacturer will result in more frequent fluid and filter changes.
Page 398: All Wheel Drive (Awd) - If Equipped
398 MAINTAINING YOUR VEHICLE All Wheel Drive (AWD) — If Equipped The all wheel drive system consists of a Transfer Case and Front Differential. The exterior surface of these components should be inspected for evidence of fluid leaks. Confirmed leaks should be repaired as soon as possible.
Page 399 extreme hot or cold weather and other extreme condi- tions will have an adverse effect on paint, metal trim, and underbody protection. The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle.
Page 400 400 MAINTAINING YOUR VEHICLE CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces. Special Care • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month.
Page 401 Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion. To remove heavy soil and/or excessive brake dust, use Mopar Wheel Cleaner (05066247AB) or equivalent or select a nonabrasive, non-acidic cleaner.
Page 402 402 MAINTAINING YOUR VEHICLE WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.
Page 403: Cleaning The Center Console Cup Holders
1. Clean with a wet soft rag or micro-fiber towel. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If soap is used, wipe clean with a clean damp rag. 2. Dry with a soft tissue. Seat Belt Maintenance Do not bleach, dye, or clean the belts with chemical solvents or abrasive cleaners.
Page 404: Fuses (Power Distribution Centers)
404 MAINTAINING YOUR VEHICLE FUSES (POWER DISTRIBUTION CENTERS) Fuses (Front Power Distribution Center) A power distribution center is located in the engine compartment. This center contains fuses and relays. Front Power Distribution Center Cavity Car- Mini Description tridge Fuse Fuse —...
Page 405 Cavity Car- Mini Description tridge Fuse Fuse 30 Amp — Windshield Wiper Pink 30 Amp — Anti-lock Brakes System Pink (ABS) Valves - if equipped 40 Amp — Radiator Fan Green 50 Amp — Anti-lock Brakes System (ABS) Pump Motor - if equipped 60 Amp —...
Page 406: Fuses (Rear Power Distribution Center)
406 MAINTAINING YOUR VEHICLE CAUTION! • When installing the Power Distribution Center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure.
Page 407 Rear Power Distribution Center MAINTAINING YOUR VEHICLE 407 Cavity Car- Mini Description tridge Fuse Fuse 60 Amp — Ignition Off Draw (IOD) Yellow 40 Amp — Integrated Power Mod- Green ule (IPM) — — — 40 Amp — Integrated Power Mod- Green ule (IPM) 30 Amp...
Page 408 408 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse — 15 Amp Diagnostic Link Connec- Blue tor (DLC)/Wireless Con- trol Module (WCM)/ Wireless Ignition Node (WIN) — 20 Amp Power Outlet Yellow — — — 11 * — —...
Page 409 Cavity Car- Mini Description tridge Fuse Fuse — 10 Amp Occupant Restraint Con- troller (ORC) — 10 Amp Ignition Run — 5 Amp Cluster/Electronic Sta- Orange bility Program (ESP) - if equipped/Powertrain Control Module (PCM)/ Stop Light Switch — 10 Amp Door Modules/Power Mirrors/Steering Con- trol Module (SCM)
Page 410 410 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse — 5 Amp Auto Inside Rearview Orange Mirror - if equipped/ Heated Seats - if equipped/Switch Bank — 10 Amp AC Heater Control/ Headlights/Tire Pres- sure Monitoring - if equipped 30 Amp —...
Page 411: Vehicle Storage
CAUTION! • When installing the Power Distribution Center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure.
Page 412: Replacement Light Bulbs
412 MAINTAINING YOUR VEHICLE REPLACEMENT LIGHT BULBS LIGHT BULBS — Interior Rear Courtesy/Reading Lights....W5W Rear Compartment (Trunk) Light ... . . 562 Overhead Console Reading Lights.
Page 413: Bulb Replacement
BULB REPLACEMENT Low Beam Headlight, High Beam Headlight, Park/Turn Light, and Front Side Marker Light 1. Open the hood. NOTE: Removal of the air cleaner filter housing may be necessary prior to replacing bulbs in the headlight assem- bly on the driver side of the vehicle. 2.
Page 414 414 MAINTAINING YOUR VEHICLE 3 — Park/Turn Light Bulb 4 — Side Marker Light Bulb CAUTION! Do not touch the new bulb with your fingers. Oil contami- nation will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol.
Page 415: Backup Light, Side Marker Light, Tail/Turn Light, And Tail/Stop Light
Backup Light, Side Marker Light, Tail/Turn Light, and Tail/Stop Light 1. Open the Trunk. 2. Remove two fasteners from the back of the tail light assembly. MAINTAINING YOUR VEHICLE 415 3. Pull back the trunk liner. 4. Remove the remaining fastener from the back of the tail light assembly.
Page 416 416 MAINTAINING YOUR VEHICLE 7. Pull the tail light assembly clear from the vehicle to access the bulbs. 8. Turn the appropriate bulb and socket assembly counter-clockwise to remove it from the tail light assem- bly. 2 — Side Marker Light Bulb 1 —...
Page 417 MAINTAINING YOUR VEHICLE 417 3 — Tail/Turn Light Bulb 4 — Tail/Stop Light Bulb...
Page 418: License Light
418 MAINTAINING YOUR VEHICLE 9. Disconnect the bulb from the socket assembly and install the replacement bulb. 10. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise. 11. Reinstall the tail light assembly, fasteners, electrical connector, and trunk liner.
Page 419: Fluids And Capacities
FLUIDS AND CAPACITIES Fuel (approximate) 2.7 Liter Engine 3.5 Liter Engine without All Wheel Drive 3.5 Liter Engine with All Wheel Drive 5.7 Liter Engine Engine Oil-With Filter 2.7 Liter Engine (SAE 5W-20, API Certified) 3.5 Liter Engine (SAE 10W-30, API Certified) 5.7 Liter Engine (SAE 5W-20, API Certified) MAINTAINING YOUR VEHICLE 419 U.S.
Page 420 420 MAINTAINING YOUR VEHICLE Cooling System * 2.7 Liter Engine (Mopar Antifreeze/Coolant 5 Year/100,000 Mile For- mula) or equivalent. 3.5 Liter Engine without All Wheel Drive (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent. 3.5 Liter Engine with All Wheel Drive (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent.
Page 421: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (2.7 Liter) Engine Oil (3.5 Liter) Engine Oil (5.7 Liter) Spark Plugs (2.7L) Spark Plugs (3.5L) Spark Plugs (5.7L) Oil Filter (2.7 Liter) Fluids, Lubricants, and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent.
Page 422 422 MAINTAINING YOUR VEHICLE Component Oil Filter (3.5 Liter) Oil Filter (5.7 Liter) Fuel Selection (2.7 Liter) Fuel Selection (3.5 Liter) Fuel Selection (5.7 Liter) Fluids, Lubricants, and Genuine Parts Mopar 05281090 or equivalent. Mopar 05281090 or equivalent. 87 Octane 87 to 89 Octane 87 to 89 Octane...
Page 423: Chassis
Chassis Component Automatic Transmission Brake Master Cylinder Front Axle Power Steering Reservoir Rear Axle Transfer Case Fluids, Lubricants and Genuine Parts Mopar ATF+4 Automatic Transmission Fluid. Mopar DOT 3, SAE J1703 or equivalent should be used. If DOT 3 brake fluid is not available, then DOT 4 is acceptable.
Page 425 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..426 Maintenance Schedule ....426 Required Maintenance Intervals ... 429...
Page 426 426 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 427 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been 6 months since your last oil change even if the oil change indicator message is NOT illumi- nated.
Page 428 428 MAINTENANCE SCHEDULES • Check the fluid levels of coolant reservoir, brake master cylinder, power steering, and transmission, and add as needed. • Check all lights and other electrical items for correct operation. At Each Oil Change • Change the engine oil filter. •...
Page 429 Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate the tires. If using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if nec- essary. Inspect the brake linings, and replace if necessary. Replace the air conditioning filter (if equipped).
Page 430 430 MAINTENANCE SCHEDULES Maintenance Items Replace the engine air cleaner filter. Inspect the transfer case fluid — All Wheel Drive (AWD). Replace the spark plugs on 5.7L engines. Change the rear axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or fre- quent trailer towing.
Page 431 Maintenance Items Replace the spark plugs on 2.7L and 3.5L engines. Replace the timing belt on 3.5L engines. Change the automatic transmission fluid & filter. Replace the accessory drive belt on 2.7L engines. WARNING! You can be badly injured working on or around a motor vehicle.
Page 433: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......434 Prepare For The Appointment .
Page 434: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 435 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 436 436 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 437: Warranty Information (U.s. Vehicles Only)
WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 438: In Canada
438 IF YOU NEED CONSUMER ASSISTANCE To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 400 Seventh Street, SW., Wash- ington, DC 20590. You can also obtain other information about motor vehicle...
Page 439 • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features. They show exactly how to find and correct problems the first time, using step-by-step troubleshooting and driveability procedures, proven diagnostic tests and a complete list of all tools and equipment.
Page 440: Quality Grades
440 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 441: Temperature Grades
Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 443 INDEX...
Page 444 444 INDEX About Your Brakes ....278,280 ABS (Anti-Lock Brake System) ....280 Adding Engine Coolant (Antifreeze) .
Page 445 Auto Down Power Windows ....35 Auto Unlock, Doors ..... . . 31 Auto Up Power Windows .
Page 446 446 INDEX B-Pillar Location ......294 Brake Assist System ..... . 285 Brake Control System, Electronic .
Page 447 Checks, Safety ......75 Child Restraint ....65,66,67,70,72 Child Restraint Tether Anchors .
Page 448 448 INDEX Selection of Coolant (Antifreeze) ..389,419,421 Corrosion Protection ..... 398 Cruise Control (Speed Control) ....135 Cruise Light .
Page 449 Electrical Power Outlets ....149 Electronic Brake Control System Brake Assist System ....285 Electronic Stability Program .
Page 450 450 INDEX Oil Filter Disposal ..... . 378 Oil Selection ..... . . 376,419 Oil Synthetic .
Page 451 Cooling System ..... . . 388 Engine Oil ......374,375 Power Steering .
Page 452 452 INDEX Gasoline, Reformulated ....320 Gauges Coolant Temperature ....165 Fuel .
Page 453 Heated Seats ......118 Heater ....... 239 Heater, Engine Block .
Page 454 454 INDEX Key, Sentry (Immobilizer) ....15 Key-In Reminder ......15 Keyless Entry System .
Page 455 Headlights On With Wipers ... . 125,131 High Beam ......127,168 High Beam Indicator .
Page 456 456 INDEX Lower Anchors and Tether for CHildren (LATCH) ......68,70 Lubrication, Body ..... . . 385 Lumbar Support .
Page 457 Occupant Restraints ..... . . 40 Octane Rating, Gasoline (Fuel) ... . 319,421 Odometer .
Page 458 458 INDEX Phone, Cellular ..... 87,209,211 Phone, Hands-Free (UConnect™) ..87,209,211 Placard, Tire and Loading Information ..294 Port Universal Serial Bus (USB) .
Page 459 Rear Window Defroster ....250 Rear Window Features ....250 Rearview Mirrors .
Page 460 460 INDEX Schedule, Maintenance ....426 Seat Belt Maintenance ....403 Seat Belt Reminder .
Page 461 Setting the Clock ....192,196,211,215 Settings, Personal ......186 Shifting .
Page 462 462 INDEX Storage, Vehicle ..... . 248,411 Storing Your Vehicle ..... . 411 Stuck, Freeing .
Page 463 Life of Tires ......304 Load Capacity ..... 294,295 Pressure Monitor System (TPMS) .
Page 464 464 INDEX Fluid ......398,423 Maintenance ......398 Transmission .
Page 465 Vehicle Storage ..... . . 248,411 Vehicle Theft Alarm (Security Alarm) ..18 Video Entertainment System (Rear Seat Video System) .
Page 466 INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS / ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN)Fob with Integrated KeyTip Start FeatureIgnition Key RemovalKey-In-Ignition ReminderSENTRY KEY Replacement KeysCustomer Key (Fob) ProgrammingGeneral InformationSECURITY ALARM SYSTEM - IF EQUIPPED Rearming of the SystemTo Arm the SystemTo Disarm the SystemILLUMINATED ENTRY SYSTEM REMOTE KEYLESS ENTRY To unlock the doorsTo lock the doorsTo unlatch the trunkUsing The Panic AlarmProgramming Additional TransmittersTransmitter Battery ServiceGeneral Information REMOTE STARTING SYSTEM - IF EQUIPPED How To Use Remote StartDOOR LOCKS Manual Door LocksPower Door LocksChild Protection Door LockWINDOWS Power WindowsWind BuffetingTRUNK LOCK AND RELEASE TRUNK SAFETY WARNING Trunk Emergency Release OCCUPANT RESTRAINTS Lap/Shoulder BeltsLap/Shoulder Belt Untwisting ProcedureSeat Belt PretensionersEnhanced Seat Belt Reminder System (BeltAlert) Automatic Locking Mode - If EquippedSeat Belts and Pregnant WomenSeat Belt Extender...

This manual is also suitable for:

2008 lx48 charger

Dodge 2008 Charger Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

INTRODUCTION

Chapters

Related Manuals for Dodge 2008 Charger

Summary of Contents for Dodge 2008 Charger
