Page 1 Sprinter 2 0 0 8 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefor. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.
Page 3 Thank you for choosing the new Sprinter Vehicle. Before your first journey, please familiar- ize yourself with your vehicle and how it operates, as well as its driving, control and convenience functions. Before you drive off, read these Operat- ing Instructions. This will help you get the most out of your vehicle and avoid endangering yourself and others.
Page 4 Symbols Optional equipment Warning Environmental note Caution Action required Sequence of actions (several ) Continuation symbol Page reference page Display in the multifunction Display display Trademarks ® is a registered trademark of Chrysler Vans LLC.
Page 5: Table Of Contents
Contents ...5 Introduction ...17 At a glance ...33 Safety ...81 Controls in detail ...301 Operation ...429 Practical hints ...599 *Technical data Index ... 637...
Page 7: Introduction
Introduction Environmental protection Environmental note Chrysler’s declared policy is one of compre- hensive environmental protection. The objectives are for the natural resourc- es which form the basis of our existence on this planet to be used sparingly and in a manner which takes the requirements of both nature and humanity into ac- count.
Page 8 Introduction Environmental protection Personal driving style Do not depress the accelerator pedal when starting the engine. Do not warm up the engine when the vehicle is stationary. Adopt an anticipatory style of driving and keep a sufficient distance from other vehicles. Avoid frequent, sudden acceleration.
Page 9: Operating Safety
Operating safety Warning Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth de- fects or other reproductive harm. In addition, certain fluids contained in ve- hicles, and certain products of compo- nent wear, contain chemicals known to the State of California to cause cancer...
Page 10 Introduction Operating safety Warning Always have maintenance work carried out at an authorized Sprinter Dealer which has the necessary specialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 11 Service and warranty information The manufacturer warrants to the origi- nal and each subsequent owner of a Mercedes-Benz heavy-duty on highway diesel engine that: (1) the engine was designed, built and equipped so as to conform at the time of sale with the applicable regu- lations adopted by the Federal Envi- ronmental Protection Agency, and (2) the emission control system of such...
Page 12 Introduction Operating safety Digital speedometer and total distance recorder Do not allow the electronically stored to- tal distance covered by your vehicle to be modified as a result of tampering with the electronics system. This type of modification or failing to in- form the buyer when selling the vehicle could constitute an offense punishable by law, depending on the country con-...
Page 13 Vehicle alterations The manufacturer recommends the use of genuine Sprinter parts and conversion parts as well as accessories that have been expressly approved for your vehi- cle model ( page 600). These parts have been subjected to spe- cial tests in order to determine their safety, reliability and suitability.
Page 14 Introduction Operating safety Body builders and dealers who make any modifications which may affect the final certification of the engine, vehicle or equipment assume the sole responsibil- ity for the vehicle, including labeling and documentation, affected by their modifi- cations. It is their responsibility to certify that the altered vehicle conforms to all applica- ble standards and regulations affected...
Page 15 Correct use Warning Be sure to read the Operating Instructions. Otherwise, you may not be aware of certain risks and could injure yourself or others. Observe the following information when using your vehicle: The safety notes in this manual The “Technical data” section in this manual Traffic rules and regulations Motor vehicle laws and safety stan-...
Page 16 Introduction Operating safety In the USA: Chrysler Vans LLC Customer Center P.O. Box 21-8004 Auburn Hills, MI 48321-8001 United States of America Telephone: 800-992-1997 In Canada: Chrysler Canada, Inc. Customer Center P.O. Box 1621 Windsor, Ontario N9A 4H6 Telephone: (800) 465-2001...
Page 17 Introduction REPORTING SAFETY DEFECTS REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect, which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to noti- fying the manufacturer.
Page 18 Introduction Information regarding electronic recording devices Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety. Chrysler Vans LLC may access the information and share it with others for safety research or vehicle diagnosis purposes with the consent of the vehicle owner or lessee...
Page 19: At A Glance
At a glance At a glance Cockpit... 18 Instrument cluster... 20 Steering wheel with buttons*... 25 Center console... 26 Overhead control panel*... 27 Switch units... 28 Door control panel... 31...
Page 20: At A Glance
At a glance Cockpit Cockpit N68.10-2287-31...
Page 21 Function Page 1 Door control panel 2 Light switch 3 Combination switch Turn signals High-beam head- lamps Windshield wipers Rear window wiper* 4 Cruise control lever* 5 Horn 6 Steering wheel without/ with* buttons Function Page 7 Instrument cluster 8 Storage compartment 9 Storage compartment with interior lamp Overhead control panel*...
Page 22: Instrument Cluster
At a glance Instrument cluster Instrument cluster...
Page 23 Function Page 1 Instrument cluster on ve- hicles without steering wheel buttons 2 Instrument cluster on ve- hicles with steering wheel buttons* On vehicles without steering wheel but- tons: Changes the standard display Selects menus Function Page On vehicles with steering wheel but- tons*: Checks the engine...
Page 24 At a glance Instrument cluster Function c Fuel gauge with: Reserve fuel warning lamp Fuel filler flap location indicator Ö : Fuel filler flap is on the left- hand side Page Vehicles without steering wheel buttons: Display 8 contains a digital fuel gauge.
Page 25 Indicator and Warning Lamps Page Brake fluid level too EBV malfunction Malfunction in trailer's brake booster N Engine oil level warning as47 ± Engine diagnostic indicator lamp q Pre-glow system, die- sel engine only Turn signal, left Indicator and warning lamps Page X Combination low tire pressure/TPMS mal- function telltale, USA...
Page 26 At a glance Instrument cluster Indicator and warning lamps Page Water in the fuel # Battery charge mal- function . Defective bulb Handbrake applied B Low-beam headlamps ™ Operating speed gov- ernor on* A High-beam headlamps < Seat belt reminder Vehicles with steering wheel buttons: Corresponding messages may also be shown in display 9...
Page 27: Steering Wheel With Buttons
Steering wheel with buttons* N46.10-2074-31 Function Page 1 Display Controlling the operat- ing system 2 To select a submenu or adjust the volume Up/increases the volume Down/decreases the volume 3 Telephone* functions s Accepts a call/ starts dialing At a glance Steering wheel with buttons* Function Page...
Page 28: Center Console
At a glance Center console Center console N68.10-2288-31 Function Page Storage compartment Radio* or COMAND*, see the separate oper- ating instructions Air-conditioning control panel Center console switch unit Function Page Storage compart- ment or CD changer*, see the separate operating instruc- tions Cup holder with Ashtray...
Page 29: Overhead Control Panel
Overhead control panel Function Page 1 Hands-free microphone for telephone* 2 Switches the right-hand reading lamp on/off 3 Switches the automatic interior lighting on/off At a glance Overhead control panel* Function Page Eyeglass compartment or Anti-theft alarm sys- tem (ATA)* 5 Switches the interior lighting on/off...
Page 30: Switch Units
At a glance Switch units Switch units Center console switch unit N54.25-2915-31 The number of switches may vary, depending on the vehicle’s equip- ment. Function Page Opens/closes the left- hand electric sliding door* Switches the left/right seat heating* & on/off Switches the rear win- dow heating* on/off...
Page 31 Additional switch units N54.25-2913-31 Switch unit between the light switch and the steering wheel Function Page ³ Switches the heater booster function* on/off Switches auxiliary ö heating*on/off ³ Switches the heater booster function* on/off Adjusts the working engine speed* Switches the operating speed governor* on/off At a glance...
Page 32 At a glance Switch units N54.25-2912-31 Switch unit between the steering wheel and the ignition lock Function Page Switches the rear-com- partment convenience interior lighting* on/off The layout of the switches may vary, depending on the vehicle’s equip- ment.
Page 33: Door Control Panel
Door control panel N54.25-2914-31 Function Page 1 Adjusts the exterior mirrors* 2 Selects an exterior mirror* 3 Opens/closes the left- hand side window 4 Opens/closes the right- hand side window At a glance Door control panel...
Page 35: Safety
Safety Safety Occupant safety... 34 Emergency exit... 66 Driving safety systems... 69 Anti-theft systems... 77...
Page 36: Safety
Safety Occupant safety Occupant safety Restraint systems This section contains all the most impor- tant information about the restraint sys- tems in your vehicle. In an accident, your vehicle collides with another object, e.g. another vehicle. This may cause your ve- hicle to accelerate or decelerate ex- tremely quickly.
Page 37 This is partly because an airbag is not activated in all accident situa- tions because in some cases it would not provide any additional protection to that already afforded by a correct- ly fastened seat belt. Furthermore, an activated airbag can only provide increased protection if the seat belt is being worn correctly, be- cause:...
Page 38 Safety Occupant safety Warning (Continued) The airbags or emergency tensioning re- tractors could, for example, be activated inadvertently or could fail in accidents in which the deceleration force is sufficient to trigger the airbag. For this reason, do not modify the restraint systems. Do not tamper with electronic components or their software.
Page 39 Warning A seat belt that is worn incorrectly or not at all, or that is not correctly engaged in the seat belt buckle, cannot perform its intended protective function. In certain circumstanc- es, you could be seriously or even fatally in- jured.
Page 40 Safety Occupant safety Warning (Continued) A child must never be carried sitting on the lap of a vehicle occupant. It would not be possible to restrain the child, and the child and other vehicle occupants could be seriously or fatally injured in the event of abrupt braking or an accident.
Page 41 Warning (Continued) The belt strap could otherwise tear in the event of an accident. You or others could be seriously or fatally injured. Always have seats belts that are damaged or have been subjected to a heavy load in an accident replaced, and their anchorag- es checked, at a qualified specialist work- shop which has the necessary specialist knowledge and tools to carry out the work...
Page 42 Safety Occupant safety Pull the belt smoothly from the seat belt reel holder. Route the belt over your shoulder. Click belt latch plate 2 into buckle Adjust the belt to the correct height if necessary. Pull the shoulder section of the belt upwards to tighten the belt against your body if necessary.
Page 43 To raise the belt height: slide belt sash guide 1 upward. Belt sash guide 1 engages in vari- ous positions. To lower the belt height: press and hold release button 5 . Slide belt sash guide 1 to the de- sired height.
Page 44 Safety Occupant safety Warning A malfunction has occurred if the 1 warning lamp: does not come on when you switch on the ignition does not go out after approximately 4 sec- onds lights up again Individual systems may be activated unin- tentionally or may not be triggered in the event of an accident with a high rate of ve- hicle deceleration.
Page 45 The front airbags are not triggered un- less a second activation threshold is ex- ceeded, i.e. if there is a greater rate of vehicle deceleration in a longitudinal di- rection. Criteria for triggering of emergency tensioning retractors and airbags To determine whether it is necessary to trigger an emergency tensioning retrac- tor or airbag, the airbag control unit eval- uates the duration and direction of...
Page 46 Safety Occupant safety Vehicle deceleration or acceleration and the direction of the force are essentially determined by: the distribution of the force during the impact the collision angle the deformation characteristics of the vehicle the composition of the object in- volved in the collision, for example the other vehicle Factors that cannot be seen or mea-...
Page 47 Emergency tensioning retractors do not correct: incorrect sitting positions incorrectly worn seat belts Emergency tensioning retractors do not pull occupants back towards the backrest. When the ignition is on, the emergency tensioning retractor is activated: only if the restraint systems are op- erational (the 1 -warning lamp comes on for approximately 4 sec- onds after the ignition is switched...
Page 48 Safety Occupant safety Warning (Continued) The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose. In particular, work relevant to safety or on safety-related systems must be carried out at a qualified specialist workshop. Observe the safety regulations when dis- posing of emergency tensioning retrac- tors.
Page 49 Warning (Continued) Vehicle occupants should wear their seat belt correctly at all times and lean back against the backrest, which should be positioned as upright as possible. The head restraints should support the back of the head at about eye level. Move the passenger’s seat as far to the rear as possible, especially if a child is secured in a restraint system...
Page 50 Safety Occupant safety Warning (Continued) Do not cover the padded boss of the steering wheel, the passenger’s air- bag cover, the windowbag cover or the thorax/sidebag cover with film or other material. Do not affix any badg- es or stickers to these areas. Do not hang any hard objects, for ex- ample coat hangers, on the grab han- dles or coat hooks.
Page 51 When the vehicle occupant makes con- tact with the airbag, hot gas flows out of the inflated airbag. This reduces the load on the head and upper body of the vehi- cle occupant. The airbag is therefore in a deflated state after an accident. Warning After an airbag has been triggered: airbag parts are hot –...
Page 52 Safety Occupant safety Front airbags The front airbags are designed to in- crease protection to the driver’s and passenger’s/passengers' head and chest. The driver’s airbag is located in the steering wheel housing; the passenger’s is above the glove box. N91.60-2140-31 1 Driver’s airbag 2 Passenger’s airbag Driver’s front airbag 1 inflates in front...
Page 53 Thorax sidebags* Warning For safety reasons, the manufacturer rec- ommends that you use seat covers that have been tested for Sprinter vehicles and that have a seam for thorax/ sidebags. A thorax/sidebag may other- wise not inflate correctly and could fail to provide the intended degree of protection in the event of a collision.
Page 54 Safety Occupant safety The purpose of the thorax/sidebags is to increase the level of protection for the thorax (but not the head, neck and arms) of the occupants on the side of the vehi- cle on which the impact occurs. The thorax/sidebags are installed in the outer sides of the backrests on the driv- er’s seat and the passenger’s individual...
Page 55 You will find additional information about airbag deployment on page 48). You will find additional information about the triggering of emergency tensioning retractors and belt force limiters on ( page 44). Windowbags* Warning To ensure that windowbags can provide the intended degree of protection when deployed, make sure that no persons, an- imals or objects are present between the vehicle occupants and the deployment...
Page 56 Safety Occupant safety The windowbags are designed to in- crease protection to the head (but not to the chest or arms) of the vehicle occu- pants on the side on which the impact occurs. The relevant windowbag is installed in the side of the roof frame behind the trim panel between the A and B-pillar.
Page 57 Children in the vehicle If a child is traveling in the vehicle: secure the child in a child restraint system appropriate to his/her age and size, preferably on a suitable seat in the rear ensure that the child is strapped in throughout the trip You can obtain child seats and informa- tion about the correct child restraint sys-...
Page 58 Safety Occupant safety Warning (Continued) Do not carry heavy or hard objects inside the vehicle or load compartment unless they are secured. You will find further in- formation under “Transporting” page 276) and “Features” page 287) in the “Controls in detail” section.
Page 59 To deactivate, release seat belt buckle and let seat belt retract completely. The seat belt can again be used in the usual manner. Warning Never release the seat belt buckle while the vehicle is in motion, since the special seat belt retractor will be deactivated. Warning To reduce the risk of serious or fatal injury to a child in the event of an accident,...
Page 60 Safety Occupant safety Warning (Continued) A child must never be carried sitting on the lap of a vehicle occupant. It would not be possible to restrain the child as a result of the forces acting in the event of an ac- cident, braking or abrupt changes in di- rection.
Page 61 Warning If you no longer require the child restraint system, remove it from the vehicle or se- cure it with the seat belt. The restraint system could otherwise be thrown through the vehicle interior in the event of an accident. Warning A child secured in a child restraint system could be seriously or fatally injured in the...
Page 62 Safety Occupant safety The use of infant or child restraints is re- quired by law in all 50 states, the District of Columbia, the U.S. territories and all Canadian provinces. Infants and small children should be seated in an appropriate infant or child restraint system properly secured by a lap/shoulder belt or, if so equipped, a top tether anchorage point and a child...
Page 63 N00.00-2620-31 Warning symbol for rearward-facing child seat ISOFIX child seat securing system/ Child seat anchors - LATCH type ISOFIX is a standardized securing sys- tem on the rear seats for special LATCH ( L ower A nchors and T ethers for Ch il- dren) child restraint systems with matching mounting fittings.
Page 64 Safety Occupant safety Warning A LATCH type child restraint system that has been secured using the ISOFIX child seat securing system is unable to provide adequate protection for children who weigh more than 48 lbs (22 kg). For this reason, only secure children weighing less than 48 lbs (22 kg) in a LATCH type child restraint system secured using the ISOFIX child seat securing system.
Page 65 Warning If the child restraint system or its securing system, for example the ISOFIX child seat securing system, are damaged or have been subjected to a load in an accident, the child secured in it could suffer severe or fatal injuries in the event of an acci- dent, heavy braking or a sudden change of direction.
Page 66 Safety Occupant safety Warning Do not leave children unsupervised in the vehicle, even if they are secured by a child restraint system. The children could: injure themselves on parts of the ve- hicle be seriously or even fatally injured by prolonged exposure to extreme heat or cold Warning...
Page 67 2 TopTether anchorage 3 TopTether hook 4 TopTether belt of LATCH type child re- straint system Slide head restraint 1 upward. Guide TopTether belt 4 under head restraint 1 from the front and be- tween the two head restraint bars. Hook TopTether hook 3 into TopTether anchorage 2 on the feet of the bench seat.
Page 68: Emergency Exit
Safety Emergency exit Emergency exit Emergency exit window* The vehicle can be equipped with an emergency exit window. The emergency exit window is only intended for emer- gencies and may only be opened when the vehicle is stationary. In an emergency or following an acci- dent, the occupants of the vehicle can exit the vehicle via the open emergency exit window.
Page 69 Warning (Continued) Only vehicle occupants who are able to operate the emergency exit win- dow are permitted to sit next to the emergency exit window. Access to the emergency exit window must be free of obstacles. Do not place any large or heavy objects on the seats or in front of the seats next to the emergency exit window.
Page 70 Safety Emergency exit Warning If you continue your journey without clo- sing and locking the emergency exit win- dow, it may come out of its frame and cause an accident. You should, therefore, check the locking mechanism and safety bolts on the emer- gency exit window before setting out.
Page 71: Driving Safety Systems
Driving safety systems In this section, you will find information about the following driving safety sys- tems: ABS (Antilock Brake System) BAS (Brake Assist) ® (Electronic Stability Program) ASR (acceleration skid control) EBV (electronic brake force distribu- tion) The maximum effect of ABS, BAS, ®...
Page 72 Safety Driving safety systems Only use wheels with the recom- mended tire sizes ( page 623), oth- erwise the driving safety systems will not work correctly. Antilock Brake System (ABS) ABS regulates the brake pressure in such a way that the wheels do not lock when you brake.
Page 73 Braking If ABS intervenes during braking, you will feel the steering wheel vibrate gently and the brake pedal pulsate. If ABS intervenes: Continue to depress the brake pedal firmly until the braking situation is over. For full brake application: Depress the brake pedal with maxi- mum force.
Page 74 Safety Driving safety systems Vehicles without steering wheel but- tons: There is a malfunction if the k indi- cator lamp is permanently lit while the engine is running ( page 73). Warning If BAS malfunctions, the brake system is still available with the full brake boosting effect.
Page 75 There is a malfunction if the # indica- tor lamp is permanently lit while the en- gine is running ( page 468). ® If ESP malfunctions, engine power out- put may be reduced. CAUTION Only operate the vehicle briefly (max- imum of 10 seconds) on a brake dy- namometer.
Page 76 Safety Driving safety systems If the road surface is not capable of pro- viding sufficient traction, bearing in mind the tires, load and gradient, it is not be possible to pull away smoothly even with ASR. Vehicles without steering wheel but- tons: There is a malfunction if the k indi- cator lamp is permanently lit while the...
Page 77 Warning ® remains active despite ASR having been deactivated and carries out braking interventions if this is necessary to im- prove driving stability. The v warning lamp flashes. If ASR is deactivated, there is an in- creased risk that the brake system of your vehicle could overheat and be damaged when subjected to high loads for a long period of time.
Page 78 Safety Driving safety systems Electronic brake force distribution (EBV) EBV monitors and regulates the brake pressure at the rear wheels to improve driving stability during braking. Warning If EBV malfunctions, the brake system is still available with the full brake boosting effect.
Page 79: Anti-Theft Systems
Anti-theft systems Immobilizer The immobilizer prevents the vehicle from being started without the correct key. To switch on: remove the key from the ignition lock ( page 111). To switch off: switch on the ignition page 111). Anti-theft alarm system (ATA)* A visual and audible alarm is triggered if the alarm system is enabled and: a door is opened...
Page 80 Safety Anti-theft systems The alarm system will be triggered if the vehicle has been locked with the key and is then unlocked from the in- side. Switching off the alarm Insert the key into the ignition lock. Press the Œ button ( page 83).
Page 81 1 To deactivate tow-away protection 2 Indicator lamp Turn the key to position 0 or 1 page 111) in the ignition lock or remove the key. When the ignition is switched off page 111), you cannot deactivate tow-away protection. Press button 1 . Indicator lamp 2 lights up for ap- proximately 5 seconds after the but- ton is released.
Page 82 Safety Anti-theft systems The interior motion sensor is enabled after approximately 40 seconds. Do not leave anything (for example mascots or coat hangers) hanging on the rear-view mirror or on the grab handles on the roof trim. This will pre- vent false alarms.
Page 83: Controls In Detail
Controls in detail Controls in detail Opening and closing... 83 Key positions... 111 Seats... 112 Steering wheel adjustment... 127 Lighting... 129 Instrument cluster... 142 Operating system without steering wheel buttons... 147 Operating system with steering wheel buttons*... 151 Driving and parking... 183 Automatic transmission...
Page 84 Controls in detail Air conditioning... 215 Auxiliary heating/ventilation*... 236 Open air... 244 Driving systems... 248 Operating the vehicle... 273 Transporting... 276 Features... 287...
Page 85: Opening And Closing
Opening and closing Your vehicle is supplied with either 2 or 4* remote keyless entry transmitters or 4 keys* without remote control. Vehicle keys* which were not included with delivery must be activated before they can be used. You can obtain further information at any authorized Sprinter Dealer.
Page 86 Controls in detail Opening and closing Canada only: This device complies with RSS-210 of Industry Canada. Remote controls with keys which were not included with delivery must be acti- vated at an authorized Sprinter Dealer before they can be used. The remote keyless entry transmitter transmits in all directions.
Page 87 Warning Do not leave children unsupervised in the vehicle, even if they are secured by a child restraint system. The children could: injure themselves on parts of the vehicle unlock the door on vehicles with an elec- tric sliding door by pressing the central locking button, and then open the doors and thereby injure other persons Continued...
Page 88 Controls in detail Opening and closing To prevent theft, only use the remote control in the immediate vicinity of the vehicle. In an emergency, the driver’s door and rear door can also be unlocked manually using the key. As a precaution, both remote controls should always be carried.
Page 89 Unlocking the vehicle centrally Unlock the driver's door. Press the Œ button within 2 sec- onds again. The turn signals flash once. Locking the vehicle centrally Press the ‹ button. The turn signals flash three times if: the drive authorization system or the anti-theft alarm system (ATA)* is activated all the doors are closed...
Page 90 Controls in detail Opening and closing Locking and unlocking the vehicle with the key If the doors can no longer be locked or unlocked with the remote control, you can lock and unlock the driver's door and the rear doors with the key. Unlocking the vehicle NCV2 N72.10-2149-31...
Page 91 The anti-theft alarm system (ATA) is triggered when you open the vehicle using the key. The alarm can be disabled in the follow- ing ways: Press the Œ button on the remote control. Insert the key into the ignition lock. Locking the vehicle Only the driver's door and the rear doors can be locked with the key.
Page 92 Controls in detail Opening and closing You can open the driver’s/passenger’s door from the inside at any time, even if it is locked. Open door only when condi- tions are safe to do so. 1 Inside door handle 2 Locking knob Pull door handle 1 .
Page 93 When you open/close the sliding door, you can also detent it around half way so that it is not always nec- essary to open the door to the end stop to get in and out of the vehicle. The intermediate detent does not ful- ly engage the sliding door.
Page 94 Controls in detail Opening and closing Opening/closing the sliding door from the inside Open sliding door only when conditions are safe to do so. To unlock: pull locking knob 4 up. Only this sliding door unlocks. The other doors remain locked. To open: press button 2 to open the unlocked sliding door.
Page 95 Following a battery disconnection or malfunction, it is necessary to fully close the sliding door once by press- ing and holding the switch on the center console or in the doorway page 93) and then to fully open and close the door once by pressing one of the switches briefly.
Page 96 Controls in detail Opening and closing N72.16-2119-31 Sliding door switch in the doorway (B-pil- lar) 3 To open/close the sliding door On vehicles with a partition, the switch is located on the partition near the doorway level with the in- side door handle.
Page 97 To stop the sliding door: press lo- wer/upper part of the switch on the center console or press switch 3 in the doorway. The sliding door stops. To lock the sliding door from in- side: press lower part of the central locking switch on the center console page 104).
Page 98 Controls in detail Opening and closing The indicator lamp in the switch comes on. Press the locking knob of the sliding door down ( page 91). The indicator lamp in the switch on the center console lights up whenev- er the sliding door is open. The sliding door can jam under unfavor- able operating conditions such as frost, icing or heavy dirt.
Page 99 2 Outside door handle Briefly press button 1 or pull out- side door handle 2 . The sliding door opens or closes. When closing, a signal sounds. Press button 1 again or pull outside door handle 2 again. The sliding door stops. Opening/closing with the remote control Press and hold the...
Page 100 Controls in detail Opening and closing Make sure that the doors are closed. Switch on the ignition ( page 111). Press and hold the upper part of relevant switch 1 or 2 on the cen- ter console for 5 seconds. The indicator lamp in the switch for the sliding door concerned flashes and a warning tone sounds three...
Page 101 Resetting the sliding door: Close the sliding door completely once by pressing and holding down the switch on the center console or in the doorway. Then Open and close the sliding door com- pletely once by pressing and relea- sing one of the switches. This restores normal operation of the sliding door.
Page 102 Controls in detail Opening and closing Opening the right-hand rear door from the outside 1 Handle Pull handle 1 . Swing the rear door out to the side until it engages. Always make sure that the open rear door is correctly engaged in the de- tent.
Page 103 Opening the rear doors to an angle of 270° 1 Door retainer Open the rear door to an angle of ap- proximately 45°. Pull door retainer 1 in the direction of the arrow and hold it firmly. Open the rear door beyond 90° so that the door retainer can no longer engage.
Page 104 Controls in detail Opening and closing When the magnet on the rear door is in contact with magnetic door retain- er 2 , the rear door is held in this po- sition. If you prefer to keep door retainer 1 page 101) out of the loading area when loading the vehicle, you can swivel it 180°...
Page 105 Opening/closing the rear door from the inside The opening lever is on the inside of the right-hand rear door. If a white marking is visible, this indicates that the rear door is unlocked. Open rear doors only when conditions are safe to do so. Rear door 1 Opening lever 2 Catch...
Page 106 Controls in detail Opening and closing To close: make sure that the left- hand rear door is closed. Pull the right-hand rear door firmly closed by the door handle. To lock: slide catch 2 to the right. Only the rear door is locked. The white marking is no longer visi- ble.
Page 107 N54.25-2917-31 1 To lock/unlock the entire vehicle 2 To lock/unlock the sliding doors and rear door If the key is in position 0 or no longer in the ignition lock, the indicator lamp in the central locking switch lights up for 5 seconds after it is pressed.
Page 108 Controls in detail Opening and closing Locking the sliding doors and the rear door Press lower part 2 of the switch when the doors are closed. The indicator lamp in the switch comes on. Unlocking the sliding doors and the rear door Press lower part 2 of the switch.
Page 109 CAUTION If your vehicle is centrally locked, this could hinder rescue operations from the outside in the event of an accident. When the automatic locking when driving function is activated, there is a risk of being locked out if the vehi- cle is pushed or towed.
Page 110 Controls in detail Opening and closing Deactivating the automatic locking function for the entire vehicle Close all the doors. Turn the key to position 1 or 2 in the ignition lock ( page 111). Press upper part 1 of the switch. Keep it pressed for approximately 5 seconds.
Page 111 Partition sliding door* The partition sliding door is in the parti- tion between the cab and the load com- partment. Warning Make sure that nobody can become trapped as you close the partition sliding door. Operating the partition sliding door from inside the cab 1 To close 2 To open...
Page 112 Controls in detail Opening and closing Operating the partition sliding door from inside the load compartment 1 To close 2 To open 3 To unlock To open: press the lever to the right 3 . The sliding door is unlocked. Slide the sliding door to the left as far as the stop 1 .
Page 113: Key Positions
Key positions 0 To remove the key, to lock the steer- ing wheel 1 To unlock the steering wheel (power supply for some consumers, e.g. radio) 2 To switch on the ignition (power sup- ply for all consumers) Preglow and drive position 3 To start 1 Only vehicles with a diesel engine Controls in detail...
Page 114: Seats
Controls in detail Seats Seats Driver’s and passenger’s seats Warning Only adjust the seats when the vehicle is stationary and the handbrake is applied. You could otherwise lose control of the vehicle as a result of the seat moving and cause an accident.
Page 115 Warning (Continued) The distance from the pedals should be such that you can depress them fully. Adjust the head restraint in such a way that the upper edge of the head restraint is level with your head. Make sure that you hear the seat en- gage.
Page 116 Controls in detail Seats Standard, comfort* and suspension* seats 1 Seat fore-and-aft adjustment 2 Lumbar support adjustment 3 Backrest adjustment 4 Seat height adjustment 5 Seat angle adjustment 6 Seat suspension adjustment 7 Suspension lock lever Different settings are possible, de- pending on the seat version.
Page 117 Seat height adjustment Push or pull lever 4 repeatedly until you have reached the desired seat height. Seat angle adjustment* Turn thumbwheel 5 forward. The front of the seat cushion tilts down. Turn thumbwheel 5 backward. The front of the seat cushion tilts up. Lumbar support adjustment* Using the lumbar support, you can increase the level of support that the...
Page 118 Controls in detail Seats Seat suspension adjustment* The seat suspension must be adjusted to your body weight. Only adjust the seat suspension when the seat is unoccup- ied. Relieve the load on the seat. Select your body weight 88 to 265 lbs (40 to 120 kg) using thumb- wheel 6 for optimal seat suspensi- The seat suspension becomes har-...
Page 119 Warning The driver’s and passenger’s seat must be adjusted and properly engaged in the di- rection of travel for driving. Otherwise you will not be able to operate the vehicle safely. The restraint systems in your vehicle will only function as intended when the dri- ver’s and passenger’s seat are engaged in the direction of travel.
Page 120 Controls in detail Seats Warning Make sure nobody can become trapped when unlocking and turning the seats. Never hold your hands under the seat or near moveable parts when turning the seats. The seat release lever is located behind the seat between the seat backrest and the seat base.
Page 121 Warning You could knock yourself against the un- protected pivoting frame if the seat is oppo- site of the direction of travel and pushed right back in a longitudinal direction. Therefore, center the seat above the seat base whenever you leave it. Point out this danger to passengers.
Page 122 Controls in detail Seats Pull the seat cushion towards the front slightly and out of rear anchorage 2 . Fold the seat cushion up by the rear edge. You can store various articles in the space under the twin passenger’s seat.
Page 123 Adjusting the armrest angle Fold the armrest up by an angle of more than 45° to unlock it 2 . Fold the armrest forward to the stop 3 . There are six closely spaced positions in which the armrest can engage if you raise it.
Page 124 Controls in detail Seats To raise: pull the head restraint up to the desired position. To lower: press release button 1 and slide the head restraint down to the desired position. To adjust the angle: hold the head restraint by the lower edge and fold it to the desired position.
Page 125 Normal heating To switch on: press upper part of the & switch. An indicator lamp in the switch comes To switch off: press upper part of the & switch again. The indicator lamp in the switch goes out. Rapid heating To switch on: press lower part of the switch.
Page 126 Controls in detail Seats Warning When folding down the seat cushion, make sure that nobody can become trapped. The Warning to the co-driver is increased in the event of sudden steering move- ments or an accident if there is a key in- serted in the partition sliding door lock.
Page 127 Warning (Continued) For reasons of safety, only have seat mounting cups retrofitted at an autho- rized Sprinter Dealer. Do not exceed the maximum permis- sible number of seats for passenger vans. CAUTION For safety reasons, the rear bench seat with 4 seats must only be remo- ved or installed by a qualified specia- list workshop, e.g., an authorized Sprinter Dealer.
Page 128 Controls in detail Seats Installing the rear bench seat with 2 or 3 seats 1 Lever 2 Seat mounting cups Observe the specified installation lo- cation for the rear bench seat. A rear bench seat with 2 seats may only be installed left-sided. Check seat mounting cups 2 on the vehicle floor.
Page 129: Steering Wheel Adjustment
Steering wheel adjustment Warning Only adjust the steering wheel when the vehicle is stationary. Only drive with the steering wheel locked in position. An incorrectly secured steering wheel could make it more difficult to steer the vehicle safely, since the height and fore- and-aft adjustment could move out of po- sition when the steering wheel is turned.
Page 130 Controls in detail Steering wheel adjustment N46.15-2032-31 1 Steering column fore-and-aft adjustment 2 Steering column height 3 Lever Swing lever 3 down to the stop. The steering wheel is unlocked. Move the steering wheel to the de- sired position. Pull lever 3 up to the stop. The steering wheel is locked again.
Page 131: Lighting
Lighting Legal requirements may impose variati- ons in certain countries. If you are traveling in countries where vehicles are driven on the op- posite side of the road to that in which the vehicle is registered, you must have the headlamps: partially masked (halogen head- lamps) switched over (bi-xenon head-...
Page 132: Light Switch
Controls in detail Lighting Depending on the equipment versi- on, the lamp failure monitor may not monitor all lamps (with the exception of the turn signals)*. Warning The lamp failure monitor is only an aid. You are responsible for making sure that the vehicle lighting is functioning cor- rectly at all times.
Page 133: High-Beam Head Lamps
U Automatic headlamp control* M Lights off C Parking lamps, license plate and instrument lighting on B Low-beam headlamps on Switching on the low-beam head- lamps Turn light switch to B . The B indicator lamp in the in- strument cluster lights up. Switching on the high-beam head- lamps The combination switch is located on...
Page 134 Controls in detail Lighting Press combination switch forward The indicator lamp A in the in- strument cluster lights up. Headlamp flasher Turn key to position 1 in ignition lock page 111). Pull combination switch briefly in direction 2 . Constant headlamp mode* On vehicles with steering wheel buttons, you can set constant headlamp mode page 171).
Page 135 Warning If the light switch is at U: the headlamps could switch off tem- porarily due to extreme glare, e.g. from oncoming traffic the lights do not switch on automati- cally in foggy conditions Set the light switch to B. Otherwise you are endangering yourself and others.
Page 136 Controls in detail Lighting Front foglamps*/rear foglamp Foglamps will operate with the park- ing lamps and/or the low beam headlamps on. Foglamps should only be used in conjunction with low beam headlamps. Consult your State or Province Motor Vehicle Regula- tions regarding permissible lamp op- eration.
Page 137: Turn Signals
Switching on the rear foglamp Make sure that the parking lamps or low-beam headlamps are switched Pull light switch 1 out to the second detent. The † yellow indicator lamp next to the light switch comes on. Turn signals The combination switch is located on the left of the steering wheel.
Page 138 Controls in detail Lighting Hazard warning lamps The hazard warning lamps still operate if the ignition is switched off and the key is removed. The switch is located on the center con- sole. N54.25-2919-31 1 Hazard warning lamps switch To switch on: press the hazard war- ning lamps switch.
Page 139 Front interior lighting Standard front interior lighting 1 To switch on the interior lighting 2 Automatic control 3 To switch off the interior lighting Front interior lighting with overhead control panel* 1 To switch the left-hand reading lamp on/off 2 To switch the right-hand reading lamp on/off 3 Right-hand reading lamp 4 Interior lamp...
Page 140 Controls in detail Lighting The interior lighting switches off after approximately 20 minutes if it is con- trolled automatically and if a door re- mains open. Manual control Press button 6 . Front interior lamps 4 come on. Press button 6 again. Front interior lamps 4 switch off.
Page 141 Rear interior lamp with switch 1 To switch on the rear interior lighting 2 To switch off the rear interior lighting 3 Automatic control The rear interior lamps switch off au- tomatically after 20 minutes if a slid- ing door or rear door is open. Switching the convenient rear interi- or lighting* on/off On panel vans/crewbuses equipped...
Page 142 Controls in detail Lighting Rear interior lighting master control switch 1 To switch on the rear interior lighting 2 Automatic control 3 To switch off the rear interior lighting To switch on: press upper part 1 of the switch. The rear interior lamps are switched on when the switches on the rear in- terior lamps ( page 139) are not in...
Page 143 Load compartment motion detector* On panel vans equipped with a motion detector in the load compartment, the rear interior lighting may also switch on if motion is detected. Warning Motion detectors work with invisible in- frared beams emitted by LEDs (Light Emitting Diodes).
Page 144: Instrument Cluster
Controls in detail Instrument cluster Instrument cluster Do not hang any objects (e.g. coats) in the load compartment. This will help to prevent the motion detector from inadvertently switching on the rear interior lamps. You will find a full overview of the instru- ment cluster in the “At a glance”...
Page 145 The display in the instrument cluster is activated when you: open the driver’s door switch on the ignition press the reset button switch on the lights The display switches off automatically after approximately 30 seconds if: there is no vehicle lighting switched the key is in position 0 in the ignition lock ( page 111)
Page 146 Controls in detail Instrument cluster Warning (Continued) Only use adjustment buttons when traffic conditions permit. You will otherwise be unable to observe road and traffic conditions and could cause an accident. Do not reach through the steering wheel to press the adjustment buttons. This will make the steering wheel much more diffi- cult to control.
Page 147 Tachometer The red band in the tachometer indi- cates the engine’s overrevving range. CAUTION Do not drive in the overrevving range. Doing so could damage the engine. To protect the engine, the fuel supply is interrupted when the red band is reached.
Page 148 Controls in detail Instrument cluster Fuel gauge Vehicles without steering wheel buttons Vehicles with steering wheel but- tons* Fuel filler flap location indicator Ö : The fuel filler cap is on the left-hand side Reserve fuel warning lamp page 475) Trip meter Resetting the trip meter Vehicles with steering wheel but-...
Page 149: Operating System Without Steering Wheel Buttons
Operating system without steering wheel buttons The operating system is activated as soon as you switch on the ignition. You may perform the following using the op- erating system: Call up vehicle information Make settings Warning Only use adjustment buttons when traffic conditions permit.
Page 150 Controls in detail Operating system without steering wheel buttons Standard display N54.32-2281-31 Odometer Trip meter Time Outside temperature* or digital speedometer Fuel gauge ( page 145) Selector lever position or current shift range Changing the standard display Switch on the ignition ( page 111).
Page 151 There may be a short delay before a low- er outside temperature is displayed, for example after leaving a garage. There may also be a short delay before a rise in the outside temperature is displayed. This prevents you from seeing a temper- ature display influenced by heat from the engine when the vehicle is stationary or moving slowly.
Page 152 Controls in detail Operating system without steering wheel buttons Setting the time Switch on the ignition ( page 111). Press menu button repeatedly until the hours figure flashes. Set the hour using the ton. Press the reset button The minute display flashes. Set the minutes using the button.
Page 153: Operating System With Steering Wheel Buttons
Operating system with steering wheel buttons* The operating system is activated as soon as you switch on the ignition. You may perform the following using the op- erating system: Call up vehicle information Make settings You can use this not only to find out when the next service is due, but also to set the language for messages in the in- strument cluster, for example, and much...
Page 154 Controls in detail Operating system with steering wheel buttons* N46.10-2074-31 1 Display Controlling the operating system 2 Selects a submenu or adjusts the volume Up/increases the volume Down/decreases the volume 3 Telephone* functions s Accepts a call/starts dial- t Ends a call/rejects an incoming call 4 Jumps from one menu to another Forward...
Page 155 Several functions are combined themat- ically in the menus. The display changes when you press one of the buttons on the steering wheel. For example, the menu contains AUDIO functions for controlling the radio* or CD player*. You can use a function to call up information or to change the set- tings for the vehicle.
Page 156 Controls in detail Operating system with steering wheel buttons* Menu overview This is what the display looks like when you scroll through the menus. N54.32-2282-31 The explanations for the individual menus are shown in the following table.
Page 157 Function Page Operation menu Standard display with trip meter and odometer Displaying coolant tem- perature Calling up the service due date Tire pressure monitor Checking the engine oil level (only on vehicles with a diesel engine) Operating system with steering wheel buttons* Function Page Audio* menu...
Page 158 Controls in detail Operating system with steering wheel buttons* Function Trip computer menu Consumption statistics after start Consumption statistics after reset Distance to empty Telephone* menu Enter PIN Rejecting a call Accepting a call Ending a call Function Page Dialing for a number from the phone book Redialing Page...
Page 159 Operation menu In the Operation menu, you can select the following functions using the j or k button: Function Page Standard display with trip meter and odometer Display coolant temperature Call up the service due date* Tire pressure monitor Check the engine oil level (only on vehicles with a diesel engine) Operating system with steering wheel buttons*...
Page 160 Controls in detail Operating system with steering wheel buttons* Displaying the coolant temperature Press the j or k button re- peatedly until you see the coolant temperature in the display. The temperature displayed may climb to 250 F (120 C) when the vehicle is being driven in normal conditions and if the coolant contains the correct concentra- tion of corrosion inhibitor and antifree-...
Page 161 1 Reception frequency 2 Waveband, with memory location number if set Press the j or k button re- peatedly until you have found the desired station. Operating system with steering wheel buttons* Operating the CD player Switch on the radio and select the CD player.
Page 162 Controls in detail Operating system with steering wheel buttons* Malfunction memory menu The Malfunction memory menu displays malfunctions that may have occurred. The message in the display depends on whether malfunctions have occurred or not. Warning The operating system only records and shows malfunctions and warnings from certain systems.
Page 163 The malfunction memory is cleared when you switch off the ignition. If any new malfunctions occur, they will be displayed again. Settings menu menu has two functions: Settings To reset: Press reset button function, with which you for 3 sec. can reset all settings to the factory defaults a collection of submenus which you...
Page 164 Controls in detail Operating system with steering wheel buttons* Resetting settings You can reset the functions in all sub- menus to the factory defaults. Press the reset button for ap- proximately 3 seconds. You will see the message in the dis- play prompting you to press the reset button once more to confirm.
Page 165 If you do not press the reset but- ton a second time to confirm, the changed settings remain set. The menu is displayed again af- Settings ter approximately 5 seconds. For safety reasons, it is not possible to reset all of the functions while the vehicle is in motion.
Page 166 Controls in detail Operating system with steering wheel buttons* Instrument cluster Clock/Date page 165) page 168) Select the unit for the Set the hours (clock) Set constant temperature Select the unit for the Set the minutes speedometer (clock) Select the unit for the Select the time for- odometer Select the language...
Page 167 Instrument cluster submenu You can reach the sub- Inst. cluster menu via the menu Settings page 161). Function Page Select the unit for the temper- ature Select the unit for the speedometer and odometer Select the language Select the display for the sta- tus line Operating system with steering wheel buttons* Selecting the unit for the temperature...
Page 168 Controls in detail Operating system with steering wheel buttons* N54.32-2257-31 Press the æ or ç button to se- lect the unit for all messages in the display: (kilometers or km/h miles per hour). Selecting the unit for the odometer Select the submenu Inst.
Page 169 Use the æ or ç button to se- lect the language in which the oper- ating system messages are to be displayed. You can select: German (Deutsch) British English American English French Italian Spanish Operating system with steering wheel buttons* Selecting the display for the status line Select the...
Page 170 Controls in detail Operating system with steering wheel buttons* Selecting the unit for the tire pressure Select the submenu Inst. cluster using the æ or ç button. Press the j or k button re- peatedly until you see the Tire pres. message in the display.
Page 171 Setting the minutes Select the submenu us- Clock/Date ing the æ or ç button. Press the j or k button re- peatedly until you see the Set clock message in the display. Minutes N54.32-2263-31 Set the minutes by pressing the æ...
Page 172 Controls in detail Operating system with steering wheel buttons* Setting the month Select the submenu Clock/Date using the æ or ç button. Press the j or k button re- peatedly until you see the Date Month message in the display. Set the month by pressing the æ...
Page 173 Setting constant headlamp mode* If you have set constant headlamp mode and the light switch is at M , the fol- lowing light up automatically when the engine is running: The parking lamps and low-beam headlamps The tail lamps The license plate lamp For safety reasons, it is only possible to change this setting when the vehicle is stationary.
Page 174 Controls in detail Operating system with steering wheel buttons* USA only: If you turn the light switch to C or B , the corresponding light switches on. Constant headlamp mode remains activated if the light switch is turned to U . Canada only: If you turn the light switch to B , the low-beam headlamps are...
Page 175 N54.32-2269-31 Press the æ or ç button to switch the locator lighting Operating system with steering wheel buttons* Setting the exterior lighting delayed switch-off* (headlamps delayed Headlamps switch-off) function enables you to set whether or not the exterior lighting should remain on in the dark after the doors have been closed.
Page 176 Controls in detail Operating system with steering wheel buttons* N54.32-2270-31 Press the æ or ç button to se- lect whether and for how long the lights should remain on. Vehicle submenu You can reach the submenu via Vehicle menu ( page 161).
Page 177 Setting the windshield wiper sensitivity You can use the function to Wipe sensor set the sensitivity of the rain sensor. Press the è or ÿ button re- peatedly until you see the Vehicle message in the display. Press the j or k button re- peatedly until you see the Wipe sen- message in the display.
Page 178 Controls in detail Operating system with steering wheel buttons* Press the j or k button re- peatedly until you see the sage in the display. The current setting is highlighted. N54.32-2273-31 Press the æ or ç button to switch key dependence mes- For safety reasons, it is not possible to set the...
Page 179 Consumption statistics after start Press the è or ÿ button re- peatedly until you see the message in the display. After start N54.32-2274-31 1 Distance driven since start 2 Time elapsed since start 3 Average speed since start 4 Average fuel consumption since start Operating system with steering wheel buttons* If you turn the key to position 0 in the ignition lock or remove it, all the val-...
Page 180 Controls in detail Operating system with steering wheel buttons* Resetting the consumption statistics Press the è or ÿ button re- peatedly until you see the message in the display. After start Press the j or k button re- peatedly until you see the statistics that you want to reset in the display.
Page 181 Warning (Continued) If it is permitted to operate a cell phone while the vehicle is in motion, you must only operate it when road and traffic con- ditions permit. You may otherwise be dis- tracted from the traffic conditions, cause an accident and injure yourself and oth- ers.
Page 182 Controls in detail Operating system with steering wheel buttons* Rejecting a call If you do not wish to speak to the person who is calling, you can reject the call. Press the t button. The caller then hears the busy signal. Accepting a call You can accept a call at any time, provid- ed the cell phone is ready to receive...
Page 183 The stored names are displayed al- phabetically from A to Z, or Z to A. The operating system scrolls through the names rapidly if you press and hold the j or k button for more than one second. Releasing the button stops the rapid scroll.
Page 184 Controls in detail Operating system with steering wheel buttons* Press the j or k button re- peatedly until the number or the name you are looking for is dis- played. Press the s button. The operating system dials the se- lected phone number.
Page 185: Driving And Parking
Driving and parking Warning The movement of the pedals must not be obstructed. The vehicle’s operating and road safety are otherwise jeopardized. Objects could fall and get caught between the pedals if you accelerate or brake sud- denly. You will no longer be able to brake or accelerate.
Page 186 Controls in detail Driving and parking You will find information on: regular checks ( page 312) driving in winter ( page 406) driving when towing a trailer page 303) and other driving tips in the “Operation” section page 301). Starting the engine Warning Never run the engine in an enclosed space.
Page 187 CAUTION Do not depress the accelerator pedal when starting the engine. If you depress the brake pedal when starting the engine, pedal travel may be short and the pedal resistance may be high. Pedal travel and resistance return to normal when you depress the brake pedal again while the engine is run- ning.
Page 188 Controls in detail Driving and parking Starting the engine Gasoline engine Turn the key to position 3 in the igni- tion lock ( page 111) and release it immediately ("touch-start" function). The engine starts automatically. Diesel engine Switch on the ignition ( page 111).
Page 189 On vehicles with a reverse warning feature*, an audible warning sounds for other road users when reverse gear is engaged ( page 271). Depending on the vehicle's settings, the vehicle automatically locks itself centrally after it has driven off, at the latest ( page 106).
Page 190 Controls in detail Driving and parking Braking Warning There is no power assistance for the ser- vice brake when the engine is not running. You will need to use significantly more force to brake and could therefore lose control of the vehicle and cause an acci- dent.
Page 191 Apply the brakes so that you can feel their response after a journey on wet roads, especially if the road has been salted. The brake discs will be warmed, dry more quickly and be protected against corrosion. If you make only moderate use of the service brake, check from time to time that it is fully functional.
Page 192 Controls in detail Driving and parking Warning Always switch off the engine and apply the handbrake before leaving the vehicle. The vehicle could roll away if it is not secured. On uphill or downhill gradients steeper than 15%: apply the handbrake secure an unloaded vehicle by chock- ing the front axle ( page 521)
Page 193 Warning Regulations in some countries require the parking lamps to be switched on to illumi- nate the vehicle for other road users if parked on a public road at night. In built- up areas, night reflectors can also be used. Observe legal requirements.
Page 194 Controls in detail Driving and parking Applying the handbrake Pull lever 1 up as far as the last de- tent. The 7 indicator lamp in the in- strument cluster lights up while the engine is running. On vehicles with a folding handbrake lever, you can then press lever 1 down to the stop.
Page 195 Warning The wheels on the rear axle could lock if the handbrake lever is applied too abrupt- ly. The vehicle could then start to skid. Make sure that you apply the handbrake lever carefully to ensure that braking ap- plication is moderated. Stopping the engine CAUTION If the coolant temperature is raised,...
Page 196 Controls in detail Driving and parking General driving tips Drinking and driving Warning Drinking and driving and/or taking drugs and driving are very dangerous combina- tions. Even a small amount of alcohol or drugs can affect your reflexes, percep- tions and judgment. The possibility of a serious or even fatal accident is sharply increased when you drink or take drugs and drive.
Page 197 Driving in wet conditions Warning The vehicle may hydroplane despite hav- ing adequate tire tread depth and being driven at low speeds, depending on the depth of water on the road surface. For this reason, avoid tire ruts and brake carefully.
Page 198 Controls in detail Driving and parking causes and consequences of tire wear measures to be taken in the event of tire damage tire types for certain regions, areas of operation or conditions of vehicle interchangeability of tires, etc. Modifications to the brake system or wheels are not permissible, nor is the use of spacer plates or brake dust shields.
Page 199 Warning Although the applicable federal motor ve- hicle safety laws consider a tire to be worn when the Treadwear Indicators (TWI) become visible at approximately 1/ 16 in (1.6 mm), do not allow your tires to wear down to that level. As tread depth approaches 1/8 in (3 mm) for summer tires or 1/6 in (4 mm) for winter tires, the adhesion properties on a wet road are...
Page 200 Controls in detail Driving and parking Tire traction Tire grip is greatly reduced on a wet, snow covered or icy road. Speed and driving style must therefore be adapted to suit road conditions. The safe speed on a wet, snow covered or icy road is al- ways lower than on a dry road.
Page 201 Tire speed rating Regardless of the tire speed rating, local speed limits should be obeyed. Use pru- dent driving speeds appropriate to pre- vailing conditions. Warning Even when permitted by law, never oper- ate a vehicle at speeds greater than the maximum speed rating of the tires.
Page 202 Controls in detail Driving and parking Improper alignment will not cause vehi- cle vibration. Vibration may be the result of a tire and wheel imbalance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. Coolant temperature During severe operating conditions and stop-and-go city traffic, the coolant tem- perature may rise close to approximate- ly 250 °F (120 °C).
Page 203: Automatic Transmission
Automatic transmission Gearshift pattern P Parking position (selector lever lock) R Reverse gear N Neutral D Drive position Gearshift procedure The automatic transmission adapts to your individual driving style by continu- ously adjusting its shift points. These shift point adjustments take into ac- count the current operating and driving conditions.
Page 204 Controls in detail Automatic transmission The selector lever position engaged or the current shift range is shown in the display. Display on vehicles with steer- ing wheel buttons* ( page 151) and on vehicles without steering wheel buttons page 147). When the selector lever is in position D , you can influence the gearshifts made by the automatic transmission by:...
Page 205 ® If ASR is deactivated or ESP has malfunctioned: only move the selector lever to N if the vehicle is in danger of skidding, e.g. on icy roads. ê Drive The automatic transmission changes gear automatically. All 5 forward gears are avail- able.
Page 206 Controls in detail Automatic transmission Upshifting Press the selector lever to the right towards D+ . The automatic transmission extends the shift range by one gear. The auto- matic transmission shifts to the next gear up, depending on the current gearshift program.
Page 207 The transmission shifts ê through all 5 gears. The automatic transmission é shifts only as far as fourth gear. The automatic transmission è shifts only as far as third gear. This position allows you to use the braking effect of the engine.
Page 208 Controls in detail Automatic transmission Kickdown Use kickdown for maximum acceleration. Depress the accelerator pedal be- yond the pressure point. The automatic transmission shifts to the next gear down, depending on the engine speed. Release the accelerator pedal as soon as the desired speed has been reached.
Page 209 Trailer towing Run the engine in the moderate en- gine speed range on steep uphill gra- dients. Depending on the uphill or downhill gradient, shift down to shift range 3 or 2 ( page 204), even if cruise control* is switched on. Working on the vehicle Warning Apply the handbrake before working on...
Page 210: Good Visibility
Controls in detail Good visibility Good visibility Mirrors Before starting off, adjust the rear-view mirror and the exterior mirrors in such a way that you can get a good overview of road and traffic conditions. Rear-view mirror* Adjust the rear-view mirror manually. Setting the rear-view mirror to anti- dazzle mode 1 Anti-dazzle lever...
Page 211 Adjusting the exterior mirrors electrically* The switch and button for adjusting the exterior mirrors are located in the interi- or trim of the driver’s door. 1 Exterior mirror on the left-hand side 2 Exterior mirror on the right-hand side 3 Sets the mirror position Switch on the ignition ( page 111).
Page 212: Windshield Wipers
Controls in detail Good visibility Windshield wipers The combination switch is located on the left of the steering wheel. N54.25-2923-31 1 Single wipe 2 To switch the windshield wipers on Switching on the windshield wipers Turn key to position 1 in the ignition lock ( page 111).
Page 213 For example, if you have selected speed II and stop the vehicle,the wip- ers wipe at intermittent speed until you pull away again. The wipe intervals are longer in intermittent mode. Vehicles with rain sensor*: You can use speed I as the universal speed.
Page 214: Rear Window Wiper
Controls in detail Good visibility Intermittent wipe Only switch on intermittent wipe in damp weather conditions or when it is raining. Vehicles with rain sensor*: The a rain sensor is activated when you switch on intermittent wipe. The appro- priate wiping frequency is set automati- cally according to the rain falling on the sensor.
Page 215 Wiping with washer fluid Turn switch 1 to 5 or 2 and keep it pressed until the window is clean. Windshield heating* The windshield heating is operational while the engine is running. The windshield heating consumes a lot of energy. You should therefore switch the heating off as soon as the windshield is clear.
Page 216 Controls in detail Good visibility To switch on: press upper part of the P switch. The indicator lamp in the switch comes on. To switch off: press upper part of the P switch again. The indicator lamp in the switch goes out.
Page 217: Air Conditioning
Controls in detail Air conditioning Air conditioning N83.00-2126-31...
Page 218 Controls in detail Air conditioning Function 1 Side window defroster vents 2 Thumbwheel for air vents 3 Side air vents 4 Thumbwheel for side air vents and defroster vents 5 Swiveling center air vents 6 Thumbwheel for center air vents 7 Control panel Tempmatic Rear heating/rear...
Page 219 The interval for replacing the filter de- pends on environmental factors, e.g. high air pollution. The interval may be shorter than that indicated in the Ser- vice Booklet. Condensation may collect under the vehicle while Tempmatic is in opera- tion. Warning Air flowing out of the air vents in the foot- well when Tempmatic is in operation may...
Page 220 Controls in detail Air conditioning N83.25-2048-31 for the air-conditioning Control panel system Function Page 1 Temperature selector control 2 Airflow control with indicator 3 Switch for air-recircula- tion mode 4 Switch for reheat function (dehumidification) 5 Air distribution control 6 Switch for Economy mode Residual heat mode Switching the air conditioning sys-...
Page 221 To switch off: press the ° switch for normal mode. The indicator lamp in the switch goes out. Basic setting Air distribution control Heating Set temperature selector control 1 page 218) as required, but do not turn the control below the middle po- sition.
Page 222 Controls in detail Air conditioning Open as required: the center air vents the side air vents the ventilation vents Switch air-conditioning system on page 218) if necessary. Setting the temperature The temperature is set using temperatu- re selector control 1 in the control pa- nel ( page 218).
Page 223 The display next to the airflow con- trols indicates the speed of the air- flow. The blower switches off if you press the ß airflow control again after the slowest speed has been reached. Setting air distribution The air distribution is set using the air distribution control in the control panel page 218).
Page 224 Controls in detail Air conditioning The switch for air-recirculation mode is in the control panel ( page 218). To switch on: press the Ä switch. The indicator lamp in the switch comes on. To switch off: press the Ä switch again. The indicator lamp in the switch goes out.
Page 225 Residual heat switches off automati- cally: after about 30 minutes when you switch on the ignition if the battery’s voltage drops Reheat function (dehumidification) The reheat function quickly ensures de- frosted windows and dehumidification in the vehicle interior. To switch on: press the Å switch page 218).
Page 226 Controls in detail Air conditioning Turn air distribution control 5 to ‚ P . Close the center air vents and the air outlets for the head area and the rear compartment. Open the side air vents and direct them at the side windows. If the windshield is fogged up on the outside, switch on the windshield wipers (...
Page 227 Ventilated glove box* The glove box can be ventilated when Tempmatic is switched on, e.g. to cool its contents. 1 To switch the air supply on/off To switch on: press switch 1 to the left. To switch off: press switch 1 to the right.
Page 228 Controls in detail Air conditioning Setting the airflow The airflow is set using the airflow con- trol for the rear compartment. To increase: press the Q airflow control. To reduce: press the airflow control. The display next to the airflow con- trols indicates the speed of the air- flow.
Page 229 Alter the air distribution by turning the air vents. CAUTION Never close all the air vents, other- wise there is a risk of damage to the air-conditioning system in the rear compartment. Heater* The heater is operational when the engi- ne is running.
Page 230 Controls in detail Air conditioning If the vehicle interior has been heat- ed up, ventilate the vehicle before driving off. Keep the air inlet on the hood free of ice and snow. Position the sliders for the center air vents in the central position to provi- de practically draft-free ventilation.
Page 231 Basic setting Air distribution control Heating Set temperature selector control 1 page 228) as required, but do not turn the control below the middle po- sition. Set airflow control 2 ( page 228) as required, but do not turn the con- trol below the second speed.
Page 232 Controls in detail Air conditioning Setting the temperature The temperature is set using temperatu- re selector control 1 in the control pa- nel ( page 228). Only change the temperature in small in- crements. If you use the basic settings for heat- ing or ventilating the vehicle, you will rarely need to adjust the tempera- ture, airflow and air distribution...
Page 233 Air-recirculation mode You can switch off the flow of outside air if unpleasant odors are entering the ve- hicle from outside, e.g. before driving th- rough a tunnel. No more outside air is taken in and the air inside the vehicle is recirculated.
Page 234 Controls in detail Air conditioning Turn air distribution control 4 page 228) to Ô P . Close the center air vents and the air outlets for the head area and the rear compartment. Open the side air vents and direct them at the side windows.
Page 235 Rear heater* Rear heating control panel 1 Rear heating 2 Airflow control 3 Temperature selector control To switch on: press the switch. The indicator lamp in the switch co- mes on. To switch off: press the switch again. The indicator lamp in the switch goes out.
Page 236 Controls in detail Air conditioning To increase: turn the temperature selector control clockwise. To reduce: turn the temperature se- lector control counterclockwise. Heater booster function* The fuel-fired heater booster system heats the vehicle interior as quickly as possible while the engine is running. The auxiliary heating automatically switches to heater booster mode af- ter the engine is started.
Page 237 To switch on: press the switch ³ . The indicator lamp in the switch comes on. If you switch off the engine without switching off the heater booster function, the system will be switched on the next time the engine is started (memory function).
Page 238: Auxiliary Heating/Ventilation
Controls in detail Auxiliary heating/ventilation* Auxiliary heating/ventilation* The auxiliary heating heats or ventilates the interior to a temperature that you have set. The auxiliary heating can be operated with the engine switched on or off. The auxiliary heating is equipped with a water heater.
Page 239 The auxiliary heating heats the coolant and the vehicle interior and is therefore more favorable to the engine and con- sumes less fuel. The fuel tank must be at least a quarter full to ensure that the auxiliary heating/ventilation operates correctly.
Page 240 Controls in detail Auxiliary heating/ventilation* Before switching on Adjust the heat output to the desired temperature using the temperature control selector ( page 218). Set the air distribution as required. Operation using the switch The switch for the auxiliary heating/ ventilation is between the light switch and the steering wheel.
Page 241 You cannot use the auxiliary ventila- tion to cool the vehicle interior to a lower temperature than the outside temperature. The heating or ventilation period is limited to 60 minutes. To switch the auxiliary heating off: press the ö switch. Turn the key to position 0 in the igni- tion lock ( page 111).
Page 242 Controls in detail Auxiliary heating/ventilation* To switch the auxiliary heating on: press button 2 . Indicator lamp 1 lights up briefly. To switch the auxiliary heating off: press button 3 . Indicator lamp 1 lights up briefly. The auxiliary heating operates for around a further 2 minutes and then switches off automatically.
Page 243 Operating system without steering wheel buttons Switch on the ignition ( page 111). Press the ö switch. The ö symbol in the display flashes. Press the menu button on the in- strument cluster repeatedly until the ö symbol in the display flashes. Use the button on the in- strument cluster to select desired...
Page 244 Controls in detail Auxiliary heating/ventilation* You can reach the Aux. heat. menu via the menu Settings page 161). Press the æ or ç button to se- lect the desired switch-on time. The automatic switch-on is deactivated if setting is selected. Timer off Press the è...
Page 245 If you keep the button pressed, the values will change continuously. To return to the standard display: press and hold the button on the instrument cluster for more than 1 second do not press a button for 10 seconds Operating system with steering wheel buttons Select a switch-on time as described under “Selecting a switch-on time”...
Page 246: Open Air
Controls in detail Open air Open air Side windows You can open and close the side win- dows electrically. The switches for all side windows are lo- cated on the door control panel. Warning Make sure that nobody can become trapped as you close a side window.
Page 247 Resetting the side windows The side windows must be reset if the battery has been disconnected: Pull the two power window switches until the side windows are closed. Hold the switches in this position for about 1 second. The side windows are reset. Sliding sunroof* Warning Make sure that nobody can become...
Page 248 Controls in detail Open air Sliding sunroof switch 1 To open 2 To close 3 To raise 4 To lower CAUTION Do not raise the sliding sunroof if you have mounted a roof rack. It would otherwise strike the roof rack. You could thereby damage the slid- ing sunroof and the roof rack.
Page 249 Resetting the sliding sunroof The sliding sunroof must be reset after: the sunroof has been closed manual- ly using the emergency operation key ( page 522) the sunroof has opened with a jerk a malfunction Switch on the ignition ( page 111).
Page 250: Driving Systems
Controls in detail Driving systems Driving systems Driving systems which may form part of your vehicle are described on the follow- ing pages: Cruise control* ( page 248), which you can use to control the speed of your vehicle Parktronic system*, which is an aid for parking and maneuvering page 253) Rear view camera*, which is an aid...
Page 251: Cruise Control Lever
Warning The cruise control function cannot take account of road and traffic conditions. Always pay attention to road and traffic conditions, even when cruise control is activated. Cruise control is only an aid designed to assist driving. You are responsible for the vehicle’s speed and for braking in good time.
Page 252 Controls in detail Driving systems N54.25-2925-31 1 To store the current or a higher speed 2 To resume the last speed stored 3 To store the current speed or a lower speed 4 To deactivate cruise control Storing the current speed Accelerate/decelerate the vehicle to the desired speed.
Page 253 Resuming the stored speed Warning Only resume the stored speed if you know what this speed is and the current situa- tion is appropriate to do so. Otherwise, sudden acceleration or braking could en- danger you or others. Pull the cruise control lever briefly in the direction of arrow 2 .
Page 254 Controls in detail Driving systems Briefly press the cruise control lever upward 1 to increase the speed or downward 3 to reduce the speed. The last speed stored is increased or decreased in 1 mph increments (1 km/h increments). Press and hold the cruise control le- ver up 1 or down 3 until the de- sired speed has been reached.
Page 255 Cruise control is automatically deac- tivated if: you are braking you apply the handbrake and the 7 indicator lamp in the in- strument cluster is lit you are driving under 20 mph (30 km/h) ® or ASR is intervening and the yellow ASR/ESP ®...
Page 256 Controls in detail Driving systems Parktronic is an electronic parking aid and informs you visually and audibly of the distance between the vehicle and an obstacle. Parktronic is automatically switched on when you switch on the ignition and re- lease the handbrake. You must also move the selector lever to position D , N or R .
Page 257 Front sensors Center about 39 in (100 cm) Corners about 26 in (65 cm) Rear sensors Center about 71 in (180 cm) Corners about 39 in (100 cm) Minimum distance Center about 12 in (30 cm) Corners, front about 10 in (25 cm) Corners, rear about 12 in (30 cm) If an obstacle is within this range, all seg-...
Page 258 Controls in detail Driving systems Warning displays The warning displays indicate the dis- tance between the sensor and the ob- stacle. The warning display for the front area is located on the middle of the dashboard above the center console. N54.65-2074-31 Front area warning display 1 Left-hand side of vehicle...
Page 259 CAUTION There is a malfunction if only the red segments of the warning display light up ( page 451). The selector lever position determines whether the front and/or rear area is monitored. Transmission Monitoring position Front area R or N Front and rear area No areas activated...
Page 260 Controls in detail Driving systems Switching Parktronic on/off You can switch Parktronic on and off manually. The switch is located on the center con- sole. N54.25-2922-31 1 To switch Parktronic on/off To switch off: press upper part 1 of the switch. The indicator lamp in the switch comes on.
Page 261 1 Rear view camera monitor The angle and inclination of the monitor can be adjusted from inside the storage compartment on the center console. Warning The rear view camera is only an aid and may display potential obstacles in a ske- wed perspective, incorrectly or not at all.
Page 262 Controls in detail Driving systems Warning (Continued) Failure to pay attention could mean that you fail to notice persons or objects and, by continuing to drive, cause injury to per- sons or damage to objects and your vehic- le. The manufacturer recommends that you also use the Parktronic system* when parking your vehicle.
Page 263 For information on cleaning the camera, see “Rear view camera lens” page 422). Activating the rear view camera Make sure that the ignition is switched Engage reverse gear. The rear view camera is activated. Operating the monitor The monitor is operated using four but- tons located on a panel at the bottom of the screen.
Page 264 Controls in detail Driving systems Input for auxiliary devices (AUX) If reverse gear is engaged while auxiliary devices are in operation, the monitor will switch over to the rear view camera. When reverse gear is disengaged, the monitor will continue to show the rear view camera screen for approx.
Page 265 Menu guidance Selecting the main menu Press the m button. The main menu selection options (menu level 1) appear. Press the button until the menu you desire is highlighted. Press the m button. The required menu is selected. The following settings and menus are available in the main menu: Display ( page 264)
Page 266 Controls in detail Driving systems Display menu You can customize the monitor display in the menu. Display You can select the following submenus: Screen illumination Brightness Contrast Color Tint Back Screen illumination submenu You can configure the monitor’s back- lighting in the submenu.
Page 267 Press the button. The backlighting is set in steps. Press the m button. The submenus (menu level 2) are displayed. If 7 seconds pass without any but- tons being pressed, the menu will be exited automatically. Brightness submenu You can set the monitor’s brightness in submenu.
Page 268 Controls in detail Driving systems Contrast submenu You can set the monitor’s screen cont- rast in the submenu. Contrast Press the m button. The main menu (menu level 1) is dis- played ( page 263). Press the button until menu is highlighted. Display menu is selected.
Page 269 Press the m button. The color setting is displayed. Press the button. The color is set in steps. Press the m button. The submenus (menu level 2) are displayed. Tint submenu (NTSC color balance) You can set the monitor’s color balance in accordance with the NTSC standard in submenu.
Page 270 Controls in detail Driving systems Aspect ratio menu You can set the monitor’s display format in the menu. Aspect ratio Press the m button. The main menu (menu level 1) is dis- played ( page 263). Press the button until menu is highligh- Aspect ratio ted.
Page 271 Norm menu You can set the monitor’s video stan- dard in the menu. Norm Press the m button. The main menu (menu level 1) is displayed ( page 263). Press the button until menu is highlighted. Norm Press the m button. The submenu (menu level 2) is displayed.
Page 272 Controls in detail Driving systems Menu language menu You can select the language for the mo- nitor’s menu texts in the Menu language menu. Press the m button. The main menu (menu level 1) is dis- played ( page 263). Press the button until menu is highligh-...
Page 273 Press the button until the desired setting is highlighted. Yes: overwrite all settings with the default values. : go back to the main menu wi- thout applying the default values. Monitor shutdown while driving For safety reasons, the monitor will shut off at speeds above 6 mph (10 km/h).
Page 274 Controls in detail Driving systems Warning The reverse warning feature signal could be ignored by other road users. For this reason, the reverse warning feature can- not guarantee that there are no people or objects behind your vehicle. The reverse warning feature is a system which helps you ensure the safety of oth- er road users.
Page 275: Operating The Vehicle
Operating the vehicle Operating speed governor (ADR)* When activated, the operating speed governor (ADR) automatically increases the engine speed to a preset or adjust- able operating speed ( page 275). The idle speed of the engine auto- matically increases after a cold start. If the set operating speed is lower than the increased idle speed, the set operating speed is attained only...
Page 276 Controls in detail Operating the vehicle To switch on: press upper part 1 of the switch with the engine running. The indicator lamp in the switch comes on. Vehicles without steering wheel but- tons: The ™ indicator lamp in the in- strument cluster comes on.
Page 277 Adjustable operating speed* Adjusting the operating speed N54.25-2933-31 1 To increase speed 2 To reduce speed Switch on ADR ( page 273). To increase: press upper part 1 of the switch. On vehicles with cruise control*, press the cruise control lever* up page 249).
Page 278: Transporting
Controls in detail Transporting Transporting Loading guidelines Warning Secure and position a load as described in the loading guidelines. Otherwise, the load could slide or be thrown around in the event of strong braking maneuvers, sudden changes of direction or poor road conditions, thereby injuring you or others.
Page 279 Warning After an accident, have a damaged load compartment floor or damaged load sur- face, the lashing eyes and lashing materi- als inspected by a specialist workshop having the necessary technical expertise and tools to carry out the required work. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 280 Controls in detail Transporting During loading Observe the maximum permissible axle loads and permissible gross weight for the vehicle. CAUTION In passenger vans with the maximum number of seats, the maximum pay- load would cause the permissible rear axle load to be exceeded. Bear in mind that your vehicle's un- laden weight is increased by the in- stallation of optional equipment and...
Page 281 Load distribution The load's overall center of gravity should be as low and central as possible, between the axles near the rear axle. CAUTION Excessive loads on individual points of the load compartment floor or load surface have a negative effect on handling characteristics and could damage the floor covering.
Page 282 Controls in detail Transporting Securing a load As the driver of the vehicle, you are re- sponsible for ensuring that the load is secured against slipping, tipping over, rolling or falling down, whether driving in normal traffic situations or on poor road surfaces or as a result of having to swerve to avoid an obstacle or applying the brakes fully.
Page 283 Always use the lashing points closest to the load for securing it in place and place padding around sharp edg- Lashing materials that comply with valid standards can be obtained in any specialist shop or from an autho- rized Sprinter Dealer. If possible, use the lashing eyes when securing a load, especially if it is heavy.
Page 284 Controls in detail Transporting Warning Do not carry out any modifications or repairs to the lashing points, the lashing eyes or the lashing materials. The load or the lashing points could accidentally come loose and cause serious injury to you or others as well as damage to property.
Page 285 Warning If you tension the lashing straps between the side walls or between a side wall and the load compartment floor, the permissi- ble load for the lashing rails, lashing points or lashing eyes could be exceeded in the event of strong braking, sudden changes of direction or an accident.
Page 286 Controls in detail Transporting Mounting lashing points for load rails* 1 Locking mechanism To install: slide the lashing eye through a recess in the load rail close to the load until locking mechanism 1 in the recess engages. When you pull locking mechanism 1 out of the recess, the lashing eye is able to move within the lashing rail or load rail.
Page 287 Check whether the lashing eye is firmly in place. To remove: pull locking mechanism 1 upward and pull the lashing eye through a recess towards the locking mechanism and out of the load rail. Carrier systems It is possible to mount a roof rack if your vehicle is equipped with securing rails on the roof.
Page 288 Controls in detail Transporting Warning (Continued) Observe the maximum roof loads page 630), the maximum axle load and the maximum load-bearing capacity of the roof rack. CAUTION Make sure that: the securing bolts for the roof rack are tightened to a torque of 6.0 –...
Page 289: Features
Features Interior storage compartments Warning Only load the storage compartments in such a way that occupants cannot be in- jured by their contents in the event of an accident, braking or a sudden change in direction. For this reason, do not transport heavy, bulky, pointed or sharp-edged objects in the storage spaces or compartments.
Page 290 Controls in detail Features CAUTION The entire storage compartment is permitted to hold a maximum load of 66 lbs (30 kg). Do not store high, bulky loads in the storage compartment. You could oth- erwise damage the roof trim in the event of sudden braking.
Page 291 To open: pull glove box handle 1 in the direction of the arrow. 4 Cards holder 5 Pen holder To close: fold the cover upwards and push against it until it engages in place. Storage compartments on the dash- board Example on the right-hand side Controls in detail Features...
Page 292 Controls in detail Features Covered storage compartment above the center console* 1 Cover 2 Release handle Pull release handle 2 . Cover 1 swings upwards. The cover on the storage compart- ment must remain closed while the vehicle is in motion. Close cover 1 and engage it.
Page 293 To open: press cover 1 of the eye- glasses compartment. The eyeglasses compartment folds out. To close: press cover 1 of the eye- glasses compartment into the over- head control panel until it engages. Folding table in the backrest* 1 Folding table Pull folding table 1 forward by the tab.
Page 294 Controls in detail Features CAUTION Do not use the recesses of the cup holders as an ashtray. You could oth- erwise damage the cup holders. Cup holders in the front Example on the right-hand side 1 Cup holder in the storage compartment in the dashboard Example on the right-hand side 2 Bottle holder in the front door...
Page 295 Vehicles with the non-smoking pack- age are equipped with an additional cup holder in place of the ashtray. You can change the diameter of the cup holder. Place the container in cup holder 5 . Press clamping arm 6 onto the con- tainer.
Page 296 Controls in detail Features Ashtray Warning Switch off the engine and apply the hand- brake before removing the ashtray to empty it. Otherwise, you could accidentally put the vehicle in gear. The ashtray is located in the ashtray compartment in the center console. 1 Ashtray compartment 2 Recess 3 Cover...
Page 297 Ashtray in the passenger compart- ment* The ashtrays are located on the right- hand and left-hand side in the side trims. 1 Retaining clip To open: open the ashtray. To remove the insert: press clip 1 down and remove the entire ashtray from the trim.
Page 298 Controls in detail Features Warning Only hold the hot cigarette lighter by its knob. Otherwise, you may burn yourself. Remove the cigarette lighter if children are traveling with you. They could injure themselves on a hot cigarette lighter or start a fire. Switch on the ignition ( page 111).
Page 299 12 V socket The 12 V sockets for accessories are on the bottom of the center console (12 V, 25 A) on the inside of the driver's seat base (12 V, 15 A) in the corner trim next to each rear door in the passenger compartment (12 V, 15 A) in the load compartment next to the...
Page 300 Controls in detail Features The sockets are supplied with power even if the key is removed from the ignition lock. Please note that the battery may be discharged if you have connected an accessory, e.g. a coolbox, and the engine is switched off.
Page 301 The installation of the antenna must be approved by a qualified specialist work- shop. Always have maintenance work carried out at a qualified specialist workshop, e.g. an authorized Sprinter Dealer. Warning Only use the telephone when road, weath- er and traffic conditions permit you to do so.
Page 303: Operation
Operation Operation The first 1000 miles (1500 km)... 302 Driving tips... 303 Electronic equipment... 315 Refueling... 316 Engine compartment... 318 Battery... 335 Battery isolating switch*... 338 Tires and wheels... 341 Winter driving... 404 Maintenance and servicing... 409 Cleaning and care of the vehicle... 416...
Page 304: Operation
Operation The first 1000 miles (1500 km) The first 1000 miles (1500 km) You will find detailed information about operating, maintaining and caring for your vehicle in the “Operation” section. If you treat the engine with sufficient care from the very start, it will reward you with excellent performance for a very long time afterward.
Page 305: Driving Tips
Driving tips For information about driving in winter and with snow chains, see “Winter driv- ing” ( page 404). Rail transport Transporting your vehicle by rail may be subject to certain restrictions or require special measures to be taken in some countries due to varying tunnel heights and loading standards.
Page 306 Operation Driving tips Electrical connections* The Sprinter Vehicle is available with a variety of pre-installed conditions (lines and turn signal indicator and brake mod- ule installed and/or not installed). Make sure that the correct trailer hitch receiv- er kit is used. For further information, please see your authorized Sprinter Dealer.
Page 307 CAUTION Cargo vans with a long wheelbase of 170.3 in (4325 mm) and an overall vehicle length of 289.1 in (7344 mm) have a reduced GTW and TWR. For the permissible weights and ratings, refer to the following table. The GVWR and the front/rear GAWR of your vehicle are indicated on the certification label.
Page 308 Operation Driving tips Sprinter GVWR GAWR (FA) type 8550 lbs (3878 kg) 3970 lbs (1801 kg) 2500 4080 lbs (1851 kg) 9990 lbs (4531 kg) 3500 4410 lbs (2000 kg)* 4080 lbs (1851 kg) 11030 lbs 3500 4410 lbs (5003 kg) (2000 kg)* 1 Cargo vans with a long wheelbase of 170.3 in (4325 mm) and an overall vehicle length of 289.1 in (7344 mm) only.
Page 309 Loading the vehicle and/or a trailer When loading the a trailer, you should observe that the GCWR of your vehicle is not exceeded. You must distribute total weight be- tween the vehicle and the trailer such that neither the permissible GTW, nor the GVWR and front/rear GAWR , nor the TWR are exceeded.
Page 310 Operation Driving tips Attaching a trailer Please observe the maximum permitted trailer dimensions (width and length). Most states and all Canadian provinces require safety chains between your tow vehicle and the trailer. The chains should be crisscrossed under the trailer tongue. They must be attached to the hitch re- ceiver, and not to the vehicle’s bumper or axle.
Page 311 Towing a trailer There are many different laws, including speed limit restrictions, having to do with trailer towing. Make sure that your vehicle-trailer combination will be legal, not only for where you reside, but also for where you will be driving. A good source for this information can be the police or local authorities.
Page 312 Operation Driving tips If possible, do not brake abruptly, but rather engage the brake slightly at first to permit the trailer to activate its brake. Then increase the braking force. Warning Take into consideration that when towing a trailer, the handling characteristics are different and less stable from those when operating the vehicle without a trailer.
Page 313 Operating the vehicle outside the USA or Canada If you plan to operate your vehicle in for- eign countries, please be aware that: service facilities or replacement parts may not be readily available, unleaded gasoline for vehicles with catalytic converters may not be available;...
Page 314 Operation Driving tips Warning Exceeding the permissible maximum speed can cause tire damage, which could lead to loss of control of the vehi- cle. As the driver, you must find out about the maximum speed of the vehicle and the re- sulting permissible maximum speed of the tires (tire and tire pressure).
Page 315 CAUTION To prevent damage to the catalytic converters, only use premium un- leaded gasoline in this vehicle. Any noticeable irregularities in en- gine operation should be repaired promptly. Otherwise, excessive unburned fuel may reach the catalytic converter, causing it to overheat and potentially start a fire.
Page 316 Operation Driving tips Warning As with any vehicle, do not idle, park or operate this vehicle in areas where com- bustible materials such as grass, hay, or leaves can come into contact with the hot exhaust system, as these materials could be ignited and cause a vehicle fire.
Page 317: Electronic Equipment
Electronic equipment Radio, telephone, two-way radio, fax machine and navigation system Warning Please do not forget that your primary re- sponsibility is to drive the vehicle safely. Only operate the electronic equipment when road and traffic conditions permit. Keep in mind that at a speed of just 30 mph (about 50 km/h), your vehicle travels 44 feet (about 14 m) per second.
Page 318: Refueling
Operation Refueling Refueling Warning Fuel is highly flammable. Fire, naked flames and smoking as well as the use of auxiliary heaters (sparks) are therefore prohibited when handling fuel. For this reason, switch off the auxiliary heating when refueling. Warning Do not allow fuel to come into contact with your skin or clothing.
Page 319 Remove the key from the ignition lock. Switch off the auxiliary heating. Open the driver’s door. Open the fuel filler flap. Close all the vehicle’s doors, so that no fuel vapors can enter the vehicle. Turn fuel filler cap 2 counterclock- wise and let it hang by retaining strap 1 .
Page 320: Engine Compartment
Operation Engine compartment Engine compartment Hood Warning Do not pull the release lever while the ve- hicle is in motion. The hood could other- wise open, thereby impairing visibility and leading to loss of control of the vehicle. For this reason, only open the hood when the vehicle is parked.
Page 321 N88.40-2063-31 2 Securing hook Push up securing hook lever 2 . N88.40-2062-31 3 Support strut Operation Engine compartment Warning If the hood support strut is not engaged, the hood can fall shut. You could be in- jured. After opening the hood, you should there- fore check whether the support strut is engaged.
Page 322 Operation Engine compartment Warning Engine parts may be hot and can rotate. There is a risk of injury if the hood is open and the engine is running. Only open the hood when the engine has stopped and cooled down. Warning The engine has an electronic ignition sys- tem which carries a high voltage.
Page 323 Warning Make sure that the hood is securely en- gaged before driving off. Do no continue driving if the hood can no longer engage after an accident, for example. The hood could otherwise come loose while the vehicle is in motion and endan- ger you and/or others.
Page 324 Operation Engine compartment Service products Mechanical elements and the lubricants used for them must be carefully matched. For this reason, only brands tested and approved by the manufacturer should be used. Please contact your Sprinter Deal- er to obtain the necessary information. No lubricant additives should be used.
Page 325 Check the engine oil level on a regular ba- sis, for example weekly or each time you re- fuel. If the oil level exceeds the maximum level several times during operation, have the malfunction rectified imme- diately at an authorized Sprinter Dealer.
Page 326 Operation Engine compartment Vehicles without steering wheel buttons Press the menu button on the in- strument cluster repeatedly until you see the P symbol in the display. display flashes during the --:-- measurement process. The following messages may be dis- played: Do not add oil.
Page 327 Vehicles with steering wheel buttons* Press the button on the instru- ment cluster ( page 142). The following message is displayed for the duration of the measurement process: Engine oil level Measuring in progress The following messages may be dis- played: Do not add oil.
Page 328 Operation Engine compartment Carry out another Observe measurement after wait. pe- riod approximately 5 min- utes when the en- gine is at normal operating tempera- ture. Carry out another measurement after approximately 30 minutes when the engine has cooled down. Switch off the engine Engine oil and wait for approxi-...
Page 329 Diesel engine 1 Engine oil filler neck 2 Engine oil dipstick Gasoline engine 1 Engine oil filler neck 2 Engine oil dipstick Pull out dipstick 2 . Wipe it clean with a lint-free cloth. Operation Engine compartment Insert it into the dipstick tube as far as the stop and pull it back out.
Page 330 Operation Engine compartment N18.00-2041-31 3 Engine oil dipstick Check the engine oil level. The oil level is correct if the oil is be- tween the lower min and upper max marks on the dipstick. Add engine oil if necessary page 328). Adding engine oil For specifications of engine oils see "Service products and capacities"...
Page 331 Environmental note When adding oil, take care not to spill any. No engine oil must be allowed to enter sewage systems, surface water, ground water or soil. You would otherwise be damaging the en- vironment. Dispose of engine oil in an environmental- ly responsible manner.
Page 332 Operation Engine compartment Warning When opening the coolant expansion tank there is a risk of scalding from hot coolant spraying out. The cooling system and the coolant expansion tank are pressurized when the engine is at normal operating temperature. Wear gloves and eye protection. Only open the coolant expansion tank when the coolant temperature is less than 122 °F (50 °C).
Page 333 Brake fluid The reservoir is in the engine compart- ment. Check the brake fluid level: regularly, e.g. weekly or when refuel- only with the vehicle standing on a level surface and with the engine switched off N20.30-2063-31 1 Coolant tank cap 2 Brake fluid reservoir cap 3 Windshield washer reservoir cap The brake fluid level must be between...
Page 334 Operation Engine compartment CAUTION Brake fluid corrodes paintwork. If brake fluid comes into contact with the paintwork, immediately rinse with water. If the brake fluid does not reach the MIN mark, the vehicle’s hydraulic system could be malfunctioning. Do not add brake fluid under any cir- cumstances.
Page 335 Warning If the boiling point of the brake fluid is too low, vapor pockets may form in the brake system when the brakes are applied hard (e.g. when driving on long downhill stretches). This has a detrimental effect on braking efficiency, which could in- crease the stopping distance.
Page 336 Operation Engine compartment Warning Windshield washer concentrate is highly flammable. Fire, open flames and smok- ing are prohibited when you are handling windshield washer concentrate. Adapt the mixing ratio to the outside temperature. Use: Summerwash to protect against smearing at temperatures above freezing.
Page 337: Battery
Battery Your vehicle may be equipped with two batteries, depending on the equipment version: Starter battery in the battery recess in the driver’s footwell Auxiliary battery in the engine com- partment* Warning Risk of explosion When batteries are being charged, explosive detonating gas is emitted.
Page 338 Operation Battery Warning (Continued) Keep out of the reach of chil- dren. Children cannot appreciate the dangers involved in handling batteries and acid. Wear eye protection. When mixing water and acid, the liquid can splash in your eyes. Rinse out your eyes immediately after acid splashes with clean water, and consult a doctor im- mediately.
Page 339 The batteries must always be sufficiently charged so that they achieve their in- tended service life. Have the battery charge status checked more frequently if you use the vehicle mainly for short trips or if you leave it parked up for a long period. If you intend to leave your vehicle parked up for a long period, seek advice from an authorized Sprinter Dealer and...
Page 340: Battery Isolating Switch
Operation Battery isolating switch* Battery isolating switch* You can disconnect the current to all your vehicle’s consumers using the bat- tery isolating switch. This will prevent uncontrolled battery discharge caused by quiescent current consumption. Warning If the vehicle is equipped with an auxiliary battery in the engine compartment, it is necessary to disconnect both batteries when working on the vehicle electrical...
Page 341 CAUTION Make sure that the key is in position 0 in the ignition lock and wait at least 20 seconds before dis- connecting or connecting the battery isolating switch. You could otherwise damage electrical system compo- nents. Switching off the electrical system Take the key out of the ignition lock and wait for approximately 20 seconds.
Page 342 Operation Battery isolating switch* Switching on the electrical system 1 Connector 2 Ground pin Insert the key into the ignition lock. Press connector 1 onto ground pin 2 until you feel it engage. The connector must be in full contact with ground pin 2 .
Page 343: Tires And Wheels
Tires and wheels The tires on a new vehicle provide a bal- ance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The vehicle manufacturer strongly rec- ommends using tires equivalent to the originals in size, quality and perfor- mance when a replacement becomes necessary.
Page 344 Operation Tires and wheels CAUTION Only use tires which have been test- ed and approved for your Sprinter ve- hicle by the vehicle manufacturer. Tires approved by the vehicle manu- facturer are developed to provide the best possible performance in con- junction with the driving safety sys- tems on your Sprinter vehicle such as ABS, BAS, ASR or ESP...
Page 345 Warning Do not use a tire, wheel size or rating oth- er than that specified for your Sprinter ve- hicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteris- tics, resulting in changes to steering, han- dling, and braking of your Sprinter vehicle.
Page 346 Operation Tires and wheels Warning Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage, replace them. When replacing rims, only use genuine wheel bolts approved by the vehicle man- ufacturer and specified for the particular rim type.
Page 347 For information on tire and wheel sizes with load ratings, refer to "Tire and load- ing information" ( page 303). Radial-ply tires Warning Combining radial ply tires with other types of tires on your Sprinter vehicle will change the vehicle’s handling characteris- tics and may lead to an accident resulting in death, severe personal injuries and property damage.
Page 348 Operation Tires and wheels CAUTION Vehicles not equipped with Tire Pres- sure Monitoring System (TPMS)*: For safety reasons, whenever you change a tire, you must also change the tire valve. The following tire valves from the company Schrader must be used on the vehicles not equipped with TPMS*: TR 600 for vehicle model type...
Page 349 Tire care and maintenance Warning Regularly check the tires for damage. Damaged tires can cause tire inflation pressure loss. As a result, you could lose control of your vehicle. Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage, replace them.
Page 350 Operation Tires and wheels bumps, bulges, cuts, cracks or splits in the tread or side of the tire foreign objects between the tires (on vehicles with twin tires) Replace the tire if any of the above con- ditions is found. Also inspect the spare tire periodically for condition and inflation.
Page 351 Life of tire The service life of a tire depends on vary- ing factors including but not limited to: Driving style Tire inflation pressure Distance driven Warning Tires and spare tire should be replaced af- ter 6 years, regardless of the remaining tread.
Page 352 Operation Tires and wheels Warning Although the applicable federal motor safety laws consider a tire to be worn when the Treadwear Indicators (TWI) be- come visible at approximately (1.6 mm), we recommend that you do not allow your tires to wear down to that lev- el.
Page 353 Direction of rotation An arrow on the side wall indicates the intended direction of rotation (spinning) of the tire which means the wheel must be mounted in the direction of rotation. If a tire does not have an arrow on the side wall indicating the direction of rota- tion, the wheel can be mounted either way.
Page 354 Operation Tires and wheels 1 Tire and loading information placard on driver’s door B-pillar Tire and loading information The information below explains how to work with the information contained on the tire and loading information placard with regards to loading your vehicle. The tire and loading information placard can be found on the driver’s door B-pillar.
Page 355 The GVWR includes the weight of the ve- hicle, all occupants, fuel and cargo. The GAWR is the total allowable weight that can be carried by a single axle (front or rear). The GCWR is the total allowable weight of vehicle and trailer when weighed in combination.
Page 356 Operation Tires and wheels Placard (USA Only) For vehicles with a gross weight capacity less than 10,000 lbs (4536 kg) only. The tire and loading information placard is located on the driver’s door B-pillar. Tire and loading information placard 1 Seating capacity 2 Load limit information The data shown on this placard is for illustrative purposes only.
Page 357 Load limit information Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” 2 on the tire and loading information placard. The combined weight of all occupants, cargo/luggage and trailer tongue load (if applicable) should never exceed the weight referenced in that statement.
Page 358 Operation Tires and wheels Step 4 The resulting figure equals the avail- able amount of cargo and luggage load capacity. For example, if the “XXX” amount equals 1400 lbs and there will be five 150 lbs passengers in your vehicle, the amount of avail- able cargo and luggage load capacity is 650 lbs (1400-750 (5 x150) = 650 lbs).
Page 359 Exam- Combined Number of weight limit occupants of occu- (driver and pants and passen- cargo from gers) placard 1500 lbs 1500 lbs 1500 lbs Seating Occupants' weight Combined configura- weight of all tion occupants Front: 2 Occupant 1: 150 lbs 750 lbs Occupant 2: 180 lbs Rear: 3...
Page 360 Operation Tires and wheels Certification label Even after careful determination of the combined weight of all occupants, cargo and the trailer tongue load (if applicable) as to not exceed the permissible load limit, you must make sure that your vehi- cle never exceeds the Gross Vehicle Weight Rating (GVWR) and the Gross Axle Weight Rating (GAWR) for either the...
Page 361 Gross Combination Weight Rating (GCWR): The total allowable weight of ve- hicle and trailer when weighed in comin- bation including a 150 lbs (68 kg) allowance for the presence of a driver. Vehicle Model type GVWR 8550 lbs (3878 kg) 2500 9990 lbs (4531 kg) 3500...
Page 362 Operation Tires and wheels To assure that your vehicle does not ex- ceed the maximum permissible weight limits (GVWR and GAWR for front and rear axle and GCWR), have the loaded vehicle (including driver, passengers and all cargo and, if applicable, trailer fully loaded) weighed on a suitable commer- cial scale.
Page 363 Recommended tire inflation pressure Warning Follow recommended tire inflation pres- sures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, adversely affect handling and fuel econo- my, and are more likely to fail from being overheated. Do not overinflate tires. Overinflated tires can adversely affect handling and ride comfort, wear unevenly, increase stop- ping distance, and result in sudden defla-...
Page 364 Operation Tires and wheels The tires can be considered cold if the vehicle has been parked for at least 3 hours or driven less than 1 mile (1.6 km) at an ambient temperature of approximately 68 °F (20 °C). Follow recommended cold tire inflation pressures listed on vehicle placard.
Page 365 The data shown on the tire and loa- ding information placard and on the tire inflation pressure placard is for il- lustrative purposes only. Tire data is specific to each vehicle and may vary from the data shown in the illustrati- on below.
Page 366 Operation Tires and wheels Tire temperature and tire inflation pres- sure are also increased while driving, de- pending on the driving speed and the tire load. Tire inflation pressure changes by ap- proximately 1.5 psi (0.1 bar) per 18 °F (10 °C) of air temperature change.
Page 367 Checking tire inflation pressure The tire inflation pressure should be checked regularly, i.e. at least each time you refuel the vehicle. The preferred in- terval for checking the tire inflation pres- sure, however, is before each trip. The tire inflation pressures specified ei- ther on the tire and loading information placard or on the tire inflation pressure placard on the driver’s door B-pillar are...
Page 368 Operation Tires and wheels Warning Observe the recommended tire inflation pressures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, adversely affect handling and fuel econo- my, and are more likely to fail from being overheated. Continued Warning (Continued) Do not overinflate tires.
Page 369 In addition to the placard also con- sult the tire inflation pressure table page 628). If necessary, add air to achieve the recommended tire inflation pressu- If you have overfilled the tire, release tire inflation pressure by pushing the metal stem of the valve with for ex- ample a tip of a pen.
Page 370 Operation Tires and wheels If the telltale illuminates continuous- ly, one or more of your tires is signif- icantly underinflated. There is no malfunction in the TPMS. If the telltale flashes for 60 seconds and then stays illuminated, the TPMS system itself is not operating proper- Canada only: The Tire Pressure Monitoring System...
Page 371 Warning (Continued) Always ensure that you re-calibrate the TPMS after you inflated the tires to the recommended cold inflation pressure. Always adjust tire inflation pressure ac- cording to the tire and loading information placard on the driver’s door B-pillar. Underinflated tires wear excessively and/ or unevenly, adversely affect handling and fuel economy, and are more likely to fail from being overheated.
Page 372 Operation Tires and wheels Warning (Continued) As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illumi- nates a low tire pressure telltale when one or more of your tires is significantly under- inflated.
Page 373 Warning (Continued) TPMS malfunctions may occur for a vari- ety of reasons, including the installation of incompatible replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Al- ways check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels...
Page 374 Operation Tires and wheels Warning It is the driver’s responsibility to calibrate the TPMS on the recommended cold infla- tion pressure. Underinflated tires affect the ability to steer or brake the vehicle. You might lose control over the vehicle. Make sure the tire inflation pressure of all four tires is correct, using the tire and loading information placard 1.
Page 375 Switch on the ignition ( page 111). Press the 5 menu button on the in- strument cluster until you see the message in the display. +CAL TPMS Press the , menu button on the in- strument cluster. The following message is displayed: OK TPMS The tire pressure monitor activation process has begun.
Page 376 Operation Tires and wheels If the telltale flashes for 60 seconds and then stays illuminated, the TPMS system itself is not operating proper- Canada only: The Tire Pressure Monitoring System (TPMS) is equipped with a low tire pressure telltale in the instrument cluster ( page 20).
Page 377 54.32-2278-31 When the message Tire pres. dis- played after driving for several appears in the multifunction minutes display, the individual inflation pres- sure values are matched with the tires. The individual values are dis- played after a few minutes' driving. Warning It is the driver’s responsibility to calibrate the TPMS on the recommended cold infla-...
Page 378 Operation Tires and wheels Warning The TPMS does not warn you against in- correctly selected tire inflation pressure and does not warn you when the tire pres- sure is not properly selected for the re- spective vehicle load. It warns you only when the pressure of one or more tires decreases significantly below the refer- ence inflation pressure which was stored...
Page 379 Warning Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure rec- ommended by the vehicle manufacturer on the vehicle placard or the tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or the tire inflation pressure label, you should determine the...
Page 380 Operation Tires and wheels Warning (Continued) USA only: Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately 1 minute and then re- main continuously illuminated.
Page 381 Reactivating the Advanced TPMS The TPMS must be reactivated when you have adjusted the tire inflation pressure to a new level (e.g. because of different load or driving conditions). The TPMS is then recalibrated to the current tire in- flation pressures. Warning! It is the driver’s responsibility to calibrate the TPMS on the recommended cold infla-...
Page 382 Operation Tires and wheels Press button è or ÿ on the multifunction steering wheel repeat- edly until the standard display menu appears in the multifunction display page 157). Press the j or k button re- peatedly until you see the current in- flation pressures for each tire appear in the display or the following mes- sage appears in the display...
Page 383 1. Safety Warning Follow recommended tire inflation pres- sures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, ad- versely affect handling and fuel economy, and are more likely to fail from being over- heated. Do not overinflate tires. Overinflated tires can adversely affect handling and ride com- fort, wear unevenly, increase stopping dis- tance, and result in sudden deflation...
Page 384 Operation Tires and wheels 3. Ride comfort and vehicle stability Proper tire inflation contributes to a comfortable ride. Overinflation produces a jarring and uncomfortable ride. Tire labeling Besides the tire name (sales designa- tion) and manufacturer's name, a num- ber of markings can be found on a tire. Below are some explanations regarding the markings on your vehicle’s tires: For illustrative purposes only.
Page 385 Tire size designation, load and speed rating 1 Design standard 2 Tire width 3 Aspect ratio in % 4 Radial tire code 5 Rim diameter 6 Tire load rating 7 Tire speed rating For illustrative purposes only. The ac- tual data on tires is specific to each vehicle and may vary from the data shown in the above illustration.
Page 386 Operation Tires and wheels Tire width The tire width 2 indicates the nominal tire width in mm. Aspect ratio The aspect ratio 3 is the dimensional relationship between tire section height and section width and is expressed in percentage. The aspect ratio is arrived at by dividing section height by section width.
Page 387 The commercial vehicle tires based on European standards may have an addi- tional value in the parentheses (as illus- trated). In such cases, the value preceding the parentheses is valid for European countries and the parenthe- sized for the USA and Canada. Refer also to "Maximum tire load"...
Page 388 Operation Tires and wheels Tire speed rating The tire speed rating 6 indicates the approved maximum speed for the tire. The commercial vehicle tires based on European standards may have an addi- tional index in the parentheses. In such cases, the index preceding the paren- theses is valid for European countries and the parenthesized for the USA and Canada.
Page 389 Index Speed rating up to 50 mph (80 km/h) up to 56 mph (90 km/h) up to 62 mph (100 km/h) up to 68 mph (110 km/h) up to 74 mph (120 km/h) up to 80 mph (130 km/h) up to 87 mph (140 km/h) up to 93 mph (150 km/h) up to 100 mph (160 km/h) up to 106 mph (170 km/h)
Page 390 Operation Tires and wheels 1 DOT 2 Manufacturer’s identification mark 3 Tire size 4 Tire type code (tire manufacturer's op- tion) 5 Date of manufacture For illustrative purposes only. The ac- tual data on tires is specific to each vehicle and may vary from the data shown in the above illustration.
Page 391 DOT (Department Of Transportation) A tire branding symbol 1 which de- notes the tire meets requirements of the U.S. Department of Transportation. Manufacturer’s identification mark The manufacturer’s identification mark 2 denotes the tire manufacturer. New tires have a mark with two symbols. Retreaded tires have a mark with four symbols.
Page 392 Operation Tires and wheels Warning Tires and spare tire should be re- placed after 6 years, regardless of the remaining tread. Maximum tire load 1 Maximum tire load rating For illustrative purposes only. The ac- tual data on tires is specific to each vehicle and may vary from the data shown in the above illustration.
Page 393 Warning Do not overload the tires by exceeding the specified load limit as indicated on the tire and loading information placard on the driver’s door B-pillar. Overloading the tires can overheat them, possibly causing a blowout. Overloading the tires can also result in handling or steering problems, or brake failure.
Page 394 Operation Tires and wheels For illustrative purposes only. The ac- tual data on tires is specific to each vehicle and may vary from the data shown in the above illustration. This is the maximum permissible tire in- flation pressure for the tire. Always follow the recommended tire in- flation pressure ( page 361) for proper...
Page 395 Tire ply material 1 Plies in side wall 2 Plies under tread For illustrative purposes only. The actual data on tires is specific to each vehicle and may vary from the data shown in the above illustration. This marking tells you about the type of cord and number of plies in the side wall and under the tread.
Page 396 Operation Tires and wheels Air pressure The amount of air inside the tire pressing outward on each square inch of the tire. Air pressure is expressed in pounds per square inch (psi), or kilopascal (kPa) or bars. Aspect ratio Dimensional relationship between the tire section height and the section width expressed in percentage.
Page 397 GAWR (Gross Axle Weight Rating) The GAWR is the maximum permissible axle weight. The gross vehicle weight on each axle must never exceed the GAWR for the front and rear axle indicated on the certification label located below the driver’s seat on the mounting pillar. GCWR (Gross Combination Weight Rating) The GCWR is the total permissible...
Page 398 Operation Tires and wheels GVWR (Gross Vehicle Weight Rating) This is the maximum permissible vehicle weight of the fully loaded vehicle (weight of the vehicle including all options, pas- sengers, fuel, and cargo and, if applica- ble, trailer tongue load). It is indicated on the certification label located below the driver’s seat on the mounting pillar.
Page 399 Production options weight The combined weight of those installed regular production options weighing over 5 lbs (2.3 kg) in excess of those standard items which they replace, not previously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim.
Page 400 Operation Tires and wheels Tire load rating Numerical code associated with the maximum load a tire can support. Tire ply composition and material used This indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and side wall. Tire man- ufacturers also must indicate the ply ma- terials in the tire and side wall, which include steel, nylon, polyester, and oth-...
Page 401 Uniform tire quality grading stan- dards A tire information system that provides consumers with ratings for a tire’s trac- tion, temperature and treadwear. Rat- ings are determined by tire manufacturers using government test- ing procedures. The ratings are molded into the side wall of the tire. Vehicle capacity weight Rated cargo and luggage load plus 68 kg (150 lbs) times the vehicle’s designated...
Page 402 Operation Tires and wheels Warning (Continued) could result in changes to steering, han- dling, and braking of your Sprinter vehicle. This can cause unpredictable handling and stress to steering and suspension components. You could lose control and have an accident resulting in serious inju- ry or death.
Page 403 Rotate tires before the characteristic tire wear pattern becomes visible (shoul- der wear on front tires and tread center wear on rear tires). The reasons for any rapid or unusual wear should be corrected prior to rota- tion being performed. CAUTION If your vehicle is equipped with the tire pressure monitor*, each wheel...
Page 404 Operation Tires and wheels Warning (Continued) If a wheel hub thread is damaged, you must not drive the vehicle. Consult an au- thorized Sprinter Dealer. Only use genuine wheel bolts approved by the vehicle manufacturer and specified for your vehicle’s rims. Check tightness of wheel bolts or nuts regularly and retight- en with a torque wrench, if necessary.
Page 405 Make sure that on one axle just one type of tire (same size, type con- struction, load and speed rating) is used. Dual rear wheels: Rotate front tires by axle and the out- er rear tire side to side if there is no approved direction of rotation.
Page 406: Winter Driving
Operation Winter driving Winter driving Have your vehicle winterproofed at the onset of winter at an authorized Sprinter Dealer. This service includes the follow- ing: Oil change, if the current engine oil used has not been approved for win- ter use The antifreeze/anti-corrosion con- centration in the coolant is checked The addition of a concentrated...
Page 407 For safe handling, make sure all winter tires mounted are of the same make and have the same tread design. Warning Winter tires with a tread depth under 1/6 in (4 mm) must be replaced. They are no longer suitable for winter operation. Always observe the speed rating of the winter tires installed on your vehicle.
Page 408 Operation Winter driving When they have been removed, store wheels and tires in a cool, dry, and if possible dark place. Protect the tires from oil, grease, and gasoline/ diesel. Driving in winter Warning Downshifting to brake could cause the drive wheels to lose grip on a slippery sur- face due to the increased difference in speed between the engine and the drive...
Page 409 Apply the brakes regularly when making longer journeys on gritted or salted roads. This will have the effect of restor- ing the brakes to their normal level of performance. When stopping the vehicle after travel- ing on roads that have been salted, check that the brakes are fully functional before proceeding further.
Page 410 Operation Winter driving Please observe the following guidelines when using snow chains: Snow chains should only be used on rear wheels. In vehicles with dual rear wheels, they should be mounted on the exterior wheels. Follow the manufacturer’s mounting instruc- tions.
Page 411: Maintenance And Servicing
Maintenance and servicing Warning Before carrying out maintenance opera- tions and repairs, please make sure that you read the relevant sections of the tech- nical documentation, such as: Operating instructions and workshop in- formation Familiarize yourself in advance in particu- lar with legal requirements, such as: Safety at work and accident prevention regulations.
Page 412 Operation Maintenance and servicing Warning (Continued) The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose. In particular, work relevant to safety or on safety-related systems must be carried out at an authorized Sprinter Dealer. Service products Mechanical elements and the lubricants used for them must be carefully matched.
Page 413 Active Service System (ASSYST)* ASSYST, the Active Service System, in- forms you when the next service is due. A service that is due is displayed about a month or 1900 miles (3000 km) in ad- vance. A message is then displayed while the vehicle is in motion or the igni- tion is switched on.
Page 414 Operation Maintenance and servicing Service due date display Vehicles with steering wheel buttons The following messages may be dis- played: Service A in .. days Service A in .. miles Service A due now The letters indicate the type of ser- vice that is due.
Page 415 Vehicles with steering wheel buttons* If you have missed the service due date, one of the following messages appears in the display: Service A overdue by .. days Service A overdue by .. miles A signal also sounds. Vehicles without steering wheel but- tons If you have missed the service due date, the following symbol flashes in the dis-...
Page 416 Operation Maintenance and servicing Vehicles without steering wheel but- tons Press the menu button on the in- strument cluster repeatedly until you see the following in the display: 9 for service A ´ for service B The following are also shown: the remaining distance in miles (kilometers) the remaining time in days...
Page 417 Removing the air cleaner element Carefully pry cover 1 out of recesses 2 and remove it. Remove the filter mat. Cleaning the filter mat Wash the filter mat with clean water. Leave the filter mat to dry. CAUTION The filter mat must not be cleaned or dried in a machine.
Page 418: Cleaning And Care Of The Vehicle
Operation Cleaning and care of the vehicle Cleaning and care of the vehicle Regular and proper care will help to maintain the value of your vehicle. The best way to protect your vehicle from harmful environmental influences is to wash it and use protective treatments regularly.
Page 419 Environmental note Only clean the vehicle in a suitable place for washing vehicles. Dispose of empty containers and used cleaning materials in an environmentally responsible manner. If you need to clean the areas to- wards the top of the vehicle, always suitable ladders secure steps CAUTION...
Page 420 Operation Cleaning and care of the vehicle Automatic car wash You can clean the vehicle in an automat- ic car wash from the very start. It is pref- erable to use a car wash that does not have brushes. If the vehicle is very dirty, prewash it be- fore you drive into the car wash.
Page 421 After using an automatic car wash, wipe off wax from the windshield and the wip- er blades. This prevents smears and re- duces wiping noises which can be caused by residue on the windshield. High-pressure cleaners CAUTION Do not use high-pressure cleaners with round-spray jets for cleaning the tires.
Page 422 Operation Cleaning and care of the vehicle Steps Warning Dirty or iced-up steps and entrances cre- ate a risk of slipping or falling. Keep steps, entrances and footwear free from dirt (e.g. mud, clay, snow and ice). Engine cleaning CAUTION Do not allow water to enter the in- take and ventilation openings.
Page 423 Outside of windshield and wiper blades Turn key to position 1 in ignition lock page 111). Switch on windshield wipers page 210). When the wiper arms are vertical, turn key to position 0 in the ignition lock or remove the key. CAUTION Do not fold the windshield wipers away from the windshield unless the...
Page 424 Operation Cleaning and care of the vehicle Headlamps Wipe the headlamp lenses with a damp sponge. CAUTION Only use washer fluid which is suit- able for plastic lamp lenses. Unsuitable washer fluid may damage the plastic headlamp lenses. For this reason, do not use a dry cloth, abrasive material, solvent or solvent-based cleaning agent.
Page 425 Rear view camera Camera lens Microphone openings Clean the camera lens 1 using wa- ter and a soft cloth only. Be careful not to apply wax to the cam- era lens 1 when waxing the vehicle. If necessary, remove the wax using sham- poo with plenty of water.
Page 426 Operation Cleaning and care of the vehicle CAUTION Use a low-foaming grease solvent (e.g. washing-up liquid) diluted in wa- ter as a cleaning agent. The surface color may temporarily change shade during cleaning. Sim- ply wait for the surface to dry. Heavy soiling Wipe plastic parts with a damp, lint- free cloth (e.g.
Page 427 Clean the display surface with a commercially-available microfiber cloth and cleaner for TFT/LCD dis- plays. After drying, wipe the display surface with a dry microfiber cloth using only slight pressure. CAUTION Do not use dry, coarse or hard cloths, abrasive material, solvent or solvent- based cleaning agent.
Page 428 Operation Cleaning and care of the vehicle Warning (Continued) Risk of skidding Dirt and mud on the tires/road surface reduce wheel grip. This is especially so if the road surface is wet. The vehicle could then start to skid. Risk of slipping Dirt and mud on the steps and entrances make the steps less safe.
Page 429 Warning (Continued) The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose. In particular, work relevant to safety or on safety-related systems must be carried out at an authorized Sprinter Dealer. After driving in mud, sand, water or sim- ilar conditions: Check the brake system for operat- ing safety.
Page 431: Practical Hints
Practical hints Practical hints What to do if ... 430 Display messages... 484 Where will I find...?... 513 Changing bulbs... 525 Changing the batteries... 539 Fuel system... 542 Replacing the wiper blades... 545 Flat tire... 547 Battery... 573 Jump-starting... 581 Towing...
Page 432: Practical Hints
Practical hints What to do if ... Audible warning signals Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired.
Page 433 Problem The anti-theft alarm system is suddenly trig- gered. You hear a warning signal. Possible cause/result You have opened the vehicle using the key while the anti-theft alarm system was still primed. A message appears in the display. You are driving with the handbrake applied. You opened the driver’s door and forgot to switch off the lights.
Page 434 Practical hints What to do if ... Accident Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 435 Problem Fuel is leaking from the vehicle. You are unable to determine the extent of the damage. You are unable to determine any damage to: the major components the fuel system the engine support Possible cause/result Risk of fire and explosion The fuel line or fuel tank is malfunctioning.
Page 436 Practical hints What to do if ... Fuel and fuel tank Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 437 Problem The fuel tank has been run dry and the vehicle has a diesel engine. Fuel is leaking from the vehicle. Possible cause/result There is air in the fuel system. Risk of fire and explosion The fuel line or fuel tank is malfunctioning. There is a risk of fire and explosion from leaking fuel.
Page 438 Practical hints What to do if ... Engine Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 439 Problem The engine does not start. You can hear the starter motor working. Vehicles with a diesel engine: The engine does not start. You can hear the starter motor working. The reserve fuel warning lamp is lit and the fuel gauge is at 0.
Page 440 Practical hints What to do if ... Problem The engine does not start. You cannot hear the starter motor working. Vehicles with a gasoline engine: The engine is not running smoothly and it is misfiring. Possible cause/result The on-board voltage is too low (the battery has too little charge or is discharged).
Page 441 Problem The coolant temperature gauge is above 250 °F (+120 °C). Possible cause/result The coolant is too hot and the engine is not be- ing sufficiently cooled. Practical hints What to do if ... Suggested solutions Park your vehicle in a safe location as quickly as possible and let the engine continue to run at idle speed for about 1 to 2 minutes before switching it off.
Page 442 Practical hints What to do if ... Automatic transmission Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 443 Problem The transmission no longer changes gear cor- rectly. The acceleration ability is deteriorating. The transmission does not shift. Possible cause/result The transmission is losing oil. The transmission is in emergency mode. It is only possible to shift into second gear or re- verse gear.
Page 444 Practical hints What to do if ... Headlamps and turn signals Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Problem The headlamps are fogged up on the inside. Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work required.
Page 445 Windshield wipers Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 446 Practical hints What to do if ... Problem The windshield wipers are jammed. The windshield wipers have stopped working completely. Possible cause/result Leaves or snow, for example, are hindering the movement of the windshield wipers. The wiper motor has switched off. The windshield wiper drive has malfunctioned.
Page 447 Remote control Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 448 Practical hints What to do if ... Problem It is no longer possible to lock the vehicle us- ing the remote control. The turn signals do not flash when the vehicle is locked. Possible cause/result The doors are not closed properly. The central locking system has malfunctioned.
Page 449 Problem It is no longer possible to lock or unlock the vehicle using the remote control. Possible cause/result The remote control batteries are weak or dis- charged. The remote control is malfunctioning. Practical hints What to do if ... Suggested solutions Point the remote control towards the driver’s door handle at close range and try again.
Page 450 Practical hints What to do if ... Problem The battery check lamp on the remote control does not light up briefly when a button is pressed. You have lost a remote control. Possible cause/result The remote control batteries are discharged. Suggested solutions Change the batteries ( page 540).
Page 451 Problem The key can no longer be turned in the ignition lock. Possible cause/result The on-board voltage is too low. Practical hints What to do if ... Suggested solutions Remove the key and re-insert it into the ignition lock. Switch off all non-essential consumers, for example the seat heating, interior lighting, and try to turn the key again.
Page 452 Practical hints What to do if ... Driving systems Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 453 Problem Only the red segments in the Parktronic* warning displays are lit. A warning tone also sounds for approximate- ly 2 seconds. Parktronic* switches off after approximately 20 seconds. The indicator lamp on the Parktronic switch comes on and the red segments in the warn- ing display go out.
Page 454 Practical hints What to do if ... Problem The Parktronic* warning displays indicate im- plausible distances. For example, all the segments may be lit even though there is no obstacle present. The speed cannot be set with cruise control* activated 1 Only on vehicles with steering wheel buttons.
Page 455 Auxiliary heating* Warning Always have maintenance work carried out at an authorized Sprinter Dealer which has the necessary specialist knowledge and tools to carry out the work required. Continued Warning (Continued) The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 456 Practical hints What to do if ... Problem The battery check lamp on the remote control for the auxiliary heating does not light up briefly when a button is pressed. The auxiliary heating does not switch on or the engine does not start. Possible cause/result The remote control batteries are discharged.
Page 457 Problem The auxiliary heating does not switch on or the engine does not start The heater has overheated. Possible cause/result WARNING The auxiliary heating has overheated about ten times in succession. The engine or heater is malfunctioning. The coolant level is too low. Practical hints What to do if ...
Page 458 Practical hints What to do if ... Leaving the vehicle in storage Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Problem You wish to leave your vehicle in storage for a long period of time (longer than six weeks). Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work required.
Page 459 Indicator and warning lamps in switches Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 460 Practical hints What to do if ... Problem One or both of the indicator lamps in the switch for the seat heating flashing. The indicator lamps in the switches for the windshield heating P* and/or rear win- dow heating F* are flashing. Possible cause/result There is insufficient voltage available as * are...
Page 461 Problem The residual engine heat utilization function switches off too soon or cannot be switched on. The indicator lamp in the ° switch does not light up. Possible cause/result There is insufficient voltage available as too many consumers are switched on. Practical hints What to do if ...
Page 462 Practical hints What to do if ... Indicator and warning lamps in the instrument cluster Warning Always have maintenance work carried out at an authorized Sprinter Dealer Continued Warning (Continued) which has the necessary specialist knowl- edge and tools to carry out the work re- quired.
Page 463 Problem ® The yellow ASR/ESP warning lamp flashes while the vehicle is in motion. ® The yellow ASR/ESP warning lamp is lit while the engine is run- ning. Possible cause/result WARNING ® or ASR is intervening because at least one of the wheels has reached its tire grip limit.
Page 464 Practical hints What to do if ... Problem ® The yellow ESP , ABS-, ASR/BAS indicator lamps and the red brake system indicator lamp are lit while the engine is running. ® The yellow ESP , ABS, ASR/BAS indicator lamps and the red brake system indicator lamp are lit while the engine is running.
Page 465 Problem The red brake system indicator lamp is lit while the engine is run- ning. A signal also sounds. Possible cause/result WARNING There is insufficient brake fluid in the fluid res- ervoir. Practical hints What to do if ... Suggested solutions Also observe the messages in the dis- play on vehicles with steering wheel buttons (...
Page 466 Practical hints What to do if ... Problem When towing a trailer: The red brake system indicator lamp is lit while the engine is run- ning. A signal also sounds. Possible cause/result WARNING The trailer's brake booster is malfunctioning. The vehicle's driving and braking characteris- tics may change.
Page 467 Problem The yellow ASR/BAS indica- tor lamp is lit while the en- gine is running. Possible cause/result WARNING ASR has been deactivated due to a malfunction. The engine power output may then be lower. WARNING BAS has been deactivated due to a malfunction. The brake system continues to function with the nor- mal braking effect but with no electronic support.
Page 468 Practical hints What to do if ... Problem The yellow ABS indicator lamp is lit while the engine is running. Possible cause/result WARNING ABS has been deactivated due to a malfunction. ® , ASR and BAS as well as cruise control have also been deactivated as a result.
Page 469 Problem Possible cause/result ABS has been deactivated due to undervoltage. The battery may not be being charged. The brake system continues to function with the nor- mal braking effect but with no electronic support. The wheels could therefore lock up, for example if the brakes are applied with maximum force.
Page 470 Practical hints What to do if ... Problem ® The yellow ESP indicator lamp is lit while the engine is running. Possible cause/result WARNING ® has been deactivated due to a malfunction. Cruise control is also switched off as a result. Vehicle stability is no longer automatically controlled in good time.
Page 471 Problem The red SRS warning lamp does not go out after ap- proximately 4 seconds after the ignition system is switched on or lights up again. The red battery charge warning lamp lights up while the engine is running. Possible cause/result WARNING The restraint systems have malfunctioned.
Page 472 Practical hints What to do if ... Problem The yellow brake pad wear indicator lamp lights up after the engine is started or while the vehicle is in mo- tion. Possible cause/result The battery is malfunctioning. WARNING The brake pads/linings have reached their wear lim- Suggested solutions Stop your vehicle as soon as it is safe to do so.
Page 473 Problem The yellow engine oil level warning lamp flashes after the engine is started or while the vehicle is in mo- tion. Possible cause/result The engine oil level has dropped to the minimum lev- el. If the engine oil level falls any further, the indica- tor lamp will light up continuously.
Page 474 Practical hints What to do if ... Problem The yellow engine oil level warning lamp lights up, the - 2.0 l engine oil level mes- sage appears in the display and the warning buzzer sounds after the engine is started or while the vehicle is in motion.
Page 475 Problem The yellow engine oil level warning lamp lights up, the HI engine oil level message appears in the display and the warning buzzer sounds after the engine is started or while the vehicle is in mo- tion. The yellow engine oil level warning lamp lights up re- peatedly while the vehicle is in motion.
Page 476 Practical hints What to do if ... Problem The yellow coolant level warning lamp lights up while the engine is running. Possible cause/result The coolant level is too low. Never run the engine if the coolant level is too low. The engine could overheat and be damaged.
Page 477 Problem • The red coolant warning lamp lights up while the en- gine is running. The yellow reserve fuel warning lamp lights up while the vehicle is in motion. Possible cause/result The coolant temperature is too high. The fuel level has fallen into the reserve range. Practical hints What to do if ...
Page 478 Practical hints What to do if ... Problem The yellow reserve fuel warning lamp lights up while the engine is running and the gauge for the fuel tank shows zero although there is still fuel in the tank. The yellow preglow indicator lamp lights up while the en- gine is running.
Page 479 Problem ± The yellow engine diagnostic indicator lamp lights up or flashes while the engine is running. ‰ The yellow air cleaner indica- tor lamp lights up while the ignition is on. 1 Only vehicles with a gasoline engine. 2 Only vehicles with a diesel engine. Possible cause/result The fuel tank has run dry.
Page 480 Practical hints What to do if ... Problem USA only: Combination low tire pressure/ TPMS malfunction telltale for TPMS lights up continuously. Canada only: Low tire pressure telltale for TPMS lights up continuously. Possible cause/result WARNING The TPMS detects a loss of pressure in at least one tire.
Page 481 USA only: Combination low tire pressure/ TPMS malfunction telltale for TPMS flashes 60 seconds and then stays illuminated. There is a malfunction in the TPMS. Practical hints What to do if ... Read and observe messages in the mul- tifunction display. Have the TPMS checked at an autho- rized Sprinter Dealer as soon as possi- ble.
Page 482 Practical hints What to do if ... Warning! Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure rec- ommended by the vehicle manufacturer on the vehicle placard or the tire inflation pressure label.
Page 483 Warning (Continued) USA only: Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately 1 minute and then remain continuously illuminated.
Page 484 Practical hints What to do if ... Problem The yellow water separator indi- cator lamp lights up while the ig- nition is on. The yellow washer fluid level indi- cator lamp for the windshield washer/headlamp cleaning sys- tem lights up after the engine is started or while the vehicle is in motion.
Page 485 The yellow bulb indicator lamp lights up while the ignition is on. The yellow “door open” indicator lamp lights up while the vehicle is in motion. 1 Only vehicles with a diesel engine. One of the bulbs of the exterior lighting or on the trailer is malfunctioning.
Page 486: Display Messages
Practical hints Display messages All warning/indicator lamps (except the turn signal indicator lamps) and the display are activated when the ig- nition is switched on. Please check that they are working properly before commencing a jour- ney. Display messages on vehicles without steering wheel buttons Warnings, malfunctions or additional in- formation may also be shown in the dis-...
Page 487 Warning (Continued) Contact an authorized Sprinter Dealer im- mediately which has the necessary spe- cialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose. In particular, work relevant to safety or on safety-related systems must be carried out at an authorized Sprinter Dealer.
Page 488 Practical hints Display messages Display messages Possible cause/result There is insufficient or no oil in the engine. There is a risk of engine damage. Possible solution Stop your vehicle as soon as it is safe to do so. Switch off the engine. Check the engine oil level using the dipstick ( page 326).
Page 489 Display messages The message is displayed for 30 seconds. TPMS The message is also displayed after 30 seconds. Possible cause/result The TPMS is malfunctioning. The tire pressure monitor is not receiving sig- nals from one or more wheels because: a wheel was replaced with the spare wheel, which is not equipped with a wheel electronics unit the maximum temperature in one of the...
Page 490 Practical hints Display messages Display messages — — The message is displayed for 30 seconds. TPMS The message is also displayed after 30 seconds. Possible cause/result The tire pressure monitor detects a moderate loss of pressure in at least one of the tires, or the difference in pressure on one axle is too great.
Page 491 Display messages on vehicles with steering wheel buttons The operating system shows warnings, malfunctions or additional information in the display. Certain messages are accompanied by a warning signal or a permanent tone. High-priority messages are highlighted in red in the display. Please respond in accordance with the messages and follow the additional notes in these Operating instructions.
Page 492 Practical hints Display messages Warning (Continued) Contact an authorized Sprinter Dealer im- mediately which has the necessary spe- cialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose.
Page 493 Text messages Display messages Visit workshop unavailable Possible cause/result WARNING ABS has been deactivated due to a malfunction. ® , ASR and BAS as well as cruise control have also been deactivated as a result. The brake system is still available with the full brake boosting effect but without ABS.
Page 494 Practical hints Display messages Display messages Possible cause/result ABS has been deactivated due to undervoltage. The battery may not be being charged. The brake system is still available with the normal braking effect. Possible solution Continue driving, but with even greater care.
Page 495 Display messages Possible cause/result Visit workshop WARNING Cruise control is also switched off as a result. Vehicle stability is no longer automatically con- trolled in good time. Engine power output may be reduced. Cruise control is also switched off as a result. unavailable The battery may not be being charged.
Page 496 Practical hints Display messages Display messages Tire pres. Adjust pres. Tire pres. monitor inoperative Tire pres. displayed after driving several minutes Possible cause/result The pressure is too low in one or more tires. The TPMS is malfunctioning. The tire inflation pressure is being checked. Possible solution Check and correct tire inflation pressure as required.
Page 497 Display messages Possible cause/result The TPMS or Advanced TPMS* is unable to moni- Tire pres. monitor tor the tire pressure due to currently unavailable There are wheels without appropriate wheel sen- Tire pres. monitor sors mounted (for example winter tires). inoperative No wheel sensors...
Page 498 Practical hints Display messages Display messages Slid. sunroof open Cruise cont. Visit workshop Restraint system Visit workshop Possible cause/result You have the removed the key from the ignition lock and the sliding sunroof is still open. Cruise control is malfunctioning. WARNING The restraint systems have malfunctioned.
Page 499 Symbol messages Display symbol Display message Battery/ Alternator Visit workshop Brake wear Visit workshop Possible cause/result The battery is not being charged. Possible causes: malfunctioning alternator torn poly-V-belt WARNING The brake pads/linings have reached their wear limit. Practical hints Display messages Possible solution Stop immediately and check the poly-V- belt.
Page 500 Practical hints Display messages Display symbol Display message Brake force distribution Brake fluid Visit workshop Possible cause/result WARNING EBV has been deactivated due to undervolt- age. The battery may not be being charged. The rear wheels could lock up sooner than expected when you apply the brakes.
Page 501 Display symbol Display message Brake force distribution Visit workshop Parking brake Release brake A signal also sounds. Possible cause/result WARNING EBV has malfunctioned. The rear wheels could lock up sooner than expected when you apply the brakes. You are driving with the handbrake applied. Practical hints Display messages Possible solution...
Page 502 Practical hints Display messages Display symbol Display message Visit workshop Possible cause/result WARNING ASR has been deactivated due to a malfunc- tion. Cruise control is also switched off as a result. The engine power output may then be lower. WARNING BAS has been deactivated due to a malfunc- tion.
Page 503 Display symbol Display message unavailable Please enter PIN: You have not yet entered your details in the ì < Seatbelt sys. Visit workshop Possible cause/result ASR as well as BAS have been switched off due to undervoltage. The battery may not be being charged. The brake system is still available with the normal braking effect.
Page 504 Practical hints Display messages Display symbol Display message Coolant Stop, turn engine Coolant Check level Possible cause/result The coolant temperature is too high. The coolant level is too low. Never run the engine if the coolant level is too low. The engine could overheat and be damaged.
Page 505 Display symbol Display message Low beam left Low beam right Turn signal left Turn signal right The right-hand turn signal is malfunctioning. Brake lamp left Brake lamp right Third brake lamp High beam left Possible cause/result The left-hand low-beam headlamp is mal- functioning.
Page 506 Practical hints Display messages Display symbol Display message High beam right License plate lamp Foglamp front left Foglamp front right Rear foglamp Parking lamp front left Parking lamp front right Reverse lamp Possible cause/result The right-hand high-beam headlamp is mal- functioning.
Page 507 Display symbol Display message Tail lamp left Tail lamp right Perim. lamps Additional ind. lamps Cornering lamp left Cornering lamp right Trailer turn sig- nal left Trailer turn sig- nal right Possible cause/result The left-hand tail lamp is malfunctioning. The right-hand tail lamp is malfunctioning. A perimeter lamp is malfunctioning.
Page 508 Practical hints Display messages Display symbol Display message Trailer tail lamp A trailer tail lamp or license plate lamp is Switch off lights You have forgotten to switch off the lights Lights on auto- matic. Remove key Replace key Visit workshop Possible cause/result malfunctioning.
Page 509 Display symbol Display message Warning Tire defect Check tire(s) Possible cause/result One or more tires are deflating. The respective tire is shown in the multifunc- tion display. The tire pressure in one or more tires is al- ready below the minimum value. The respective tire is shown in the multifunc- tion display.
Page 510 Practical hints Display messages Display symbol Display message Engine oil level Stop, turn engine Possible cause/result There is insufficient or no oil in the engine. There is a risk of engine damage. Possible solution Stop your vehicle as soon as it is safe to do Switch off the engine.
Page 511 Display symbol Display message Engine oil level Check oil level Engine oil 1.0 quart (Canada: liter Possible cause/result The engine oil level has dropped to a critical level. The engine oil level is too low. Practical hints Display messages Possible solution Check the engine oil level ( page 323) and add oil as necessary.
Page 512 Practical hints Display messages Display symbol Display message Engine oil level Reduce oil level Oil sensor Visit workshop Engine oil level Not when eng. running Possible cause/result You have added too much engine oil. There is a risk of damage to the engine or the cat- alytic converter.
Page 513 Display symbol Display message Reserve fuel Drive to a gas station Tank open Check filler cap Doors open Hood open Possible cause/result The fuel level has fallen into the reserve range. The fuel filler cap is not closed. You are already driving at walking pace, even though not all the doors are closed.
Page 514 Practical hints Display messages Display symbol Display message Water in Fuel Visit workshop Washer fluid Check level Possible cause/result The water that has collected in the water separator has reached the maximum level. The washer fluid level has dropped to ap- proximately of the reservoir capacity.
Page 515: Where Will I Find
Warning triangle* The warning triangles are behind the driver's seat. N72.10-2148-31 1 Warning triangles Remove warning triangles 1 from the brackets upward. Road hazard lamp* The road hazard lamp is located in the storage compartment in the driver’s door. 1 Locked 2 Unlocked Practical hints Where will I find...?
Page 516 Practical hints Where will I find...? Fire extinguisher* The fire extinguisher is secured to the front of the passenger’s seat base. 1 Fire extinguisher 2 Tabs Pull tabs 2 upward. Take fire extinguisher 1 out of the bracket. Read the instructions on the fire ex- tinguisher carefully and familiarize yourself with its operation.
Page 517 3 First-aid kit Check the expiry dates of the first- aid kit materials every year, and re- place them if necessary. Jack and vehicle tool kit The jack and the vehicle tool kit are lo- cated under the hatch in the passen- ger’s footwell.
Page 518 Practical hints Where will I find...? Warning (Continued) Do not crawl under the vehicle if it is only supported by the jack. Make sure that no persons are present in the vehicle when raising the vehicle. Do not start the engine while the vehicle is raised.
Page 519 Remove jack 4 upward out of the retainer. Place the jack into the retainer as shown when storing it back into place. Make sure that the jack’s re- taining strap is hooked in and ten- sioned. Spare wheel If you are replacing the tires on the vehi- cle, you may use the spare wheel as a road wheel provided that: the tires are no more than 6 years...
Page 520 Practical hints Where will I find...? Open the rear doors ( page 100). Insert a screwdriver into recesses 2 and pry off covers 1 . Using the wheel wrench from the ve- hicle tool kit ( page 515), now un- screw the visible bolts approximately 20 turns counterclockwise.
Page 521 Use the pump lever to raise the spare wheel beyond the rear end of the spare wheel bracket. Carefully remove the spare wheel from the bracket. Warning Take care not to trap your fingers when you lift out the spare wheel. Practical hints Where will I find...? Chassis...
Page 522 Practical hints Where will I find...? Loosen thumb nuts 3 by hand and remove. Loosen fixing nuts 2 to the thread end. Raise spare wheel bracket 4 slight- ly and release left securing hook 1 . Slide th pump lever for the jack into sleeve on the right-hand side of the spare wheel bracket 4 .
Page 523 Premium tire sealant* The Premium tire sealant is located in the storage compartment in the right- hand doorway. 1 Latching springs 2 Electric air pump 3 Premium tire sealant To open: press both latching springs 1 down and remove the cover.
Page 524 Practical hints Where will I find...? Panel van 1 Retaining band 2 Retainer Pull support cable 1 slightly down- ward and pull it out of retainer 2 . Pull out the wheel chock. CAUTION When storing it away, make sure that the chock is secured in the retainer by the retaining band.
Page 525 N77.20-2041-31 1 Trim 2 Cover cap Remove cover cap 2 from trim 1 . N77.20-2040-31 3 Opening 4 Emergency operation key Take emergency operation key 4 from the vehicle document wallet in the glove box. Insert emergency operation key 4 into opening 3 of the drive.
Page 526 Practical hints Where will I find...? Releasing the parking lock manu- ally In the event of a malfunction, it is possi- ble to manually release the selector le- ver from the lock in parking position P , for example to have the vehicle towed away.
Page 527: Changing Bulbs
Changing bulbs Bulbs and lights are an important aspect of vehicle safety. For this reason, make sure that all bulbs are in working order at all times. Before changing bulbs Switch off the lights to avoid a short circuit. Only touch new bulbs with a clean lint-free cloth or something similar.
Page 528 Practical hints Changing bulbs Front bulbs Bulb Model 1 Additional turn sig- PY 16 W 2 Turn signal PY 21 W Bulb Model 3 Halogen headlamp: H7 55 W low-beam headlamp Bi-xenon headlamp*: D1S-35 W low-beam headlamp/high- beam headlamp 4 Halogen headlamp: H7 55 W high-beam headlamp Cornering lamp*...
Page 529 Bi-xenon headlamps* Warning Xenon bulbs carry a high voltage. You could receive a serious or fatal electric shock if you touch the electrical contacts on the xenon bulbs. Do not remove hous- ing cover 2 ( page 527) if the head- lamps are xenon headlamps.
Page 530 Practical hints Changing bulbs Press catches 1 down. Swing housing cover 2 in the direc- tion of the arrow and remove it. 3 Low-beam headlamps 4 Halogen high-beam headlamps/xenon headlamp cornering lamp* Pull the connector off the bulb hold- Unclip the retainer spring and re- move the bulb.
Page 531 Turn bulb holder 1 and the bulb counterclockwise and remove the holder. Press down on the bulb, turn it coun- terclockwise and remove it from bulb holder 1 . Press the new bulb into bulb holder 1 and screw it in clockwise. Place bulb holder 1 into the lamp and turn it clockwise.
Page 532 Practical hints Changing bulbs Rear bulbs N82.10-2529-31 Panel van/crewbus Bulb Model 1 Third brake lamp 2 Brake lamp P 21 W 3 Turn signal PY 21 W 4 Tail lamp/ R 5 W side marker/Stand- ing lamp (Canada only) 5 License plate lamp W 5 W 6 Rear foglamp (driv- P 21 W...
Page 533 Bulb Model 8 Perimeter lamp/side R 5 W marker 9 Turn signal PY 21 W a Brake lamp P 21 W b Reverse lamp P 21 W c Rear foglamp P 21 W (driver’s side) d Tail lamp R 5 W e License plate lamp R 5 W Changing the rear bulbs (van/crewbus)
Page 534 Practical hints Changing bulbs 2 Retaining lugs 3 Brake lamp 4 Side marker, Standing lamp (Canada only), tail lamp 5 Reverse lamp 6 Turn signal lamp 7 Rear foglamp (driver’s side) Release retaining lugs 2 and re- move the bulb holder from the rear lamp unit.
Page 535 Changing the rear bulbs (chassis) Example illustration of chassis 1 Securing screws 2 Lens 3 Perimeter lamp, side marker 4 Turn signal lamp 5 Brake lamp 6 Tail lamp 7 Rear foglamp (driver’s side) 8 License plate lamp 9 Reverse lamp Switch off the lighting.
Page 536 Practical hints Changing bulbs Switch off the lighting. Undo screws 1 and remove lamp housing. Turn the bulb holder 2 and remove it together with the bulb. Pull the bulb out of the bulb holder Press the new bulb into the bulb hol- der 2 .
Page 537 Clearance lamp* W 5 W (cargo and passenger vans only) 1 Securing screw 2 Lamp housing Undo screw 1 and remove lamp housing 2 in the direction of the arrow. Turn the bulb holder and remove it together with the bulb. Pull the bulb out of the bulb holder.
Page 538 Practical hints Changing bulbs Insert a screwdriver or similar imple- ment at the side and carefully pry off lens 1 in the direction of the arrow. Turn bulb holder 2 in the direction of the arrow and remove it together with the bulb.
Page 539 Entry lamp* W 5 W N82.20-2081-31 1 Lamp housing 2 Bulb holder 3 Cable connector Press in the latching springs of lamp housing 1 using a suitable tool, for example a screwdriver. Pry off lamp housing 1 . Remove cable connector 3 . Turn bulb holder 2 in the direction of the arrow and remove it together with the bulb.
Page 540 Practical hints Changing bulbs Switch off the lighting. Press in the latching springs of lamp housing 1 using a suitable tool, for example a screwdriver. Pry off lamp housing 1 . Remove bulb 2 from the bulb hold- Insert new bulb 2 . Align lamp housing 1 on the right and engage it.
Page 541: Changing The Batteries
Changing the batteries If the remote control batteries (remote keyless entry) are discharged, you will only be able to lock and unlock the vehi- cle manually using the key. If the batteries in the auxiliary heating remote control are discharged, you will only be able to switch the auxiliary heat- ing on or off using the auxiliary heating/ heater booster switch inside the vehicle...
Page 542 Practical hints Changing the batteries Always replace all the batteries at the same time. Suitable batteries are available from an authorized Sprinter Dealer. You can also have the batter- ies changed there and return used batteries. Remote control (remote keyless entry) You need two CR 2025 3 V cell batteries or equivalent.
Page 543 Remove the battery and install a new one (note correct polarity; positive terminal up). Press battery cover 1 until it snaps into place. Check the function of all remote con- trol buttons on vehicle. Auxiliary heating remote control* You need three Micro/AAA/LR03 bat- teries or equivalent.
Page 544: Fuel System
Practical hints Fuel system Fuel system Draining the fuel filter On vehicles with a diesel engine, it is necessary to drain the fuel filter if the / indicator lamp lights up. CAUTION Drain the fuel filter with water sepa- rator immediately if the / indica- tor lamp lights up.
Page 545 Switch off the engine and open the hood ( page 318). Place a suitable container under drain hose 1 . Switch on the ignition ( page 111). Unscrew drain plug 2 immediately one turn or until liquid flows out of drain hose 1 .
Page 546 Practical hints Fuel system Environmental note Have the drained liquid disposed of at an authorized Sprinter Dealer. Drain the fuel filter again if the / indicator lamp remains lit. CAUTION If the / indicator lamp remains lit even after draining for the second time, have the cause checked imme- diately at an authorized Sprinter Dealer.
Page 547: Replacing The Wiper Blades
Replacing the wiper blades CAUTION Do not open the hood while the wiper arms are folded away from the wind- shield. You would damage the hood and the wiper arms. Do not fold the wiper arms onto the windshield without wiper blades be- ing attached.
Page 548 Practical hints Replacing the wiper blades Press two retaining clips 2 together in the direction of the arrow and fold wiper blade 1 away from wiper arm 3 . Pull wiper blade 1 up and out of the retainer. Installing the wiper blades Slide wiper blade 1 into the retainer on the wiper arm.
Page 549: Flat Tire
Flat tire The vehicle is either equipped with a spare wheel or the Premium tire seal- ant*. The spare wheel is located under the rear end of the vehicle if the vehicle is not equipped with Premium tire sealant* page 517). Warning Defective or worn tires, and tire pressures that are either too high or too low, can...
Page 550 Practical hints Flat tire Preparing the vehicle Park the vehicle as far away as pos- sible from traffic and on a level, firm, and non-slip surface. Switch on the hazard warning lamps. Apply the handbrake. Engage first gear or reverse gear or move the selector lever to position P .
Page 551 Preparing the vehicle Prepare the vehicle as described page 548). Prevent the vehicle from rolling away using chocks or similar. Warning The vehicle could slip off the jack on uphill and downhill gradients. To avoid the risk of causing serious or fa- tal injury, or damage to the vehicle, do not change wheels on uphill and downhill gra- dients.
Page 552 Practical hints Flat tire Hydraulic jack Assemble the three-part pump lever for the jack. P58.10-2053-31 1 Pressure release screw Close pressure release screw 1 . To do this, turn the flattened section on the pump lever clockwise to the stop. Never turn pressure release screw 1 more than 1 or 2 full turns.
Page 553 Jacking point at the front axle The vehicle jacking point is located un- der the longitudinal member in front of the front axle. N40.10-2260-31 Jacking points at the rear axle The vehicle jacking point is located un- der the longitudinal member in front of the rear axle.
Page 554 Practical hints Flat tire Removing a wheel Unscrew the wheel bolts or wheel nuts. CAUTION Do not place the wheel bolts or the wheel nuts in sand or dirt. The bolt and wheel hub threads could other- wise be damaged. For wheels with wheel nuts remove the wheel nut cover.
Page 555 Push the wheel onto the wheel hub and press it on. CAUTION If your vehicle is equipped with the tire pressure monitor, each wheel has an electronic component. Tire mounting tools should not be ap- plied in the area of the valve, as this could damage the electronic compo- nents.
Page 556 Practical hints Flat tire For wheels with wheel nuts: Center the wheel nut cover over the wheel and push it onto the wheel. Screw on the wheel nuts and tighten them finger tight. Screw on the three wheel nuts that hold the wheel nut cover first.
Page 557 Vehicles with wheel caps: Make sure that the opening in the wheel cap is positioned over the tire vent. Vehicles with center caps: Make sure that the retaining lugs of the hub cap are positioned over the bolts. Give the middle of the center cap a knock to engage it on the wheel.
Page 558 Practical hints Flat tire Warning (Continued) Check the tire pressure and correct it if necessary Have the wheel bolts or wheel nuts re- tightened after 30 miles (50 km) to a torque of: 177 lb-ft (240 Nm) (steel wheel)/ 133 lb- ft (180 Nm) (light-alloy wheel) for wheel bolts or 133 lb-ft (180 Nm) for wheel nuts.
Page 559 Using Premium tire sealant* You can use the Premium tire sealant to seal small punctures, particularly those in the tire tread. Tire sealants can be used at outside temperatures down to – 22 °F (–30 °C). Prepare the vehicle as described page 548).
Page 560 Practical hints Flat tire CAUTION Only connect the electric air pump to the 12 V socket ( page 297) on the center console (12 V, 25 A, 300 watts). You could otherwise damage the vehicle electrical sys- tem. Try to park the vehicle in such a way that the tire puncture is close to the ground.
Page 561 Warning (Continued) Immediately change out of clothing that has been in contact with tire sealant. If an allergic reaction occurs, consult a doctor immediately. Keep tire sealant away from children. If tire sealant is swallowed, immediately rinse your mouth out thoroughly and drink plenty of water.
Page 562 Practical hints Flat tire Tire sealant bottle for single tires 7 Valve 8 Tire sealant bottle with hook, hose and valve core extractor Tire sealant bottle for twin tires 7 Valve 8 Tire sealant bottle with hook, hose and angle brackets Shake tire sealant bottle 8 .
Page 563 Single tire 9 Hook a Knob b Lever c Valve core extractor d Tire valve Pull knob a out of valve core extrac- tor c as far as the stop. Unscrew and remove the valve cap from tire valve d on the flat tire. Hook the tire sealant bottle into the upper vent hole in the wheel using hook 9 .
Page 564 Practical hints Flat tire CAUTION Do not connect the electric air pump connector to the cigarette lighter socket or another 12 V socket. These are not designed for operating the electric air pump. Start the engine ( page 186). Press I on electric air pump switch 1 .
Page 565 Press lever b and remove valve core extractor c from tire valve d . Screw the valve cap onto tire valve d . After filling with tire sealant page 570). Twin tires, inner wheel 9 Valve extension a Valve core extractor Unscrew and remove the valve cap from valve extension 9 on the flat tire.
Page 566 Practical hints Flat tire a Valve core extractor b Hook c Knob d Angle bracket e Tire valve Pull knob c out of valve core extractor a as far as the stop. Screw valve core extractor a clock- wise onto tire valve e . Press knob c into the valve core of tire valve e , turning it gently as you do so, until the shaft of valve core...
Page 567 Connect connector 6 to the 12 V socket (12 V, 25 A, 300 watts) on the center console ( page 297). CAUTION Do not connect the electric air pump connector to the cigarette lighter socket or another 12 V socket. These are not designed for operating the electric air pump.
Page 568 Practical hints Flat tire Turn knob c clockwise until the valve core is firmly screwed into tire valve e . Do not unscrew the valve core ex- tractor from the tire valve while the valve core is unscrewed from the tire valve.
Page 569 9 Handle a Turning workpiece Unscrew and remove the valve cap from tire valve d on the flat tire. Guide valve tool through the opening in the wheel and press it onto tire valve b . Use one hand to hold handle 9 on valve tool firmly and use the other hand to unscrew and remove the valve core from the valve tool using...
Page 570 Practical hints Flat tire c Angle bracket d Hook Hook tire sealant valve 8 into the upper vent hole in the wheel using hook d . Press angle bracket c on hose of tire sealant bottle 8 ( page 560) to the stop on tire valve b and clamp it into place.
Page 571 Allow the electric air pump to run un- til tire sealant bottle 8 is completely empty. Press 0 on electric air pump switch 1 after about 15 seconds. Unscrew angle bracket c from tire valve b and remove it. Screw in the valve core with the valve tool again and take out the valve tool through the opening.
Page 572 Practical hints Flat tire After filling with tire sealant Turn the pressure release screw on pressure gauge 5 counterclock- wise and bleed the system. Turn the key to position 0 in the igni- tion lock ( page 111). Pull the electric air pump connector out of the 12 V socket.
Page 573 Correct the tire pressure accordingly if it does not correspond to the rec- ommended tire pressure page 361). Increasing the tire pressure Switch on the electric air pump. Reducing the tire pressure Open the pressure release screw on pressure gauge 5 . Drive to the nearest workshop and have the tire repaired or replaced.
Page 574 Practical hints Flat tire Environmental note Have the used Premium tire sealant dis- posed of at an authorized Sprinter Dealer. CAUTION Have the tire sealant bottle replaced every 8 years at an authorized Sprinter Dealer.
Page 575: Battery
Battery Your vehicle may be equipped with two batteries, depending on the equipment version: Starter battery in the battery recess in the driver’s footwell Auxiliary battery* in the engine com- partment The auxiliary battery* in the engine compartment is not suitable for jump-starting operations.
Page 576 Practical hints Battery Have the batteries removed at an autho- rized Sprinter Dealer which has the nec- essary specialist knowledge and tools to carry out the work required. The manufacturer recommends that you use an authorized Sprinter Dealer for this purpose. Disconnecting the battery Warning There is a risk of a short circuit if the pos-...
Page 577 CAUTION Switch off the engine and take the key out of the ignition lock before you loosen or disconnect the termi- nal clamps. You may otherwise de- stroy electronic components such as the alternator. Always disconnect the starter bat- tery in the battery recess in the driv- er’s footwell first.
Page 578 Practical hints Battery To install: place floor covering 1 into the driver’s footwell. Warning The movement of the pedals must not be ob- structed. The vehicle’s operating and road safety are otherwise jeopardized. Make sure to push the floor covering under the plate metal bracket of the accelerator pedal.
Page 579 Remove cover 1 upward. Starter battery in the driver’s footwell Loosen the negative terminal of the battery first and remove it so that the negative terminal cannot come into contact with the pole terminal. Remove the cover from the positive terminal.
Page 580 Practical hints Battery Loosen the negative terminal of the battery first and remove it so that the negative terminal cannot come into contact with the pole terminal. Remove the cover from the positive terminal. Loosen the positive terminal and re- move it.
Page 581 Pull retainer 3 upward and slide the battery out of its anchorage in the di- rection of travel. Fold the clip upward and remove the battery from the battery recess. Auxiliary battery* in the engine com- partment Disconnect the battery page 577).
Page 582 Practical hints Battery Warning Only charge the battery in well-ventilated areas. As the battery is being charged, gases can escape and generate minor ex- plosions, which can injure you and others and may cause damage to the paintwork or permit acid corrosion on the vehicle. During the charge procedure, there is a risk of acid burns due to gases escaping from the battery.
Page 583: Jump-Starting
Jump-starting If the starter battery in the battery re- cess in the driver’s footwell is dis- charged, the engine can be jump-started from another vehicle using jump leads. For this purpose, the vehicle is equipped with a jump-starting connection point. The auxiliary battery* in the engine compartment is not suitable for jump-starting operations.
Page 584 Practical hints Jump-starting Make sure that the two vehicles do not touch. Apply the handbrake or move the se- lector lever to position P . Switch off all electrical consumers. Switch on the battery isolating switch* if necessary ( page 338). Remove the key from the ignition lock.
Page 585 1 Positive terminal of jump-starting con- nection point (under cover) 2 Positive terminal of donor battery 3 Negative terminal of donor battery 4 Ground contact of own vehicle (negative terminal of your own battery) Do not connect the jumper cable to the auxiliary battery* in the engine compartment.
Page 586 Practical hints Jump-starting Tow-starting CAUTION Your vehicle is equipped with an au- tomatic transmission. Do not tow- start your vehicle. Warning When tow-starting another vehicle, its weight should not be greater than the per- missible gross weight of your vehicle. Use a rigid towing bar and secure this only to the front towing eye page 585).
Page 587: Towing
Towing Warning Tow the vehicle using a rigid towing bar if: the engine is not running, there is a malfunction in the power supply or the vehicle’s electrical system. There is no power assistance for the steering and braking when the engine is not running.
Page 588 Practical hints Towing 1 Cover Installing the towing eye Press bottom of cover 1 in the di- rection of the arrow and remove it. You will see the fixture for the towing eye. Take the towing eye and the wheel wrench from the vehicle tool kit page 515).
Page 589 Deactivate the automatic locking while driving function when towing . You could otherwise become locked out when pushing or towing the vehi- cle. Switch on the ignition ( page 111). For a distance of up to 30 miles (50 km), move the selector lever to position N .
Page 590 Practical hints Towing With front axle damage Turn the key to position 1 in the igni- tion lock( page 111). CAUTION The vehicle must not be towed with its front wheels raised and with the key in position 2 in the ignition lock. Active brake intervention by ESP ASR could otherwise lock the wheels and damage the brake system.
Page 591: Fuses
Fuses Warning Only use fuses of the amperage recom- mended by the manufacturer. Any autho- rized Sprinter Dealer will be happy to advise you. Do not attempt to repair or bridge blown fuses. Have the cause determined and rectified at a qualified specialist workshop, e.g. an authorized Sprinter Dealer.
Page 592 Practical hints Fuses N54.15-2148-31 1 Unlocked 2 Locked To open: release 1 the quick-re- lease lock and remove the cover. To close: attach the cover at the bot- tom and fold it closed. The cover must engage. Lock 2 the quick-release lock.
Page 593 Practical hints Fuses...
Page 594 Practical hints Fuses Consumer Amp. Horn Electric steering lock ESTL (electronic ignition switch EIS) Terminal 30 Z, vehicles with gasoline engine/ electronic ignition switch Light switch/center con- sole switch unit Windshield wipers Fuel pump MRM (jacket tube mod- ule) Terminal 87 (2) Consumer 15 A Terminal 87 (3)
Page 595 Fuse block F55/1 No. Consumer Amp. Control panel, left door 25 A Diagnostic socket 10 A Brake system (valves) 25 A Brake system (delivery 40 A pump) Terminal 87 (5), vehicles 7,5 A with gasoline engine Terminal 87 (6), vehicles 7,5 A with gasoline engine Headlamp cleaning system*...
Page 596 Practical hints Fuses Preliminary fuse box in the battery re- cess in the driver’s footwell F59 Consumer Amp. Pre-glow relay/second- 80/40 A ary air pump Engine fan (air-condi- 60/40 A tioning system) – cab chassis/crewcab Signal acquisition and actuation module SAM/ fuse and relay block SRB Auxiliary battery* in the engine compartment/...
Page 597 Practical hints Fuses...
Page 598 Practical hints Fuse Box in the Driver’s Seat Fuse Box in the Driver’s Seat Fuses Consumer Mirror adjustment*/rear window heating* Rear window wiper* Rear view camera*/tele- phone*/pre-wiring mount- ing slot (roof)* Operating speed governor (ADR)*/PTO*/trailer con- nection unit AAG* Terminal 87 electronic transmission control ETC, control unit/automatic transmission, control and...
Page 599 Consumer Amp. 12V socket* rear left, load/ 15 A passenger compartment 12V socket, driver’s seat 15 A base 12V socket rear right, load/ 15 A passenger compartment Auxiliary heating* 25 A Consumer Amp. Heater booster* 25 A Unassigned Unassigned Brake booster* 30 A Blower unit (rear heating*)/ electric sliding door*, left/...
Page 601: Technical Data
*Technical data *Technical data Genuine Sprinter Vehicle parts... 600 Vehicle electronics... 602 Service products and capacities... 604 Rims and tires... 623 Tire inflation pressure... 626 Lashing points and carrier systems... 629 Vehicle identification labels... 632...
Page 602: Technical Data
*Technical data Genuine Sprinter Vehicle parts Genuine Sprinter Vehicle parts The “Technical data” section contains important technical data regarding your vehicle. You will find other vehicle-specific and equipment-dependent technical data, such as: engine power output data speeds vehicle dimensions vehicle weights in your vehicle documents.
Page 603 Genuine Sprinter vehicle parts are sub- jected to the most stringent quality in- spections and will ensure that the vehicle is maintained at a high level of operating efficiency and safety, and that it maintains its value. Each part has been specifically designed and manufactured or selected and approved for use in Sprinter vehicles.
Page 604: Vehicle Electronics
*Technical data Vehicle electronics Vehicle electronics Tampering with the engine elec- tronics Work on the engine electronics and all associated parts such as control units, sensors and connector leads should only be performed at an au- thorized Sprinter Dealer. Vehicle parts could otherwise wear more quickly and the vehicle’s warranty or general operating permit could be in-...
Page 605 You may retrofit telephones and two- way radios provided that the maximum transmission outputs listed below are not exceeded. Always have this type of equipment professionally installed with an exterior antenna which has been in- stalled in such a way as to be reflection- free.
Page 606: Service Products And Capacities
*Technical data Service products and capacities Service products and capacities Service products are: fuels lubricants (e.g. engine oils, transmis- sion oils, hydraulic fluids, greases) antifreeze additives, coolant brake fluid Service products are tested for suitabili- ty in our assemblies. Approved service products meet the highest quality stan- dards and are listed in the Mercedes- Benz Specifications for Service Pro-...
Page 607 Warning Failure to use fluids and lubricants which meet the standards and specifications de- scribed in this booklet or failure to adhere to the specified replacement intervals may result in damage to safety/ and/or emissions-related systems of your vehi- cle, such as the brake system, which could cause an accident and/or serious injury to you and others.
Page 608 *Technical data Service products and capacities Warning (Continued) Change out of clothing soiled with service products immediately to avoid the risk of fire and other injuries. Fire, naked flames and smoking are there- fore prohibited when handling service products due to their highly flammable nature.
Page 609 Valid Mercedes-Benz oil specification sheets: Engine MB sheet Gasoline 229.3, 229.31 M272 229.5, 229.51 Diesel 228.51, 229.31, OM642 229.51 Always refer to the following viscosity chart for the proper viscosity grade based on ambient temperature. Select oil viscosity according to the lowest air temperature expected before the next oil change.
Page 610 *Technical data Service products and capacities The following oils have been determined to meet the Chrysler Vans LLC requirements as shown below: MB approved engine MB sheet Fuchs Titan Supersyn 5W-30 229.3 Longlife SAE 5W-30 229.5 Havoline Ultra S 5W- 5W-30 229.31 Havoline Ultra S 5W-...
Page 611 The following oils have been determined to meet the Chrysler Vans LLC requirements as shown below: MB approved engine MB sheet Pentospeed 0W-30 229.3 Pentospeed 0W-30 0W-30 229.3 229.5 Q Diesel Plus 5W-30 229.51 Q European Engine 5W-40 229.3 Q European Engine Ul- 5W-30 229.5 Quaker State Euro...
Page 612 *Technical data Service products and capacities Fuels Warning Gasoline is highly flammable and poison- ous. It burns violently and can cause seri- ous injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking ma- terials near gasoline! Direct skin contact with fuels and the inhalation of fuel va- pors are damaging to health.
Page 613 Do not exceed an engine speed of 3000 rpm if the vehicle is loaded with a light load, such as two persons and no cargo. Do not exceed of maximum ac- celerator pedal position if the vehicle is fully loaded or operating in moun- tainous terrain.
Page 614 *Technical data Service products and capacities CAUTION The following may lead to increased wear or engine damage: Using gasoline that does not meet the specifications men- tioned above The use of non-approved special additives Fuels for diesel engines CAUTION Marine diesel fuel, Bio diesel fuel, heating oil or the like must not be used.
Page 615 CAUTION As bio diesel can be refined from a va- riety of raw materials resulting in widely varying properties, the only ap- proved bio diesel content is one that meets ASTM D6751 specification. It must also have the necessary oxida- tion stability (min.
Page 616 *Technical data Service products and capacities For more information on diesel fuels contact your authorized Sprinter Dealer. Commercially available vehicular ULTRA-LOW SULFUR HIGHWAY DIE- SEL FUEL may contain up to 5% bio diesel. This proportion will not have an effect on performance and wear. Diesel fuels for use at very low tem- peratures Only use commercially available vehicu-...
Page 617 Do not blend other specific fuel addi- tives with diesel fuel except for fuel flow improver. They only result in unneces- sary cost, and may be harmful to the en- gine operation. Warning Under no circumstances should gasoline be mixed with diesel fuel. Due to the high pressure and high temper- ature in the injection system, there is a risk of fire and explosion.
Page 618 *Technical data Service products and capacities Coolants, lubricants, etc. Air conditioning The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere. Refrigerant R-134a Automatic transmission Automatic transmission fluid Service interval Product name/product number —...
Page 619 Service interval Product name/product number Brakes Use brake fluid approved for Chrysler Vans LLC standard MB 331.0 and/or Chrysler Vans LLC material standard MS-9971, brake fluid certified to DOT 4 Plus standards, that also maintains a minimum dry boiling point (ERBP) of 500 °F (260 °C), a minimum wet boiling point (WERBP) of 356 °F (180 °C) and a maximum viscosity of 1500 mm Brake fluid 2 years...
Page 620 *Technical data Service products and capacities Engine cooling system Whenever the coolant is replaced, a concentration of 50% by volume of corrosion inhibitor/antifreeze should be maintained. This provides antifreeze protection down to -34,6 °F (-37 °C). Do not exceed a concentration of 55% by volume (antifreeze protection down to approximately -49 °F (-45 °C)), as the heat dissi- pation properties deteriorate at higher concentrations.
Page 621 Service interval Product name/product number Engine Engine oil for gasoline engine 1 year or 10,000 M272 mi (16,000 km) Engine oil for diesel engine 2 years or 10,000 OM642 mi (16,000 km) 1 Chrysler Vans LLC Material Standard-No. 2 Follow the interval, time or mileage, that occurs first. Service products and capacities see “Engine oils”...
Page 622 *Technical data Service products and capacities Power steering Power steering, no fluid service required. Power steering fluid Rear axle Gear oil 1 Chrysler Vans LLC Material Standard-No. 2 Follow the interval, time or mileage, that occurs first. 3 Synthetic automotive gear lubricant without fricition modifier. Service interval Product name/product number —...
Page 623 Capacities Vehicle Engine with oil filter Engine oil 2500 CRD, 3500 CRD 2500, 3500 1 Whenever the coolant is replaced, a concentration of 50% by volume of corrosion inhibitor/antifreeze should be maintained. This provides antifreeze pro- tection down to -34,6 °F (-37 °C). Do not exceed a concentration of 55% by volume (antifreeze protection down to approximately -49 °F (-45 °C)), as the heat dissipation properties deteriorate at higher concentrations.
Page 624 *Technical data Service products and capacities Fuel consumption Environmental note A vehicle’s CO emissions and fuel con- sumption depend on: efficient use of fuel by the engine the style of driving adopted other non-technical factors such as environmental influences or road con- ditions The vehicle will use more fuel than usual in the following conditions:...
Page 625: Rims And Tires
Rims and tires CAUTION Only use tires which have been test- ed and approved for your Sprinter ve- hicle by the vehicle manufacturer. Tires approved by the vehicle manu- facturer are developed to provide the best possible performance in con- junction with the driving safety sys- tems on your Sprinter vehicle such as ABS, BAS, ASR or ESP...
Page 626 *Technical data Rims and tires Warning Loose wheel nuts or bolts could cause the vehicle to lose a wheel while it is in mo- tion. This would jeopardize the operating and road safety of the vehicle. You could lose control of the vehicle as a result, cause an accident an injure yourself or others.
Page 627 Vehicle Model Type Rims (steel) Rims (light alloy) Wheel offset Half dual spacing Wheel fixture Tightening torque (steel wheel) Tightening torque (light-alloy wheel) Summer tires All-season tires Winter tires 1 Radial-ply tires 2 Radial-ply tires 2500 6.5 J x 16 6.5 J x 16 2.13 in (54 mm) Wheel bolts...
Page 628: Tire Inflation Pressure
*Technical data Tire inflation pressure Tire inflation pressure Observe the information on recom- mended tire inflation pressure in the “Operation” section ( page 361). The following table lists the recommen- ded cold tire inflation pressures for all load conditions up to the maximum per- missible weight limits (GAWR).
Page 629 Set the correct tire pressure before loading the vehicle. If the vehicle has been loaded, check the tire pressures and correct them if necessary. The tires can be considered cold if the vehicle has been parked for at least 3 hours or driven less than 1 mile (1.6 km) at an ambient temperature of approximately 68 °F (20 °C).
Page 630 *Technical data Tire inflation pressure Tire Permissible axle loads (see certification label) Front axle 3970 lbs (1801 kg) LT 215/85 R 16 — 115/112 N LT 215/85 R 16 — 115/112 Q LT 245/75 R 16 47 psi (3.2 bar) — 120/116 L LT 245/75 R 16 47 psi (3.2 bar) —...
Page 631: Lashing Points And Carrier Systems
Lashing points and carrier systems Lashing points CAUTION Observe the data on the maximum load-bearing capacity of the individu- al lashing points. During full-braking applications, for example, forces can be involved that are much greater than the weight force of the load. Always use several lashing points in order to distribute force absorption, and make sure that the lashing...
Page 632 *Technical data Lashing points and carrier systems The specified values only apply to loads on the load compartment floor if: the load is secured to 2 lashing points on the rail and the distance to the next lashing point used on the same rail is about 3 ft (1 m).
Page 633 CAUTION The weight of any load carried on the roof, including the roof rack, must not exceed the maximum permissible roof load. The roof rack supports must be ar- ranged at equal distances. The manufacturer recommends that you have an anti-roll bar installed on the front axle.
Page 634: Vehicle Identification Labels
*Technical data Vehicle identification labels Vehicle identification labels For certain vehicles, vehicle data cards are delivered with the vehicle. These vehicle data cards contain all the important details of your vehicle, e.g. vehicle identification number, engine number and subassembly numbers together with the model and optional equipment codes.
Page 635 The Vehicle Identification Number (VIN) can be found: on the vehicle or incomplete vehicle safety certification label embossed on the engine compart- ment rear bulk ( page 379) Example vehicle safety certification label (U.S. vehicles) Example incomplete vehicle safety certi- fication label (U.S.
Page 636 *Technical data Vehicle identification labels Example incomplete vehicle safety certi- fication label (Canada vehicles) 2 VIN Example Engine Compartment 3 VIN (embossed on the engine compart- ment rear bulk) 4 Engine number (engraved on gasoline en- gine) 5 Engine number (engraved on diesel en- gine) 6 Emission control information label and engine oil warning label...
Page 637 Example emission control information la- bel for diesel engines (U.S. vehicles) Example emission control information la- bel for diesel engines (Canada vehicles) *Technical data Vehicle identification labels Example emission control information la- bel for gasoline engines...
Page 638 *Technical data Vehicle identification labels The data shown on the labels is for il- lustrative purposes only. The data is specific to each vehicle and may vary from the data shown in the illustra- tion. Refer to the label on your vehicle for data specific to your vehicle.
Page 639: Index
Numerics 12 V socket ....297 see Antilock Brake System Acceleration skid control (ASR) . 73 activating/deactivating ..74 display message .
Page 640 Index Alarm audible ....431 Anticorrosion/antifreeze fluid ..618 Antilock Brake System (ABS) ..70 display message .
Page 641 stopping ....206 towing ....587 trailer towing .
Page 642 Index Brake lamp ....530 changing bulbs ....531 high-mounted third brake lamp . 530 Brake pads/linings display message .
Page 643 Checking tire pressure electronically with the Advanced Tire Pressure Monitoring System (Advanced TPMS) ... . 373 Checking tire pressure electronically with the Tire Pressure Monitoring System (TPMS) ....367 Checks, regular .
Page 644 Index Consumption statistics (vehicles with steering wheel buttons) ....177 Coolant ..... 618 adding .
Page 645 Display ..... 158 vehicles with steering wheel buttons ....158 display messages .
Page 646 Index see Electronic brake force distribution Electric sliding door ..92 programming the key ..97 programming the remote control . 97 reset ..... . . 98 unlocking mechanism for the electric drive .
Page 647 Environmental protection ..5 ® /ASR warning lamp . .22 Exterior lighting ... . . 129 additional bulbs ... . . 533 Constant headlamp mode (vehicles with steering wheel buttons) .
Page 648 Index Gasoline ....610 consumption ....622 reserve fuel warning lamp .
Page 649 Heater ....228 – air distribution ....230 airflow ....230 air-recirculation mode .
Page 650 Index brake pad/lining wear ..470 coolant ....474 engine diagnostic ... . 477 ®...
