  • Page 1 Challenger SRT8 2 0 0 8 O W N E R ’ S M A N U A L...
  • Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefor. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.

  • Page 3: Introduction

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...

  • Page 5: Table Of Contents

    CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.
  • Page 7 INTRODUCTION 5...

  • Page 8: Warnings And Cautions

    The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel and is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN Location Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.

  • Page 9: Vehicle Modifications/Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
  • Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . .12 FOB With Integrated Key .
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Open The Trunk .....25 Using The Panic Alarm ....25 Programming Additional Transmitters .
  • Page 13 Event Data Recorder (EDR) ....56 Child Restraint ......58 Engine Break-In Recommendations .

  • Page 14: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Fob with Integrated Key and a Wireless Ignition Node (WIN) with an integral ignition switch. You can insert the double-sided integrated key into the ignition switch with either side up.

  • Page 15: Fob With Integrated Key

    Fob With Integrated Key The Fob with Integrated Key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a valet key, which stores in the rear of the Fob. The valet key allows for entry into the vehicle should the battery in the vehicle or the Fob go dead.

  • Page 16: Ignition Key Removal

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Ignition Key Removal Place the shift lever in PARK. Turn the key to the LOCK position and then remove the key. NOTE: The power window switches, radio, power sunroof (if equipped), and ignition-powered power out- lets will remain active for up to 60 minutes after the ignition switch is turned to the LOCK position.

  • Page 17: Key-In-Ignition Reminder

    Key-In-Ignition Reminder If you open the driver’s door and the key is in the ignition, a chime will sound to remind you to remove the key. NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position.

  • Page 18: Replacement Keys

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • The Sentry Key Immobilizer System is not compat- ible with aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. • Exxon/Mobil Speedpass™, additional RKE transmit- ters, or any other transponder-equipped components on the same key chain will not cause a fault unless the additional part is physically held against the trans-...

  • Page 19: Customer Key Programming

    programming a blank transmitter to the vehicle electron- ics. A blank transmitter is one that has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle RKE transmitters with you to the authorized dealer. Customer Key Programming If you have two valid RKE transmitters with integrated keys, you can program new transmitters to the system by performing the following steps:...

  • Page 20: General Information

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory. This will prevent the lost key from starting your vehicle. The remaining keys must then be reprogrammed.

  • Page 21: To Arm The System

    To Arm The System Remove the key from the ignition switch and either press a power door LOCK switch while the driver or passenger door is open or press the LOCK button on the Remote Keyless Entry (RKE) transmitter. After the last door is closed, or if all doors are closed, the system will arm itself in about 16 seconds.

  • Page 22: Illuminated Entry System

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Vehicle Security Alarm System is designed to protect your vehicle; however, you can create conditions where the system will give you a false alarm. If one of the previously-described arming sequences has occurred, the system will arm regardless of whether you are in the vehicle or not.

  • Page 23: Remote Keyless Entry

    REMOTE KEYLESS ENTRY The Remote Keyless Entry (RKE) allows you to lock or unlock the doors, open the trunk, or activate the Panic Alarm from distances up to about 35 ft (11 m) using a hand-held radio transmitter. The transmitter need not be pointed at the vehicle to activate the system.
  • Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Key Unlock, Driver Door/All Doors First This feature lets you program the system to unlock either the driver’s door or both doors on the first press of the UNLOCK button on the transmitter. Refer to “Remote Key Unlock,”...

  • Page 25: To Lock The Doors

    Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4. • When not using the EVIC, perform the following steps: 1. Press and hold the UNLOCK button on a programmed transmitter for at least four seconds, but no longer than 10 seconds.

  • Page 26: Express Down Window Feature

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the transmitter. This feature can be turned on or turned off. Refer to “Sound Horn with Remote Key Lock,”...

  • Page 27: Things To Know Before Starting Your Vehicle 25

    To Open The Trunk Press the TRUNK button on the transmitter two times within five seconds to open the trunk. Using The Panic Alarm To turn the Panic Alarm feature ON or OFF, press and hold the PANIC button on the transmitter for at least one second and release.

  • Page 28: General Information

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Battery access is through a door located on the rear of the fob. Insert a small, flat blade screwdriver into the slot and gently pry open the access door. 1 — Battery Access Door 2.

  • Page 29: Remote Starting System

    If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1. A weak battery in the transmitter. The expected life of the battery is a minimum of three years. 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios.
  • Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Enter Remote Start Mode Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds. The parking lights will flash and the horn will honk twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15-minute cycle.

  • Page 31: Door Locks

    To Turn Off the Engine While in Remote Start Mode Press and release the REMOTE START button one time. NOTE: To avoid inadvertent shut downs, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request.

  • Page 32: Power Door Locks

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the key from the ignition and lock your vehicle.
  • Page 33 the key in the vehicle. Removing the key or closing the door will allow the locks to operate. If a door is open, the key is in the ignition, and the ignition is in the LOCK or ACC position, a chime will sound as a reminder to remove the key.
  • Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled. Refer to “Unlock Doors Automati- cally on Exit,” under “Personal Settings (Customer Pro- grammable Features),” under “Electronic Vehicle Infor- mation Center (EVIC)”...

  • Page 35: Windows

    WINDOWS Power Windows The window controls on the driver’s door control both of the door windows. Power Window Switches THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 There is a single window control on the passenger’s door trim panel that operates the window on the passenger’s door.

  • Page 36: Wind Buffeting

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches. Such entrapment may result in serious injury or death. AUTO-Down Feature The driver’s door power window switch and passenger door power window switch on some models have an AUTO-...

  • Page 37: Trunk Lock And Release

    TRUNK LOCK AND RELEASE The trunk lid can be released from inside the vehicle by pressing the Trunk Release button. The button is located on the instrument panel to the left of the steering wheel. NOTE: The transmission must be in PARK before the switch will operate.

  • Page 38: Trunk Safety Warning

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK SAFETY WARNING WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended.

  • Page 39: Occupant Restraints

    OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, the front airbags for both the driver and front passenger, and the supplemental side curtain airbags for the driver and passengers seated next to a window.

  • Page 40: Lap/Shoulder Belts

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle.
  • Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt.
  • Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
  • Page 43 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.

  • Page 44: Lap/Shoulder Belt Untwisting Procedure

    42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.

  • Page 45: Seat Belt Pretensioners

    Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove any slack from the seat belts in the event of a collision. These devices improve the performance of the seat belt system by assuring that the belt is tight around the occupant in a collision.

  • Page 46: Automatic Locking Mode - If Equipped

    44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. With all doors closed, and the ignition switch in any position except ON or START, buckle the driver’s seat belt. 2. Turn the ignition switch to the ON position, but do not start the engine.

  • Page 47: Seat Belts And Pregnant Women

    How to Engage the Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will here a clicking sound.

  • Page 48: Driver And Front Passenger Supplemental Restraint System (Srs) - Airbag

    46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug and in the recommended seating posi- tion.
  • Page 49 The front airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. WARNING! • Do not put anything on or around the front airbag covers or attempt to open them. You may damage the airbags and you could be injured because the airbags are no longer functional.
  • Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Do not stack luggage or other cargo up high enough to block the location of the side curtain airbag. The area where the side curtain airbag is located should remain free from any obstructions. •...
  • Page 51 WARNING! Infants in rear-facing child restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag. An airbag deployment could cause severe injury or death to infants in that position. 2. Children who are not big enough to wear the vehicle seat belt properly should be secured in the rear seat in child restraints or belt-positioning booster seats.
  • Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions, the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
  • Page 53 • Knee Impact Bolsters • Front Acceleration Sensors • Driver and Front Passenger Seat Belt Pretensioners How the Airbag System Works • The Occupant Restraint Controller (ORC) determines if a frontal collision is severe enough to require the airbags to inflate. The front airbag inflators are de- signed to provide different rates of airbag inflation from direction provided by the ORC.
  • Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Ignoring the AIRBAG Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
  • Page 55 • The Supplemental Side Impact SRS Side Curtain Airbags are designed to activate only in certain side collisions. When the ORC detects a collision requiring the side curtain airbag to inflate, it signals the inflators on the crash side of the vehicle. A quantity of nontoxic gas is generated to inflate the side curtain airbag.
  • Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE inflation. These airborne particles may irritate the skin, eyes, nose, or throat. If you have skin or eye irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air. If the irritation continues, see your doctor.
  • Page 57 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper passenger side of the instrument panel.

  • Page 58: Event Data Recorder (Edr)

    56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data param- eters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near deployment, and up to a quarter second of high-speed deceleration data during and/or after airbag deploy-...
  • Page 59 a potentially sensitive nature, such as would identify a particular driver, vehicle, or crash, will be treated confi- dentially. Confidential data will not be disclosed by Chrysler LLC to any third party except when: 1. Used for research purposes, such as to match data with a particular crash record in an aggregate database, provided confidentiality of personal data is thereafter preserved, 2.

  • Page 60: Child Restraint

    58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint Everyone in your vehicle needs to be buckled up all the time, including babies and children. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.
  • Page 61 infant carriers do, so they can be used rearward-facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. Both types of child restraints are held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system.
  • Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably and whose legs are long enough to bend over the front of the seat when their back is against the seatback should use the lap/shoulder belt in a rear seat.
  • Page 63 Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it. • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits.
  • Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child re- straint in any vehicle. All three rear-seating positions have lower anchorages that are capable of accommodating LATCH-compatible child seats.
  • Page 65 Again, carefully follow the installation instructions that are provided with the child restraint system. The rear seat lower anchorages are round bars located at the rear of the seat cushion where it meets the seatback and are just visible when you lean into the rear seat to install the child restraint.
  • Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. • When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children.
  • Page 67 keep the belt tight; however, any seat belt system will loosen with time, so check the belt occasionally and pull it tight if necessary. The seat belt must be in the Automatic Locking mode in order to enable a child restraint to be tightly installed. Refer to “Automatic Locking Mode”...
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint. Tether Strap Mounting 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.

  • Page 69: Engine Break-In Recommendations

    Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.

  • Page 70: Safety Tips

    68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.

  • Page 71: Safety Checks You Should Make Inside The Vehicle

    Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area. If it is necessary to sit in a parked vehicle with the engine running, adjust your heating or cooling controls to force outside air into the vehicle.

  • Page 72: Periodic Safety Checks You Should Make Outside The Vehicle

    70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light The light should come on and remain on for six to eight seconds as a bulb check when the ignition switch is first turned ON. If the light is not lit during starting, see your authorized dealer.

  • Page 73: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......75 Automatic Dimming Inside Mirror ..75 Outside Mirrors .
  • Page 74 72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition System — If Equipped ..104 Voice Recognition System (VR) Operation ..104 Commands ......105 Voice Training .
  • Page 75 Windshield Wipers And Washers ... . 122 Intermittent Wiper System ....122 Mist Feature ......123 Windshield Washers .
  • Page 76 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips ....135 General Information ....136 Power Sunroof —...

  • Page 77: Mirrors

    MIRRORS Automatic Dimming Inside Mirror This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.

  • Page 78: Exterior Mirrors Folding Feature - If Equipped

    76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger-side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger-side convex mirror could cause you to collide with another vehicle or other object.

  • Page 79: Heated Remote Control Mirrors - If Equipped

    Power Mirror Control Heated Remote Control Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the Electric Rear Window Defroster. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on the sun visor.

  • Page 80: Hands-Free Communication (Uconnect ) - If Equipped

    0.96 or higher. See the UConnect supported phones. NOTE: For UConnect following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone...
  • Page 81 different electronic devices to connect to each other without wires or a docking station, so UConnect works no matter where you stow your cellular phone (be it your purse, pocket, or briefcase), as long as your phone is turned on and has been paired to the vehicle’s UConnect system.

  • Page 82: Operation

    80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The radio display will be used for visual prompts from the UConnect system such as CELL or caller ID on certain radios. Operation Voice commands can be used to operate the UConnect system and to navigate through the UConnect menu structure.
  • Page 83 To activate the UConnect system from idle, simply press the PHONE button and follow the audible prompts for directions. All UConnect system sessions begin with a press of the PHONE button on the radio control head. Cancel Command At any prompt, after the beep, you can say Cancel and you will be returned to the main menu.
  • Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You will then be asked to give your cellular phone a priority level between 1 and 7, with 1 being the highest priority. You can pair up to seven cellular phones to your UConnect system.
  • Page 85 • The system will prompt you to say the name of the person you want to call. • After the Ready prompt and the following beep, say the name of the person you want to call. For example, you can say John Doe, where John Doe is a previ- ously stored name entry in the UConnect phonebook.
  • Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The UConnect system will allow you to enter up to 32 names in the phonebook with each name having up to four associated phone numbers and designations. Each language has a separate 32-name phonebook accessible only in that language.
  • Page 87 • You will then be asked for the name of the phonebook entry that you wish to edit. • Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. • When prompted, recite the new phone number for the phonebook entry that you are editing.
  • Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the name, the UConnect system will ask you which designation you wish to delete: home, work, mobile, pager, or all. Say the designation you wish to delete. • Note that only the phonebook entry in the current language is deleted.

  • Page 89: Phone Call Features

    Phone Call Features The following features can be accessed through the UConnect system if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the UConnect your cellular service provider for the features that you have.
  • Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Place/Retrieve a Call From Hold To put a call on hold, press the PHONE button until you hear a single beep. This indicates that the call is on hold. To bring the call back from hold, press and hold the PHONE button until you hear a single beep.

  • Page 91: Uconnect System Features

    Redial • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Redial. • The UConnect system will call the last number that was dialed from your cellular phone. NOTE: This may not be the last number dialed from the UConnect system.
  • Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say the name of the language you wish to switch to English, Espanol, or Francais. • Continue to follow the system prompts to complete language selection.
  • Page 93 Your phone must be turned on and paired to the UConnect system to allow use of this vehicle feature in emergency situations, when the cell phone has network coverage and stays paired to the UConnect system. Towing Assistance If you need towing assistance: •...
  • Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When calling a number with your UConnect system that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can press the “Voice Recognition” button and say the sequence you wish to enter, followed by the word Send.
  • Page 95 Turning Confirmation Prompts On/Off Turning confirmation prompts off will stop the system from confirming your choices (e.g., the UConnect sys- tem will not repeat a phone number before you dial it). • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Setup Confirmations.

  • Page 96: Advanced Phone Connectivity

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mute/Un-Mute (Mute Off) When you mute the UConnect system, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the UConnect system: •...
  • Page 97 • When prompted, say List Phones. • The UConnect system will play the phone names of all paired cellular phones in order from the highest to the lowest priority. To “select” or “delete” a paired phone being announced, press the “Voice Recogni- tion”...

  • Page 98: Things You Should Know About Your Uconnect System

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your UConnect System UConnect Tutorial To hear a brief tutorial of the system features, press the PHONE button and say “UConnect Tutorial.” Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used.
  • Page 99 • Speak normally, without pausing, just as you would speak to a person sitting a few feet/meters away from you. • Make sure that no one other than you is speaking during a voice recognition period. • Performance is maximized under: •...
  • Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Far End Audio Performance • Audio quality is maximized under: • low-to-medium blower setting, • low-to-medium vehicle speed, • low road noise, • smooth road surface, • fully closed windows, • dry weather conditions, and •...
  • Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99...
  • Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101...
  • Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
  • Page 105 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...

  • Page 106: General Information

    104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...

  • Page 107: Commands

    Pressing the VR hard-key while the system is speaking is known as “barging in.” The system will be interrupted and you can add or change commands. This will become helpful once you start to learn the options. NOTE: At any time, you can say the words CANCEL, HELP, or MAIN MENU.
  • Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Main Menu Start a dialogue by pressing the VR hard-key. You may say MAIN MENU to switch to the main menu. In this mode, you can say the following commands: • RADIO (to switch to the radio mode) •...
  • Page 109 • NEXT CHANNEL (to select the next channel) • PREVIOUS CHANNEL (to select the previous chan- nel) • LIST CHANNEL (to hear a list of available channels) • SELECT NAME (to say the name of a channel) • RADIO MENU (to switch to the radio menu) •...

  • Page 110: Voice Training

    108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE − PREVIOUS (to play the previous memo) − DELETE (to delete a memo) • DELETE ALL (to delete all memos) NOTE: Keep in mind that you have to press the VR hard-key first and wait for the beep, before speaking the “barge in”...

  • Page 111: Seats

    SEATS Easy Entry Seats Pushing the lever upward (toward the front of the vehicle) allows the seat back to dump forward and the seat to slide forward. This allows for easier access to the rear seat. Easy Entry Seats UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Power Seats The power seat switch is on the outboard side of the seat near the floor.

  • Page 112: Front Seat Back Recline

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 113: Lumbar Support

    Lumbar Support This feature allows you to increase or decrease the amount of lumbar support. Turn the control lever for- ward to increase and rearward to decrease the desired amount of lumbar support. Lumbar Support UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear.

  • Page 114: Heated Seats

    112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats Heated seats provide comfort and warmth on cold days and can help soothe sore muscles and backs. The heaters provide the same heat level for both cushion and back. The driver seat and front passenger seat are heated. The controls for each heater are located near the bottom center of the instrument panel.

  • Page 115: Folding Rear Seat - If Equipped

    illuminated changes from two to one, indicating the change. Operation on the low setting also turns off automatically after 30 minutes. NOTE: Once a heat setting is selected, heat will be felt within two to five minutes. WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when using the...

  • Page 116: To Open And Close The Hood

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. WARNING! • Be certain that the seatback is securely locked into position.
  • Page 117 Next, move to the outside of the vehicle and push the safety catch to the left. The safety catch is located under the center front edge of the hood. Hood Safety Catch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 To prevent possible damage, do not slam the hood to close it.

  • Page 118: Lights

    116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instrument panel lights, instrument panel light dimming, interior lights, and fog lights.

  • Page 119: Automatic Headlights - If Equipped

    Automatic Headlights — If Equipped This system automatically turns the headlights on or off according to ambient light levels. To turn the system on, rotate the headlight switch counterclockwise to the AUTO (A) position. When the system is on, the headlight time delay feature is also on.

  • Page 120: Daytime Running Lights - If Equipped

    118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you turn the headlights, park lights, or ignition switch ON again, the system will cancel the delay. If you turn the headlights off before the ignition, they will turn off in the normal manner. NOTE: The lights must be turned off within 45 seconds of turning the ignition OFF to activate this feature.

  • Page 121: Multifunction Control Lever

    Multifunction Control Lever The multifunction control lever controls the operation of the turn signals, headlight beam selection, and passing lights. The lever is located on the left side of the steering column. Multifunction Control Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Turn Signals Move the multifunction control lever up or down and the corresponding turn signal indicator in the instrument...

  • Page 122: Overhead Console Map/Reading Lights

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Highbeam/Lowbeam Select Switch Push the multifunction control lever away from you to switch the headlights to HIGH beam. Pull the lever toward you to switch the headlights back to LOW beam. Flash to Pass You can signal another vehicle with your headlights by lightly pulling the multifunction control lever toward you.

  • Page 123: Interior Lights

    Interior Lights The interior lights come on when a door is opened. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.

  • Page 124: Windshield Wipers And Washers

    122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The multifunction control lever operates the windshield wipers and washer when the ignition switch is in the ON position. The lever is located on the left side of the steering column. Windshield Wiper/Washer Control Rotate the end of the multifunction control lever to the first detent past the intermittent settings for low speed...

  • Page 125: Mist Feature

    regulate the wipe interval from a minimum of one cycle every second to a maximum of approximately 23 seconds between cycles. WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use.

  • Page 126: Headlights On With Wipers (Available With Auto Headlights Only)

    124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights On with Wipers (Available with Auto Headlights Only) When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned on if the headlight switch is placed in the AUTO (A) position. In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature.

  • Page 127: Tilt/Telescoping Steering Column

    WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column.

  • Page 128: Electronic Speed Control

    126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE outward or push it inward as desired. To lock the steering column in position, push the control handle inward until fully engaged. WARNING! Do not adjust the steering wheel while driving. The telescoping adjustment must be locked while driv- ing.

  • Page 129: To Activate

    To Activate Push and release the ON/OFF button located on the end of the speed control lever. The indicator light in the instrument cluster will illuminate to show that the speed control sys- tem is on. To turn the system off, push and release the ON/OFF button again.

  • Page 130: To Resume Speed

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pushing and releasing the ON/OFF button or turning off the ignition erases the set speed from memory. To Resume Speed If you deactivated the speed control without erasing the set speed from memory and your vehicle speed is above 20 mph (32 km/h), you can resume the previous set speed.

  • Page 131: Overhead Console

    On steep hills, a greater speed loss or gain may occur, so it may be preferable to drive without speed control. WARNING! Speed control can be dangerous where the system can’t maintain a constant speed. Your vehicle could go too fast for the conditions and you could lose control.

  • Page 132: Sunglasses Storage

    130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE These lights also turn on when a door is opened, or when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is turned fully upward, past the second detent. Sunglasses Storage At the rear of the console, a compartment is provided for the storage of a pair of sunglasses.

  • Page 133: Programming Homelink

    WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
  • Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) from the HomeLink buttons while keeping the EVIC display in view. For optimal training, point the battery end of the hand- held transmitter away from the HomeLink .
  • Page 135 This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). 1 — Garage Door Opener 2 — Training Button UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 6.

  • Page 136: Gate Operator/Canadian Programming

    134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to “time-out” (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.

  • Page 137: Reprogramming A Single Homelink Button

    Reprogramming A Single HomeLink Button To reprogram a channel that has been previously trained, follow these steps: 1. Turn the ignition switch to the ON/RUN position. 2. Press and hold the desired HomeLink button for 20 seconds until the EVIC display states “CHANNEL # TRAINING.”...

  • Page 138: General Information

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies...

  • Page 139: Opening Sunroof - Manually

    WARNING! • Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. •...

  • Page 140: Closing Sunroof - Express

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the switch in the forward position, the sunroof will close fully and then stop automatically. Release the switch once the sunroof stops moving. Closing Sunroof - Express Press the switch forward and release, and the sunroof will close automatically from any position.

  • Page 141: Sunshade Operation

    Sunshade Operation The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens. NOTE: The sunshade cannot be closed if the sunroof is open. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears.

  • Page 142: Electrical Power Outlets

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLETS There are two 12-volt electrical outlets on this vehicle. Both of the outlets are protected by a fuse. The front 12-volt power outlet has power available only when the ignition is ON. This outlet will also operate a conventional cigar lighter unit.

  • Page 143: Electrical Outlet Use With Engine Off

    The center console outlet is powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent engine starting. Center Console Power Outlet UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Electrical Outlet Use With Engine Off CAUTION! •...

  • Page 144: Cupholders

    142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Cupholders The front cupholders are located in the center console. Front Cupholders Rear Cupholders The rear seat cupholders are located in the center armrest between the rear seats. The cupholders are positioned forward in the armrest and side-by-side to provide conve- nient access to beverage cans or bottles while maintaining a resting place for the rear occupants’...

  • Page 145: Console Features

    CONSOLE FEATURES Sliding Center Console Armrest The center console armrest slides forward with three detents to provide flexibility for comfort, cupholder use, and shifting ease. Sliding Console Armrest UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Console Storage The center console has a storage compartment located underneath the armrest, and also contains a 12-volt power outlet and a molded-in coin holder (designed to hold various size coins).

  • Page 146: Rear Window Features

    144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Defroster The pushbutton for the rear window defroster is located on the mode knob of the climate control switch bank. Press this button to turn on the rear window defroster and the electric remote control heated mirrors (if equipped).
  • Page 147 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....148 Instrument Cluster ..... . 149 Instrument Cluster Description .
  • Page 148 146 UNDERSTANDING YOUR INSTRUMENT PANEL Electrical Disturbances ....175 AM Reception ..... . . 175 FM Reception .
  • Page 149 Operating Instructions - Satellite Mode ..197 Operating Instructions - Hands-Free Phone (If Equipped) ......199 Kicker High Performance Sound System With Driver-Selectable Surround (DSS) –...

  • Page 150: Understanding Your Instrument Panel

    148 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Instrument Cluster 3 — Glove Box 4 — Radio 5 — Heated Seat Switch 6 — ESP OFF Switch 7 — Hazard Warning Switch 8 — Climate Control 9 —...

  • Page 151: Instrument Cluster

    UNDERSTANDING YOUR INSTRUMENT PANEL 149 INSTRUMENT CLUSTER...

  • Page 152: Instrument Cluster Description

    150 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Press this button to change the display from odometer to either of two trip odometer settings.
  • Page 153 7. Electronic Throttle Control (ETC) Warning Light This light will turn on briefly as a bulb check when the ignition switch is turned ON. This light will also turn on while the engine is running if there is a problem with the Elec- tronic Throttle Control system.
  • Page 154 152 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, refer to Section 7 and follow the warnings under the Cooling System Pressure Cap paragraph.
  • Page 155 12. Electronic Stability Program (ESP)/Traction Control System (TCS) Indicator Light If this indicator light flashes during accelera- tion, ease up on the accelerator and apply as little throttle as possible. Adapt your speed and driving to the prevailing road conditions, and do not switch off the ESP.
  • Page 156 154 UNDERSTANDING YOUR INSTRUMENT PANEL 16. Seat Belt Reminder Light This light will turn on for five to eight seconds as a bulb check when the ignition switch is first turned ON. A chime will sound if the driver’s seat belt is unbuckled during the bulb check.
  • Page 157 20. Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the Anti-Lock Brake System (ABS).
  • Page 158 156 UNDERSTANDING YOUR INSTRUMENT PANEL remain on if the parking brake is applied or if a brake fault is detected. If the parking brake is not applied and the light remains on, or if the light does not turn on, have the light inspected by an authorized dealer.
  • Page 159 maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
  • Page 160 158 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Anti-Lock Brake Warning Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required.

  • Page 161: Electronic Vehicle Information Center (Evic)

    ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) Electronic Vehicle Information Center The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display. It is located in the instrument cluster below the speedometer. Vehicles UNDERSTANDING YOUR INSTRUMENT PANEL 159 equipped with steering wheel-mounted buttons (de- scribed in this section) are also equipped with the EVIC.
  • Page 162 160 UNDERSTANDING YOUR INSTRUMENT PANEL • Surround Sound Modes (If Equipped with Driver- Selectable Surround [DSS]) • Performance Features The system allows the driver to select information by pressing the following buttons mounted on the steering wheel. MENU Button Press and release the MENU button and the mode displayed will change between Trip Functions, Performance Pages, Navigation (If Equipped), System Warnings, System Status,...

  • Page 163: Electronic Vehicle Information Center (Evic) Displays

    Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the Electronic Vehicle Information Center (EVIC) displays the following messages: • Turn Signal On (with a continuous warning chime if the vehicle is driven more than 1 mi [1.6 km] with either turn signal on) •...

  • Page 164: Engine Oil Change Indicator System

    162 UNDERSTANDING YOUR INSTRUMENT PANEL • Left Rear Low Pressure (with a single chime) • Right Front Low Pressure (with a single chime) • Right Rear Low Pressure (with a single chime) • Check TPM System (with a single chime) •...

  • Page 165: Trip Functions

    Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the MENU button. To reset the oil change indica- tor system (after performing the scheduled maintenance) refer to the following procedure.
  • Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL Press the SCROLL button to cycle through all the Trip Computer functions. The Trip Functions mode displays the following. Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET”...

  • Page 167: Performance Features

    Elapsed Time Shows the total elapsed time of travel since the last reset when the ignition switch is in the ACC position. Elapsed time will increment when the ignition switch is in the ON or START position. Display Units of Measure in To make your selection, press and release the FUNC- TION SELECT button until “US”...
  • Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL The Performance Features include the following: • 0-60 mph (0-100 km/h) • Braking Distance • 1/8 Mile • 1/4 Mile • Instantaneous G-Force • Peak G-Force • Digital Speedometer To access, press and release the MENU button until Performance Features displays in the EVIC.
  • Page 169 Braking Distance When selected, this screen displays the vehicle’s braking distance and the speed at which the brake pedal was depressed. • This feature will only function when applying the brakes at speeds above 30 mph (48 km/h). • Engaging the parking brake will disable this feature. •...
  • Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL • The time and speed will continue to display until the FUNCTION SELECT button is pressed. • Pressing the FUNCTION SELECT button will clear the current run and display the vehicle’s best 1/8 mile (1/4 mile) run. •...

  • Page 171: Compass Display

    Compass Display COMPASS Button The compass readings indicate the direction the vehicle is facing. Press and release the COMPASS button to display one of eight com- pass readings and the outside temperature. Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually.
  • Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Variance Compass Variance is the difference between magnetic North and geographic North. In some areas of the country, the difference between magnetic and geographic North is great enough to cause the compass to give false readings.

  • Page 173: Driver-Selectable Surround Sound (Dss) - If Equipped

    1. Turn the ignition switch ON. 2. Press and hold the COMPASS button for approxi- mately two seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4. Press and release FUNCTION SELECT button until the proper variance zone is selected according to the map.

  • Page 174: Personal Settings (Customer Programmable Features)

    172 UNDERSTANDING YOUR INSTRUMENT PANEL Personal Settings (Customer Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK. Press and release the MENU button until Personal Set- tings displays in the EVIC. Use the SCROLL button to display one of the following choices.
  • Page 175 on the first press of the RKE UNLOCK button. To make your selection, press and release the FUNCTION SE- LECT button until “Driver Door 1st Press” or “All Doors 1st Press” appears. Sound Horn with Remote Key Lock When ON is selected, a short horn sound will occur when the RKE LOCK button is pressed.
  • Page 176 174 UNDERSTANDING YOUR INSTRUMENT PANEL Turn Headlights On with Remote Key Unlock When this feature is selected, the headlights will activate and remain on for up to 90 seconds when the doors are unlocked with the RKE transmitter. To make your selec- tion, press and release the FUNCTION SELECT button until “OFF,”...

  • Page 177: Radio General Information

    RADIO GENERAL INFORMATION Radio Broadcast Signals Your new radio will provide excellent reception under most operating conditions. Like any system, however, car radios have performance limitations, due to mobile op- eration and natural phenomena, which might lead you to believe your sound system is malfunctioning. To help you understand and save you concern about these “ap- parent”...

  • Page 178: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)

    176 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The radio, steering wheel radio controls, and 6-disc CD/DVD changer (if equipped) will remain active for up to 60 minutes after the ignition switch is turned OFF. Opening either door will cancel this feature. The time is programmable.

  • Page 179: Operating Instructions - Radio Mode

    Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
  • Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button (UConnect Hands-Free Phone) — If Equipped Press this button to operate the Hands-Free Phone (UConnect ) feature (if equipped). Refer to “Hands-Free Communication (UConnect )” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UConnect”...
  • Page 181 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in AM, FM or Satellite (if equipped) frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
  • Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
  • Page 183 Program Type 16-Digit Character Display Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
  • Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL • Angle – Repeatedly pressing SELECT will change the viewing angle if supported by the DVD disc (if equipped). NOTE: The available selections for each of the above entries varies depending upon the disc. NOTE: These selections can only be made while playing a DVD.
  • Page 185 Subtitle Language — If Equipped Selecting this item allows you to choose a default subtitle language (effective only if the language is supported by the disc). You can select a language not listed by scrolling down and selecting other. Enter the country code using the TUNE/SCROLL control knob to scroll up and down to select the number and then push to select.

  • Page 186: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)

    184 UNDERSTANDING YOUR INSTRUMENT PANEL SET Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET button. The symbol SET 1 will now show in the display window. Select the button (1-6) you wish to lock onto this station and press and release that button.
  • Page 187 CAUTION! The radio may shut down during extremely hot conditions. When this occurs, the radio will indicate “Disc Hot” and shut off until a safe temperature is reached. This shutdown is necessary to protect the optics of the DVD player and other radio internal components.

  • Page 188: Notes On Playing Mp3/Wma Files

    186 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the EJECT button for five seconds and all CDs will be ejected from the radio. The disc can be ejected with the radio and ignition OFF. SEEK Button (CD MODE) Press the right SEEK button for the next selection on the CD.
  • Page 189 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
  • Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL When using the MP3/WMA encoder to compress audio data to an MP3/WMA file, the bit rate and sampling frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3/WMA files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates.

  • Page 191: List Button (Disc Mode For Mp3/Wma Play)

    • Number of files and folders - Loading times will increase with more files and folders To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option before writing to the disc.
  • Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to the proper level. If the AUX audio is not loud enough, turn the device’s volume up.

  • Page 193: Sales Code Rer - Multimedia System - If Equipped

    Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to “Satellite Radio” in this section. Dolby Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

  • Page 194: Operating Instructions - Satellite Radio

    192 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If your vehicle is not equipped with UConnect , the unit will respond with a “Not Equipped With UConnect ” message when selecting controls related to this feature. A 6.5 in (16.5 cm) touch screen allows easy menu selec- tion, while the Advanced Voice Dialog System recognizes more than 1,000 words for audio, navigation, entertain- ment, and hands-free mobile phone use.

  • Page 195: Clock Setting Procedure

    Clock Setting Procedure The GPS receiver in this system is synchronized to the time data being transmitted by the GPS satellites. The satellites’ clock is Greenwich Mean Time (GMT). This is the worldwide standard for time. This makes the sys- tem’s clock very accurate once the appropriate time zone and daylight savings information is set.
  • Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL 3. When this feature is on, a check mark will appear in the box next to the words “Daylight Savings.” Touch the screen where the words “Daylight Savings” are dis- played to change the current setting. Setting the User Clock If you wish to set the clock to a time different from the system clock, you can manually adjust the time by...

  • Page 197: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)

    2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. When this feature is on, a check mark will appear in the box next to the words “Show Time if Radio is Off.” Touch the screen where the words “Show Time if Radio is Off”...

  • Page 198: Selecting Satellite Mode

    196 UNDERSTANDING YOUR INSTRUMENT PANEL To access the ESN/SID, refer to the following steps: ESN/SID Access With REQ/RES Radios With the ignition switch in the ON/RUN or ACC posi- tion and the radio on, press the SETUP button and scroll using the Tune/Scroll control knob until Sirius ID is selected.

  • Page 199: Reception Quality

    Reception Quality Satellite reception may be interrupted due to one of the following reasons: • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception in the form of short audio mutes. •...
  • Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button — REU Radio Pressing the INFO button will display information about Artist, Song Title, and Composer (if available). Pressing the INFO button again will close the INFO screen. RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows.

  • Page 201: Operating Instructions - Hands-Free Phone (If Equipped)

    SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.

  • Page 202: Kicker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped

    200 UNDERSTANDING YOUR INSTRUMENT PANEL KICKER HIGH PERFORMANCE SOUND SYSTEM WITH DRIVER-SELECTABLE SURROUND (DSS) – IF EQUIPPED Your vehicle is equipped with a state of the art audio amplifier that provides 5.1-channel surround sound from any stereo audio source. A new feature of the Kicker audio system offers the ability to choose surround sound for any audio source.

  • Page 203: Remote Sound System Controls

    REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the surface of the steering wheel at the 3 and 9 o’clock positions. Vehicles equipped with steering wheel-mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC). The EVIC features a driver-interactive display.

  • Page 204: Cd/Dvd Disc Maintenance

    202 UNDERSTANDING YOUR INSTRUMENT PANEL SCROLL Button When the EVIC is in the Compass/Temp/ Audio screen, press the SCROLL button to seek up and down radio stations, tracks, chapters, files, etc., depending on which radio is in the vehicle. CD/DVD DISC MAINTENANCE To keep the CD/DVD discs in good condition, take the following precautions: 1.

  • Page 205: Climate Controls

    CLIMATE CONTROLS Manual Air Conditioning and Heating System The Manual Temperature Control consists of a series of outer rotary dials and inner pushbuttons. UNDERSTANDING YOUR INSTRUMENT PANEL 203 Blower Control Use this control to regulate the amount of air forced through the ven- tilation system in any mode.
  • Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Use this control to regulate the tem- perature of the air inside the passenger compartment. The blue area of the scale indicates cooler temperatures while the red area indicates warmer temperatures. NOTE: If your air conditioning performance seems lower than expected, check the front of the A/C con- denser (located in front of the radiator) for an accumu- lation of dirt or insects.
  • Page 207 NOTE: For all settings except full cold or full hot, there is a difference in temperature between the upper and lower outlets. The warmer air flows to the floor outlets. This feature gives improved comfort during sunny but cool conditions. •...

  • Page 208: Operating Tips

    206 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • Continuous use of the recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended. • The use of the recirculation mode in cold or damp weather may cause windows to fog on the inside, because of moisture build-up inside the vehicle.
  • Page 209 Summer Operation The engine cooling system in air-conditioned vehicles must be protected with a high-quality antifreeze coolant to provide proper corrosion protection and to protect against engine overheating. A 50% solution of ethylene glycol antifreeze coolant in water is recommended. Refer to “Maintenance Procedures”...
  • Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL Outside Air Intake Make sure the air intake, located directly in front of the windshield, is free of obstructions such as leaves. Leaves collected in the air intake may reduce airflow, and if they enter the plenum, they could plug the water drains. In winter months, make sure the air intake is clear of ice, slush, and snow.
  • Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 Control Setting Suggestions for Various Weather Conditions...
  • Page 213 STARTING AND OPERATING CONTENTS Starting Procedures ..... 214 Automatic Transmission ....215 Keyless Go .
  • Page 214 212 STARTING AND OPERATING Traction ......230 Driving Through Water ....230 Flowing/Rising Water .
  • Page 215 Tire Chains ......261 Snow Tires ......262 Tire Rotation Recommendations .

  • Page 216: Starting And Operating

    214 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.

  • Page 217: Automatic Transmission

    Automatic Transmission The shift lever must be in the NEUTRAL or PARK position before you can start the engine. Apply the brakes before shifting into any driving gear. STARTING AND OPERATING 215 CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: •...

  • Page 218: Keyless Go

    216 STARTING AND OPERATING Keyless Go This function allows the driver to operate the ignition switch with the push of a button, as long as the ENGINE START/STOP button is installed and the Keyless Go igni- tion key (FOBIK) is in the passen- ger compartment.

  • Page 219: Normal Starting

    Normal Starting Using The ENGINE START/STOP Button (Tip Start) NOTE: Normal Starting of either a cold or a warm engine is obtained without pumping or depressing the accelerator pedal. Press and hold your foot on the brake pedal and then press and release the ENGINE START/STOP button twice.

  • Page 220: If Engine Fails To Start

    218 STARTING AND OPERATING If Engine Fails To Start WARNING! • Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. •...

  • Page 221: After Starting

    Then, turn the ignition switch to the START position and release it as soon as the starter engages. The starter motor will disengage automatically in 10 seconds. Once this occurs, release the accelerator pedal, turn the ignition switch to the LOCK position, wait 10 to 15 seconds, then repeat the normal starting procedure.

  • Page 222: Automatic Transmission

    220 STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
  • Page 223 • Shift lever position • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, de- pendent on the driving style, the driving situation, and the road characteristics. NOTE: • After selecting any driving position, wait a moment to allow the gear to engage fully before accelerating, especially when the engine is cold.

  • Page 224: Brake/Transmission Shift Interlock System

    222 STARTING AND OPERATING WARNING! Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is run- ning. Before exiting a vehicle, you should always shift the transmission into PARK, remove the key from the ignition, and apply the parking brake.

  • Page 225: 5-Speed Automatic Transmission

    Brake Interlock Override To activate the override, first insert the key into the ignition switch and turn it to the ACC or ON position. Then, press the pink-colored tab through the access port with a small flat-bladed screwdriver or alike. While pressing the override tab, move the shift lever out of the PARK position.
  • Page 226 224 STARTING AND OPERATING Gear Ranges PARK PARK supplements the parking brake by locking the transmission. The engine can be started in this range. Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. When parking on a flat surface, place the shift lever in the PARK position first, and then apply the parking brake.
  • Page 227 CAUTION! Damage to the shifter could result if the shift lever is moved out of PARK before the ignition is turned from the LOCK to ON position. REVERSE Shift into REVERSE gear only when the vehicle is com- pletely stopped. NEUTRAL In NEUTRAL, no power is transmitted from the engine to the drive axle.
  • Page 228 226 STARTING AND OPERATING DRIVE This range should be used for most city and highway driving. It provides the smoothest upshifts and down- shifts and the best fuel economy. The transmission automatically upshifts through 5th gear. The DRIVE position provides optimum driving characteristics under all normal operating conditions.
  • Page 229 A reset feature is available to allow the vehicle to be driven to an authorized dealer for service. To reset the transmission, use the following procedure: 1. Stop the vehicle. 2. Move the shift lever to the PARK position. 3. Turn OFF the engine. 4.

  • Page 230: Autostick

    228 STARTING AND OPERATING AUTOSTICK Autostick is a driver-interactive transmission that offers manual gear shifting to provide you with more control of the vehicle. Autostick allows you to maximize engine braking, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations.

  • Page 231: Autostick General Information

    one second. The transmission will now operate automati- cally, shifting between the five available gears. Autostick General Information • You can start out in 1st or 2nd gear. The system will ignore attempts to upshift at too low of a vehicle speed. •...

  • Page 232: Traction

    230 STARTING AND OPERATING Traction When driving on wet or slushy roads, it is possible for a wedge of water to build up between the tire and road surface. This is known as hydroplaning and may cause partial or complete loss of vehicle control and stopping ability.
  • Page 233 Shallow Standing Water Although your vehicle is capable of driving through shallow standing water, consider the following Caution and Warning before doing so. CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle.

  • Page 234: Parking Brake

    232 STARTING AND OPERATING WARNING! • Driving through standing water limits your vehi- cle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. • Driving through standing water limits your vehi- cle’s braking capabilities, which increases stop- ping distances.
  • Page 235 When parking on a hill, it is important to apply the parking brake before placing the shift lever in PARK, otherwise the load on the transmission locking mecha- nism may make it difficult to move the shift lever out of PARK.

  • Page 236: Brake System

    234 STARTING AND OPERATING WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Don’t leave the key in the ignition.

  • Page 237: Anti-Lock Brake System (Abs)

    Anti-Lock Brake System (ABS) The Anti-Lock Brake System (ABS) provides increased vehicle stability and brake performance under most braking conditions. The system automatically “pumps” the brakes during severe braking conditions to prevent wheel lock-up. The Electronic Brake Force Distribution (EBD) prevents the rear wheels from over-braking and provides greater control of available braking forces applied to the rear axle.
  • Page 238 236 STARTING AND OPERATING WARNING! • The Anti-Lock Brake System (ABS) contains sophisticated elec- tronic equipment that may be susceptible to interference caused by improperly installed or high output radio transmitting equipment. This interference can cause possible loss of anti-lock braking capability.

  • Page 239: Power Steering

    If both the Brake Warning Light and the ABS Light remain on, the ABS and EBD systems are not functioning. Immediate repair to the ABS system is required. POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces.

  • Page 240: Electronic Brake Control System

    238 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system commonly referred to as ESP. This system includes the ABS (Anti-Lock Brake System), the TCS (Traction Control System), the BAS (Brake Assist System), and the ESP (Electronic Stability Program).

  • Page 241: Tcs (Traction Control System)

    TCS (Traction Control System) This system monitors the amount of wheel spin of each driven wheel. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability. BAS (Brake Assist System) This system complements the ABS by optimizing the vehicle braking capability during emergency braking...

  • Page 242: Esp (Electronic Stability Program)

    240 STARTING AND OPERATING ESP (Electronic Stability Program) This system enhances directional control and stability of the vehicle under various driving conditions. The ESP corrects for oversteering and understeering the vehicle by applying the brake of the appropriate wheel. Engine power may also be reduced to assist in counteracting the condition of oversteer or understeer and help the vehicle maintain the desired path.
  • Page 243 WARNING! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. The ESP cannot prevent accidents, including those result- ing from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
  • Page 244 242 STARTING AND OPERATING The ESP OFF switch is located in the switch bank near the bottom center of the instrument panel. To enter the “Par- tial Off” mode, momentarily depress the ESP OFF switch and the ESP/TCS Indicator Light will illuminate. To turn the ESP ON again, momentarily depress the ESP OFF switch and the ESP/TCS Indicator Light will turn off.
  • Page 245 this message. The “ESP OFF” message may appear in the Electronic Vehicle Information Center (EVIC). Refer to “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4. To turn ESP ON again, momentarily depress the ESP OFF switch. NOTE: The ESP OFF message will display and the audible chime will sound when the shift lever is moved into the PARK position from any position other than PARK and then moved out of the PARK position.

  • Page 246: Synchronizing Esp

    244 STARTING AND OPERATING WARNING! With the ESP switched OFF, the enhanced vehicle stability offered by ESP is unavailable. In an emer- gency evasive maneuver, the ESP system will not en- gage to assist in maintaining stability. The “Full Off” ESP mode is intended for off-highway or off-road only.

  • Page 247: Tire Safety Information

    NOTE: • The ESP/TCS Indicator Light and the ESP/BAS Mal- function Indicator Light will turn on momentarily each time the ignition switch is turned ON. • Each time the ignition is turned ON, the ESP System will be ON even if it was turned OFF previously. •...
  • Page 248 246 STARTING AND OPERATING NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
  • Page 249 Tire Sizing Chart Size Designation: P = Passenger Car tire size based on U.S. design standards ...blank... = Passenger Car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%)
  • Page 250 248 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...

  • Page 251: Tire Identification Number

    Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation —...

  • Page 252: Tire Loading And Tire Pressure

    250 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side B-Pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
  • Page 253 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
  • Page 254 252 STARTING AND OPERATING 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
  • Page 255 STARTING AND OPERATING 253...

  • Page 256: Tires - General Information

    254 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 257: Tire Inflation Pressures

    2. Economy— Improper inflation pressures can cause uneven wear pat- terns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under-inflation also increases tire rolling resistance and results in higher fuel consumption. 3.
  • Page 258 256 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...

  • Page 259: Radial Ply Tires

    Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.

  • Page 260: Tire Spinning

    258 STARTING AND OPERATING Tire Spinning When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 35 mph (55 km/h). Refer to the paragraph on “Freeing A Stuck Vehicle” in Section 6. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure.

  • Page 261: Life Of Tire

    These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the tread wear indicators, the tire should be replaced. Many states have laws requiring tire replacement at this point.

  • Page 262: Replacement Tires

    260 STARTING AND OPERATING Replacement Tires The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance when replacement is needed.

  • Page 263: Alignment And Balance

    CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer readings. Alignment And Balance Poor suspension alignment may result in: • Fast tire wear. • Uneven tire wear, such as feathering and one-sided wear.

  • Page 264: Snow Tires

    262 STARTING AND OPERATING SNOW TIRES Some areas of the country require the use of snow tires during the winter. Standard tires are of the all season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall. If you need snow tires, select tires equivalent in size and type to the original equipment tires.

  • Page 265: Tire Rotation - Standard Tires

    Tire Rotation — Standard Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram. STARTING AND OPERATING 263 Tire Rotation — Optional Tires The suggested rotation method is the “side-to-side” as shown in the following diagram.

  • Page 266: Tire Pressure Monitor System (Tpms)

    264 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) • The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold placard pressure. • The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C).
  • Page 267 pressures. The vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. − For example, your vehicle may have a recom- mended cold (parked for more than three hours) placard pressure of 30 psi (207 kPa).

  • Page 268: Premium System

    266 STARTING AND OPERATING NOTE: • The TPMS is not intended to replace normal tire care and maintenance or to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure.
  • Page 269 • CORAX Receiver module, • Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and • TPM Telltale Light The matching full size spare wheel and tire assembly (if equipped) has a TPM sensor. The full size spare can be used in place of any of the four road tires.
  • Page 270 268 STARTING AND OPERATING Should this occur, you should stop as soon as possible and inflate the tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the TPM Telltale Light will turn off.

  • Page 271: General Information

    If the ignition key is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the TPM Telltale Light will no longer flash, and the CHECK TPM SYSTEM message will no longer display, and a pressure value will display in place of the dashes.

  • Page 272: Fuel Requirements

    270 STARTING AND OPERATING FUEL REQUIREMENTS 6.1L Engine The 6.1L engine is designed to meet all emissions regulations and provide excel- lent fuel economy and performance when using high-quality premium unleaded gasoline with an octane rating of 91 or higher. Light spark knock at low engine speeds is not harmful to your engine.

  • Page 273: Gasoline/Oxygenate Blends

    Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.

  • Page 274: Materials Added To Fuel

    272 STARTING AND OPERATING Materials Added to Fuel All gasoline sold in the United States is required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and they would result in additional cost. Therefore, you should not have to add anything to the fuel.

  • Page 275: Carbon Monoxide Warnings

    Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.

  • Page 276: Adding Fuel

    274 STARTING AND OPERATING ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. Use a finger to pull open the door. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.

  • Page 277: Loose Fuel Filler Cap Message

    WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.

  • Page 278: Vehicle Loading

    276 STARTING AND OPERATING VEHICLE LOADING The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information should be used for passenger and luggage loading as indicated. Do not exceed the specified Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight Rating (GAWR).

  • Page 279: Overloading

    WARNING! Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory...

  • Page 280: Trailer Towing

    278 STARTING AND OPERATING NOTE: Refer to the “Vehicle Certification Label” affixed to the rear of the driver’s door for your vehicle’s GVWR and GAWRs. TRAILER TOWING Trailer towing with this vehicle is not recommended. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Recreational towing for this vehicle is not recommended.

  • Page 281: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....280 If Your Engine Overheats ....280 TIREFIT Tire Repair .

  • Page 282: Hazard Warning Flasher

    280 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The hazard warning switch is located in the switch bank near the bottom center of the instrument panel. Depress the switch to activate the flashers. When activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.

  • Page 283: Tirefit Tire Repair

    NOTE: There are steps that you can take to slow down an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to the engine cooling system and turning off the A/C removes this heat.
  • Page 284 282 WHAT TO DO IN EMERGENCIES The TIREFIT system is located under an access panel in the trunk. TIREFIT Location Tire Fit Kit 1. Air pump hose 2. Power plug and cable 3. AIR PUMP switch 4. Pressure gauge 5. TIREFIT sealant bottle 6.
  • Page 285 WARNING! • Do not attempt to repair a tire on the side of the vehicle close to traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or repairing a tire. • Cuts or punctures larger than approximately 0.16 in (4 mm), tire damage caused by driving with extremely low tire pressure or on a flat tire, or a damaged wheel can pose a hazard while driving.
  • Page 286 284 WHAT TO DO IN EMERGENCIES 9. Press the switch 3 on the air pump to I (ON). The air pump should start to inflate the tire and the tire sealant (white fluid) will flow from the sealant bottle 5 through the TIREFIT sealant hose 6 and into the tire.
  • Page 287 20. Release the parking brake and drive the vehicle for approximately 10 minutes to ensure optimum distribu- tion of the tire sealant within the tire. 21. Turn on the hazard warning flashers. 22. Move the shift lever to the PARK position, turn OFF the engine, and set the parking brake.

  • Page 288: Jump Starting

    286 WHAT TO DO IN EMERGENCIES NOTE: • If a pressure of at least 19 psi (1.3 bar) cannot be maintained in the tire, the tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance.
  • Page 289 NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump-starting. 1. Wear eye protection and remove any metal jewelry such as watchbands or bracelets that might make an inadvertent electrical contact.
  • Page 290 288 WHAT TO DO IN EMERGENCIES 6. Connect the other cable, first to the negative terminal of the booster battery and then to the engine ground (-) of the vehicle with the discharged battery. Make sure you have a good contact on the engine ground. Refer to the following illustration for jump-starting connections.

  • Page 291: Freeing A Stuck Vehicle

    WARNING! • You should not try to start your vehicle by pushing or towing. • Do not connect the cable to the negative post of the discharged battery. The resulting electrical spark could cause the battery to explode. • During cold weather when temperatures are be- low the freezing point, electrolyte in a discharged battery may freeze.
  • Page 292 290 WHAT TO DO IN EMERGENCIES CAUTION! • When “rocking” a stuck vehicle by moving be- tween “1st” and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Racing the engine or spinning the wheels too fast may lead to transmission overheating and failure.

  • Page 293: Towing A Disabled Vehicle

    TOWING A DISABLED VEHICLE Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position. The only ap- proved method of towing without the ignition key is with a flat-bed truck. Proper towing equipment is neces- sary to prevent damage to the vehicle.

  • Page 294: Towing This Vehicle Behind Another Vehicle With A Tow Dolly

    292 WHAT TO DO IN EMERGENCIES CAUTION! • Do not attempt to tow this vehicle from the front with sling type towing equipment. Damage to the front fascia will result. • If the transmission is not operative or if the vehicle is to be towed more than 30 mi (48 km), then the only approved method of towing is with a flat-bed truck.

  • Page 295: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 6.1L ....296 Onboard Diagnostic System — OBD II ..297 Loose Fuel Filler Cap ....297 Emissions Inspection And Maintenance Programs .
  • Page 296 294 MAINTAINING YOUR VEHICLE Power Steering — Fluid Check ... . 310 Front And Rear Suspension Ball Joints ..311 Steering Linkage ..... . 311 Body Lubrication .
  • Page 297 Center Tail/Backup Light ....340 Center High-Mounted Stop Light (CHMSL) . . . 340 License Light ......340 Fluid Capacities .

  • Page 298: Maintaining Your Vehicle

    296 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 6.1L 1 — Remote Jump-Start Positive Battery Post 2 — Fuses (Integrated Power Module) 3 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Access Cover 5 — Coolant Bottle 6 — Power Steering Fluid 7 —...

  • Page 299: Onboard Diagnostic System - Obd Ii

    ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.

  • Page 300: Emissions Inspection And Maintenance Programs

    298 MAINTAINING YOUR VEHICLE Trip Odometer button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the MIL. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...

  • Page 301: Replacement Parts

    5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition key or start the engine. This means that the vehicle’s OBD II system is not ready and you should not proceed to the I/M station.

  • Page 302: Dealer Service

    300 MAINTAINING YOUR VEHICLE DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these service manuals before attempting any procedure yourself.

  • Page 303: Engine Oil

    Engine Oil Checking Oil Level To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about five minutes after a fully warmed engine is shut off or before starting the engine after it has sat overnight.
  • Page 304 302 MAINTAINING YOUR VEHICLE Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and meet the requirements of Chrysler Material Standard MS-10725.

  • Page 305: Engine Oil Filter

    Materials Added to Engine Oil The manufacturer strongly recommends against the addi- tion of any additives (other than leak detection dyes) to the engine oil. Engine oil is an engineered product and its performance may be impaired by supplemental additives. Disposing of Used Engine Oil and Oil Filters Care should be taken in disposing of used engine oil and oil filters from your vehicle.

  • Page 306: Spark Plugs

    304 MAINTAINING YOUR VEHICLE Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emissions control. New plugs should be installed at the specified mileage. The entire set should be replaced if there is any malfunction due to a faulty spark plug.

  • Page 307: Catalytic Converter

    Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emissions control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
  • Page 308 306 MAINTAINING YOUR VEHICLE WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.

  • Page 309: Maintenance-Free Battery

    MAINTAINING YOUR VEHICLE 307 Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump starting (Refer to Jump Starting in Section 6 of this manual).
  • Page 310 308 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area immediately with large amounts of water.

  • Page 311: Air Conditioner Maintenance

    Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time.

  • Page 312: A/C Air Filter - If Equipped

    310 MAINTAINING YOUR VEHICLE Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.

  • Page 313: Front And Rear Suspension Ball Joints

    WARNING! Fluid level should be checked on a level surface and with the engine OFF to prevent injury from moving parts and to ensure accurate fluid level reading. Do not overfill. Use only manufacturer’s recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.

  • Page 314: Windshield Wiper Blades

    312 MAINTAINING YOUR VEHICLE The external lock cylinders should be lubricated twice a year, preferably in the Fall and Spring. Apply a small amount of a high quality lubricant such as MOPAR Lock Cylinder Lubricant or equivalent directly into the lock cylinder.

  • Page 315: Exhaust System

    WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.

  • Page 316: Cooling System

    314 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position. The fan is tempera- ture controlled and can start at any time the ignition switch is in the ON position.
  • Page 317 drain from the coolant recovery bottle. DO NOT RE- MOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown in the Maintenance Schedule in Section If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner.
  • Page 318 316 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to five years or 100,000 mi (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
  • Page 319 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated.
  • Page 320 318 MAINTAINING YOUR VEHICLE service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill.

  • Page 321: Hoses And Vacuum/Vapor Harnesses

    • Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean, also. • Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install ONLY the correct type thermostat.

  • Page 322: Brake System

    320 MAINTAINING YOUR VEHICLE Care should be taken with installing quick connect fittings to ensure they are properly installed and fully connected. See your authorized dealer for service. Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Suggested service intervals can be found in the Mainte- nance Schedule in Section 8.
  • Page 323 necessarily an indication of leakage. Actual dripping of hot fluid when systems are under pressure (during vehicle operation), should be noted before a hose is replaced based on leakage. • Inspect the brake hoses whenever the brake system is serviced and at every engine oil change. Inspect hy- draulic brake hoses for surface cracking, scuffing, or worn spots.

  • Page 324: Automatic Transmission

    322 MAINTAINING YOUR VEHICLE Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. WARNING! • Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire.
  • Page 325 CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than that recommended by the manufacturer will result in more frequent fluid and filter changes.

  • Page 326: Front And Rear Wheel Bearings

    324 MAINTAINING YOUR VEHICLE Special Additives Automatic Transmission Fluid (ATF) is an engineered product and its performance may be impaired by supple- mental additives. Therefore, do not add any fluid addi- tives to the transmission. The only exception to this policy is the use of special dyes to aid in detecting fluid leaks.
  • Page 327 • Salt in the air near seacoast localities. • Atmospheric fallout/industrial pollutants. Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or a mild car wash soap, and rinse the panels completely with clear water.
  • Page 328 326 MAINTAINING YOUR VEHICLE • If your vehicle is damaged due to an accident or similar cause that destroys the paint and protective coating, have your vehicle repaired as soon as pos- sible. The cost of such repairs is considered the respon- sibility of the owner.
  • Page 329 Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and MOPAR Total Clean or equivalent.

  • Page 330: Cleaning The Center Console Cupholders

    328 MAINTAINING YOUR VEHICLE quarter window equipped with the radio antenna. Do not use scrapers or other sharp instruments that may scratch the elements. When cleaning the rear view mirror, spray cleaner on the towel or rag that you are using. Do not spray cleaner directly on the mirror.

  • Page 331: Fuses

    FUSES Integrated Power Module (IPM) The Integrated Power Module (IPM) is located in the engine compartment. This module contains fuses and relays. Integrated Power Module MAINTAINING YOUR VEHICLE 329 CAUTION! • When installing the integrated power module cover, it is important to ensure the cover is prop- erly positioned and fully latched.
  • Page 332 330 MAINTAINING YOUR VEHICLE Cartridge Mini- Cavity Description Fuse Fuse — 15 Amp Washer Motor Blue — 25 Amp Powertrain Control Mod- Neutral ule (PCM) — 25 Amp Ignition Run/Start Neutral — 25 Amp EGR Solenoid/Alternator Neutral — — — —...

  • Page 333: Rear Power Distribution Center

    MAINTAINING YOUR VEHICLE 331 Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Access Panel...
  • Page 334 332 MAINTAINING YOUR VEHICLE CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
  • Page 335 Cavity Cartridge Mini- Description Fuse Fuse — 15 Amp Diagnostic Link Connec- Blue tor (DLC)/Wireless Con- trol Module (WCM)/ Wireless Ignition Node (WIN) — 20 Amp Power Outlet Yellow — — — 11 * — — — 12 * — —...
  • Page 336 334 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description Fuse Fuse — 10 Amp Ignition Run — 5 Amp Cluster/Electronic Stabil- Orange ity Program (ESP)/ Powertrain Control Mod- ule (PCM)/STOP LIGHT Switch — 10 Amp Door Modules/Power Mirrors/Steering Control Module (SCM) —...

  • Page 337: Vehicle Storage

    Cavity Cartridge Mini- Description Fuse Fuse 30 Amp — Rear Window Defroster Pink 20 Amp — Amplifier - if equipped/ Blue Sunroof - if equipped * Cavities 11, 12, and 13 contain self-resetting fuses (circuit breakers) that are only serviceable by an autho- rized dealer.

  • Page 338: Replacement Light Bulbs

    336 MAINTAINING YOUR VEHICLE REPLACEMENT LIGHT BULBS LIGHT BULBS — Interior Rear Courtesy/Reading Lights....W5W Rear Compartment (Trunk) Light ... . . 562 Overhead Console Reading Lights.

  • Page 339: Bulb Replacement

    BULB REPLACEMENT Low Beam Headlight, High Beam Headlight, and Park/Turn Light — Models with High Intensity Discharge (HID) Headlights HID Headlights The headlights are a type of high voltage discharge tube. High voltage can remain in the circuit even with the HEADLIGHT switch off and the key removed.

  • Page 340: Front/Rear Side Marker Light

    338 MAINTAINING YOUR VEHICLE Front/Rear Side Marker Light 1. Remove the front/rear side marker. Use a fiber stick or similar tool to gently pry the light on the outboard side to disengage the clip. NOTE: • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to scratch the paint.
  • Page 341 3. Remove the fasteners from the back of the tail light assembly. 4. Pull back the trunk liner. 5. Remove the remaining fasteners from the back of the tail light assembly. 6. Pull the tail light assembly clear from the vehicle to access the bulbs.
  • Page 342 340 MAINTAINING YOUR VEHICLE 11. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise. 12. Reinstall the tail light assembly, fasteners, electrical connector, and trunk liner. 13. Close the trunk. Center Tail/Backup Light See your authorized dealer for bulb replacement.

  • Page 343: Fluid Capacities

    MAINTAINING YOUR VEHICLE 341 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 19 Gallons 72 Liters Engine Oil with Filter 6.1 Liter Engine (SAE 0W-40) 7 Quarts 6.6 Liters Cooling System * 6.1 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile 15 Quarts 14.4 Liters Formula) or equivalent * Includes heater and coolant recovery bottle filled to MAX level.

  • Page 344: Fluids, Lubricants And Genuine Parts

    342 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (6.1L) Oil Filter (6.1L) Spark Plugs (6.1L) Fuel Selection (6.1L) Fluids, Lubricants, and Genuine Parts MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and...
  • Page 345 Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Rear Axle Fluids, Lubricants, and Genuine Parts MOPAR ATF+4 Automatic Transmission Fluid MOPAR DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids.

  • Page 347: Maintenance Schedules

    MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..346 Maintenance Schedule ....346 Required Maintenance Intervals ... 348...

  • Page 348: Emission Control System Maintenance

    346 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type, must be done at the times or mileages specified to ensure the continued proper functioning of the Emission Control System. These, and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
  • Page 349 • Change your engine oil more often if you drive your vehicle for an extended period of time. • Under no circumstances should oil change intervals exceed 6,000 mi (10 000 km) or six months, whichever comes first. Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change.
  • Page 350 348 MAINTENANCE SCHEDULES Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate the tires. If using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if nec- essary. Inspect the brake linings, and replace if necessary. Replace the air conditioning filter (if equipped).
  • Page 351 Maintenance Items Replace the engine air cleaner filter. Change the rear axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or fre- quent trailer towing. Change the automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing.
  • Page 352 350 MAINTENANCE SCHEDULES WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
  • Page 353 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......353 Prepare For The Appointment .
  • Page 354 352 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......358 Treadwear ......359 Traction Grades .

  • Page 355: Suggestions For Obtaining Service For Your Vehicle

    SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.

  • Page 356: Chrysler Llc Customer Center

    354 IF YOU NEED CONSUMER ASSISTANCE high quality service. The manufacturer’s authorized deal- ers have the facilities, factory-trained technicians, special tools, and the latest information to ensure the vehicle is fixed correctly and in a timely manner. This is why you should always talk to an authorized dealer’s service manager first.

  • Page 357: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.

  • Page 358: Warranty Information (U.s. Vehicles Only)

    356 IF YOU NEED CONSUMER ASSISTANCE WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 359: In Canada

    To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administra- tor, NHTSA, 400 Seventh Street, SW., Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.

  • Page 360: Department Of Transportation Uniform Tire Quality Grades

    358 IF YOU NEED CONSUMER ASSISTANCE • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.

  • Page 361: Treadwear

    Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
  • Page 362 360 IF YOU NEED CONSUMER ASSISTANCE Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law. WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
  • Page 363 INDEX...
  • Page 364 362 INDEX About Your Brakes ....232,234 ABS (Anti-Lock Brake System) ... . 235,238 Adding Engine Coolant (Antifreeze) .
  • Page 365 Auto Unlock, Doors ..... . . 31 Automatic Dimming Mirror ....75 Automatic Door Locks .
  • Page 366 364 INDEX Master Cylinder ..... . . 321 Parking ......232 Warning Light .
  • Page 367 Cold Weather Operation ....217 Compact Disc (CD) Maintenance ... . . 202 Compass .
  • Page 368 366 INDEX Diagnostic System, Onboard ....297 Digital Video Disc (DVD) Player ... . . 191 Dimmer Switch, Headlight .
  • Page 369 Break-In Recommendations ....67 Checking Oil Level ..... 301 Compartment .
  • Page 370 368 INDEX Flashers Hazard Warning ..... . . 280 Turn Signal ..... . 70,119,152 Flash-To-Pass .
  • Page 371 Fueling ....... 274 Fuses ....... . 329 Garage Door Opener (HomeLink ) .
  • Page 372 370 INDEX Washers ......312 Heated Mirrors ......77 Heated Seats .
  • Page 373 Knee Bolster ......46 Lane Change and Turn Signals ....119 Lap/Shoulder Belts .
  • Page 374 372 INDEX Illuminated Entry ..... . . 20 Instrument Cluster ....116,150 Intensity Control .
  • Page 375 Maintenance Free Battery ....307 Maintenance, General ..... 300 Maintenance Procedures .
  • Page 376 374 INDEX Change Interval ..... . . 301 Checking ......301 Dipstick .
  • Page 377 Mirrors ......76 Outlet (Auxiliary Electrical Outlet) ..140 Seats .
  • Page 378 376 INDEX Remote Keyless Entry (RKE) ....21 Remote Sound System (Radio) Controls ..201 Remote Starting System ....27 Remote Trunk Release .
  • Page 379 Seats ....... . . 109 Adjustment ......109 Head Restraints .
  • Page 380 378 INDEX Spark Plugs ......304,342 Specifications Fuel (Gasoline) ......342 Oil .
  • Page 381 Theft Alarm (Security Alarm) ....18 Theft System (Security Alarm) ....18 Tilt Steering Column .
  • Page 382 380 INDEX Trailer Towing ......278 Transmission ......322 Automatic .
  • Page 383 Viscosity, Engine Oil ..... . 302 Voice Recognition System (VR) ....104 Warning Flasher, Hazard .
  • Page 384 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
  • Page 385 81-226-0810 First Edition Printed in U.S.A.

This manual is also suitable for:

2008 lc22 challenger srt8Challenger srt8 2008

Table of Contents

Save PDF
