Needle-nose pliers
•
4-mm Allen wrench (if you want to reverse the direction that
the front door opens)
•
Keys to the rack doors and side panels
•
13-mm wrench (for rack removal from pallet)
•
17-mm wrench (for rack removal from pallet)
Removing and Replacing the Rack Doors
WARNING:
never attempt to remove or install them by yourself.
WARNING:
and accidentally injure someone.
Removing the Front Door
1 Pull the door latch and open the front door all the way (see Figure 1-1).
2 While holding the door, pull the hinge pin upward so that it clears the
door's hinge-pin housing (see Figure 1-1).
The hinge pin's retention clip prevents the hinge from being pulled out of
the hinge body.
8
Installation Guide
Because of the size and weight of the rack cabinet doors,
When storing the doors, lay the doors flat so they do not fall over
