Standard LCD icon configurations (2-way only)

Icon
The transmit icon will be displayed while the remote control is
transmitting a command to the vehicle.
Icon
The signal icon will be displayed if a command is transmitted to
the vehicle but the command page is not received.
Icon
The receive icon will be displayed while the remote control is
receiving a page from the vehicle.
Icon
The auxiliary and sensor icons will display which auxiliary is oper-
ating, or which security sensor (zone 2,4 or 7) is in Warn Away
or alarm state.
Icon
The garage door icon—for use with optional 519H2.
and
The above Warn Away
tripped, but not to full alarm.
and
The above icons will display when a security feature has been
tripped to a full alarm condition.
© 2008 directed electronics
Icons
displays when a security feature has been
®
Icons
®
9
