Door Closing and Door Alignment

IMPORTANT: To comply with American Disabilities Act (ADA)
guidelines, fully retract the rollers into the cabinet to lower the
refrigerator.
Door Closing
The base grille covers the leveling screws and roller assemblies
located at the bottom of the refrigerator cabinet below the freezer
drawer. Before making adjustments, remove the base grille and
move the refrigerator to its final location.
1. Remove the base grille. Grasp the grille firmly and pull it
toward you.
2. Move the refrigerator to its final location.
NOTE: To allow the refrigerator to roll easier, raise the leveling
legs off the floor by turning the leveling screws
counterclockwise. The front rollers will be touching the floor.
3. So the doors will close easier, use a
leveling screws clockwise. This will raise the front of the
refrigerator tilting it slightly downward to the rear. Turn both
leveling screws the same amount.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the leveling screws. This
makes it easier to turn the screws.
A. Leveling screw
B. Front roller
4. Open both doors again to make sure they close as easily as
you like and that they stay closed. If not, tilt the refrigerator
slightly more to the rear by turning both leveling screws to the
right. It may take several more turns.
NOTE: To keep the refrigerator level, you should turn both
leveling screws the same amount.
5. Replace the base grille.
Pull open the freezer drawer.
Align the three clips on the back of the base grille with the
three tabs at the base of the refrigerator.
Push the base grille in toward the refrigerator until it is
firmly in place.
B. Clip
" hex driver to turn both
"
A
B
A
B
A. Tab
Door Alignment
If the space between the refrigerator doors and freezer drawer
looks uneven, you can adjust it using the following instructions:
1. Remove the top hinge cover.
2. Loosen the top hinge screws using a
3. Have someone hold the door in place or put a spacer between
the doors and drawer.
4. Tighten the top hinge screws once the door is in the desired
location.
5. Replace the top hinge cover.
FILTERS AND
ACCESSORIES

Water Filtration System

Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
Water Filter Status Light
The water filter status light on the control panel will help you know
when to order and replace the water filter.
GOOD - The water filter icon on the control lights up in BLUE.
ORDER a replacement filter - The water filter icon on the
control lights up in YELLOW.
REPLACE the water filter - The water filter icon on the control
lights up in RED and "Replace Filter" will appear on the
display.
EXPIRED - The water filter icon lights up in RED and "Replace
Filter" flashes on the display.
NOTE: If water flow to your water dispenser or ice maker
decreases noticeably, change the filter sooner. The disposable
water filter should be replaced at least every 6 months,
depending on your water quality and usage.
After changing the water filter, reset the status. Press and hold
the WATER FILTER button for 3 seconds. When the system is
reset, the water filter icon will return to its BLUE color and the
words "Replace Filter" will disappear from the display.
Changing the Water Filter
1. Locate the water filter in the top-right corner of the refrigerator
compartment.
2. Lift open the filter cover door. The filter will be released and
then eject as the door is opened.
3. When the door is completely open, pull the filter straight out.
NOTE: There may be some water in the filter. Some spilling
may occur. Use a towel to wipe up any spills.
" socket or wrench.
9
