- Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Headrest Video Monitor MODEL HVM500...
-
Page 3: Table Of Contents
Table of Contents Warranty ..........4 Safety Instructions . -
Page 4: Limited Three-Year Warranty
Limited Three-Year Warranty For a period of THREE YEARS from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any VIDEO MONITOR (hereafter the "UNIT"), which proves to be defective in workmanship or material defect under normal and reason- able use during the first 3 years after the purchase and installation of the unit provided the following conditions... -
Page 5: Safety Instructions
Safety Instructions WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE INCLUDED HARDWARE. THIS MONITOR IS ONLY DESIGNED FOR REAR SEAT PASSENGER VIEWING AND IS NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION. -
Page 6: Important Information
Important Information FCC NOTICE This device complies with Part 15 of FCC rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer- ence that may cause undesired operation. -
Page 7: Basic Operation
Basic Operation 2 3 1 6 MONITOR DESCRIPTION Screen - TFT active matrix LCD screen. Input jack - for audio/video source. Power/Source button - press to turn the monitor on/off or change video source. Press to turn the monitor on. Press for more than three seconds to turn the monitor off. -
Page 8: On-Screen Menus
On-Screen Menus The Setup Menu is a list of programming selec- tions that control system operation and screen settings. Each selection has a list of settings that can be changed to optimize system operation. Some settings may have additional settings. Notes that include any specific programming instructions for these are included under the selection heading. -
Page 9: Setup Menu Descriptions And Operation
SETUP MENU DESCRIPTIONS AND OPERATION Following are explanations of the many settings that can be changed to customize the operation of your Rear Seat Entertainment system. To change the settings described, follow the directions in the on-screen menu’s section or the special instructions in each menu. SELECTION VOLUME CHANNEL (TVM300 ONLY) -
Page 10: System Settings Menu
IMPORTANT! Any changes in the following menus must be written into the MCB1000 and ESP/ESP2 software. Before the menu is exited the Write to System procedure must be completed. SYSTEM SETTINGS MENU SELECTION PASSIVE/ACTIVE ARMING CHIRPS ON/OFF IGNITION LOCK ON/OFF IGNITION UNLOCK ON/OFF PASSIVE/ACTIVE LOCKING WRITE TO SYSTEM... -
Page 11: Assign Source Names Menu
FM MODULATOR ANTENNA TV CATV STD WRITE TO SYSTEM ASSIGN SOURCE NAMES MENU NOTE: In this menu use the monitor’s MODE button or the remote’s MENU button to toggle through the available choices for source names. SELECTION SOURCE 1: AV1 SOURCE 2: AV2 SOURCE 3: AV3 WRITE TO SYSTEM... -
Page 12: Assign Trigger Names Menu
ASSIGN TRIGGER NAMES MENU NOTE: In this menu use the monitor’s MODE button or the remote’s MENU button to toggle through the available choices for zone names. SELECTION ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8 WRITE TO SYSTEM... -
Page 13: Installation
Installation MONITOR SPECIFICATIONS Screen size 5" Resolution 74,880 pixels View angle Top 30 degrees Bottom 10 degrees Left 45 degrees Right 45 degrees Video system ntsc/pal Osd language English Power requirements 10 - 15 vdc Operating temp. 35 - 115 degrees fahrenheit INSTALLATION OPTIONS The Directed HVM 500 5"... -
Page 14: Wiring Guide
Wiring Guide WIRING PRECAUTIONS Read all wiring information before attempting to install this monitor. Use only solder and tape or quality solder- less connectors when terminating wires. Incorrect or poor connections may cause damage to the monitor or the vehicle. Disconnect the ground wire from the bat- tery or remove the fuses for any impacted circuits before making any connections. - Page 15 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security, car stereo products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered.
