- Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Headrest Monitor Bucket MODEL HRB100...
-
Page 3: Table Of Contents
Table of Contents Limited Three-Year Warranty ........4 Safety Instructions . -
Page 4: Limited Three-Year Warranty
Limited Three-Year Warranty For a period of THREE YEARS from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any HEADREST BUCKET (hereafter the "UNIT"), which proves to be defective in workmanship or material defect under normal and reason- able use during the first 3 years after the purchase and installation of the unit provided the following conditions... -
Page 5: Safety Instructions
Safety Instructions WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE INCLUDED HARDWARE. THIS UNIT IS ONLY DESIGNED FOR REAR SEAT PASSENGER VIEWING AND IS NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION. -
Page 6: Important Information
Important Information FCC NOTICE This device complies with Part 15 of FCC rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer- ence that may cause undesired operation. -
Page 7: Basic Operation
Basic Operation DESCRIPTION Monitor bucket Receiver bracket Release tab Hinge Hot foot connector Mounting feet VIEWING ANGLE The picture viewing angle can be easily adjust- ed by pulling on the release tab. © 2003 Directed Electronics, Inc. MAINTENANCE Keep the unit clean and free of dust and mois- ture and it will provide years of trouble-free operation. -
Page 8: Installation
The HRB100 will accommodate the Directed Video 5.6”, 6.8”, and 7.0” monitors. The HRB100 consists of two major pieces: the receiver bracket and the headrest bucket. Using the supplied template, center the cut out area on the headrest or seatback and mark the fabric area to be cut as indi- cated. -
Page 9: Installation With Removable Headrest Cover
INSTALLATION WITH REMOVABLE HEADREST COVER Remove the headrest cover to determine if it has room in it for the monitor without structurally weakening it. With the cover still removed, position the cutout template against the rear of the headrest and mark the area to be cut out. Remove the material to a depth sufficient for the lip of the mounting bezel to fit flush against the rear of the headrest once... - Page 10 © 2003 Directed Electronics, Inc.
- Page 11 © 2003 Directed Electronics, Inc.
- Page 12 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security, car stereo products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered.
