wiring the control unit

The wiring harness supplied with this unit is the standard 12-pin harness used by DEI® security systems. Three
wires in the plug are not used. The upgrade from this unit to a security system would simply require unplugging
and exchanging control units and connecting the necessary wires to the vehicle. The functions of all the wires
that are used in the primary harness are displayed in the following wiring diagram and their connections are
described in the wire connection guides.

primary harness (H1) wiring diagram

______
H1/1
______
H1/2
______
H1/3
______
H1/4
______
H1/5
______
H1/6
______
H1/7
______
H1/8
H1/9
______
H1/10
______
H1/11
______
H1/12

remote start ribbon harness wiring diagram

______
1
______
2
______
3
______
4
______
5
© 1999 Directed Electronics, Inc. Vista, CA
ORANGE
WHITE
WHITE/BLUE
BLACK/WHITE
GREEN
BLUE
VIOLET
BLACK
NO WIRE
BROWN
RED
RED/WHITE
RED
YELLOW
PINK
ORANGE
PURPLE
(-) 500
(+)/(-) SELECTABLE LIGHT FLASH OUTPUT
(-)200 A DOMELIGHT SUPERVISION OUTPUT
M
(-) CHASSIS GROUND INPUT
(+) CONSTANT POWER INPUT
(-)200 A CHANNEL 2 PROGRAMMABLE OUTPUT
M
(+) IGNITION INPUT TO REMOTE START
(-) 200 A IGNITION RELAY TURN-ON
M
(-) 200 A ACCESSORY RELAY TURN-ON
M
(-) 200 A STARTER RELAY TURN-ON
M
A ARMED OUTPUT
M
(-) ACTIVATION INPUT
NO FUNCTION
NO FUNCTION
NO FUNCTION
(-) HORN H0NK OUTPUT
(+) CONSTANT POWER
