Field Controls 46252300 Instruction Sheet page 2

IDENTIFY WHICH MODEL POWER VENTER YOU HAVE
CAUTION: Avoid applying excess pressure on the blower wheel when handling. This will cause an imbalance of the
blower wheel which will result in excessive vibration and premature motor failure.
1. Remove motor cover. (See Figure 1)
2. Verify which power venter you have to determine which section to reference. (See Figure 2)
3. Refer to one of the following sections for removal and installation of the replacement motor kit.
4. This kit is pre-assembled for the SWGII series power venter but includes an adapter plate for mounting to an SWG
series venter.
Figure 1
Figure 2
Page 2
