(NOTE: CK-20FG units are designed for the Flame Guard units built by
American Water Heater. All other manufacturers use CK-20F)
Designed for use with the SWG Series Power Venter for controlling a 30-
millivolt controlled Natural or L.P. Gas appliances with a pressure tap port
in the Gas Valve. This kit may also be used with the PVG series sidewall
Power Venters, DI series Draft Inducers, and CAS-4 Combustion Air
System. The included junction box is not required when using a PVG or
CAS-4.
I
TEMS INCLUDED IN KIT
1) Junction box
1) Fan control gas pressure switch with built in post purge option
1) 1/8" NPT x 3 inch pipe nipple
1) 1/8" NPT pipe tee
1) TCA-1 Thermocouple Adapter (CK-20F)
1) TCA-2 Left Handed Thermocouple Adapter (CK-20FG)
1) 6 ft. length of 12-2 wire
1) 12 inch jumper wire
1) Flexible conduit connector
2) GSK-3 Spillage Switch
THESE INSTRUCTIONS MUST REMAIN WITH EQUIPMENT
SYSTEM CONTROL KIT
Model: CK-20F and CK-20FG
DO NOT DESTROY
Advertisement
Table of Contents
Related Manuals for Field Controls 46285000
Summary of Contents for Field Controls 46285000
- Page 1 SYSTEM CONTROL KIT Model: CK-20F and CK-20FG (NOTE: CK-20FG units are designed for the Flame Guard units built by American Water Heater. All other manufacturers use CK-20F) Designed for use with the SWG Series Power Venter for controlling a 30- millivolt controlled Natural or L.P.
- Page 2 MOUNTING JUNCTION BOX The junction box can be mounted at the venter or remotely mounted away from the venter. (See Figure 1 & 2) 1. Remove one of the knockouts from the side of the junction box. Install the flexible conduit connector onto the CK-20F junction box and secure with fastening nut.
- Page 3 3. Mount the two spillage switches onto the draft hood and connect inside terminals of switches with jumper wire. Connect outside terminals to lead wires which are connected to the thermocouple junction block. (See Diagram A) 4. Route jacketed lead wires or accepted wiring enclosure on the outside of the water heater enclosure. Secure them to the enclosure with an accepted hold down tab.
- Page 4 REPAIR AND REPLACEMENT PARTS LIST DESCRIPTION PART NUMBER Gas Pressure Switch 46284200 GSK-3 Spillage Switch 46086400 Thermocouple Junction Box 46082700 INSTALLATION INFORMATION CK-20F MODEL NO.:____________________________________________________________ INSTALLER'S NAME:_____________________________________________________ INSTALLER'S COMPANY: _________________________________________________ INSTALLER'S PHONE NO.: ________________________________________________ DATE OF INSTALLATION:_________________________________________________ P/N 46285000 Rev G 02/04 Page 4...
