Belkin F1DN102D User Manual
Omniview secure dvi dual-link kvm switch
Hide thumbs
Also See for F1DN102D:
- User manual (2 pages) ,
- Specifications (2 pages) ,
- Quick installation manual (2 pages)
Table of Contents
Advertisement
Quick Links
Belkin Tech Support
US: 800-282-2355
310-898-1100, ext. 2263
UK: 0845 607 77 87
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 65 64857620
Europe: www.belkin.com/support
Belkin International, Inc.
501 West Walnut Street
Los Angeles, CA 90220, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
+44 (0) 1933 35 2000
+44 (0) 1933 31 2000 fax
© 2008 Belkin International, Inc. All rights reserved. All trade names are registered trademarks
of respective manufacturers listed. Windows, Windows Vista, Microsoft, and IntelliMouse are
either registered trademarks or trademarks of Microsoft Corporation in the United States and/
or other countries. Mac OS and Mac are trademarks of Apple Inc., registered in the U.S. and
other countries.
OmniView
Dual-Link KVM Switch
Belkin Ltd.
4 Pioneer Avenue
Tuggerah Business Park
Tuggerah, NSW 2259, Australia
+61 (0) 2 4350 4600
+61 (0) 2 4350 4700 fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
+31 (0) 20 654 7300
+31 (0) 20 654 7349 fax
Secure DVI
®
PM00507
Advertisement
Table of Contents
Related Manuals for Belkin F1DN102D
Summary of Contents for Belkin F1DN102D
- Page 1 +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2008 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows, Windows Vista, Microsoft, and IntelliMouse are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries.
-
Page 2: User Manual
OmniView Secure DVI ® Dual-Link KVM Switch User Manual F1DN102D F1DN104D... -
Page 4: Table Of Contents
Table of Contents Introduction .....................1 Package Contents ................1 Overview ....................2 Security Features................2 Other Features ................3 Equipment Requirements ..............4 System Requirements ..............5 Unit Display Diagrams ..............6 Specifications .................. 7 Installation ....................8 Pre-Configuration ................8 Mounting the Switch (optional) ............9 Connecting the Console to the Switch ..........10 Connecting Computers to the Switch ..........11 Powering Up the Systems ...............12... -
Page 6: Introduction
Introduction Congratulations and thank you for purchasing this Belkin OmniView Secure DVI Dual-Link KVM Switch (the Switch). Designed especially for secure military and government installations, the Switch provides the centralized control required by today’s IA (Information Assurance) computer environments. It... -
Page 7: Overview
Overview Security Features • Dedicated Processors Designed specifically for secure environments, the Switch features a dedicated processor per computer port. This keeps each computer running on different security levels completely separated and secure at all times, and prevents any unintended data transfer between computers. • No Memory Buffer The Switch does not have a memory buffer and does not have the ability to store data. -
Page 8: Other Features
The Switch includes a global power adapter and interchangeable plugs, to allow for both domestic and international installations. The 2- and 4-Port Switches require an optional Rack-Mount Kit for rack installation (Belkin part number F1D005). Includes AC plugs for the U.S., U.K., Europe, and Australia. -
Page 9: Equipment Requirements
Overview Equipment Requirements Cables Belkin highly recommends you use Belkin DVI/USB KVM Cable Kits with Audio & Mic for your Switch to help ensure superior performance. These cables offer the highest quality possible to ensure optimal data and audio video transmission. One Cable Kit is required per connected computer. -
Page 10: System Requirements
Overview System Requirements Operating-System (OS) Platforms The Switch is compatible with computers running on, but not limited to, the following OS platforms: • Windows 2000 ® • Windows XP (Home/Professional) • Windows 2003 Server • Windows Vista ® • Red Hat Linux Desktop ® ® • Red Hat Enterprise Linux WS • Mac OS X v10.3 and higher ® Keyboards • USB-compatible (including wireless keyboards) Mice • USB-compatible (including wireless or optical mice) Monitors... -
Page 11: Unit Display Diagrams
Switch has not been opened or compromised since time of production. If for any reason one of the seals is missing or appears disrupted, please call Belkin Technical Support at (800) 282-2355. -
Page 12: Specifications
0-80% RH, non-condensing Warranty: 3 years Dimensions: (F1DN102D) 11 x 1.75 x 6 in. (279 x 45 x 150mm) (F1DN104D) 11 x 1.75 x 6 in. (279 x 45 x 150mm) Weight: (F1DN102D) 2.5 lbs. (1.1kg.) (F1DN104D) 2.5 lbs. (1.1kg.) Made in the USA of imported parts The Switch includes a 5-volt, 3-Amp power adapter. -
Page 13: Installation
You may register your product online by going to https://www.belkin.com/registration/. Pre-Configuration Where to place the Switch: The enclosure of the Switch is designed for desktop or rack-mount configuration. An optional Rack-Mount Kit (Belkin part number F1D005) is available for use with the 2- and 4-Port Switches. Consider the following when deciding where to place the Switch: • your proximity to the port selectors on the front of the Switch • the lengths of the cables attached to your keyboard, monitor, and mouse • the location of your computers in relation to your console... -
Page 14: Mounting The Switch (Optional)
Bracket Installation (F1DN102D and F1DN104D) The 2- and 4-Port Switches can be installed into a 19-inch rack using an optional Rack-Mount Kit, sold separately (Belkin part number F1D005). 1.1 Attach the Rack-Mount Bracket to the Switch using the Phillips screws provided. (Refer to diagram below.) 1.2 Mount the Switch to the rack rails. -
Page 15: Connecting The Console To The Switch
Plugging and unplugging cables while computers are powered on may cause irreversible damage to the computers and/or the Switch. Belkin International, Inc., is not responsible for damage caused by your failure to do so. Before you connect your console to the Switch, make sure that your USB keyboard and mouse work properly with all your computers (the Human Interface Device (HID) USB drivers are installed on all computers). -
Page 16: Connecting Computers To The Switch
Step 3 Connecting Computers to the Switch (required) 3.1 Make sure all computers and the Switch are powered off. 3.2 Using the Belkin DVI/USB KVM Cable Kit (F1D9201-XX), connect the male DVI connector to the monitor port on your computer. Then connect the other end of the cable into an available port on the Switch. (Refer to diagram below.) -
Page 17: Powering Up The Systems
Installation Step 4 Powering Up the Systems (required) 4.1 Power on the attached monitor. 4.2 Attach the power adapter to the DC power jack labeled “5V, 3A” on the back of the Switch. Only use the power adapter supplied with the Switch. (Refer to diagram below.) 4.3 Power on your computers. -
Page 18: Using Your Switch
Using your Switch Selecting a Computer Using Port Selectors Now that you have connected your console and computers to the Switch, it is ready for use. You can select which computer you wish to control by pressing the corresponding port selector on the front of the Switch. The LED will illuminate to indicate which computer (or port) is currently selected. -
Page 19: Frequently Asked Questions
You can register your Switch on the Web by directing your browser to: https://www.belkin.com/registration. Where can I go to report a product issue? You may call Belkin Secure KVM Support at (800) 282-2355 or direct your web browser to http://www.belkin.com/support/contact/email/technicalsupport/. How does the Switch allow the user to switch between computers? The Switch only supports one method of port selection. The user can access the desired computer by pushing the associated port selector. - Page 20 , Kensington , and ® ® many other manufacturers. Please contact Belkin Technical Support at (800) 282-2355 for any compatibility issues you may experience. General My computer does not boot when connected to the Switch but works fine when I connect my keyboard, video, and mouse directly to my computer.
-
Page 21: Troubleshooting
Troubleshooting Keyboard The computer does not detect my keyboard, or my keyboard does not work when I switch computers or reboot. • C heck that the keyboard you are using is connected properly to the Switch. • C heck that the USB cable between the Switch and the computer is firmly connected. • T ry connecting to a different USB port on the computer. • M ake sure the keyboard works when directly plugged into the computer (the HID USB driver is installed on the computer). Rebooting may be necessary when trying this. - Page 22 Troubleshooting Mouse The computer does not detect my mouse, or my mouse does not work when I switch computers or reboot. • C heck that the mouse you are using is connected properly to the Switch. • C heck that the USB cable between the Switch and the computer is completely connected. • T ry connecting to a different USB port on the computer. • M ake sure the mouse works when directly plugged into the computer (the HID USB driver is installed on the computer). Rebooting may be necessary when trying this.
-
Page 23: Information
What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product has been improperly installed, altered in any way, or tampered with. - Page 24 Belkin product and how to proceed with your claim. Belkin reserves the right to review the damaged Belkin product. All costs of shipping the Belkin product to Belkin for inspection shall be borne solely by the purchaser. If Belkin...
