Belkin OmniView Secure DVI Dual-Link KVM Switch User Manual Common Criteria Supplement
®
Models: F1DN102D F1DN104D
This section supplements the Belkin Quick Installation Guide in accordance with AGD_PRE.1 Common Criteria
Assurance Measure requirements.
This User Guidance and Common Criteria EAL 4 validation apply to the TOE Common Criteria Evaluated version of
OmniView Secure KVM Models listed below:
®
• F1DN102D
• F1DN104D
Before you begin: The users of the Belkin OmniView
documentation and guidance prior to proceeding with installation and use of the KVM Switch. All documentation and
guidance can be found in the following document(s):
• Belkin OmniView
(document number PM00507)
• Belkin OmniView
(document number PM00506)
1.1 Receipt and preparation of TOE and Environment prior to installation
Receipt
• Assure that tamper seals are intact on the KVM switch. There should be one tamper-evident tape on each side
of the Switch enclosure (total of two tapes). If both tapes are visible and do not appear to be disrupted, the
Switch has not been opened or compromised since time of production. If for any reason one of the tapes is
missing or appears disrupted, the user should call Belkin Technical Support at (800) 282-2355.
Environment preparation
• The Belkin OmniView KVM secure must be located in a physically secure location providing physical protection
and limited (authorized user) access controls.
1.2 Verification of Common Criteria components
The following are authorized devices for the Common Criteria Evaluated configuration. Assure that installation
processes resulting in the following hardware/firmware configuration:
TOE Belkin Secure DVI Dual-Link KVM Switch 2-Port PN # F1DN102D v.111111
Belkin Secure DVI Dual-Link KVM Switch 4-Port PN # F1DN104D v.111111
including: Firmware software component version 1.0.1
Environment USB Mouse (Peripheral Group Member)
Environment USB Keyboard (Peripheral Group Member)
Environment Monitor – Dual-Link DVI connector (Peripheral Group Member)
Environment Host Computers Qty. 2 or 4 based on KVM used (IT Environment Computer Resources)
Environment Belkin DVI/USB KVM Cable (one per KVM):
F1D9201-06 – 6 ft. (1.8m)
F1D9201-10 – 10 ft. (3m)
F1D9201-15 – 15 ft. (4.6m)
Belkin OmniView Secure DVI KVM Switch User Manual Common Criteria Supplement
®
OmniView
Secure DVI Dual-Link KVM Switch User Manual F1DN102D, F1DN104D
®
Secure DVI Dual-Link KVM Quick Installation Guide F1DN102D, F1DN104D
®
Secure KVM Switch
®
Secure DVI Dual-Link KVM Switch must review all associated
®
