- Page 1 2011 Genius lt bike owners manual scott sPorts sa | 17 RTE DU CROCHET | 1762 GIVISIEZ | SWITZERLAND © 2009 SCOTT SPORTS SA, ALL RIGHTS RESERVED | SCOTT-SPORTS.COM...
-
Page 2: Table Of Contents
Technical Data Genius LT P. 006 Geometry Chip P. 007 The Genius LT should be adjusted exactly to the current rider for reaching maximum safety and fun while riding. TWINLOC Remote Control Lever P. 008 All adjustments should be done at the local Scott dealer Rear Shock Technology P. -
Page 3: Genius Lt Concept
GENIUS LT CONCEPT GEOMETRY GENIUS LT Genius LT is a new step on All Mountain Bikes, redefining this category of bikes with a maximum travel of 185mm but yet good in uphill sections. Scott’s focus was not only on lightweight but also on a durable frame with an innovative suspension technology in combination with an optimized kinematics of the rear swingarm. -
Page 4: Technical Data Genius Lt
TECHNICAL DATA GENIUS LT GEOMETRY CHIP With the help of the Geometry Chip you will be able to adjust your BB height above Travel 185/110/0mm ground in 2 positions: Suspension Ratio 2.85/1.69/0 Piston stroke 65 mm Low BB: lower center of gravity over ground, slacker/ more relaxed headangle... -
Page 5: Twinloc Remote Control Lever
TWINLOC in combination with Equalizer 3 and a RockShox/SRAM fork on Genius LT now allows also the remote control of the front fork to shift between lock-out and open mode at the same time when you change the modes on the Scott rear shox. - Page 6 *** g Copying, using or disclosing such information and data without written BIKE twinloc-rocks-cable-ass.asm 10/06/2009 1 / 1 SCOTT SPORTS SA permission of SCOTT SPORTS SA is prohibited. Route du Crochet 17 CABLE Scale Material Projection 1762 Givisiez ASSEMBLY OF THE REMOTE CABLE...
-
Page 7: Rear Shock Technology
EQUALIZER 3 SHOCK AND TWINLOC REMOTE CONTROL LEVER The heart of the TC-System is the new developed and innovative Scott Equalizer 3 Shock made by DT Swiss, offering three functions which make this system possible. In the drawing of the shock and remote lever, shown below, you will see the parts By using the TWINLOC remote lever you can chose following functions on the rear indicated with numbers which will be used in the manual for the adjustment and set-up. -
Page 8: Basic Set-Up Of The Twinloc Remote Control
1.5 mm allen key insert a new cable via lever hole and cable housing and push it into the shock as shown. remove the end cap of the cable with pliers 2011 SCOTT BIKE OWNERS MANUAL... - Page 9 Keep 35mm cable length from the edge of the cable sled. 2011 SCOTT BIKE OWNERS MANUAL...
-
Page 10: Recommended Tools For The Shock Set-Up
To adjust the air pressure of the air chamber of the Scott Equalizer 2 Shock please refer removing the pump from the shock valve, this will result in an exact air pressure. -
Page 11: Set-Up Of Rebound Equalizer 3 Shock
- If it bounces more than 3 times the rebound is too fast. Turn BOTH screws 1-2 “clicks” clockwise - If it does not bounce the rebound is too slow. Turn BOTH screws 1-2 “clicks” counter clockwise. 2011 SCOTT BIKE OWNERS MANUAL... - Page 12 Important: Please make sure that both rebound wheels show the same number below the arrow Note that you have to mount the Scott Equalizer 3 Shock always as shown underneath. on the shock body. Mounting the rear shock in a different position can cause severe damages to the frame, the linkage levers and the rear shock.
-
Page 13: Set-Up Of Other Shock Models
SET-UP OF OTHER SHOCK MODELS FRONT DERAILLEUR (FD) MOUNTING DETAILS On Genius LT you will find a Shimano E-type front derailleur but fixed directly on the Scott strongly recommends using only the Scott Equalizer 3 Shock with the swingarm without the plate that is fixed normally between the bottom bracket bearing... -
Page 14: Chainguide
CHAINGUIDE Details for the assembly on the alloy frames of Genius LT: The Carbon as well as the alloy frames of Genius LT can be fitted with ISCG chainguide systems. A set of all spare parts for this action can be ordered via the Scott distribution with... -
Page 15: Headset Options
HEADSET OPTIONS SCOTT SMART CABLE ROUTING: Genius LT features a tapered headset and fork steerer system to match with semi- The direct and straight cable system on all our full suspension models allows Smart integrated headsets of the “50-61”mm range. -
Page 16: Cable Housing Length
Genius LT can be used with 3 different disc rotor sizes on the rear brake. The rear disc brake on Genius LT is Postmount (PM) Standard on the left seatstay and all complete bikes are delivered with 185mm rotors, so between the calliper and the PM 45 MM mount on the seatstay are 2 washers with a laser logo of “185mm”. -
Page 17: Ids 2 / Replaceable Dropout
It is also possible to use 180mm rotors. To do so, please remove the 2 washers with a laser logo of “185mm” and fix the calliper directly on the PM on the seatstay. All Genius LT bikes feature the new IDS 2 System of Scott. 3 different version of IDS 2 are available,... -
Page 18: Front Fork Set-Up/ Change Of Front Fork
We recommend the same for the chain also. you can also order the right side RD hanger separately via the Scott distribution in case you need this to repair a damage on the RD hanger. -
Page 19: Warranty
In case such an annual maintenance service has not been effected the warranty of 5 years for the frame shall be reduced to 3 years. Costs for maintenance and service have to be born by the owner of the SCOTT bike. Shock Nr.
